USER MANUAL SSMA 12 A1 SILVERCREST

Last Information Update

Operating instructions and safety instructions

(五) (25)

NL BE STA AEMIXED OR ACCU

STAAPMIXER OF ACCO

Diagram showing a hand pouring liquid into a container with a valve, no text or symbols present

Icon showing a document and a recycling bin with an 'O' symbol (no text or numbers present)

FR

Polyethylen Low-Density

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

1. Intended use 22
2. Package contents....22
3. Technical specifications ....23

3.1 Short-time duty....23

3.2 Cool-down time 23

1. Safety instructions ....23
2. Copyright....27
3. Before you start....28

6.1 Fitting the blender attachment (8)....28

6.2 Removing the blender attachment (8)....28

6.3 Adjusting the speed....28

6.4 The measuring cup (9) 28

6.5 Inserting / removing the battery pack 28

1. Getting started....29

7.1 Operation with blender attachment (8)....29
7.2 Processing times chart....31
7.3 Recipe suggestions....32
8. Cleaning 34
9. Storage when not in use 34
10. Troubleshooting....34
11. Environmental regulations and disposal information....35
12. Conformity notes ....36
13. Warranty information....37

Congratulations!

By purchasing the rechargeable battery stick blender, hereinafter referred to as the stick blender, you have opted for a quality product.

Before first using it, familiarise yourself with the way the stick blender works and read these operating instructions through carefully. Be careful to follow the safety instructions and only use the stick blender as described in the operating instructions and for the applications given. Keep these operating instructions in a safe place. If you pass the stick blender on to someone else, make sure to give them all the relevant documents with it.

1. Intended use

This stick blender is a household appliance and must be used exclusively for chopping and puréeing various boneless foods. The stick blender may not be used outdoors or in tropical climates. The stick blender is not intended for corporate or commercial applications. Use the stick blender only in residential areas for private use, any other use is not as intended. This stick blender fulfils all relevant norms and standards relating to CE conformity. If the stick blender is modified in a way not agreed with the manufacturer, compliance with these standards is no longer guaranteed. The manufacturer accepts no liability for any damage or malfunctions resulting from this.

Observe the regulations and laws in the country of use.

2. Package contents

Remove the stick blender and all the accessories from the packaging. Remove the packaging material and check that all components are complete and undamaged. If you find anything missing or damaged, please contact the manufacturer.

• Motor unit
• Blender attachment
• Measuring cup
• Quick Guide (the detailed operating instructions are available online)

The required battery pack and charger are not included in the package.

Due to its design, this device can only be powered with a 2 Ah battery pack or 2.5 Ah battery pack from the X 12 V TEAM (Parkside) series.

Please observe the safety instructions and notes on charging and correct use given in the operating instructions for your X 12 V TEAM (Parkside) series battery pack and charger. A detailed description of the charging process and further information can be found in these separate operating instructions.

On the inside of the cover is a diagram of the stick blender with all its control elements numbered. The meanings of the numbers are as follows:

1 Battery pack compartment cover

2 Battery pack compartment

3 Safety button (cancel operation lock)

4 I button (low speed)

5 II button (high speed)

6 LED (ready for operation)

7 Motor unit

8 Blender attachment

9 Measuring cup

3. Technical specifications

Manufacturer TARGA GmbH
Name SilverCrest SSMA 12 A1
Power supply 12 V	---Not included in the package:2 Ah or 2.5 Ah battery pack from the X 12 V TEAM(Parkside) series
Power consumption 150W
Short-time duty 5 minutes
Measuring cup (9) capacity 700 ml liquid
Measuring cup (9) processing volume max	300 ml liquid

The technical data and design may be changed without prior notice.

3.1 Short-time duty

The short-time duty (KB time) indicates how long the stick blender can be operated without the motor overheating and getting damaged. The short operating time (short-time duty) for the stick blender is 5 minutes.

3.2 Cool-down time

After the maximum operating time of up to 5 minutes, allow the stick blender to cool for at least 3 minutes before continuing to process your food.

4. Safety instructions

Before you use this device for the first time, please read the following notes in this manual and heed all warnings, even if you are familiar with handling electronic devices and household appliances. Keep

these operating instructions in a safe place for future reference. If you sell the device or pass it on, it is essential that you also hand over these operating instructions. They are a part of the device.

