SSMN 2 C1 - Massage device SILVERCREST - Free user manual and instructions
Find the device manual for free SSMN 2 C1 SILVERCREST in PDF.
| Product Type | Shiatsu Neck Massager |
| Brand | SilverCrest |
| Model | SSMN 2 C1 |
| Intended Use | Massaging the neck of people with warming function and shiatsu style; indoor household use only |
| Mains Power Adaptor Input | 100–240 V~, 50/60 Hz, 0.5 A |
| Mains Power Adaptor Output | 12 V ---, 1.0 A |
| Massager Input Voltage | 12 V === |
| Power Consumption | 12 W |
| Protection Class | II / ☐ |
| Duration of Use | Max. 15 minutes (automatic shut-off) |
| Massage Heads | 2 rotating heads with shiatsu nodes |
| Speed Settings | Low and high speed rotation |
| Warming Function | Yes, activated by light and heat function button; red indicator light |
| Control Buttons | Power button, massage button (speed/pause), light and heat function button |
| Hand Loops | Yes, for adjusting position around neck |
| Removable Cover | Yes, machine-washable at 30°C delicate cycle |
| Scope of Delivery | Shiatsu neck massager, mains power adaptor, instruction manual |
| Safety Certification | TUV Rheinland/GS certified (adaptor model KL-AD-120100) |
| Warranty | 3 years from date of purchase |
| Disposal | Recyclable packaging; product not household waste |
Frequently Asked Questions - SSMN 2 C1 SILVERCREST
User questions about SSMN 2 C1 SILVERCREST
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Massage device in PDF format for free! Find your manual SSMN 2 C1 - SILVERCREST and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. SSMN 2 C1 by SILVERCREST.
USER MANUAL SSMN 2 C1 SILVERCREST
GB
SHIATSU NECK MASSAGER
Operation and safety notes
SI
NAPRAVA ZA SHIATSU MASAŽO ZATILJA
GB Operation and safety notes Page 5
List of pictograms used....Page 6
Introduction......Page 6
Intended use....Page 6
Description of parts....Page 6
Technical data....Page 7
Scope of delivery....Page 7
Safety advice....Page 7
Before use......Page 9
Operation Page 9
Warming function....Page 9
Switch off the product....Page 9
Cleaning and care....Page 9
Storage Page 10
Disposal Page 10
Warranty Page 10
| List of pictograms used | |||
 | Observe caution and safety notes! Danger -Risk of electric shock! | ||
 | Only use in dry indoor rooms. Fire hazard! | ||
 | Voltage (alternating current) | Hz | Hertz (mains frequency) |
 | Direct current Do not use bleach | ||
 | The cover is machine-washable.Set the washing machine to a delicate wash cycle at 30 °C | Do not dry in a tumbler dryer | |
 | WARNING: Do not use this product near water. | Do not iron | |
 | Short-circuit proof safety transformer Do not dry clean | ||
 | Polarity Safety class II | ||
 | SMPS (Switch mode power supply unit) (switching power supply) | Power | |
 | Massage function Light and heat function | ||
 | Protection against contact with the fingers | ||
Shiatsu neck massager SSMN 2 C1
- Introduction
We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.
Intendeduse
The product is only designed for massaging the neck of people with warming function and shiatsu style (shi = finger, astu = pressure in Japanese). The product is only for indoor household use. It is not intended for medical or commercial purposes and is not a substitute for medical treatment. Any other form of use is not permitted and may result in injury or damage of the product. The manufacturer accepts no liability for any damage caused by improper use.
• Description of parts
1 Removable cover
2 Massage heads
3
Socket
4
Heat function indicator
5
Light and heat function button
6
Power button
7
Massage button
8
Hand loops
●Technicaldata
Mains power adaptor
Input voltage: 100-240 V \~, 50/60 Hz
Rated current: 0.5 A
Output voltage: 12 V ---
Output current: 1.0 A
Protection class: II / ☐
Model no.: KL-AD-120100
TUV Rheinland/GS certified
Shiatsu neck massager
Input voltage: 12 V ===
Rated power: 12 W
Polarity:
Duration of use: max. 15 min (automatic
shut-off)
- Scope of delivery
Immediately after unpacking, please check the package contents for completeness and if the product and all parts are in good condition. Remove all packaging materials before use.
1 Shiatsu neck massager
1 Mains power adaptor
1 Instruction Manual
Safety advice
Read all safety advices and instructions. Non-observance of the safety advices and instructions may cause electric shock, fire and/or bad injuries.
