USER MANUAL PHD 170 D2 PARKSIDE

Black industrial water heater with coiled hose and wheels (no visible text or symbols)

PDF ONLINE parkside-diy.com

Hochdruckreiniger / Pressure Washer / Nettoyeur haute pression PHD 170 D2

DE AT CH

Hochdruckreiniger

Translation of the original instructions

NL BE

Hogedrukreiniger

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

Technical diagram of a power<|im_start|> Puerto Rico air purifier with numbered parts and labeled components

Inhaltsverzeichnis

Einleitung......4

Introduction......26

Proper use....26

Scope of delivery/accessories....27

Description of functions...... 27

Overview.... 27

Technical data.... 28

Safety information...... 28

Meaning of the safety information.... 29

Pictograms and symbols......29

Safe initial start-up of the device....30

Preparation....34

Control elements......34

Setting up the device.... 34

Establishing a water supply...... 34

Select the attachment.... 36

Fitting and removing attachments.... 36

Operation......36

Cleaning using cleaning agent.... 36

Switching on....37

Interrupting the operation......38

Bleeding.... 38

Ending the operation....38

Transport.... 38

Cleaning, maintenance and storage....38

Cleaning.... 39

Maintenance....39

Storage....39

Troubleshooting......40

Disposal/environmental protection....41

Service....42

Guarantee....42

Repair service....43

Service Centre......44

Importer......44

Spare parts and accessories......44

Translation of the original EU declaration of conformity....45

Introduction

Congratulations on purchasing your new pressure washer (hereafter referred to as device or power tool). You have chosen a high-quality device. This device was quality-tested and subjected to a final inspection during production, therefore ensuring proper functioning of your device. In some cases, residual amounts of water may be present on or in the device or in hose lines. This is not a flaw or a defect and is no cause for concern.

The instruction manual forms part of this device. It contains important information on safety, use and disposal. Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Use the device only as described and for the stated fields of application. Store the instruction manual carefully and ensure that all documents are handed over in the event that the device is passed on to another user.

Proper use

This device is only intended for the following use:

- Cleaning machines, vehicles, buildings, tools, facades, terraces, garden equipment etc. with a high-pressure water jet.

Always follow the manufacturer's instructions for the object being cleaned.

Any other use that is not expressly permitted in this instruction manual may pose a serious hazard to the user and result in damage to the device. The operator or user of the machine is responsible for any accidents or personal injury and/or material damage to third parties or their property. The machine is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use. The warranty is void in the case of commercial use. The manufacturer is not liable for damage caused by improper use or incorrect operation.

Scope of delivery/accessories

Unpack the device and check that everything is present.

Dispose of the packaging material properly.

• Pressure Washer
• Trigger gun
• Lance
  • High-pressure hose
• Cleaning agent tank (pre-assembled)
  • Standard vario-nozzle
• Turbo dirt blaster
• Rotating washing brush
  • Cleaning agent URM 500 (500 ml)
• Coupling (Water connection), Filter insert
• Quick connector with garden hose adaptor
• Nozzle cleaning needle
  • Translation of the original instructions

Small parts/Accessories are stored in a sealed paper bag.

Description of functions

The pressure washer cleans using a high-pressure water jet. If necessary, it can also be operated with additional cleaning agents.

Please refer to the descriptions below for information on how the operating elements work.

Overview

The illustrations for the device can be found on the front fold-out page.

1 Lance
2 U-handle
3 Release (U-handle)
4 On/Off switch
5 Nozzle cleaning needle
6 Trigger gun
7 Holder (Turbo dirt blaster)
8 Pressure indicator
9 Holder (Trigger gun)
10 Rotating washing brush
11 High-pressure hose
12 Hose reel with crank handle
13 Holder (Accessories)
14 Holder (Power cord)
15 Power cord
16 Sealing cap with suction hose
17 Cleaning agent tank
18 Wheels
19 Coupling (Water connection)
20 Filter insert
21 Water connection
22 Standard vario-nozzle
23 Guide for high-pressure hose
24 Switch lever
25 Child safety lock
26 Release (High-pressure hose)
27 Articulated joint
28 Release button

