USER MANUAL SMSP 500 A1 SILVERCREST

For EU market: Imported for GB market by:

HOYER Handel GmbH Lidl Great Britain Ltd

Kühnehöfe 12 Lidl House · 14 Kingston Road

22761 Hamburg Surbiton · KT5 9NU

GERMANY

Stand der Informationen · Status of information · Version des information

GB Operating instructions

MILK FROTHER

1. Overview 17
2. Intended purpose 18
3. Safety information 18
4. Items supplied 21
5. How to use 21
6. Operation 22

6.1 Preparation tips 22
6.2 The programs 22
6.3 Starting the preparation.... 23
6.4 Boil-dry protection / overheating protection.... 23

1. Cleaning 24
2. Storage 24
3. Disposal 25
4. Trouble-shooting 25
5. Technical specifications 26
6. Warranty of the HOYER Handel GmbH 27

1. Overview

1 Lid
2 Sealing ring
3 Whisk
4 Handle
5 Pot
6 Drive axle
7 Operating panel
8 Power cable with mains plug
9 Base with cable spool
10 Marker line: minimum filling volume (75 ml)
11 Marker line: maximum filling volume (150 ml) for programs 1/2/4
12 Marker line: maximum filling volume (300 ml) for program 3
13 Spout
14 Program 1: warm and firm milk froth
15 Program 2: warm and creamy milk froth
16 Button: selecting a program / Switching off
17 Ring with control lights
18 Program 3: heat milk with a little milk froth
19 Program 4: cold frothing
20 Cable spool

Thank you for your trust!

Congratulations on your new milk frother.

For safe handling of the device and in order to get to know the entire range of features:

• Read these operating instructions thoroughly prior to initial use.
• Above all, observe the safety information!
• The device should only be used as described in these operating instructions.
• Keep this copy of the operating instructions for reference.
• If you pass the device on to someone else, please include this copy of the operating instructions. The operating instructions are a part of the product.

We hope you enjoy your new milk frother!

Symbols on the device

The food-safe material of devices with this symbol will not change the taste or smell of food.

Parts of the device marked with this symbol must not be cleaned in the dishwasher.

2. Intended purpose

The milk frother is intended exclusively for frothing (warm or cold) or heating milk. The device is designed for private, domestic use. The device must only be used indoors. This device must not be used for commercial purposes.

Foreseeable misuse

WARNING! Risk of material damage!

• Always operate the milk frother with the whisk 3, otherwise the milk may burn.
• Never fill the pot 5 with liquids other than fresh, cool milk!

3. Safety information

Warnings

If necessary, the following warnings are used in these operating instructions:

DANGER! High risk: failure to observe this warning may result in injury to life and limb.

WARNING! Moderate risk: failure to observe this warning may result in injury or serious material damage.

CAUTION: low risk: ignoring this warning may result in minor injuries or damage to property.

NOTE: circumstances and specifics that must be observed when handling the device.

Instructions for safe operation

- This device can be used by children from the age of 8 and people with restricted physical, sensory or intellectual abilities or a lack of experience or knowledge if they are supervised or have been instructed in how to use this device safely and if they have understood the resulting dangers.

- Children must not play with the device.

- Cleaning and user maintenance must not be carried out by children unless they are 8 years or older and supervised.

- Children under the age of 8 must be kept away from the device and the power cable.

- Misuse may result in injuries.

The pot, the device base, the power cable and the mains plug must not be immersed in water or other liquids.

- This device is equally intended for use in the home and in applications similar to the home, such as for example...

... in kitchens for staff in shops, offices and other commercial settings;

... on agricultural properties;

... by customers in hotels, motels and other residential facilities; ... in bed-and-breakfast establishments.

- This device is not intended to be operated using an external timer or a separate remote control system.

- Fill the device only up to the maximum filling level MAX, as hot milk froth may otherwise spray out.

- Use the milk frother only with the supplied device base.

- Liquid must never overflow onto the device plug connections of the device.

- Remember that the surface of the heating element remains hot after use.

- The device must be disconnected from the mains if left unattended and prior to assembly, disassembly or cleaning.

- If the power cable of this device should become damaged, it must be replaced by the manufacturer, the manufacturer's customer service department or a similarly qualified specialist in order to avoid any hazards.

- Please take note of the chapter on cleaning (see "Cleaning" on page 24).

DANGER for children!

