Product type	Air purifier
Brand	Livarno Lux
Model	LLK 19 A1
Power supply	220-240 V~ 50-60 Hz
Rated power	19 W
Standby power consumption	≤ 0.5 W
Recommended room size	max. 15 m²
Power levels	3 (I, II, III)
Filter type	Pollen filter and pre-filter
Pollen filter replacement interval	Every 6 months
Pre-filter cleaning interval	Every 2 to 4 weeks
Filter replacement indicator	Flashing LED
Warranty	3 years
Intended use	Dry indoor rooms, domestic use
Included accessories	1 pollen filter inserted, 1 quick start guide
Certifications	CE, GS (Geprüfte Sicherheit)

Frequently Asked Questions - LLK 19 A1 Livarno Lux

How do I replace the pollen filter?

When the filter LED flashes, replace the pollen filter. Remove the pre-filter by grasping it by the recessed handle, then pull out the pollen filter by the tab. Insert a new filter, replace the pre-filter, and press the reset button until the LED flashes briefly.

How do I clean the pre-filter?

The pre-filter can be cleaned with a vacuum cleaner or with water. If you wash it with water, let it dry completely before reinstalling. Clean it every 2 to 4 weeks.

What is the maximum room size for this device?

This device is designed for dry indoor rooms with a maximum area of 15 m².

How do I reset the filter indicator after replacement?

After inserting a new pollen filter, press the reset button located inside the device until the filter LED flashes briefly, confirming the reset.

Can I use the device in a bathroom?

No, this is prohibited. Never use the device near a sink, bathtub, shower, or swimming pool due to the risk of electric shock from moisture.

What should I do if the device does not work?

First check that the power socket is properly plugged in and the device is turned on. If the problem persists, contact customer service. Never attempt to repair the device yourself.

How do I turn off the device completely?

Press and hold the On/Off button for about 3 seconds until the LED turns off. For complete isolation from the mains, unplug the power plug.

What power levels are available?

The device has 3 power levels: I (low), II (medium), III (high). Press the On/Off button repeatedly to cycle through them.

What is the standby power consumption?

The standby power consumption is very low, ≤ 0.5 W.

How should I store the device if not used for a long time?

Unplug the power plug and store the cable in the storage compartment provided. Place the device in a dry place out of reach of children.

USER MANUAL LLK 19 A1 Livarno Lux

LUFTREINIGER LLK 19 A1 AIR PURIFIER LLK 19 A1 PURIFICATEUR D'AIR LLK 19 A1

For EU market: Imported for GB market by:

HOYER Handel GmbH Lidl Great Britain Ltd

Kühnehöfe 12 Lidl House · 14 Kingston Road

22761 Hamburg Surbiton · KTS 9NU

GERMANY

Stand der Informationen · Status of information · Version des information

GB Operating instructions

AIR PURIFIER

Symbol of a trash bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

1. Overview 12
2. Intended purpose 13
3. Safety information 13
4. Items supplied 15
5. Setting up the device 16
6. Operation 16

6.1 Putting the device into operation and switching it off 16

6.2 Changing the filter 16

1. Cleaning 17
2. Storage 17
3. Disposal 17
4. Trouble-shooting 18
5. Technical specifications .... 18
6. Warranty of the HOYER Handel GmbH 19

1. Overview

1 Air outlet
2 Recessed grip on the rear of the device for transporting
3 Filter LED: if the LED flashes, the pollen filter needs to be replaced.
4 On/off switch and power stage adjustment I, II, III
5 LED is lit when the device is switched on
6 Pre-filter in front of the air inlet
7 Cable compartment with power cable and mains plug
8 Recessed grip for removing the pre-filter
9 Filter reset button
10 Pollen filter

Thank you for your trust!

Congratulations on your new air purifier.

For safe handling of the device and in order to get to know the entire range of features:

• Read these operating instructions thoroughly prior to initial use.
• Above all, observe the safety information!
• The device should only be used as described in these operating instructions.
• Keep this copy of the operating instructions for reference.
• If you pass the device on to someone else, please include this copy of the operating instructions. The operating instructions are a part of the product.

We hope you enjoy your new air purifier!

Symbols on the device

Change the filter when the LED flashes.

2. Intended purpose

The device can be used as an air purifier for dry indoor spaces up to approx. 15 m ^4 .