29 Turbo dirt blaster

30 Cleaning agent

31 Quick connector with garden hose adaptor

Technical data

Pressure Washer ...... PHD 170 D2

Rated voltage U .....230 V \~; 50 Hz

Rated output P .....2400 W

Length Power cord ....5 m

Protection class

.....回 II (double insulation)

Protection type ......IPX5

Weight 11.4 kg

Length of high-pressure hose .... 10 m

Operating pressure (ρ) ..... 11,5 MPa

Max. permissible pressure ( p_max )

17 MPa

Max. inlet pressure ( p_in;max ) ...0.8 MPa

Max. inlet temperature ( T_in;max ) ..40 °C

Rated flow rate (Q) .. 330 l/h (5,5 l/min)

Max. rated flow rate ( Q_max )

500 l/h (8,3 l/min)

Max. suction height ....0.5 m

Sound pressure level ( L_pA )

80.8 dB; K_pA=3 dB

Sound power level ( L_WA )

- Measured .....94.0 dB; K_WA =2.32 dB

– Guaranteed 96 dB

Vibration (a_h) .... <2.5 m/s^2

Information on the power supply

This device is only intended for operation in premises having a service current capacity of at least 100 A per phase at the transfer point (house connection). The user must ensure that the device is only operated on a suitable supply network. If necessary, clarify with the responsible power supplier whether the operating current capacity is sufficient for the device.

Levels of noise and vibration were determined according to the standards and regulations in the declaration of conformity.

The specified total vibration value and the stated noise emission value have been measured according to a standardised test method and can be used to compare one power tool with another. The specified total vibration value and the stated specified noise emission value can also be used for a provisional assessment of the load.

WARNING! The vibration and noise emissions may deviate from the specified values during actual use of the power tool, depending on how the power tool is being used. Try to keep the exposure to vibrations as low as possible. An example of a measure to reduce vibration exposure is limiting the working hours. All parts of the operating cycle have to be considered while doing so (for example, times when the power tool is switched off and times when it is switched on but running without any load).

Safety information

CAUTION! The following basic safety precautions must be observed while using electrical devices to protect against electric shock, injury and risk of fire.

Meaning of the safety information

▲ DANGER! If you do not observe this safety instruction, an accident will occur. The result of which is severe bodily injury or death.

⚠ WARNING! If you do not observe this safety instruction, an accident may occur. The result of which is likely severe bodily injury or death.

▲ CAUTION! If you do not observe this safety instruction, an accident will occur. The result of which is likely minor or moderate bodily injury.

NOTICE! If you do not observe this safety instruction, an accident will occur. The result of which is possible damage to property.

Pictograms and symbols Symbols on the device

Attention!

Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly.

Attention! If the cable gets damaged during use, it must be disconnected from the supply network immediately. This also includes connecting to the water supply or trying to eliminate leaks.

According to current regulations, the pressure washer must never be connected to the drinking water network without a system separator. A suitable system separator must be used in accordance with EN 12729 Type BA.

Protection class II (double insulation)

Guaranteed sound power level L_WA in dB.

This device is only intended for operation in premises having a service current capacity of at least 100 A per phase at the interface point.

Nozzle cleaning needle

Operate the device vertically only. Never use horizontally.

High-pressure jets can be dangerous if used incorrectly. The jet must not be directed at persons, animals, active electrical equipment or the device itself.

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

Safe initial start-up of the device

General Information

• Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly.
• The device must not be used by children. Children must be supervised to ensure that they do not play with the device.

The device can be operated by individuals with reduced physical, sensory or mental abilities or a lack of experience and knowledge if they are supervised or have been instructed in the safe use of the device and understand the resulting hazards.

• People who are not familiar with the instruction manual may not use the device.

- Pressure washers may only be operated by instructed persons.

- The machine must not be used at altitudes over 2000 m.

• In the case of a malfunction or defect during operation, the device must be switched off immediately and the mains plug unplugged. For possible causes of a malfunction: Troubleshooting, p. 40. Or, contact our service centre.
• Note that the user is responsible for any accidents or risks to others and their property.
• Observe noise protection rules and other local regulations.

