USER MANUAL Mirror HQ Xblitz

Interior view of a car dashboard and steering wheel (no text or symbols visible)

PL

INSTRUKCJA OBSŁUGI

WIDEOREJESTRATOR

Carefully read the enclosed operating instructions and safety notes before use to avoid accidental damage to the equipment or unintentional injury.

PURPOSE OF THE PRODUCT

The Xblitz Mirror HQ car camera is a camera built into the rear-view mirror, it allows you to monitor the route of your vehicle and record any traffic incidents, in addition, the device comes with a second camera that can be used, for example, as a reversing camera. The video recorder is made of the highest quality components.

01. CONTENTS OF THE KIT

SEE FIGURE A

1. Camera

2. Auxiliary/reversing camera

3. Connection cable for auxiliary/reversing camera

4. Memory card reader
5. Instructions
6. Fastening elastics
7. Charger

02. DESCRIPTION OF THE RECORDER

SEE FIGURE B

1. Micro SD card port
2. AV input (connection point for auxiliary camera/reversing camera)
3. Mini USB port (camera power supply)
4. RESET button
5. Location of rubber bands
6. Lens
7. Loudspeaker
8. Microphone
9. POWER button
10. Display

03. BEFORE USE

1. It is recommended to use original micro SD cards of class 10 or higher.
2. Before inserting the card into the recorder, it must be formatted in the computer in the FAT32 or exFAT file system (depending on the card) and then in the recorder.
3. The memory card must be installed when the device is switched off. Failure to do so may damage the card and the device. The same applies when removing the card.
4. A fully charged battery allows recording without power for up to 5 minutes. The battery in the unit is mainly used to maintain the recorder settings.
5. When the memory card fills up, the oldest unprotected recordings will be overwritten if the LOOP RECORDING function is activated.
6. Make sure that motion detection and parking mode are switched off while driving to avoid the device switching on and off on its own, e.g. when stopping at an intersection or driving on uneven ground and thus losing memory card space. Switching on these modes is recommended only when leaving the vehicle parked.
7. Sound: the device has a condenser microphone that records all ambient sounds. Sounds may overlap causing distortion.

04. KEYS, SCREEN AND MENU ICONS

A. KEYS

POWER - Hold down 3 sec to switch the camera on or off. A short press fades out / wakes up the screen.

RESET - Press to reset the camera and restore the default settings on the camera.

B. SCREEN ICONS

VIDEO MODE

SEE FIGURE C

1. Recording status

a. Red icon - camera is recording
b. White icon - camera is not recording

1. Recording resolution

2. Date and time

3. Camera not recording: remaining recording time on micro SD card. Camera is recording: recorded loop time
4. Information on video security

a. Padlock open - video unsecured
b. Padlock closed - video secured

1. Information on sound recording

a. Microphone - sound recording enabled
b. Microphone crossed out - sound recording disabled

1. SD card information

a. Card - the device is equipped with a micro SD card
b. Card crossed out - no micro SD card in the device

1. Battery power status

2. Video protection - activation of this function protects the current recording from being overwritten

3. Recording - start/stop video recording

4. Back - return to main menu

PHOTO MODE

SEE FIGURE D

1. Date and time
2. Image resolution
3. SD card information
   a. Card - the device is equipped with an SD card
   b. Card crossed out - no micro SD card in the device
4. Battery power status
5. Image files - preview of image files stored on the SD card
6. Picture taking
7. Back - return to main menu

C. MAIN MENU

SEE FIGURE E

1. Preview - Switch to video mode

2. Camera - switch to photo mode

3. Playback - preview of video recorded on micro SD card

a. Normal - recordings of normal loops stored on the micro SD card

b. Parking mode - Recordings made in parking mode

c. Emergency - Recordings protected after a sudden event and activation of the G-Sensor shock sensor

1. Recording - start video recording

2. Secure Video - secure/unsecure the currently recorded video.

Note: function also available by pressing the icon in VIDEO MODE.