The device is designed for private home use and must not be used for commercial purposes. The device must only be used indoors.

Foreseeable misuse

FIRE HAZARD!

• Never use the device to dry textile materials or other objects on, above or in front of the device.
• The device must not be used in vehicles of any kind.

3. Safety information

Warnings

If necessary, the following warnings are used in these operating instructions:

DANGER! High risk: failure to observe this warning may result in injury to life and limb.

WARNING! Moderate risk: failure to observe this warning may result in injury or serious material damage.

CAUTION: low risk: ignoring this warning may result in minor injuries or damage to property.

NOTE: circumstances and specifics that must be observed when handling the device.

Instructions for safe operation

• This device can be used by children from the age of 8 and over if they are supervised.
• This device can be used by people with restricted physical, sensory or intellectual abilities or people without adequate experience and understanding if they are supervised or instructed on how to use this device safely and if they are aware of the resulting dangers.
• Children must not play with the device.
• Change the filter regularly.
• Do not use the device:
• in the immediate vicinity of a sink, bathtub, shower, or swimming pool, or other damp areas
• if it has been previously dropped
• if it shows visible signs of damage
• Use the device on a horizontal and stable surface.
• If the mains power cable of this device should become damaged, it must be replaced by the manufacturer, the manufacturer's customer service department or a similarly qualified specialist, in order to avoid any hazards.
• Unplug the device before cleaning or performing any other maintenance.
• There must be at least 30 cm of clear space around the device.
• Please take note of the chapter on cleaning.

DANGER for children!

- Packing materials are not children's toys. Children should not be allowed to play with the plastic bags: there is a risk of suffocation.

- Keep the device out of the reach of children.

DANGER to and from pets and livestock!

Electrical devices can represent a danger to pets and livestock. In addition, animals can also cause damage to the device. For this reason you should keep

animals away from electrical devices at all times.

DANGER! Risk of electric shock due to moisture!

• The device, the mains power cable and the mains plug must not be immersed in water or any other liquids.
• Protect the device from moisture, water drops and water splashes: failure to observe this instruction may result in an electric shock hazard.
• If liquid gets into the device, disconnect the mains plug immediately. Have the device checked before reusing.
• Never touch the device with wet hands.

- If the device has fallen into water, pull out the mains plug immediately, and only then remove the device from the water. Do not use the device again, and have it checked by a specialist workshop.

DANGER! Risk of electric shock!

- Do not use the device if the device or the mains power cable has any visible damage, or if the device has previously been dropped.

- Only connect the mains plug to a properly installed and easily accessible wall socket whose voltage corresponds to the specifications on the rating plate. The wall socket must still be easily accessible after the device is plugged in.

- Ensure that the mains power cable cannot be damaged by sharp edges or hot points.

- When using the device, ensure that the mains power cable cannot be trapped or crushed.

- Even after it has been switched off, the device is not completely disconnected from the mains power supply. In order to fully disconnect it, pull out the mains plug.

- When removing the mains plug from the wall socket, always pull on the plug and never the cable.

- Pull the mains plug out of the wall socket:

• when a malfunction occurs
• when you are not using the device
• before you clean the device
• before changing the filter
• during thunderstorms

- Never attempt to reach into the device interior by sticking your fingers or objects through the ventilation gratings.

- To avoid any risk, do not make modifications to the product.

- When using an extension cable, this must correspond to the applicable safety regulations.

FIRE HAZARD!

• There must be no flammable objects (e.g. curtains, paper, etc.) in close proximity to the device during operation.
• Never use the device to dry textile materials or other objects on, above or in front of the device.
• The device must only be set up on a solid, level, dry and non-flammable surface.
• When setting up the device, keep a minimum distance of 30 cm all around from other devices and walls.
• Never operate the device in a potentially explosive environment or close to flammable gases or liquids.
• Ensure at all times that the air can enter and exit freely. Heat can otherwise accumulate in the device.

WARNING! Risk of material damage!

• Never place the device on hot surfaces (e.g. hot plates) or near to heat sources or open fire.
• Only use the original accessories.
• Do not clean using sharp objects or abrasive cleaning agents.

4. Items supplied

1 air purifier

1 pollen filter (inserted) 10

1 copy of the short manual (included)

1 copy of the operating instructions (online)

Unpacking

1. Remove all parts from the packaging.

2. Check that all parts are present and intact.

5. Setting up the device

FIRE HAZARD!