- Packing materials are not children's toys. Children should not be allowed to play with the plastic bags: there is a risk of suffocation.

DANGER to and from pets and livestock!

Electrical devices can represent a danger to pets and livestock. In addition, animals can also cause damage to the device. For this reason you should keep animals away from electrical devices at all times.

DANGER! Risk of electric shock due to moisture!

- Protect the device from moisture, water drops and water splashes: failure to observe this instruction may result in an electric shock hazard. - If liquid gets into the device base, immediately pull out the mains plug. Have the device checked before reusing.

DANGER! Risk of electric shock!

• Do not use the device if the device or the power cable has any visible damage, or if the device base has previously been dropped.
• Only connect the mains plug to a properly installed and easily accessible wall socket with earthing contact whose voltage corresponds to the specifications on the rating plate. The wall socket must still be easily accessible after the device is plugged in.

• Ensure that the power cable cannot be damaged by sharp edges or hot spots. Do not wrap the power cable around the device.

• Even after it has been switched off, the device is not completely disconnected from the power supply. In order to fully disconnect it, pull out the mains plug.

• When using the device, ensure that the power cable cannot be trapped or crushed.
• When removing the mains plug from the wall socket, always pull on the plug and never the cable.
• Pull the mains plug out of the wall socket:
• when a malfunction occurs
• when you are not using the milk frother
• before cleaning the milk frother
• during thunderstorms
• In order to avoid any hazards, do not make modifications to the device.

DANGER! Risk of injury through scalding!

• Operate the milk frother only with the lid on, as otherwise hot milk froth may spray out.
• The milk frother becomes hot during operation. Touch it only using the handle.

WARNING! Risk of material damage!

- The device is fitted with non-slip silicon feet. Because furniture can be coated with a wide variety of varnishes and plastics, and treated with various care products, the possibility cannot be excluded that some of these substances have components that may attack and soften the silicon feet. If necessary, place a non-slip mat under the device.

- Fill the device at least up to above the marker line MIN 10 with 75 ml of milk, as the milk may otherwise burn and the device may overheat.

• Never fill the milk frother with liquids other than cool fresh milk!
• Allow the device to cool down for approx. 3 minutes before using it again.
  To prevent the milk from burning and overheating, never use the device without the whisk in place.
• Place the device on a stable, level surface.
• Do not use any astringent or abrasive cleaning agents.

4. Items supplied

1 lid 1
1whisk3
1 pot 5
1 base 9 with power cable 8
1 complete copy of the operating instructions (on the Internet)
1 copy of the short manual (enclosed with the device)

5. How to use

DANGER! Risk of electric shock!

• Only connect the mains plug 8 to a properly installed and easily accessible wall socket with earthing contact whose voltage corresponds to the specifications on the rating plate. The wall socket must still be easily accessible after the device is plugged in.

• Pull the mains plug 8 out from the wall socket after every use.

• Remove all packing material.

• Check to ensure that all parts are present and undamaged.
• Clean the device prior to its first use! (see "Cleaning" on page 24)
• Place the whisk 3 on the drive axle 6.
• If necessary, unwind the power cable 8 completely and feed it through the recess in the base 9.
• Place the device on a dry, level, non-slip surface.

6. Operation

6.1 Preparation tips

The quality of the milk froth depends heavily on the milk used and can vary.

• Only use cow's milk. Other types of milk are difficult to froth or cause the pot 5 to overflow.
• Cool milk with a fat content of 3.5% or 1.5% is particularly suitable for frothing. Warm milk and skimmed milk do not froth so well.
• Do not try to froth the same milk a second time, as it will no longer froth and may burn.
• Leave the milk froth to stand for a while after preparation. This can improve the consistency and milk that is still liquid can collect at the bottom of the pot 5.

6.2 The programs

WARNING! Risk of material damage!

• Fill the device with at least 75 ml of milk above the marker line MNO, as the milk may otherwise burn and the device may overheat.
• Make sure you use the whisk 3 also for program 3 to prevent the milk from burning and overheating!

Figure A: there are 4 programs available for preparation.

Symbol	Program	Selecting a program	Marker line
	Program 1Warm and thick milk froth(red control light)	Press 1x	up to mb
	Program 2Warm and creamy milk froth(red control light)	Press 2x	up to mb
	Program 3Hot milk with minimum froth (red control light)	Press 3x	up to mb
	Program 4Cold milk froth(white control light)	Press 4x	up to mb

6.3 Starting the preparation

DANGER! Risk of injury through scalding!