Preparation

• Protect yourself against splashing water or dirt by wearing protective goggles and suitable protective clothing.
• Aerosols may be produced during the use of pressure washers. Inhalation of aerosols may be harmful to health. Depending on the application, the use of fully shielded nozzles (e.g. surface cleaners) can significantly reduce the emission of aqueous aerosols. Depending on the environ-

ment to be cleaned, wear a suitable respirator of class FFP 2 or comparable to protect against the inhalation of aerosols if the use of a fully shielded nozzle is not possible.

- Do not work with a damaged or incomplete device or one which has been converted without the permission of the manufacturer. Before commissioning, have a specialist check that the required electrical protective measures are in place.

• The device may only be connected to a power outlet that has been installed by an experienced electrician in accordance with IEC 60364-1.
• Prior to use, always check the power cord and extension cord for signs of damage or wear and tear. If the cord is damaged during use, it must be disconnected from the supply network immediately. DO NOT TOUCH THE CABLE BE-

FORE IT HAS BEEN DIS- CONNECTED FROM THE POWER SUPPLY. Do not use the device if the cord is damaged or worn.

• If the power cord of this device is damaged, it must be replaced by the manufacturer, their customer service or by a similarly qualified person in order to avoid hazards. contact the service centre.
• Connect the device only to a power outlet with a residual current circuit breaker (FI switch) of rated residual current no more than 30 mA.
• Use only extension cords that are designed for outdoor use. The connection must be dry and routed above the ground. We recommend using a cable drum that holds the power outlet at least 60 mm above the ground.
• Extension cords must have a minimum wire cross section of 2 × 2.5 mm^2 .
  • High-pressure hoses, fittings and couplings

are important for device safety. Only use high-pressure hoses, fittings and couplings recommended by the manufacturer.

• Do not start the device up if the power cord, water supply or other important parts such as the high-pressure hose or spray gun are damaged or leaky.
• Only use the device standing and on a firm, level surface.
• Never use the device if there are children or animals nearby. People nearby must wear protective clothing.

Operation

• Pay attention, be aware of what you are doing and take the utmost care when working with the device. Do not use the device if you are tired or you are under the influence of drugs, alcohol or medication.
• High-pressure jets can be dangerous if used incorrectly. The jet must not

be directed at persons, animals, active electrical equipment or the device itself.

- Do not direct the jet at yourself or others to clean clothing or shoes. - If you come into contact with cleaning agents, rinse them with sufficient clean water.

- Never use the power cord to pull the plug out of the outlet or to pull the device. Protect the power cord from heat, oil and sharp edges.

- Explosion hazard – do not spray flammable liquids.

- Do not use the device near flammable liquids or gases. There is a risk of fire or explosion if this advice is not heeded.

- Never transport the device while the drive is running.

- Switch off the device and disconnect the plug from the power outlet. Make sure that all moving parts have come to a complete stop

- when leaving the device, - before changing the accessories, - before removing obstructions or loosening blockages, - before checking the device, cleaning it or performing maintenance work on it.

- If the device starts to vibrate abnormally, an immediate check is required, :

- search for signs of damage, - replace damaged parts, - contact the service centre.

Cleaning, maintenance and storage

- Allow the motor to cool down before storing the device for a longer period.

- Replace worn or damaged parts in the interests of safety. Use only original spare parts and accessories. Using externally produced parts results in the immedi-

ate loss of any warranty claim.

• The device may only be opened by an authorised electrician. Always contact our service centre for repairs.
• Switch the drive off, disconnect the device from the power supply and allow the device to cool off if you want to clean, adjust, store the device or to exchange an accessory part.
• Handle the device with care and keep it clean.
• Store the device out of reach of children.

Preparation

⚠ WARNING! Risk of injury due to unintentional start-up. Do not insert the plug into the outlet until the device is fully prepared for use.

Control elements

Familiarise yourself with the operating elements before using the device for the first time.