The device must only be set up on a solid, level, dry and non-flammable surface. For example, the device must not be placed on a deep-pile carpet.
- When setting up the device, keep a minimum distance of 30 cm all around from other devices and walls.
- There must be no flammable objects (e.g. curtains, paper, etc.) in close proximity to the device during operation.

• Select a location which complies with the safety information.
• Select a location where no persons, animals or plants are directly above the outlet opening.
• Ensure that the device is standing securely.

6. Operation

6.1 Putting the device into operation and switching it off

1. Pull out as much power cable as you need from the cable compartment and plug the mains plug 7 into a wall socket that complies with the technical specifications.

- The LEDs 3 and 5 light up briefly.

1. Use the button 4 to switch the device on, change the power stages and switch the device off again.

- Press 1x: switches on the device. The lowest power stage (I) is selected and the LED 5 lights up dimly.

• Press 2x: the medium power stage (II) is selected and the LED 5 lights up slightly brighter.
• Press 3x: the highest power stage ( III) is selected and the LED 5 lights up brightly. Pressing repeatedly returns the device to the lowest power stage (I).
• Press and hold the button 4 for approx. 3 seconds: the device switches off and the LED 5 goes out.

6.2 Changing the filter

If the filter LED 3 flashes and an audio signal sounds, the pollen filter 10 must be replaced.

Intervals

Filter How often?		What should be done?
Pre-filter 6	every2 - 4 weeks	clean
Pollen filter 10	every6 months	replace

1. Remove the pre-filter 6. It is best to hold it by the recessed grip 8 on the side of the device.
2. Figure A: remove the pollen filter 10 from the air purifier by pulling it out by the tab at the top and dispose of it in the household waste.
3. Carefully vacuum the pre-filter 6 with a vacuum cleaner.
4. Figure B: press the filter reset button 9 inside the device until the LED 3 for the filter indicator flashes briefly. This tells the device that a new pollen filter 10 has been inserted.
5. Insert the new pollen filter 10 and place the pre-filter 6 back onto the device.

7. Cleaning

In order to enjoy your device for a long time, you should regularly clean it.

DANGER! Risk of electric shock!

• Disconnect the mains plug 7 before any cleaning.
• Never immerse the device in water.
• Do not let water or cleaning agent run into the device.

WARNING! Risk of material damage!

- Do not clean using sharp objects or abrasive cleaning agents.

Device

1. The pre-filter 6 can be cleaned with a vacuum cleaner. If necessary, this filter can also be cleaned with water.
2. Clean the outside of the device with a damp cloth. You can also use a little detergent.
3. Wipe with a cloth moistened with clear water.
4. Wipe the inside of the device with a dry cloth.
5. Do not use the device until it is completely dry again.

8. Storage

• Pull out the mains plug 7 if you are not using the device for an extended period.
• Slide the mains power cable into the cable compartment.

9. Disposal

This product is subject to the provisions of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this symbol. Products identified with this symbol may not be discarded with normal household waste, but must be taken to a collection point for recycling electric and electronic appliances.

Symbol of a trash bin with crossed lines indicating no waste or discharge, and a solid black rectangle below (no text or labels)

This recycling symbol marks e.g. an object or parts of the material as valuable for recycling. Recycling helps to reduce the consumption of raw

materials and protect the environment.

Packaging

When disposing of the packaging, make sure you comply with the environmental regulations applicable in your country.

10. Trouble-shooting

If your device fails to function as required, please try this checklist first. Perhaps there is only a minor problem, and you can solve it yourself.

DANGER! Risk of electric shock!

- Do not attempt to repair the device yourself under any circumstances.

Fault	Possible causes / action
No function	Has the device been connected to the power supply?Check the connection.
The effectiveness of the device seems to be wearing off.	Change the pollen filter 10.