KEEP ALL SAFETY NOTICES AND INSTRUCTIONS FOR FUTURE REFERENCE!
WARNING! DANGER TO LIFE
AND RISK OF ACCIDENT FOR INFANTS AND CHIL- DREN! Never leave children unsupervised with the packaging materials. The packaging material poses a suffocation hazard. Children frequently underestimate the dangers. Please always keep the product out of the reach of children.
⚠️ CAUTION! This product is not a toy for children! Children are not aware of the dangers associated with handling electrical products.
■ This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Children should not clean or perform user maintenance unsupervised.
⚠️ CAUTION! The product has a heated surface. Persons insensitive to heat must be careful when using it.
⚠ WARNING! Avoid the hazard of life by electric shock:
- Do not insert needles or pointed objects into the product.
■ Never immerse the product into water or any liquid.
■ Never touch the product, or the mains power adaptor with wet hands or use it in very humid environments.
■ Only use the provided mains power adaptor as described in Technical Data section.
■ Make sure that the details on the rating label are in conformity with your mains voltage.
In the event of malfunctions, remove the mains power adaptor from the mains socket.
■ Do not open the product or attempt to repair it yourself.
Defective products should only be repaired by qualified personal.
■ Always remove the mains power adaptor from the mains socket after each use and before clean the product.
- Keep the power cord away from hot surfaces, sharp edges and mechanical forces.
■ Never let the power cord becomes a trip hazard, that no-one can get tangled in it or tread on it.
- Allow the product to cool down before moving it to a different location.
WARNING! HAZ-ARD OF FIRE!
operate the product close to or below curtains, wall cupboards or other inflammable materials.
- Do not use the product on swollen, burnt, inflamed, diseased or injured regions of the skin and body areas. If in doubt, obtain medical advice before using the product.
■ Never use the product if you have injuries or pain in the neck.
- Before use
Note: Remove all packaging material from the product.
Connect the connection plug at the wire of the mains power adaptor to the socket 3 at the inner side of the hand loops 8.
Place the massager around your neck and aligns the massage heads 2 on the side of your neck, use the hand loops 8 to adjust it. The control buttons must be on the left.
Plug the mains power adaptor to the mains power socket.
☐ Ensure the massager heads aligned to your neck.
Operation
To switch on the massager, press the power button 6 to start rotation of massage heads 2 in low speed.
To change the rotation speed of the massage heads 2, use the massage button 7 to toggle between low speed rotation / high speed rotation / pause. To stop the massage function, press the power button 6.
Note: Never use the product for more than 15 minutes. A longer massage may lead to tension caused by overstimulation of the muscles.
Note: If you found yourself painful or uncomfortable, stop the massage immediately.
Warming function
To complement the massage with the warming function, press the light and heat functions button 5 to turn on the heat function. The red heat function indicator 4 and the red light of the massage heads 2 switch on.
- Switch off the product
To switch off the product, press the power button 6, the heat function indicator 4 and
the light of the message heads 2 will go off, the massage heads 2 stop rotating. The product switches off automatically after 15 minutes.
To turn off completely, disconnect the mains power adaptor from the power supply.
- Cleaning and care
Disconnect the mains power adaptor from the mains socket and unplug connection plug from the socket 3 before cleaning.
■ WARNING Never inperse the product, or mains power adaptor into water.
■ Ensure the product is completely dry before connecting the mains power adaptor.
- Do not use abrasive, aggressive or chemical cleaning agents to clean the product. It could damage the product.
■ Never allow any liquid to enter the product.
☐ Use a damp lint-free cloth to clean the product. Use a little mild detergent on the cloth if necessary.
To clean the removable cover 1, open the zip on the removable cover 1 completely. Clean the removable cover 1 in accordance with the cleaning symbols on the label. It is machine-washable. Set the washing machine to a delicate wash cycle at 30 °C.
Storage
Let the product completely cool down before storage.
Do not place other objects on top of the product.
☐ If the product is not used for a certain period of time, store the product in a clean and dry location.
●Disposal
The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.
Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics / 20-22: paper and fibre-board/80-98: composite materials.
The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.
Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.
To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.
Warranty
The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your
legal rights are not limited in any way by our warranty detailed below.
The warranty for this product is 3 years from the date of purchase. Should this product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you.
The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the product has been damaged, or used or maintained improperly.
The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.
CE
Pooblaščeni serviser:
OWIM GmbH & Co. KG
Stiftsbergstraße 1
DE-74167 Neckarsulm
NEMČIJA