Trigger gun (6)

- Switch lever (24)

• Pulling the switch lever: Activates the pressure jet
• Releasing the switch lever: De-activates the pressure jet

- Child safety lock (25) (Viewed from behind)

← The switch lever is locked 🔒.
→ You can pull the switch lever 🔒.

⚠ WARNING! Risk of injury due to pressure jet! Lock the switch lever every time you take a break.

• Pressure indicator (8)

The more red lines visible, the higher the pressure.

U-handle (2)

With the bow-type handle pulled out, you can conveniently roll the device.

• Pulling out the handle: Pull the curved handle upwards.
• Pulling in the handle: Press the release (3) on the bow-type handle and pull the bow-type handle down.

Setting up the device

1. Place the device horizontally on a level surface.
2. Make sure that the high-pressure hose (11) passes through the guide for the high-pressure hose (23).
3. Insert the high-pressure hose (11) into the high-pressure connection on the trigger gun (6).

Establishing a water supply

You have two options to supply the device with water:

• Household water connection
- Suctioning standing, clean water, e.g. rain barrel

Household water connection

Requirements

• Supply hose: Garden hose with fitted quick connector with garden hose adaptor (31); ∅ 13 mm (½"); length between 5 m and 30 m
  • Minimum pump capacity: 330 l/h (5,5 l/min)

- System separator

A system separator (check valve) prevents the backflow of water and cleaning agent into the drinking water pipeline.

• According to current regulations, a pressure washer must never be connected to the drinking water network without a system separator. A suitable system separator must be used in accordance with EN 12729 Type BA.
• Water that has flowed through a system separator is classified as non-potable.
• System separators are available from specialist dealers.

Procedure

1. Insert the filter insert (20) in the water connection (21).
2. Fit the coupling (19) on the water connection (21).

3. Attach the quick connector with garden hose adaptor (31) to the supply hose.

4. Remove the grooved clamping nut.

5. Push the clamping nut over the end of the hose.
6. Insert the end of the hose into the thread of the quick connector with garden hose adaptor.
7. Fix the quick connector with garden hose adaptor with the clamping nut.

8. Check whether the quick connector with garden hose adaptor is fitted securely to the hose.

9. Connect the supply hose to the water supply.

10. Bleed the supply hose: Open the water supply until the water flows bubble-free out of the other end of

the supply hose. Close the water supply.

1. Connect the quick connector with garden hose adaptor (31) on the supply hose to the coupling (19).

Suctioning water

Requirements

• NOTICE! Contamination from backwashed cleaning agent! Do not draw in any water from natural accumulations.
• Suction hose with filter basket (not included, Spare parts and accessories, p. 44)
• standing, clean water, e.g. rain barrel
  • Max. suction height: 0.5 m

Procedure

⚠ WARNING! Electric shock! The device itself must not be submerged in the water collector.

NOTICE! Damage due to dry running! Ensure there is a sufficient and reliable water supply.

1. Connect the suction hose with filter basket to the coupling (19) on the water connection (21) of the device.
2. Insert the end with the filter basket into the water collector.
3. Remove the lance (1) from the trigger gun (6).
4. Press and hold the switch lever (24).
5. Move the On/Off switch (4) to the position "I" (ON). The device begins to suction water and air can escape.
6. Once the device is free of air, you can release the switch lever.
7. Fit an attachment.

Select the attachment

Standard vario-nozzle (22)

The tip can be rotated.

Control elements

- Vario fan jet (Direction of rotation as seen from behind)

○ Wide fan jet Low pressure for cleaning agent The higher the pres- sure, the less clean- ing agent is sucked in

○ Narrow fan jet High pressure

Turbo dirt blaster (29)

The rotating water jet is suitable for working with low water consumption.

Rotating washing brush (10)

• The rotating washing brush is not generally suitable for sensitive and painted surfaces (e.g. car paint).
• Do not apply any pressure to the rotating washing brush. The cleaning function is produced by the rotational movement and the flow of water.
• The rotating washing brush works in low-pressure operation. The cleaning agent is automatically sucked in.

