USER MANUAL PELSB 3000 A1 PARKSIDE

Black outdoor lawn brush with attached device and inset showing motion (no text or symbols)

Electric Leaf Blower & Vacuum

Translation of the original instructions

NL BE

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

Technical diagram of a power tool with labeled parts including a 10-pin connector and a 14-pin body.

Inhaltsverzeichnis

Einleitung.... 4

Service-Center....24

Importeur.... 24

Scope of delivery/accessories......27

Overview.... 27

Description of functions....27

Technical data....27

Safety information....28

Meaning of the safety information...... 28

Pictograms and symbols.... 28

Safe operation of your leaf blower.....29

Preparation....37

Control elements....38

Attaching and removing the blower pipe.... 38

Attaching and removing the suction pipe.... 38

Fitting and removing the collection bag....38

Putting on the carrying strap.... 39

Operation.... 39

Switching on and off....39

Working instructions.... 39

Emptying the collection bag.... 40

Transport....40

Cleaning, maintenance and storage..... 40

Cleaning....40

Maintenance.... 40

Removing obstructions and blockages....40

Storage.... 41

Disposal/environmental protection......41

Troubleshooting.... 41

Service.... 42

Guarantee.... 42

Repair service.... 43

Service Centre.... 43

Importer.... 43

Spare parts and accessories.... 43

Translation of the original EU declaration of conformity.... 44

Exploded view.... 231

Introduction

Congratulations on purchasing your new electric leaf vacuum/blower (hereafter referred to as device or power tool).

You have chosen a high-quality device. This device was quality-tested and subjected to a final inspection during production, therefore ensuring proper functioning of your device.

The instruction manual forms part of this device. It contains important information on safety, use and disposal. Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Use the device only as described and for the stated fields of application. Store the instruction manual carefully and ensure that all documents are handed over in the event that the device is passed on to another user.

Proper use

This device is only intended for the following use:

• Suctioning dry foliage.
• To collect dry leaves/remove them from hard to reach areas (e.g. under vehicles).

The device is intended for use by adults. Children under the age of 16 may not use the device, except under supervision.

Any other use that is not expressly permitted in this instruction manual may pose a serious hazard to the user and result in damage to the device. The operator or user of the machine is responsible for any accidents or personal injury and/or material damage to third parties or their property. The machine is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use. The warranty is void in the case of commercial use. The manufacturer is not liable for damage caused by improper use or incorrect operation.

DANGER! A leaf vacuum is not a wet vacuum! Please avoid vacuuming wet materials (leaves, dirt, branches, limbs, pinecones, grass, sand, bark mulch/shredded material etc.). Do not vacuum on damp or wet grass. Incorrect use can, under certain circumstances, lead to blockages in the shredding chamber and therefore to reduced performance. The machine may then have to be completely disassembled and cleaned. This work must be carried out by a specialist and is not covered by the warranty.

Scope of delivery/accessories

Unpack the device and check that everything is present.

Dispose of the packaging material properly.

• Electric Leaf Blower & Vacuum
- Blower pipe (two-part)
- Suction pipe (two-part)
- Carrying strap
- Collection bag
• Translation of the original instructions

Overview

The illustrations for the device can be found on the front and back fold-out page.

1 Motor housing
2 T-handle
3 Rotary wheel
4 Handle
5 On/Off switch
6 Cable strain relief
7 Power cord
8 Protective cover
9 Lock

10 Blower pipe

11 Auxiliary handle

12.1 Eyelet, Suction mode

12.2 Eyelet, Blowing mode

13 Carrying strap

14 Screw, Suction opening

15 Collection bag

16 Carabiner

17 Suction pipe

18 Screw, Suction pipe

19 Screw, Auxiliary handle

(Fig. B)

20 Eyelet, Collection bag
21 Ventilation hole
22 Push-fit lock

Description of functions

In suction mode, the vacuumed leaves are shredded to reduce the volume, then blown through the discharge channel and collected in the collection bag.

In blowing mode, foliage can quickly be gathered or blown out of hard to reach areas with the cordless leaf blower.

Please refer to the descriptions below for information on how the operating elements work.