- Always operate the milk frother with the lid 1 on, otherwise hot milk froth may spray out!

WARNING! Risk of material damage!

• Fill the device with at least 75 ml of milk above the marker line MIN 10, as the milk may otherwise burn and the device may overheat.
• Allow the device to cool down for approx. 3 minutes before using it again.
• If you remove the milk froth other than by pouring it out, take care not to scratch the non-stick coating on the inside of the pot 5.

• Never fill the pot 5 with liquids other than fresh, cool milk!

• Remove the pot 5 from the base 9.

• Add the maximum amount of milk according to the program selected.
• Close the pot 5 with the lid 1.
• Place the pot 5 on the base 9.
• Press the button ⏻ 16 once or repeatedly to select the desired program.
• A control light on the ring 17 flashes at the corresponding symbol.
• After a short time, the program starts and the control light is lit continuously.
• The program stops automatically after preparation and the control light flashes. Wait until the control light switches off before removing the lid.

NOTES:

• To interrupt a program, press the button ⏻ 16 or lift the pot 5 from the base 9.
• Put the milk froth on the coffee using a silicone spatula, for example. This leaves the rest of the milk that has not been frothed in the pot 5.

6.4 Boil-dry protection / overheating protection

Boil-dry protection

If the device is switched on without milk or with too little milk, it will switch off automatically after a certain time. The 3 red control lights are lit continuously and the device does not start.

- Allow the device to cool down. If necessary, pour out the hot milk and pour in at least 75 ml of cold milk above the marker line MIN 10.

Overheating protection

If the device is operated several times in succession without allowing it to cool down in between, it will switch off automatically after some time. The 3 red control lights are lit continuously and the device does not start.

- Allow the device to cool down for at least 5 minutes.

7. Cleaning

DANGER! Risk of electric shock!

• Pull the mains plug 8 out of the wall socket before you clean the milk frother.
• The pot 5, the base 9, the power cable and the mains plug 8 must not be immersed in water or other liquids.

DANGER! Risk of injury through scalding!

- The inside of the pot 5 becomes hot during operation. Allow the pot 5 to cool down before cleaning.

WARNING! Risk of material damage!

- Do not use any astringent or abrasive cleaning agents.

First cleaning / Thorough cleaning

NOTE: if, for example, the spiral becomes detached from the plastic connector when removing the whisk 3, simply press it back together (plug-in connection).

1. Remove the whisk 3 from the pot 5. Clean the lid 1, the whisk 3 and the inside of the pot 5 by hand with warm water and detergent. Wipe the inside of the pot with a soft cloth. Rinse thoroughly with clean water and dry the parts.
2. Only wipe the base 9 with a slightly damp cloth.
3. Clean the outside of the pot 5 with a damp cloth. You can also use a little detergent. Wipe with a clean cloth with clear water.
4. Allow all parts to dry thoroughly before assembling them.

Cleaning after each use

Clean the inside of the pot 5 after each use when it has cooled down.

1. Leave the whisk 3 assembled in the pot 5. Fill with water and a little detergent up to the marker line MAXI (150 ml).
2. Start program 1 and let it run for approx. 10 seconds.
3. Remove the pot 5 from the base 9 and pour out the water.
4. Rinse with clear water.

8. Storage

DANGER for children!

- Keep the device out of the reach of children.

• Allow the device to cool down and clean it before putting it away.
  • Figure B: wind the power cable 8 in the bottom of the base 9 in the direction of the arrow in the cable spool 20.

9. Disposal

This product is subject to the provisions of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this symbol. Products identified with this symbol may not be discarded with normal household waste, but must be taken to a collection point for recycling electric and electronic appliances.

This recycling symbol marks e.g. an object or parts of the material as valuable for recycling. Recycling helps to reduce the consumption of raw materials and protect the environment.

Packaging

When disposing of the packaging, make sure you comply with the environmental regulations applicable in your country.

10. Trouble-shooting

If your device fails to function as required, please try this checklist first. Perhaps there is only a minor problem, and you can solve it yourself.

DANGER! Risk of electric shock!

- Do not attempt to repair the device yourself under any circumstances.

Fault	Possible causes / actions
No function	Has the device been connected to the power supply?Check the connection.
3 red control lights are lit and the device does not start	Too little or no milk in the pot 5? Allow the device to cool down. Pour out hot milk if necessary, and pour in at least 75 ml of cold milk above the marker line MIN 10 .
	Device in continuous operation without a cool-down period? Allow the device to cool down for at least 5 minutes.