Adjusting the rotating washing brush

1. Loosen the screw on the articulated joint (27).
2. Adjust the angle of the rotating washing brush (10).
3. Tighten the screw on the articulated joint (27).

Fitting and removing attachments

Fitting the nozzle

1. Fit the lance (1) on the trigger gun (6) (Bayonet locking device: plug and turn).
2. Fit the attachment on the lance (1). The attachment clicks into place.

Removing the nozzle

1. Press and hold the release button (28) on the front end of the lance (1)
2. Pull the attachment off the lance (1).
3. Remove the lance (1) from the trigger gun (6) (Bayonet locking device: push, turn and pull).

Fit the rotating washing brush (10)

1. Remove the lance (1) from the trigger gun (6) (Bayonet locking device: push, turn and pull).
2. Mount the attachment on the trigger gun (6) (Bayonet locking device: plug and turn).

Remove the rotating washing brush (10)

1. Remove the attachment from the trigger gun (6) (Bayonet locking device: push, turn and pull).

Operation

Cleaning using cleaning agent

Requirements for the cleaning agent

• This device has been designed to be used with a neutral cleaning agent based on biodegradable anionic surfactants.
• Use of other cleaning agents or chemicals can negatively impact the safety of the device and can

cause damage. Such damage to the device is not covered by the warranty.

- You can buy cleaning agents from our online shop, Spare parts and accessories, p. 44.

Requirements

- The cleaning agent tank is filled with cleaning agent.

- The tip of the standard vario-nozzle is moved to the front.

Filling and emptying the cleaning agent tank

1. Remove the sealing cap with suction hose (16) from the cleaning agent tank (17).
2. Pull the cleaning agent tank up and then away from the device. The cleaning agent tank is removed and can be filled or emptied.
3. Insert the cleaning agent tank in reverse order.
4. Seal the cleaning agent tank with the sealing cap.
5. Push the suction hose into the cleaning agent tank until it reaches the bottom.

Switching on

⚠ WARNING! A leaky water system can result in electric shock! Move the On/Off switch (4) to the position "0" (OFF). Pull out the plug. Try connecting the water again (see Establishing a water supply, p. 34).

⚠ WARNING! The device may only be used in an upright position! There is a risk of an electric shock if the device falls over. Move the On/Off switch (4) to the position “0” (OFF). Pull out the plug. Only now may you bring the device into the upright position. For your own safety, wait about

five minutes until you restore the electrical connection.

⚠ WARNING! Unsuitable extension cables can be dangerous! Use only extension cables that are designed for outdoor use. The connection must be dry and routed above the ground. We recommend using a cable drum that holds the socket at least 60 mm above the ground.

1. Ensure that the On/Off switch (4) is in the "0" (OFF) position.
2. Put the device in an upright position.
3. Insert the mains plug into an socket with residual current circuitry. The right part of the holder for the mains connection cable (14) as seen from behind is rotatable. This allows you to easily remove the mains connection cable (15).
4. NOTICE! Dry running will damage the device. Do not operate the pressure washer with the tap turned off. Turn the tap on fully.
5. Move the On/Off switch (4) to the position "I" (ON).

The motor switches on briefly un-til the necessary pressure has built up. The motor then stops.

1. WARNING! Be aware of the recoil force when the water jet commences. There is a risk of injuring yourself or other people. Ensure that your footing is secure. Keep a good hold on the trigger gun (6). Press the switch lever (24) on the trigger gun (6).

The nozzle starts working at pressure and the motor starts. If you release the switch lever (24), the motor stops. The high pressure is maintained in the system.

Interrupting the operation

You can insert the trigger gun (6) with lance and nozzle into the holder (9) for the trigger gun.

1. Release the switch lever (24) on the trigger gun (6).

2. If you put down the trigger gun: Lock the switch lever using the child safety lock (25) (seen from behind).

← The switch lever is locked 🔒.

→ You can pull the switch lever 🔒.

⚠ WARNING! Risk of injury due to pressure jet! Lock the switch lever every time you take a break.

