DCG20BKNE - Coffee grinder CUISINART - Free user manual and instructions

Product type	Electric coffee grinder
Brand	Cuisinart
Model	DCG20BKNE
Bowl capacity	Approximately 120 g of coffee beans
Bowl material	Stainless steel
Blade material	Stainless steel
Power	160 W
Power supply	220-240 V, 50/60 Hz
Dimensions (L x W x H)	Approximately 12 x 12 x 20 cm
Weight	Approximately 0.8 kg
Cord length	Approximately 60 cm
Main function	Pulse grinding (hold On/Off button)
Grind types	Coarse (10 s), medium (20 s), fine (30 s)
Safety device	Prevents operation without lid
Noise level	Approximately 80 dB
Care of bowl and lid	Wipe with a damp cloth; lid dishwasher safe (top rack)
Care of base	Do not immerse, wipe with a damp cloth
Repairability	Not repairable; no spare parts available
Warranty (France)	3 years upon presentation of proof of purchase
Included accessories	None
Intended use	Grinding roasted coffee beans only
Measurement indicator	Graduated marks on lid
Color	Black

Frequently Asked Questions - DCG20BKNE CUISINART

How to use the Cuisinart DCG20BKNE coffee grinder?

Plug in the appliance, remove the lid, fill the bowl with roasted coffee beans (do not exceed the top of the bowl), replace the lid, then press and hold the On/Off button until the desired grind is achieved. Release to stop.

What is the maximum capacity of the bowl?

It is recommended not to fill beyond the top of the stainless steel bowl, which is approximately 120 g of coffee beans.

What types of coffee can be ground?

This grinder is designed only for roasted coffee beans. Do not use it to grind nuts, spices, or unroasted beans, as this may dull the blade and cause poor grinding or injury.

How to clean the coffee grinder?

Make sure the appliance is unplugged. Wipe the inside of the stainless steel bowl and lid with a damp paper towel, then dry completely. The lid can be washed in hot water or on the top rack of the dishwasher. Never immerse the base in water.

Does the grinder work without the lid?

No, a safety device prevents the appliance from operating if the lid is not properly in place.

What is the grinding time for coarse, medium, or fine grind?

For a coarse grind (ideal for a French press), grind for about 10 seconds. For a medium grind (automatic drip), about 20 seconds. For a fine grind (espresso), about 30 seconds. These times are approximate and may vary according to your preferences.

Can the grinder be used continuously?

It is not recommended to operate the appliance continuously for more than 40 seconds per use to avoid overheating.

How to store the power cord?

Excess cord can be stored by pressing one section at a time into the cord storage space at the base of the appliance.

What to do if the appliance does not work?

Check that the lid is properly in place (safety), that the appliance is plugged in and the outlet works. If the problem persists, contact Cuisinart consumer service. The appliance is not user-repairable.

What is the warranty of the Cuisinart DCG20BKNE grinder?

In France, the appliance has a 3-year warranty from the date of purchase, upon presentation of the receipt or invoice. It covers manufacturing defects, provided the appliance has been used in accordance with the instructions.

USER MANUAL DCG20BKNE CUISINART

Black Cuisinart portable kitchen appliance with lid and base (no visible text or symbols on body)

COFFEE GRINDER

DCG20BKNE

Q186a

Cuisinart®

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the following:

1. Read all instructions.
2. THIS IS AN ATTENDED APPLIANCE. Do not leave unattended during use, unplug after each use.
3. To protect against risk of electrical shock, do not immerse cord, plug or grinder in water or other liquid.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety. Close supervision is necessary when any appliance is used by or near children. Children should be supervised to ensure that they do not play with the appliance.
5. Unplug from outlet when not in use, before assembling or dissembling parts and before cleaning. To unplug, grasp the plug and pull from the outlet. Never pull from the power cord.
6. Avoid contact with moving parts.
7. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Contact the manufacturer at their customer service telephone number for information on examination, repair, or adjustment.
8. The use of attachments not recommended or sold by Cuisinart may cause fire, electrical shock, or risk of injury.
9. Do not use outdoors.
10. Do not let cord hand over edge of table or counter, or touch hot surfaces.
11. Check hopper for presence of foreign objects before using.
12. Use this appliance to grind roasted coffee beans only. Grinding other substances, such as nuts, spices or unroasted beans may dull the blade and cause poor grinding or injury.
13. Do not operate your appliance in an garage or under a wall cabinet. When storing in a garage always unplug the unit from the electrical outlet. Not doing so could create a risk of fire, especially if the appliance touches the walls of the garage or the door touches the unit as it closes.