11. Technical specifications

Model: SMSP 500 A1
Mains voltage:	220 – 240 V ~ 50/60 Hz
Protection class:	I
Power rating: 500 W
Milk filling volumeWarming up:Frothing:	min. 75 ml – max. 300 mlmin. 75 ml – max. 150 ml

NOTE: no action by the user is required to switch the product between 50 and 60 Hz. The product adjusts itself for both 50 and 60 Hz.

Symbols used

	Geprüfte Sicherheit (certified safety): devices must comply with the generally acknowledged rules of technology and the German Product Safety Act (Produkt-sicherheitsgesetz - ProdSG). (Not for UK)
	With the CE marking, HOYER Handel GmbH declares the conformity with EU guidelines.
	This symbol reminds you to dispose of the packaging in an environmentally friendly manner.
PAP	Recyclable materials are marked with the recycling symbol (3 arrows). The material can be specified by the recycling number in the centre (here: 21) and/or an abbreviation (here: PAP).
~	AC voltage
	It is a recyclable product which is subject to an extended producer responsibility and for which the rules of waste separation apply.
	With the UKCA marking, HOYER Handel GmbH declares that the product is in conformity with the UKCA requirements.
	The symbol identifies the product manufacturer.

Subject to technical modifications.

12. Warranty of the HOYER Handel GmbH

Dear Customer,

your device is provided with a 3 year warranty starting with the purchase date. In the event of product defects, you are entitled to statutory rights against the vendor. These statutory rights are not restricted by our warranty presented in the following.

Warranty conditions

The warranty period starts with the purchase date. Please keep the original purchase receipt in a safe place. This document is required to verify the purchase.

If within three years from the purchase date of this product a material or factory defect occurs, the product will be repaired or replaced by us – at our discretion – free of charge to you, or the purchase price will be refunded. This warranty implies that within the period of three years the defective device and the purchase receipt are presented, including a brief written description of the defect and the time it occurred.

If the defect is covered by our warranty, the repaired or a new product will be returned to you. No new warranty period starts with a repair or replacement of the product.

Warranty period and statutory claims for defects

The warranty period is not extended when the warranty has been claimed. This also applies to replaced and repaired parts. Any damages and defects already existing at the time of purchase must be reported immediately upon unpacking. Repairs arising after the expiration of the warranty period are subject to a charge.

Warranty coverage

The device was produced carefully according to strict quality guidelines and tested diligently prior to delivery. The warranty applies to material or factory defects.

Excluded from the warranty are wear parts subject to normal wear and damages to fragile parts, e.g. switches, lamps or other parts manufactured from glass.

This warranty expires if the product is damaged, not used as intended or not serviced. For the proper operation of the product, all instructions listed in the operating instructions must be observed carefully. Any form of use and handling that is advised against in the operating instructions or warned against must always be avoided.

The product is only intended for private and not for commercial use. In the case of incorrect and improper treatment, use of force and interventions not performed by our authorised Service Centre, the warranty shall cease.

Handling in case of a warranty claim

In order to ensure prompt processing of your matter, please observe the following notes:

- Please keep the article number IAN: 482036_2410 and the purchase receipt as a purchase verification for all inquiries.

- The article number can be found on the rating plate, an engraving, the title page of your instructions (in the bottom left), or as a label on the rear or underside of the device.

- If faulty operation or other defects occur, first contact the Service Centre listed in the following by telephone or email.

- Then, you are able to send a product reported as defective free of charge to the service address specified to you, including the purchase receipt and the information on the defect and when it occurred.

At www.lidl-service.com you can download this and many other manuals, product videos and installation software.

PDF ONLINE www.lidl-service.com

This QR code takes you directly to the Lidl Service website (www.lidl-service.com), where you can enter the article number (IAN)

482036_2410 to open your user instructions.

Service Centre

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

MT Service Malta

Tel.: [phone]

E-Mail: [e-mail]

CY Service Cyprus

Tel.: [phone]

E-Mail: [e-mail]

IAN: 482036_2410

Supplier

Please note that the following address is no service address. First contact the aforementioned Service Centre.

HOYER Handel GmbH

Kühnehöfe 12

22761 Hamburg

GERMANY

Sommaire