Explanation of symbols used

DANGER! This signal word indicates a danger with a high risk, which will lead to death or major injuries if not avoided.

WARNING! This signal word indicates a danger with a moderate risk, which can lead to death or major injuries if not avoided.

DANGER! This symbol denotes danger for human health and risk of death and/or risk of damage to property due to electric shock.

Risk of fire! This symbol warns that fires could start if the warning is left unheeded.

This symbol indicates that you should never immerse the motor unit (7) in water.

This symbol designates parts which are dishwasher-safe.

This symbol designates products whose physical and chemical composition has been tested and found to be non-hazardous to health when used in contact with food in accordance with the requirements of Regulation EU 1935/2004.

This symbol denotes further information on the topic.

The device is part of the X 12 V TEAM (Parkside) series.

DC voltage

This symbol on the measuring cup (9) indicates the maximum amount of liquid that can be processed in the measuring cup (9) without the contents overflowing.

Manufacturer's address

Foreseeable misuse

• The stick blender must not be used for chopping hard or very hard foods. This includes, for example, frozen foods, coffee beans, grains and spices. It cannot be used for processing chocolate. This could cause damage to property.
• Non-food substances should not be processed. This could damage the stick blender.
• The stick blender should not be operated in the air, but only for blending suitable food. Prolonged operation in the air can damage the stick blender.
• The stick blender must only be operated with a battery pack and charger from the X 12 V TEAM (Parkside) series.

DANGER! Please observe the safety instructions and notes on charging and correct use given in the operating instructions for your X 12 V TEAM (Parkside) series battery and charger. A detailed description of the charging process and further information can be found in these separate operating instructions.

Personal safety

- This appliance must not be used by children. The stick blender and its battery pack should be kept out of the reach of children. Make sure that children are supervised and do not play with this device.

Keep the blender attachment (8) out of the reach of children to ensure that they cannot injure themselves with it.

DANGER! Packaging material is not a toy. Do not allow children to play with plastic bags. There is a risk of suffocation. Keep the appliance out of the reach of children.

- This device may be used by persons with reduced physical, sensory or mental capabilities and/or who have no experience in, or knowledge of, using such appliances providing they are supervised or have been instructed in how to use the appliance safely and have understood the associated risks.

- Do not allow children to play with the device.

DANGER! Risk of injury

- Before replacing accessories or additional parts which move when the device is running, the device must be switched off.

- Remove the battery pack before assembling, disassembling or cleaning the stick blender. There is a danger of injury!

- Wait for the blade in the blender attachment (8) to stop before removing the motor unit (7). Never reach into the rotating blade. There is a danger of injury!

- Be careful when cleaning the stick blender! The blade in the blender attachment (8) is very sharp! There is a danger of injury!

- After switching off, wait for the blade to stop moving before removing the stick blender from the food. There is a danger of injury!

- Never reach into the rotating blade of the blender attachment (8). Do not hold any objects in the blade and keep loose clothing and long hair away from the rotating blade. There is a danger of injury!

DANGER: Risk of electric shock

• Never operate the stick blender near a bath tub, a shower or a full sink.
• Never open the housing of the motor unit (7). It does not contain any replaceable parts. Opening the housing can expose you to the risk of electric shock.
• If you notice smoke, unusual noises or smells, remove the battery pack immediately. If this occurs, do not continue to use the stick blender and have it checked out by an expert. Never inhale smoke from a possible device fire. If you do inadvertently inhale smoke, seek medical attention. Inhaling smoke can be harmful to your health, there is a risk of injury!

Never immerse the motor unit (7) in water and do not allow liquid to penetrate into the housing of the motor unit (7).

• If liquid does penetrate into the casing of the motor block (7), remove the battery pack and contact customer services. There is a risk of electric shock!
• Never touch the motor unit (7) with wet hands. There is a risk of electric shock!

DANGER of fire

After the maximum operating time of up to 5 minutes, allow the stick blender to cool for at least 3 minutes before continuing to process your food. There is a risk of fire.

5. Copyright

All the contents of this user manual are protected by copyright and provided to the reader for information only. Copying data and information without the prior explicit written consent of the author is strictly forbidden. This also applies to any commercial use of the contents and information. All texts and diagrams are up-to-date as of the date of printing. Subject to change without notice.