1. When taking longer breaks: Move the On/Off switch (4) to the position "0" (OFF).

Bleeding

Bleeding the supply hose

1. Close the tap.

2. Remove the supply hose from the device.

3. For more, see Establishing a water supply, p. 34

Bleeding the device

1. Move the On/Off switch (4) to the position "I" (ON).

2. Wait until pressure has built up and the motor stops.

3. Move the On/Off switch (4) to the position "0" (OFF).

4. Press the switch lever (24) on the trigger gun (6) until the pressure has been released.

5. Repeat these steps several times until there is no more air in the device.

Ending the operation

1. After working with cleaning agents:

- Empty the cleaning agent tank (17).

- Rinse the device with clear water until the lines are free of cleaning agent.

1. Release the switch lever (24).
2. Move the On/Off switch (4) to the position "0" (OFF).
3. Close the tap.
4. Press the switch lever (24) on the trigger gun (6) until the pressure has been released.
5. Pull out the plug. Wind the mains connection cable (15) on the holder (14).
6. Disconnect the device from the water supply.

Transport

How to prepare the device for safe rolling.

• Switch off the device and disconnect the plug from the power outlet. Make sure that all moving parts have come to a complete stop.
• Roll the high-pressure hose (11) around the hose reel (12), and wrap the power cord (15) around the holder (14).
• Pull out the U-handle.

Ask a second person to help you if you wish to carry the device.

Cleaning, maintenance and storage

⚠ WARNING! Electric shock! Risk of injury due to unintentional start-up. Protect yourself when performing maintenance or cleaning work. Switch off the device and disconnect the mains plug from the socket. You should have any repair and maintenance work that is not described in

these instructions carried out by our Service Centre. Only use original replacement parts.

Cleaning

NOTICE! Risk of damage! Improper cleaning can damage the device. Never spray down the device with water. Do not clean the device under running water. Do not use any abrasive cleaning agents or solvents. Always keep the device clean.

Cleaning after operation

1. Move the On/Off switch (4) to the position "0" (OFF).
2. Pull out the plug.
3. Keep the ventilation slits clean and free of objects.
4. Clean the device with a soft brush or a slightly damp cloth.

Cleaning the standard vario-nozzle In rare cases, the standard vario-nozzle may become clogged by foreign bodies.

1. Remove the standard vario-nozzle (22).
2. Remove the foreign body from the front using the nozzle cleaning needle (5).
3. Rinse the standard vario-nozzle with water from the front to remove the foreign body.

Cleaning the filter insert in the water connection

1. Remove the coupling (19) from the water connection (21).
2. Remove the filter insert (20) from the water connection.
3. Clean the filter insert under running water.
4. Fit the filter insert (20) and coupling (19) in reverse order.

Maintenance

The device is maintenance free.

Storage

Notes

Always store the device and accessories:

• clean
• dry
  • protected against dust
  • protected against frost
  • out of the reach of children

Preparing the device for storage

NOTICE! The pressure washer and accessories will be destroyed by frost if they are not completely emptied of water.

1. Completely empty the water from the device.

2. Disconnect the device from the water supply.

3. Turn on the pressure washer with the On/Off switch (4) for a maximum of 1 minute.
4. Press the switch lever (24) on the trigger gun (6) until there is no more water coming out of the trigger gun (6) or the attachments.

5. Turn off the device.

6. Completely empty the water from the accessories.

7. Store all attachments upright in the holders with the connection facing downwards.

8. Roll the high-pressure hose around the hose reel (12).

9. Store the mains connection cable in the holder (14) provided.

Troubleshooting

The following table will assist you in fixing faults:

Problem Possible cause	Error correction
Machine does not start	On/Off switch (4) turned off	Check the position of the On/Off switch
	No mains power supply Check	check the socket, mains connection cable, plug and fuse and have them repaired by a qualified electrician if necessary.
	Incorrect voltage supply Check	check whether the electrical system matches the information on the type plate
Device does not convey water	Air locks in the pressure washer	Turn the device on and press the switch lever (24).
		Bleeding, p. 38
	Air locks in the pressure washer	Bleeding, p. 38No pressure in device
	Pressure loss in line Check	the water supply