1. Mute - enable/disable audio recording. Note: this function is also available by pressing the icon in VIDEO MODE.

2. Settings (see D) - access to camera settings

D. SETTINGS

VIDEO MODE

1. Resolution - set the resolution in which the front camera will record (max. 1920x1080p).

2. Loop time - select the length of the loop in which the camera will save the recording files.

3. Unpowered recording time - setting the time the camera will record when the power is disconnected (for the use of battery power in emergency situations, it is recommended to set this value to minimum).

4. Audio recording - switch on/off audio recording by the camera. Function also available from other interface levels.

5. Time-lapse video - time-lapse recording settings. Note: function only available when using the ACC adapter.

6. Disable time-lapse recording - deactivate time-lapse recording.

Note: function only available when using the ACC adapter.

PHOTO MODE

1. Photo resolution - setting the resolution at which the camera will shoot.

2. Exposure - adjusts exposure values for photos.

3. ISO - adjusts ISO sensitivity for photos.

GENERAL SETTINGS

1. SD card format - format the micro SD card in the camera.

2. Software version - information about the software version installed in the device.

05. CAMERA INSTALLATION

SEE FIGURE F

1. Insert the memory card into the camera.
2. Attach the camera to the rear-view mirror.
3. Attach the camera using the rubber bands provided.
4. Route the power cable and secondary camera cable.
5. Connect the power cable and secondary camera cable.
6. Plug the power supply into the cigarette lighter socket.

The location of the secondary camera depends on your preference. The camera meets IP67 waterproof standards (completely dustproof and protected against immersion in water - max. 30 minutes at a depth of up to 1 metre).

MOUNTING OF AN AUXILIARY CAMERA AS A REVERSING CAMERA:

1. Plug the black cable of the secondary camera into the AVIN port on the main unit, then drag it to the secondary camera location and connect. Ensure that the main unit can see the secondary camera (if not, check that the cable is correctly inserted into both ports).
2. Connect the wires coming from the auxiliary camera to the reverse light supply wires (red=plus). Connecting in this way will allow it to be used as a reversing camera.
3. The outdoor installation should be well insulated and should not be mechanically stressed.

06. GETTING STARTED

1. Mount and connect the camera to the power supply.
2. Insert a micro SD memory card formatted to the FAT32 or exFAT file system (depending on the type).
   NOTE: Please only insert and remove the memory card when the device is switched off.
3. Set in the menu:

a. date and time
b. Loop recording (adjust recording time)
c. set the highest resolution available
d. set the G-Sensor to the lowest possible sensitivity so that the camera does not pick up bumps on the road and protect your recordings unnecessarily

1. Make sure that PARKING MODE and MOVEMENT DETECTION are turned off. If they are left on during normal use they will unnecessarily save recordings

and reduce the space on the memory card.

Switching on parking mode is only recommended when leaving the vehicle parked, and can be quickly switched on and off in recording mode using the icon on the home screen.

1. The camera will start recording automatically every time you switch it on (provided there is no permanent power supply in your car's cigarette lighter socket).

07. MAIN FEATURES OF THE CAMERA

1. Camera modes

The camera has 3 modes of operation.

a. Recording mode: in this mode, the camera records video.
b. Photo mode: in this mode, the camera takes photos.
c. Playback mode: view footage recorded by the camera.

2. Loop recording

Setting the recording time (length) of the video files, when the memory card fills up the oldest recording will be overwritten.

3. Resolution

The camera can record in several resolutions. The higher the resolution, the better the quality of the recordings, but the files will also take up more space on the memory card. It is recommended to use the highest resolution available.

4. G-Sensor

Gravity sensor. When the sensor is activated on impact, the recording file is protected from being overwritten. It is recommended that the lowest available value is set, as at a higher value the camera may pick up bumps caused by uneven road surfaces, which can cause the memory card to fill up.