6. Before you start

Remove the stick blender and all accessories from the packaging and check that the package contents are complete. Remove any protective films. Keep the packaging material away from children and dispose of appropriately.

Before first use, clean the stick blender carefully as described in the chapter on "Cleaning".

Dry all parts completely before assembling the stick blender:

6.1 Fitting the blender attachment (8)

• Place the motor unit (7) on the blender attachment (8) so that the arrow marking (▼) points to the open lock on the blender attachment (8).
• Now turn the motor unit (7) in the direction of the closed lock symbol so that the arrow marking (▼) points to the closed lock on the blender attachment (8). You should hear and feel the blender attachment (8) click into place.

6.2 Removing the blender attachment (8)

• Turn the motor unit (7) in the direction of the open lock symbol 6 so that the arrow marking (▼) points to the open lock 6 on the blender attachment (8).
• Now remove the motor unit (7) from the blender attachment (8).

6.3 Adjusting the speed

Press the I and II buttons (4, 5) to select the stick blender speed. This allows you to set the optimum speed for each food to be processed.

• Press the I button (4) to blend at normal speed.
• Press the II button (5) to blend at higher speed.

6.4 The measuring cup (9)

• You can measure liquids up to 700 ml using the enclosed measuring cup (9).
• You can also use the measuring cup (9) to process your food.

When using the measuring cup (9) for food processing, only fill a maximum amount of 300 ml (Otherwise, liquid may run or splash out of the measuring cup (9).

6.5 Inserting / removing the battery pack

To insert or remove the battery pack, proceed as follows:

- First remove the battery pack compartment cover (1). Turn the battery pack compartment cover (1) in the direction of the open lock symbol ☐ so that the arrow marking (▼) points to the open lock ☐ on the motor unit (7). Next lift the battery pack compartment cover (1) to remove it.

Inserting the battery pack

- Insert the battery pack so that it clicks into the battery pack compartment (2).

Removing the battery pack

- Unlock the battery pack by pressing and holding the two red latches on the battery pack while pulling the battery pack upwards out of the battery pack compartment (2).

- Place the battery pack compartment cover (1) on the motor unit (7) so that the arrow marking (▼) points to the open lock on the motor unit (7). Turn the battery pack compartment cover (1) in the direction of the closed lock symbol on the motor unit (7) so that the arrow marking (▼) points to the closed lock on the motor unit (7).

Battery level

- During operation, the LED (6) indicates the current battery charging level:

LED (6) lights up continuously Charge level OK

LED (6) flashes Charge level low >>> Charge the battery

7. Getting started

The stick blender is suitable for the following applications:

chopping and puréeing fruit and vegetables in soups, sauces and dips
mixing drinks
making milkshakes

Warning! Risk of injury!

If you are using the stick blender to purée hot food in a saucepan, remove the saucepan from the hob before blending and make sure that the liquid is not boiling.

Allow hot food to cool down slightly to avoid scalding.

It is recommended that you adjust the speed of the stick blender to the food you are processing.

Use normal speed for soft foods and the higher speed for harder foods.

7.1 Operation with blender attachment (8)

If possible, put the food you wish to chop in a tall, narrow container with a flat bottom. This is perfect to achieve even puréeing results. Of course, you can also use the blender in a normal saucepan.

Function of the safety button (3) and the LED (6)

This stick blender is equipped with a safety function to protect you from injury caused by accidental operation. For this reason, the safety button (3) must be kept pressed for approx. 3 seconds before starting to process your food. The LED (6) lights green to indicate that the device is ready for operation. After you finish the blending process, the device remains ready for operation for a further 7 seconds, during which you can start another blending process.

If no new food processing is started within 7 seconds, the LED (6) goes out. A new blending process is then only possible again once operational readiness has been reactivated by pressing the safety button (3) first. In order to avoid injuries from the rotating blade, only switch the stick blender on once the blender attachment (8) is in the food.