Technical data

Electric Leaf Blower & Vacuum

PELSB 3000 A1

Rated voltage U ....230-240 V\~, 50 Hz

Rated input power P ....3000 W

No-load rotation speed n_0

10 000 - 15 000 min ^-1

Weight with accessories ....≈4.05 kg

Air speed .... ≤ 320 km/h

Air volume ....≤ 14 m ^3 /min

Chopping rate 16:1

Collection bag 551

Protection class □ II

Protection type ......IPX0

Sound power level ( L_WA )

– Guaranteed ....103 dB

Blowing mode

Sound power level ( L_WA )

- Measured 97.8 dB; K_WA = 3.05 dB

Sound pressure level ( L_pA )

82.8 dB; K_pA = 3 dB

Vibration a_h

Handle 2.36 m/s ^2 ; K= 1.5 m/s ^2

Auxiliary handle ...... 2.41 m/s ^2 ; K= 1.5 m/s ^2

Suction mode

Sound power level ( L_WA )

- Measured ....100.4 dB; K_WA=2.07 dB

Sound pressure level ( L_pA )

85.3 dB; K_pA = 3 dB

Vibration a_h

Handle 2.48 m/s²; K=1.5 m/s²

Auxiliary handle ...... 2.55 m/s ^2 ; K= 1.5 m/s ^2

Levels of noise and vibration were determined according to the standards and regulations in the declaration of conformity.

The specified total vibration value and the stated noise emission value have been measured according to a standardised test method and can be used to compare one power tool with another. The specified total vibration value and the stated specified noise

emission value can also be used for a provisional assessment of the load.

WARNING! The vibration and noise emissions may deviate from the specified values during actual use of the power tool, depending on how the power tool is being used. Try to keep the exposure to vibrations as low as possible. An example of a measure to reduce vibration exposure is limiting the working hours. All parts of the operating cycle have to be considered while doing so (for example, times when the power tool is switched off and times when it is switched on but running without any load).

Safety information

This section deals with the basic safety instructions for using the device.

Meaning of the safety information

⚠ DANGER! If you do not observe this safety instruction, an accident will occur. The result of which is severe bodily injury or death.

⚠ WARNING! If you do not observe this safety instruction, an accident may occur. The result of which is likely severe bodily injury or death.

⚠️ CAUTION! If you do not observe this safety instruction, an accident will occur. The result of which is likely minor or moderate bodily injury.

NOTICE! If you do not observe this safety instruction, an accident will occur. The result of which is possible damage to property.

Pictograms and symbols

Symbols on the device

Attention!

Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly.

For safety reasons, make sure that the protective cover is fitted on the suction opening!

For safety reasons, both suction pipe sections and the collection bag must be correctly mounted before you can start the machine.

Risk of injury due to ejected parts! Keep persons in the vicinity away from the device

Rotating impeller. Keep away from hands!

Attention! Disconnect the mains plug before cleaning and maintenance work.

Use hearing protection

Use eye protection

Use a mask

Use foot protection

Do not wear long hair uncovered. Use a hair net.

Use of the device in the rain or a damp environment is prohibited.

Pull out mains plug immediately, if the mains cable is damaged, entangled or severed.

Guaranteed sound power level LWA in dB.

Protection class II (double insulation)

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

Rotary dial scale

Switching on

Switching off

Keep a safety distance of at least 5 m from other people.

Safe operation of your leaf blower

IMPORTANT!

• READ THROUGH CARE- FULLY BEFORE USE!
• KEEP THIS DOCUMENTATION!

Attention! The following basic safety precautions must be observed while using electrical devices to protect against electric shock, injury and risk of fire:

Instruction

• Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly.
  • Children, individuals with limited physical, sensory or mental capabilities, as well as those who have insufficient experi-

ence or knowledge or are not familiar with the instructions must never be permitted to use the machine. Local regulations may specify an age restriction for the user.

• Note that the user is responsible for any accidents or risks to others and their property.
- Observe noise protection rules and other local regulations.
- Do not use the machine at altitudes higher than 2000 m.

Preparation

- Never use the device if there are children or animals nearby. People nearby must wear protective clothing.