5. Parking mode

When enabled, the camera catches a jolt from the car (for example during a parking bump), turns on and starts recording a short video protected from overwriting. It is advisable to switch this function off for the duration of the drive, as it may block loop recording.

Note: to ensure that the camera properly records a full-length recording, leave it under a constant power source.

6. Motion detection

This mode starts recording when the camera detects movement (e.g. a person in front of the vehicle). The function only works when the camera is not recording and is connected to power. The recordings are not protected against overwriting.

7. Audio recording

Along with video recording, the camera can also record audio.

8. Reversing camera

The additional camera can be used as a reversing camera. When properly connected, the image will automatically switch to the view from the additional camera when reverse gear is engaged.

08. PRECAUTIONS

1. Do not disassemble or tamper with the camera yourself. If a malfunction occurs, please contact the service department.
2. Use only original accessories.
3. Only use the original charger supplied. The use of any other power supply may adversely affect battery performance.
4. The device may not be used in contravention of the laws of your country or region.
5. Permissible operating temperatures are 0 - 35°C. Storage: +5 to +45°C. Humidity: 5-90% non-condensing.
6. Do not subject the device to damage or physical impact.
7. Take care of the cleanliness of the product, especially the lens. Do not use detergents or chemicals when cleaning.
8. Clean only when the unit is unplugged.
9. Keep the device out of the reach of children.
10. Do not expose the device to very high temperatures or fire.
11. If you smell burnt plastic or electronics from the camera, unplug the unit as soon as possible and contact the service department.

09. FAQ

1. Device does not switch on, screen flashes.

The device's battery must be charged before start-up.

1. The unit does not automatically switch on/off.

The reason for this behaviour may be the constant power supply in the cigarette lighter socket.

1. The device restarts while driving.

It is recommended to check the power source.

1. The device does not record in Loop (it records randomly).

Check the setting of the „motion detection“ and „parking mode“ functions - both should be switched off while driving.

1. The device shows the message „card full”.

Check the „G-sensor“ and „parking mode“ functions and set them to minimum. The card must be formatted in the computer in the FAT32 or exFAT file system (depending on the card) and then in the recorder.

6 The device records noisy, distorted, unclear sound.

The device has a highly sensitive microphone that records any ambient noises. The recorded sounds may overlap. Windscreen air vents may also distort

the sound.

6. The device is not responding.

Briefly press the Reset button or restore the device to factory settings.

7. There are transverse lanes in the footage.

Incorrect setting of the frame rate value. Set the frequency value to „50Hz” or „60Hz” depending on local settings.

NOTES:

Due to continuous product improvement, the manufacturer reserves the right to make changes to the device and its kit without prior notice, some functions described in this manual may differ slightly in reality.

Use only the original charger with a charging current of 5V/2A (do not plug directly into a 220/230V socket). Failure to do so may damage the camera or lead to dangerous situations.

To play files on a computer, remove the memory card from the camera and connect it to the computer using the reader.

10. SPECIFICATION

Processor: Mstar 8336 | Sensor: GC2053 | Lens: 6G | Recording resolution: main camera: Full HD 1080P/30fps + secondary camera: HD 720P/30fps | Viewing angle: 150° | Display: LCD 5 inches | Memory: Micro SD cards up to 128 GB | G-sensor: Yes | Motion detection: Yes | Loop recording: | Parking mode: Yes | Recording format: .TS | Power supply: 5V/2A | USB: mini USB | Microphone/speaker: built-in | Battery: built-in | Dimensions: 258x75x40mm | Weight: 250g

11. WARRANTY/ COMPLAINTS CARD

The product comes with a 24-month warranty. Warranty conditions can be found at: https://xblitz.pl/gwarancja/

Complaints should be made using the complaint form found at: http://reklamacje.

kgktrade.pl/

Details, contact and address of the service can be found at: www.xblitz.pl Specifications and contents are subject to change without notice. We apologise for any inconvenience.