The procedure is as follows:

• Put the food to be processed in a suitable container or saucepan.
• Place the blender attachment (8) into the food vertically.
• Start the stick blender by pressing the button (4) or the button (5) depending on the desired speed. Press and hold the corresponding button (4, 5) during the blending or puréeing process and adjust the speed to your requirements by changing the button (4, 5) as necessary. If the blender attachment (8) sticks to the bottom of the container, release the button (4, 5) briefly and then continue mixing.
• To ensure even processing of the mix, move the stick blender gently backwards and forwards.
• When you have the results you want, release the button (4, 5) while the blender attachment (8) is still in the mixture.
• Wait for the blade to stop moving before removing the blender attachment (8) from the puréed food.

If you notice any unusual noises during operation, e.g., squeaking or similar, apply a small amount of neutral cooking oil to the drive shaft of the blender attachment(8). Please also refer to the adjacent sample diagram.

Diagram showing a hand pouring liquid into a container with a valve, no text or symbols present

7.2 Processing times chart

The table below gives a guideline on how to process different foodstuffs. Follow the recommended processing times to prevent the stick blender from overheating. If you have not achieved a satisfactory blending result within this time, pause the blending process and allow the motor to cool down first. Then you can continue the blending process.

After the maximum operating time of up to 5 minutes, allow the stick blender to cool for at least 3 minutes.

Food Recommended	quantity	Speed Processing	time
Fruit, vegetables 100 - 200 g		Level I or II*	30-60 seconds
Soups, sauces, baby food	100 - 400 ml	Level I or II*	60 seconds
Milk drinks, shakes 100 -	1000 ml	Level I or II*	60 seconds

*: Set the speed according to the desired consistency.

When using the measuring cup (9) for processing, only fill a maximum amount of 300 ml (9). Otherwise, liquid may run or splash out of the measuring cup (9). When using larger quantities, please always use a mixing container that is suitable for the quantity to be processed.

7.3 Recipe suggestions

Tomato and basil soup

Ingredients Quantit	y Note
Peeled tomatoes 250 g
1 onion approx. 50 g
1 garlic clove approx.	5 g small
Vegetable broth 150 ml
basil	6	leaves
Butter approx. 10 g
Salt, pepper taste and	adjust the seasoning

Method:

Peel the onions and garlic and chop finely with the basil leaves. Melt the butter in a pan, add the diced onion and garlic. After sautéing briefly, add the tomato pieces to the pan and sauté briefly, then pour in the stock and add the basil. Cover the soup and simmer for 10 minutes. Purée the soup and then season with salt and pepper.

Strawberry cream

Ingredients Quantity Note
Strawberries	500 g
Binder	1 tbsp.	e.g. agar-agar, pectins, starch
Sugar	1 tsp.
vanilla sugar	1 sachet
Sheep's milk yoghurt	150 g
Lime syrup	100 ml

Method:

Blend 250 g of the strawberries and the remaining ingredients at speed I. To obtain a nice creamy mixture, increase the speed to level II until the desired creaminess is achieved. Dice the remaining 250 g strawberries and divide all but 2 tbsp into 3 bowls. Then divide the cream evenly between the bowls and decorate with the remaining diced strawberries. Then chill in the fridge for 3-4 hours.

Parsley and basil pesto

Ingredients Quantity Note
basil	14	bunch
Flatleaf parsley	12 bunch
Pine nuts	1 tbsp.
Parmesan	35 g
salt 1 pinch
pepper	1 pinch
Olive oil	65 ml

Method:

Wash the basil and parsley. Pluck the parsley leaves and dice the cheese. Then place all the ingredients in the measuring cup (9) supplied and purée finely at level Ⅲ. Slowly move the stick blender up and down while puréeing. Divide the pesto between 2 screw-top jars and cover with a little oil.

Fig and cream cheese dip with walnuts

Ingredients Quantity Note
Cream cheese 300 g
Dried figs 4 pieces
Walnuts 50 g
Honey 1 tbsp.
Lime	12
salt 1 pinch
pepper	1 pinch

Method:

Finely chop the walnuts. Blend the juice of half the lime, the cream cheese, honey, dried figs, salt and pepper at speed I until creamy. Finally, stir in the finely chopped walnuts.

Salsa dip

Ingredients Quantity Note
Tomatoes 250 g
Red pepper	12 pod
Onion	1 small
Garlic	12 clove
Chilli pepper pod	12
Tomato purée	1 tbsp.
Parsley	1 bunch
salt 1 pinch
pepper 1 pinch
Sugar	1 pinch

Method:

Wash the onion, tomatoes, pepper, garlic clove, chilli pepper and parsley and remove any seeds. Dice the ingredients into medium-sized pieces. Blend the ingredients as required. The higher the speed, the finer the salsa.