- The personal protective equipment protects your own health and the health of others and ensures the smooth operation of the machine. Wear suitable work clothing during the entire time the machine is in use:

- Sturdy shoes with non-slip soles

- Sturdy, long trousers

- Gloves

- Protective goggles

• Hearing protection

• Respiratory protection to protect against dust

- Never use the machine barefooted or wearing open sandals.

- Do not wear loose hanging clothing or jewellery that could be sucked into the air intake. Wear protective headwear to contain long hair. Keep long hair away from the suction openings.

- Pay attention to people, especially children, pets, open windows, etc. The blown material can be thrown in their direction. Stop working if they are in close proximity. Keep a safety distance of 5 m around you.

- Familiarise yourself with your surroundings and be aware of possible hazards that may be overheard when working.

- Carefully inspect the surface to be cleaned and remove all wires, stones,

cans and other foreign bodies.

- Use a rake or broom to remove foreign bodies before operation.

- Operate the machine in a recommended position and only when standing on a solid, flat surface.

- Use all parts of the blowing pipe so that the airflow can work close to the ground.

- In very dry conditions, lightly moisten the surface or use a sprayer to reduce the build-up of dust.

- Do not work with a damaged or incomplete machine or one which has been converted without the permission of the manufacturer. Before use, check the safety status of the machine, in particular the power cord and the switch.

- Only use the machine when fully assembled.

- Only use the machine in suction mode if the collection bag is attached. Check the collection bag

regularly for wear or damage.

- Never operate the machine with defective protection equipment or faulty protection covers or without any protection equipment. Never operate the machine with a damaged or worn out power cord.

• We recommend that you only operate the machine at reasonable times – not early in the morning or late at night when others may be disturbed.

- Do not operate the machine on a paved surface or a gravel surface where the ejected material could cause injury.

• Always perform a visual inspection prior to use to make sure that the housing is undamaged. Replace worn or damaged components in sets to ensure balance. Replace damaged or illegible markings.

- Prior to use, always check the power cord and extension cord for signs of damage or wear

and tear. If the cord is damaged during use, it must be disconnected from the supply network immediately. DO NOT TOUCH THE CABLE BEFORE IT HAS BEEN DISCONNECTED FROM THE POWER SUPPLY. Do not use the device if the cord is damaged or worn.

- Ensure that the mains voltage and mains frequency match the specifications on the rating plate.

- Connect the device only to a power outlet with a residual current device (RCD) of rated residual current no more than 30 mA.

- If the power cord of this device is damaged, it must be replaced by the manufacturer, their customer service or by a similarly qualified person in order to avoid hazards. contact the service centre.

- Only use extension cables (of type H07RN-F) that are intended for outdoor use and are la-

belled accordingly. The wire cross section of the extension cable must be at least 2.5 mm ^2 . The extension cable must not be longer than 75 m. The coupling of the extension cable must be protected against splash water, must be made of rubber or must be covered with rubber. Always roll out the cable drum completely before use. Check the power cord for damage.

- Use the strain relief provided to attach the extension cable.

Operation

- Pay attention, be aware of what you are doing and take the utmost care when working with the device. Do not use the device if you are tired or you are under the influence of drugs, alcohol or medication.

- Do not let other people touch the machine or the extension cable. Keep the machine away from people, especially children, and pets.

- Do not switch on the machine if it is held upside down or is not in operating position.

- Avoid starting the machine unintentionally. Make sure the machine is switched off before connecting it to the power supply, picking it up or carrying it. Having your finger on the switch when carrying the machine or connecting the machine to the power supply when it is switched on can cause accidents.

- Never point the machine at others, and in particular, do not point the air jet at the eyes and ears during operation.

• Always ensure secure positioning, particularly on slopes, when working. Always hold the machine firmly with both hands and only work with a correctly adjusted carrying strap.

- Do not stretch too far and do not lose your balance.

- Keep fingers and feet away from the suction pipe opening and im-

peller. There is a risk of injury.

- Prolonged use of the machine can lead to blood circulation disorders in the hands caused by vibration. However, you can extend the duration of use by wearing suitable gloves or taking regular breaks.

• Operation of the device in bad weather is to be avoided, especially if there is a risk of lightning. Only work in daylight or where there is good artificial lighting.