14. This appliance is for indoor, domestic use only and is not intended to be used in applications such as:

15. staff kitchen areas in shops, offices and other working environments;

16. farm houses;
17. by customers in hotels, motels and other residential type environments;

18. bed and breakfast type establishments.

19. Periodically check all parts before assembly. If any part is damaged DO NOT USE.

20. Keep hands, spatulas and other utensils away from moving blades whilst the appliance is in operation.

21. Make sure the motor has completely stopped before removing the lid.
22. Always ensure the blades and bowl have been thoroughly cleaned after each use and have dried completely before storing.
23. To protect against fire, electric shock or personal injury, do not immerse the cord, plug or housing base in water or other liquids or place in a dishwasher.

SAVE THESE INSTRUCTIONS

OPERATING INSTRUCTIONS

1. Plug cord into outlet.
2. Remove lid from base of grinder.
3. Fill stainless steel bowl with desired quantity of beans (see measurement suggestions on reverse.) For best results, do not fill beans above the top of the stainless steel bowl.
4. Place the lid onto grinder base.
5. Press and hold On/Off button to begin grinding. Please note: A safety feature of this grinder requires that the grinder will not operate unless the lid is in place.
6. Grind until beans are ground to desired consistency (see grinding suggestions on reverse.) To stop grinding, release pressure from On/Off button.
7. Remove plug from outlet.
8. Measure ground coffee into coffeemaker filter using scoop (not included), tablespoon or lid measurement markings. See measurement suggestions on reverse.

GRINDING SUGGESTIONS:

Some general guidelines for grinding are listed below. However, times will vary depending upon the amount and type of coffee used and your personal preference. The best way to determine how coarse or fine to grind your coffee is to experiment with different grinds and coffee types to suit your taste.

Set up to 40 seconds for one single use. Do not to run the unit continuously.

GRIND TIME	SUGGESTED USE	GRIND
Coarse	Percolator/French Press	10 Seconds
Medium	Automatic Drip	20 Seconds
Fine	Espresso	30 Seconds

1. On/Off Button
2. Lid
3. Stainless Steel Blades
4. Measurement Markings
5. Stainless Steel Bowl
6. Grinder Base

7. Cord Storage

MEASUREMENT SUGGESTIONS:

For the richest coffee flavour, we suggest using one and one-half (1½) round-ed tablespoons of ground coffee for every 150ml of water.

The measurement markings on the lid indicate reference measurements.

For example, for automatic drip coffee, if you fill the lid to the .... marking with whole beans, you will have enough ground coffee to reach the .. marking.

Note: These markings are approximate. Experiment with different quantities to determine what works best for you.

CLEANING, STORAGE AND MAINTENANCE INSTRUCTIONS

1. Be sure that grinder plug has been removed from outlet.
2. Wipe inside of stainless steel bowl and lid with damp paper towel. Dry completely.
3. If desired, lid may be washed in warm water or in the top rack of a dishwasher. Never immerse the grinder base unit in water or other liquid.
4. Store excess cord by pressing a section at a time into the cord storage area in the base of the unit.
5. Maintenance: Any other servicing should be preformed by an authorised service representative.

PRÉCAUTIONS IMPORTANTES

grof French Press 10 seconden

FÖRVARING OCH SKÖTSEL

- bed and breakfast-lignende etablissementer.

ENGLISH : CUISINART guarantees easier contact with its customer services in every country. For details of the customer services in your area, call:

Empty rounded rectangle with three horizontal dashed lines inside (no text or symbols)

[e-mail]

Cuisinart offers you a 3-year warranty. We offer a standard exchange of the appliance (identical or equivalent) during this period. To benefit from the warranty, the original proof of purchase (sales ticket or receipt) must be attached to this warranty slip along with your full contact details. The warranty does not cover damage resulting from misuse, falls, dismantling, or repair by unauthorized persons. This guarantee in no way affects your rights under statutory law.