Enjoy!

8. Cleaning

Risk of injury! Be careful when cleaning the stick blender! The blade in the blender attachment (8) is very sharp!

Warning about property damage! Do not use abrasive or astringent detergents or tools which could scratch the surface (e.g. metal sponges). Otherwise you could damage the stick blender.

It is recommended that you clean the blender attachment (8) right after you use it to avoid the food drying on it. Rinse the blender attachment (8) off straight-away with cold water, especially if you have been processing very salty foods.

• Remove the battery pack.
• Remove the blender attachment (8) from the motor unit (7).
• Clean the motor unit (7) with a slightly damp cloth and then dry it carefully. Use a little washing-up liquid if necessary. Cleaning in detergent water would cause irreparable damage!
• You can clean the blender attachment (8) and measuring cup (9) in detergent water. After cleaning, rinse with plenty of clean water to remove detergent residues. Dry the blender attachment (8) and measuring cup (9) up carefully.
  • Alternatively, you can also clean the blender attachment (8) and measuring cup (9) in the dishwasher.

To achieve optimum cleaning results when cleaning the blender attachment (8) in the dishwasher, please ensure that it is positioned vertically and with the blade pointing upwards. Then allow the blender attachment (8) to dry thoroughly.

9. Storage when not in use

If you do not use the stick blender for a longer period of time, remove the battery pack and clean it as described in the previous chapter. Store the stick blender in a dry and clean place out of the reach of children.

10. Troubleshooting

If your stick blender does not work as normal, follow the instructions below to try to solve the problem. If working through the tips below does not fix the fault, please contact our hotline.

The stick blender does not work

• Check that the battery is charged. If necessary, charge the battery and try again.
• Check that the battery pack is inserted properly. Remove the battery pack and insert it correctly.

The blade does not rotate / rotates slowly

• The motor unit (7) and the blender attachment (8) are not fitted together correctly. Check the fitting.
• Check if there is an obstacle in the mixing container. Remove it.
• The food you are mixing is too hard or too tough.

11. Environmental regulations and disposal information

	Devices marked with this symbol are subject to the European Directive 2012/19/EU. All electrical and electronic devices must be disposed of separately from household waste at official disposal centres. Avoid damage to the environment and risks to your personal health by disposing of the device properly. For further information about proper disposal, contact your local government, disposal bodies or the shop where you bought the device.
	The symbol of the crossed-out wheelie bin on conventional and rechargeable batteries indicates that they cannot be disposed of in normal domestic waste but must be disposed of separately.Where batteries contain toxic materials, the chemical symbol of the toxic material is shown underneath the symbol, with meanings as follows:- Pb: Battery contains lead- Cd: Battery contains cadmium- Hg: Battery contains mercuryYou are obliged by law to return used batteries. Old batteries can contain toxic materials which can be damaging to health or the environment if not properly stored or disposed of. Batteries also contain important raw materials, such as iron, zinc, manganese and nickel, which can be reused.After use, you can return the batteries to us or to a local collection point (e.g. in retail outlets or a local collection point) free of charge. Please note that batteries must be disposed of fully discharged at appropriate collection points for old batteries. If disposing of batteries which are not fully discharged, take precautions to prevent short circuits.
	Dispose of all packaging in an environmentally friendly manner. Cardboard packaging can be taken to paper recycling centres or public collection points for recycling. Any film or plastic contained in the packaging should be taken to your public collection points for disposal.
ES/PT

Only relevant for France:

FR ÉLÉMENTS D'EMBALLAGE FR

The product, the accessories, the printed material and the packaging are recyclable. They are subject to enhanced manufacturer responsibility and are sorted and collected separately.

Only relevant for Spain and Portugal:

Please separate the packaging material and dispose of it in the relevant collection containers in accordance with the symbols on the packaging:

Symbol		Material	Contained in the following packaging elements for this product
		Low density polyethylene	Plastic bag to protect the device
		Corrugated cardboard Sales packaging

12. Conformity notes

The product complies with the requirements of the applicable European and national directives. Evidence of conformity has been provided. The manufacturer has the relevant declarations and documentation.