- Do not vacuum burning, glowing or smoking materials (e.g. cigarettes, embers etc.), vapours or highly flammable, toxic or explosive substances.

- Stop the machine and remove the plug from the power outlet. Ensure that all moving parts are at a full standstill:

- When you are not using the machine or when you are transporting or leaving it unattended;

- When you inspect the machine, clean it or remove blockages;

- When you perform cleaning or maintenance work, or swap accessories;

- If the power cord or extension cable is damaged;

• After contact with foreign objects or if abnormal vibration occurs.

- Do not use the machine in a closed or poorly ventilated area.

- Do not use the machine near flammable liquids or gases. There is a risk of fire or explosion if this advice is not heeded.

- In the event of an accident or malfunction, switch the machine off immediately, disconnect the mains plug and ensure that all movable parts have stopped moving. Then, check the machine etc. If you have any questions, please contact your dealer.

- Walk at a steady pace, do not run.

- Make sure that the mains voltage matches the details on the type plate.

- Keep the power cord away from the working area and always run it behind the person operating the machine.

- Do not carry the machine by the power cord. Do not use the power cord to pull the plug out of the power outlet. Protect the power cord from heat, oil and sharp edges.

- Damaged cables, couplings and plugs or power cords that do not comply with the regulations must not be used. If the power cord is damaged, immediately remove the plug from the power outlet. Never touch the power cord unless the mains plug has been removed.

- Keep the extension cable away from dangerous moving parts to prevent damage to cables that can lead to contact with live parts.

- Ensure that the in-feed is empty prior to starting the machine.

- Keep your face and body away from the infeed opening.

- Do not allow hands or other body parts or clothing to enter the in-feed or discharge chute, or to be in the vicinity of moving parts.

- Avoid an abnormal body posture. When material is being taken in by the machine, never stand on a higher level than the base of the machine.

• Always maintain your balance to ensure secure footing on slopes. Walk, do not run.

- Do not stand within the ejection zone while operating the machine.

- When feeding material into the machine, ensure that no metallic objects, stones, bottles, canisters or other foreign objects are taken in.

- Do not allow processed material to accumulate in the ejection zone since this can prevent proper ejection and cause the material to be brought

back into the machine via the infeed opening.

- If the machine becomes clogged, turn off the power source and disconnect the machine from the mains supply before freeing any refuse.

- Never operate the machine with defective protective equipment or shields, or without safety equipment, e.g. without the collection bag being connected.

- Keep the power source free of refuse or other accumulated material to prevent it from becoming damaged and avoid a potential fire.

- Do not transport the machine while the power source is running.

- If the cutting mechanism comes into contact with a foreign object or the machine starts to emit unusual noises or vibrate, immediately turn off the power source and wait for the machine to come to a standstill. Disconnect the machine from the power supply, and per-

form the following steps before re-starting and operating the machine:

- Investigate for damage; - Replace or repair damaged parts;

- Check for loose parts and tighten as necessary.

- Do not tilt the machine while the power source is running.

- Ensure that you do not connect a damaged power cord to the power supply or touch a damaged cord before it has been disconnected from the power supply since damaged cords pose the risk of coming into contact with live parts.

- Ensure that you do not touch any of the dangerous moving parts before you have unplugged the machine from the power supply, and that the dangerous moving parts have come to a complete standstill.

- Do not vacuum hot, glowing, flammable, explosive or hazardous substances. These in-

clude hot ashes, petrol, solvents, acids or alkalis amongst others. Risk of fire and injury.

• Make sure not to damage the power cord by pulling it over sharp edges, getting it trapped or by pulling on the cord.

- Never use the power cord to pull the plug out of the outlet or to pull the device. Protect the power cord from heat, oil and sharp edges.

- Never transport the device while the drive is running.

- Switch off the device and disconnect the plug from the power outlet. Make sure that all moving parts have come to a complete stop

• when leaving the device,
• before changing the accessories,
• before removing obstructions or loosening blockages,
• before checking the device, cleaning it or performing maintenance work on it.

- If the device starts to vibrate abnormally, an immediate check is required:

• Examine for loose parts and tighten these,
• search for signs of damage,
• replace damaged accessories. For repairs, contact the service centre.