11. Technical specifications

Model: LLK 19 A1

Mains voltage: 220 - 240 V ~ 50 - 60 Hz

Power rating: 19 W

Power consumption in standby: ≤ 0,5 W

Symbols used

	Double insulation
	Geprüfte Sicherheit (certified safety): devices must comply with the generally acknowledged rules of technology and the German Product Safety Act (Produkt-sicherheitsgesetz - ProdSG). (Not for UK)
	With the CE marking, HOYER Handel GmbH declares the conformity with EU guidelines.
	This symbol reminds you to dispose of the packaging in an environmentally friendly manner.
PAP	Recyclable materials are marked with the recycling symbol (3 arrows). The material can be specified by the recycling number in the centre (here: 21) and/or an abbreviation (here: PAP).
~	AC voltage
	It is a recyclable product which is subject to an extended producer responsibility and for which the rules of waste separation apply.
UKCA	With the UKCA marking, HOYER Handel GmbH declares that the product is in conformity with the UKCA requirements.
	The symbol identifies the product manufacturer.

Subject to technical modifications.

12. Warranty of the HOYER Handel GmbH

Dear Customer,

your device is provided with a 3 year warranty starting with the purchase date. In the event of product defects, you are entitled to statutory rights against the vendor. These statutory rights are not restricted by our warranty presented in the following.

Warranty conditions

The warranty period starts with the purchase date. Please keep the original purchase receipt in a safe place. This document is required to verify the purchase.

If within three years from the purchase date of this product a material or factory defect occurs, the product will be repaired or replaced by us – at our discretion – free of charge to you, or the purchase price will be refunded. This warranty implies that within the period of three years the defective device and the purchase receipt are presented, including a brief written description of the defect and the time it occurred.

If the defect is covered by our warranty, the repaired or a new product will be returned to you. No new warranty period starts with a repair or replacement of the product.

Warranty period and statutory claims for defects

The warranty period is not extended when the warranty has been claimed. This also applies to replaced and repaired parts. Any damages and defects already existing at the time of purchase must be reported immediately upon unpacking. Repairs arising after the expiration of the warranty period are subject to a charge.

Warranty coverage

The device was produced carefully according to strict quality guidelines and tested diligently prior to delivery. The warranty applies to material or factory defects.

Excluded from the warranty are wear parts subject to normal wear and damages to fragile parts, e.g. switches, lamps or other parts manufactured from glass.

This warranty expires if the product is damaged, not used as intended or not serviced. For the proper operation of the product, all instructions listed in the operating instructions must be observed carefully. Any form of use and handling that is advised against in the operating instructions or warned against must always be avoided.

The product is only intended for private and not for commercial use. In the case of incorrect and improper treatment, use of force and interventions not performed by our authorised Service Centre, the warranty shall cease.

Handling in case of a warranty claim

In order to ensure prompt processing of your matter, please observe the following notes:

- Please keep the article number IAN: 489979_2501 and the purchase receipt as a purchase verification for all inquiries.

- The article number can be found on the rating plate, an engraving, the title page of your instructions (in the bottom left), or as a label on the rear or underside of the device.

- If faulty operation or other defects occur, first contact the Service Centre listed in the following by telephone or email.

- Then, you are able to send a product reported as defective free of charge to the service address specified to you, including the purchase receipt and the information on the defect and when it occurred.

At www.lidl-service.com you can download this and many other manuals, product videos and installation software.

This QR code takes you directly to the Lidl Service website (www.lidl-service.com), where you can enter the article number (IAN)

489979_2501 to open your user instructions.

Service Centre

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

MT Service Malta

Tel.: [phone]

E-Mail: [e-mail]

CY Service Cyprus

Tel.: [phone]

E-Mail: [e-mail]

IAN: 489979_2501

Supplier

Please note that the following address is no service address. First contact the aforementioned Service Centre.

HOYER Handel GmbH

Kühnehöfe 12

22761 Hamburg

GERMANY

Sommaire

Symbol of a trash bin with crossed lines indicating no waste or discharge, and a solid black rectangle below (no text or labels)

Symbol of a trash bin with crossed lines indicating no waste or discharge (no text or labels)

Symbol of a trash bin with crossed lines indicating no waste or discharge, and a solid black rectangle below (no text or labels)

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Symbol of a trash bin crossed with no text or labels, accompanied by a black rectangular block below (no readable text or symbols)

Symbol of a trash bin crossed with two crossed lines and a solid black rectangle below (no text or labels)

Symbol of a trash bin crossed with no text or labels, accompanied by a black rectangular block below (no readable text or symbols)

Symbol of a trash bin with crossed lines indicating no waste or discharge (no text or labels)