The complete EU Declaration of Conformity and any other conformity declaration (where applicable) are available for download from this link:

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Contact address in accordance with 2023/988 Product Safety Regulation: [e-mail]

13. Warranty information

Warranty of TARGA GmbH

Dear Customer,

This device is sold with three years warranty from the date of purchase. In the event of product defects, you have legal rights towards the seller. These statutory rights are not restricted by our warranty as described below.

Warranty conditions

The warranty period commences upon the date of purchase. Please keep the original receipt in a safe place as it is required as proof of purchase. If any material or manufacturing faults occur within three years of purchase of this product, we will repair or replace the product free of charge as we deem appropriate.

Warranty period and legal warranty rights

The warranty period is not extended in the event of a warranty claim. This also applies to replaced and repaired parts. Any damage or defects discovered upon purchase must be reported immediately when the product has been unpacked. Any repairs required after the warranty period will be subject to charge.

Scope of warranty

The device was carefully manufactured in compliance with stringent quality guidelines and subjected to thorough testing before it left the works. The warranty applies to material and manufacturing faults. This warranty does not cover product components which are subject to normal wear and which can therefore be regarded as wearing parts, or damage to fragile components such as switches, rechargeable batteries or components made of glass. This warranty is void if the product is damaged, incorrectly used or serviced. To ensure correct use of the product, always comply fully with all instructions contained in the user manual. The warnings and recommendations in the user manual regarding correct and incorrect use and handling of the product must always be observed and complied with. The product is solely designed for private use and is not suitable for commercial applications. The warranty is rendered void in the event of incorrect handling and misuse, if it is subjected to force, and also if any person other than our authorised service technicians interfere with the device. No new warranty period commences if the product is repaired or replaced.

Submitting warranty claims

To ensure speedy handling of your complaint, please note the following:

- Before using your product for the first time, please read the enclosed documentation carefully. Should any problems arise which cannot be solved in this way, please call our hotline.

- Always have your receipt, the product article number as well as the serial number (if available) to hand as proof of purchase.

- If it is not possible to solve the problem on the phone, our hotline support staff will initiate further servicing procedures depending on the fault.

- You can find this and many more manuals, product videos and installation software available for download at www.lidl-service.com. This QR code takes you directly to the LIDL service page (www.lidl-service.com). There, you can enter the item number (IAN) to access your operating manual.

PDF ONLINE www.lidl-service.com

Service

Phone: [phone]

E-Mail: [e-mail]

Phone: 1800

101010

E-Mail: [e-mail]

Phone: 800

62230

E-Mail: [e-mail]

Phone: 8009

4241

E-Mail: [e-mail]

IAN: 488568_2407

Manufacturer

Please note that the following address is not a service address. First contact the service point stated above.

TARGA

GmbH

Coesterweg 45

59494 Soest

GERMANY

Table des matières

Illustration of a hand pouring liquid into a container with a valve, no text or symbols present

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Cher client, chère cliente,

Cher client, chère cliente,

Illustration of a hand pouring liquid into a container with a valve, showing fluid flow direction (no text or symbols)

7.3 Receptsuggesties

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Contactadres overeenkomstig Verordening 2023/988 inzake productveiligheid: [e-mail]

13. Garantie

Illustration of a hand pouring liquid into a container with a tool, no text or symbols present

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Diagram showing a hand pouring liquid into a water tank with a valve, illustrating fluid flow (no text or symbols)

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Diagram showing a hand pouring liquid into a water tank with a valve, illustrating fluid flow (no text or symbols)

7.2 Tabul'ka dôb spracovania

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Diagram showing a hand pouring liquid into a container with a valve, no text or symbols present

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Diagram showing a hand pouring liquid into a container with an arrow indicating flow direction (no text or symbols)

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Diagram showing a hand pouring liquid into a container with a valve, no text or symbols present

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf

Simple black-and-white icon set showing a droplet, factory building, and horizontal bar (no text or symbols)

Egyenfeszültség

Diagram showing a hand pouring liquid into a container with an arrow indicating flow direction (no text or symbols)

https://www.targa.gmbh/downloads/conformity/488568_2407.pdf