Cleaning, maintenance and storage

• Allow the motor to cool down before storing the device for a longer period.
• Replace worn or damaged parts in the interests of safety. Use only original spare parts and accessories. Using externally produced parts results in the immediate loss of any warranty claim.
• The device may only be opened by an authorised electrician. Always contact our service centre for repairs.
• Switch the drive off, disconnect the device from the power supply and al-

low the device to cool off if you want to clean, adjust, store the device or to exchange an accessory part.

• Handle the device with care and keep it clean.
• Store the device out of reach of children.

Residual risks

There will always be residual risks even if you operate this device according to the instructions. The following hazards may occur in connection with the type and design of this device:

• Eye damage if no suitable eye protection is worn.
• Lung damage if suitable respiratory protection is not worn.
• Hearing damage if suitable ear protection is not worn.
• Health injuries resulting from the effect of hand/arm vibration in the event that the tool is used over a longer period of time or is not used and maintained properly.

⚠ WARNING! Danger due to electromagnetic field

generated while the tool is in operation. Under certain circumstances, this field may negatively affect active or passive medical implants. In order to reduce the danger of serious or fatal injuries, we recommend that individuals who wear medical implants should consult their doctor and the manufacturer of the implant before operating the tool.

Preparation

⚠ WARNING! Risk of injury due to unintentional start-up. Do not insert the plug into the outlet until the device is fully prepared for use.

Before operating the machine, you must:

• install the blower or suction pipes,
- install the collection bag for suctioning leaves,
- tightly screw on the protective cover for leaf blowing.

NOTICE! The machine has two safety contacts. There is one safety contact in the motor housing (1) where the blower pipe (10) or collection bag (15) is inserted. The second safety contact is located in the suction opening where the protective cover (8) or the suction pipe (17) is fitted. The screws (14, 18) must be tightened hand-tight depending on blowing or suction mode.

⚠ WARNING! Risk of injury! When installing or removing the blow pipe, suction pipe, protective cover or collection bag, the machine must be switched off and the moving parts must be stationary. Disconnect the mains plug before carrying out any work!

Control elements

Familiarise yourself with the operating elements before using the device for the first time.

- Rotary wheel (3)

Stepless regulation of the suction and blowing power

- On/Off switch

- Switching on: Position On

- Switching off: Position Off

Attaching and removing the blower pipe

Notes

• WARNING! Personal injury! Never use the machine with only one pipe section fitted.
• When putting it together, make sure that the symbols (☐) on the pipe ends, as shown, interlock.
  • CAUTION! The pipe parts must not be disassembled again once they have been assembled.

Fitting the blower pipe (Fig. A)

CAUTION! The protective cover of the suction opening (8) must be closed.

1. Removing the suction pipe (Fig. B), p. 38
2. Fit the blower pipe parts (10) together, if necessary.
3. Push the blower pipe (10) onto the blow opening of the motor housing (1). The blower pipe clicks into place.
4. The screw (14) must be screwed tight and hand-tightened, otherwise the machine cannot be started later.

Removing the blower pipe (Fig. A)

1. Release the lock (9).
2. Pull the blower pipe (10) to the front.

Attaching and removing the suction pipe

Notes

• WARNING! Personal injury! Never use the machine with only one pipe section fitted.
• When putting it together, make sure that the symbols (☐) on the pipe ends, as shown, interlock.

- CAUTION! The pipe parts must not be disassembled again once they have been assembled.

Attaching the suction pipe (Fig. B)

1. Removing the blower pipe (Fig. A), p. 38
2. Loosen the screw (14).
3. Open the protective cover (8).
4. Fit the suction pipe parts (17) together, if necessary.
5. Hang the suction pipe (17) with the ridge on the hook on the underside of the motor housing (1) (see detailed illustration).
6. Attach the suction pipe (17) to the suction opening.
7. Turn the screw (18) into the motor housing (1).

The screw (18) must be screwed tight and hand-tightened, otherwise the machine cannot be started later.

1. The auxiliary handle (11) can be locked in various positions.

To change the handle position, release the screw (19), change the handle position and tighten the screw again.

Removing the suction pipe (Fig. B)

1. Loosen the screw (18).
2. Remove the suction pipe (17).
3. Close the protective cover (8).
4. Secure the protective cover with the screw (14).

Fitting and removing the collection bag

Notes

• WARNING! In suction mode the machine must only be operated with the collection bag mounted.
• The ventilation opening (21) on the collection bag improves air circulation.

Fitting the collection bag (Fig. B)

1. If necessary, remove the blower pipe (10).
2. Now push the collection bag (15) onto the blow opening of the motor housing (1) until it engages in the lock (9).
3. Hook the carabiner (16) of the collection bag (15) on the eyelets (20) provided on the suction pipe (17).

Removing the collection bag (Fig. B)

1. Release the lock (9).

2. Pull the collection bag (15) downwards.

Putting on the carrying strap

Notes

• WARNING! Never wear the carrying strap diagonally across your shoulders and chest: only wear it on one shoulder to ensure you can detach the machine quickly from your body in the event of danger.

• NOTICE! Pulling the push-fit lock (22) releases the carrying strap (13) quickly. To open the push-fit lock, press the two clamps together.

• Place the carrying strap (13) on one shoulder.

• Adjust the length of the strap so that the carabiner hook is about 10 cm below your hip.

• Attach the carabiner hook on the eyelet to hook in the strap:

Blowing mode: Position 12.2

Suction mode: Position 12.1

Operation

⚠️ DANGER! Risk of injury! Always wear appropriate protective equipment and work gloves while working with the machine. Make sure that the machine is in working order before each use. Ensure that the collection bag and pipe are installed correctly. Stop using the machine if the on/off switch or rotary dial is damaged. Personal protective equipment and a fully functional machine reduce the risk of injuries and accidents.

⚠ WARNING! Injury hazard caused by rotating tool. After the machine has been switched off, the impeller continues moving for some time.

Switching on and off

Switching on (Fig. C)

1. Make a loop from the end of the extension cable and attach this to the cable strain relief (6).
2. Connect the device to the power supply.
3. Slide the on/off switch (5) to position On.

Switching off (Fig. C)

1. Slide the on/off switch (5) to position Off.

2. Pull the device plug out of the wall outlet if you are leaving the device unattended or if you have finished working.

Working instructions

⚠ WARNING! This device is only intended for the following use:

- As a blower for piling up dry foliage or blowing it out of hard-to-reach places.

- As a vacuum for vacuuming up dry foliage. The machine also serves as a shredder in suction mode.

The dry leaves are shredded, their volume reduced and prepared for possible composting. The intensity of the shredding depends on the size of the leaves and the residual moisture they contain. Any use other than that which is described above can damage the machine and thus pose a risk to the user.

⚠ WARNING! When working with the machine, take care not to knock it against hard objects that could cause damage. Do not vacuum up solid objects such as stones, branches or branch cuttings, fir cones or similar, as these could damage the machine, especially the shredding unit. Repairs of this kind are not covered by the warranty.

Overload protection

The motor switches off automatically in the event of an overload.

Notes

- NOTICE! The machine is only ready for operation again once it has cooled down completely.

Procedure

- Switch off the machine.

- Pull out the mains plug.

- Then check whether there is a blockage in the impeller or clogging in the collection bag and remove this (Removing obstructions and blockages, p. 40).

Blowing mode

(Fig. A)

⚠ WARNING! For safety reasons, make sure that the protective cover (8) on the suction opening is closed.

• For best results with the blower, maintain a distance of 5 - 10 cm from the ground.
• Direct the flow of air away from you. Be careful not to catch any heavy objects in

the jet of air which could cause injuries or damage.

• Start work with the highest blowing power to quickly collect the leaves lying around. Select a lower blowing power to compact the previously collected pile of leaves.
• Before blowing, use a broom or rake to loosen any leaves stuck to the ground.
• Hold the machine by the handle (4) or by the handle (4) and T-handle (2) when working.

Suction mode

(Fig. B)

⚠ WARNING! For safety reasons, both suction pipe sections and the collection bag must be correctly mounted before you can start the machine.

• Always hold the machine tight with both hands during operation: Use the handle (4) and the auxiliary handle (11) for this.
• Make sure that not too many leaves are sucked in at the same time. This prevents the suction pipe (17) from clogging and blocking the impeller.

Emptying the collection bag

Notes

• NOTICE! The suction capacity is significantly reduced when the collection bag is full.
• NOTICE! Compostable material does not belong in household waste!

Procedure

Empty the collection bag (15) when it is full or when the suction power of the machine decreases.

1. Turn off the machine and wait until the impeller has stopped.
2. Disconnect the power cord (7).
3. Remove the carabiner (16) from the eye-lets (20).
4. Remove the collection bag (Fitting and removing the collection bag, p. 38).
5. Open the zip on the collection bag.
6. Empty the collection bag completely.
7. Refit the emptied collection bag.

Transport

Information on transporting the machine:

- Switch off the device and disconnect the plug from the power outlet. Make

sure that all moving parts have come to a complete stop.

- Carry the machine with two hands. Use the handle (4) and T-handle (2) or the handle and auxiliary handle (11).

Cleaning, maintenance and storage

⚠ WARNING! Electric shock! Risk of injury due to unintentional start-up. Protect yourself when performing maintenance or cleaning work. Switch off the device and disconnect the mains plug from the socket.

You should have any repair and maintenance work that is not described in these instructions carried out by our Service Centre. Only use original replacement parts.

Cleaning

⚠ WARNING! Electric shock! Never spray down the device with water.

NOTICE! Risk of damage. Chemical substances may attack the plastic parts of the machine. Do not use any cleaning agents or solvents.

• Keep the ventilation slits, motor housing and handles of the machine clean. Use a damp cloth or brush to do this.
• Clean the collection bag (15) using a brush and, if needed, compressed air.

Maintenance

• Check the device before each use for obvious defects such as loose, worn or damaged parts.
• Check the covers and protective devices for damage and correct fit. Replace these if necessary.

Removing obstructions and blockages

Leaves and fresh plant cuttings may obstruct the machine.

Notes

• WARNING! Risk of injury! Pull out the mains plug!
• NOTICE! If the protective cover (8) and/or the suction pipe (17) is not correctly screwed into place by hand, it is not possible to operate the machine.

Cleaning the impeller:

1. Open the protective cover (8) or remove the suction pipe (17).

2. Carefully remove debris or obstructions from the impeller.

3. Check that the impeller rotates easily and is in perfect condition.

Replace a defective impeller at our service centre.

1. Close the protective cover (8) or screw the suction pipe (17) back into place.

Storage

Always store the device and accessories:

• clean
• dry
  • protected against dust
  • out of the reach of children
• You can remove the blow pipe (10) or the suction pipe (17) and the collection bag (15) from the motor housing (1) for storage (see Attaching and removing the blower pipe, p. 38 or Attaching and removing the suction pipe, p. 38).

Disposal/environmental protection

The device, accessories and packaging should be properly recycled.

Troubleshooting

The following table will assist you in fixing faults:

Problem Possible Cause Remedy
Device does not start	No mains power supply Check	the socket, mains connection cable, plug and fuse and have them repaired by a qualified electrician if necessary.
	On/Off switch (5) is broken Contact the service centre.
	Defective motor Contact the service centre.
terrptions	Internal loose contact Contact	the service centre.Device works with in
	On/Off switch (5) is broken Contact the service centre.
Impeller does not move	Foreign body blocking the impeller	Removing obstructions and blockages, p. 40

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

The symbol of the crossed-out wheeled bin means that this product must not be disposed of as unsorted municipal waste at the end of its useful life.

Directive 2012/19/EU on waste electrical and electronic equipment:

Consumers are legally obliged to recycle electrical and electronic equipment in an environmentally sound manner at the end of its life. In this way, environmentally friendly and resource-saving recycling is ensured. Depending on the implementation in national law, you may have the following options:

• Return to a shop,
• Hand over to an official collection point,
• Return to the manufacturer/distributor.
  This does not affect accessories enclosed with the old devices or tools without any electrical components.
• Feed clippings to composting and do not throw them into the refuse bin.

Problem Possible Cause Remedy
Low work output	Collection bag (15) is full Emptying the collection bag (15)
	Collection bag (15) is dirty Cleaning the collection bag (15)
	Impeller or blowpipe (10) and/or suction pipe (17) is clogged or blocked	Removing obstructions and blockages, p. 40

Service

Guarantee

Dear Customer,

This product is provided with a 3 year guarantee from the date of purchase. In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.

Terms of Guarantee

The guarantee period begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase. If a material or manufacturing defect occurs within three years of the date of purchase of this product, we will repair or replace – at our choice – the product for you free of charge. This guarantee requires the defective product and proof of purchase to be presented within the three-year period with a brief written description of what constitutes the defect and when it occurred. If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The product has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery.

The guarantee applies for all material and manufacturing defects. This guarantee does

not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts (e.g. Collection bag, Blower pipe, Suction pipe) or to cover damage to breakable parts (e.g. switch).

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.

The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improper handling, use of force, or interventions not undertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure efficient handling of your query, please follow the directions below:

- Please have the receipt and product number (IAN 479064_2410) ready as proof of purchase for all enquiries.

- Please refer for the product number to the type plate on the product, an engraving on the product, the title page of the operating instructions (bottom left) or the sticker on the back or underside of the product.

- Should functional errors or other defects occur, please initially contact the service centre specified below by telephone or use the contact form available on parkside-diy.com in the category Service.

- After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid ac-

ceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the appliance inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

PDF ONLINE parkside-diy.com

You can view and download these and many other manuals on parkside-diy.com. This QR code will take you directly to parkside-diy.com. Select your country and search for the operating instructions via the search mask. You can open your operating instructions by entering the article number (IAN) 479064_2410.

Repair service

For repairs that are not covered by warranty, contact the service centre. They will gladly create a cost estimate for you.

• We can only work on devices which are sent in properly packed and with postage paid.

Note: Please send your device cleaned and with an indication of the defect to the address named for the service centre.

• The following are not accepted: devices sent in without prepaid postage, sent as bulky goods, sent as an Express shipment, or devices sent as any other form of special freight.
  • We will dispose of defective devices you ship to us free of charge.

Service Centre

GB Service Great Britain Tel.: [phone] Contact form on parkside-diy.com IAN 479064_2410

MT Service Malta Tel.: [phone] Contact form on parkside-diy.com IAN 479064_2410

Importer

Please note that the address below is not a service address. Contact the service centre named above first.

Spare parts and accessories

You can get spare parts and accessories from www.grizzlytools.shop. If you have any problems with your order, contact us via our online shop. If you have any other questions, contact: Service Centre, p. 43

Pos. nr. Name Order No.

10 Blower pipe (two-part) 91102301

11 Auxiliary handle 91105381

13 Carrying strap 91102298

15 Collection bag 91105379

17 Suction pipe (two-part) 91105385

Translation of the original EU declaration of conformity

Product: Electric Leaf Blower & Vacuum

Model: PELSB 3000 A1

Serial number: 000001-057000

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

2006/42/EC • 2014/30/EU • 2000/14/EC & 2005/88/EC • 2011/65/EU & (EU) 2015/863

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

To ensure conformity, the following harmonised standards and national standards and regulations have been applied:

EN 60335-1:2012/A15:2021 • EN 50636-2-100:2014

EN 62233:2008 • EN IEC 55014-1:2021 • EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A1:2021 • EN 61000-3-3:2013/A2:2021

EN IEC 63000:2018

In accordance with the Directive 2000/14/EC relating to noise emission, the following is confirmed: Sound power level (L WA)

- Measured: 97.8 dB/100.4 dB;

- Guaranteed: 103 dB

Followed conformity assessment procedure according to 2000/14/EC, Annex V.

This declaration of conformity is issued under the sole responsibility of the manufacturer:

Authorised representative of documentation

Sommaire

Introduction...... 45

Garantie (France)....64

Service-Center....66

Importateur.... 66

Service-Center....86

Importeur.... 86

Service-Center....107

Importador.... 107

Service-Center....128

Importatore.... 128

Ricambi e accessori.... 128

Service-Center....147

Dovozce....147

Service-Center....166

Importér.... 166

QR code image with a central logo, likely linking to a digital resource or website.

PDF ONLINE
parkside-diy.com

Service-Center....227

Importør...... 227

FSC www.fsc.org MIX Paper | Supporting responsible forestry FSC® C164682