Problem Possible cause	Error correction
Water system leaky	Connections not correctly installed	Turn off the device and disconnect it from the mains. Reconnect the device to the water supply (see Establishing a water supply, p. 34)
	Water connection (21) leaky	Turn off the device and disconnect it from the mains. Change the coupling (19) on the water connection (21) including sealing ring (see Spare parts and accessories, p. 44)
Strong pressure fluctuations	standard vario-nozzle (22) is dirty	Rinse the standard vario-nozzle (22) with water. If required, clean the nozzle bore hole with a nozzle cleaning needle (5; see Cleaning, p. 39).
	standard vario-nozzle (22) clogged	Remove the standard vario-nozzle (22) and ensure that the water can discharge from the trigger gun (6) unimpeded.

Disposal/ environmental protection

The device, accessories and packaging should be properly recycled.

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

The symbol of the crossed-out wheeled bin means that this product must not be disposed of as unsorted municipal waste at the end of its useful life.

Directive 2012/19/EU on waste electrical and electronic equipment:

Consumers are legally obliged to recycle electrical and electronic equipment in an environmentally sound manner at the end of its life. In this way, environmentally friendly and resource-saving recycling is ensured. Depending on the implementation in national law, you may have the following options:

• Return to a shop,
• Hand over to an official collection point,
• Return to the manufacturer/distributor.

This does not affect accessories enclosed with the old devices or tools without any electrical components.

Cleaning agent bottle disposal

- Product residues must be disposed of in compliance with the Waste Directive 2008/98/EC as well as national and regional requirements. For this product, no disposal code in accordance with the European Waste Catalogue (AVV) can be identified, as the use and therefore the code is determined by the consumer. Within the EU, the disposal code must be determined in consultation with the disposal contractor.

• Non-contaminated packaging can be recycled.
• Packaging that cannot be cleaned must be disposed of in the same way as the material.

Service

Guarantee

Dear Customer,

This product is provided with a 3 year guarantee from the date of purchase. In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.

Terms of Guarantee

The guarantee period begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase. If a material or manufacturing defect occurs within three years of the date of purchase of this product, we will repair or replace – at our choice – the product for you free of charge. This guarantee requires the defective product and proof of purchase to be presented within the three-year period with a brief written description of what constitutes the defect and when it occurred.

If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The product has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery.

The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts (e.g. High-pressure hose) or to cover damage to breakable parts (e.g. switch).

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.

The product is designed only for private and not commercial use.

The guarantee will be invalidated in case of misuse or improper handling, use of force, or interventions not un-

dertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure efficient handling of your query, please follow the directions below:

- Please have the receipt and product number (IAN 466665_2404) ready as proof of purchase for all enquiries.

- Please refer for the product number to the type plate on the product, an engraving on the product, the title page of the operating instructions (bottom left) or the sticker on the back or underside of the product.

- Should functional errors or other defects occur, please initially contact the service centre specified below by telephone or use the contact form available on parkside-diy.com in the category Service.

- After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the appliance inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

PDF ONLINE parkside-diy.com

You can view and download these and many other manuals on parkside-diy.com. This QR code will take you directly to parkside-diy.com. Select your country and search for the operating instructions via the search mask. You can open your operating instructions by entering the article number (IAN) 466665_2404.

Repair service

For repairs that are not covered by warranty, contact the service centre. They will gladly create a cost estimate for you.

• We can only work on devices which are sent in properly packed and with postage paid.

Note: Please send your device cleaned and with an indication of the defect to the address named for the service centre.

- The following are not accepted: devices sent in without prepaid postage, sent as bulky goods, sent as an Express shipment, or devices sent as any other form of special freight.

• We will dispose of defective devices you ship to us free of charge.

Service Centre

Service Great Britain

Tel.: [phone]

Contact form on

parkside-diy.com

IAN 466665_2404

Service Malta

Tel.: [phone]

Contact form on

parkside-diy.com

IAN 466665_2404

Importer

Please note that the address below is not a service address. Contact the service centre named above first.

Spare parts and accessories

You can get spare parts and accessories from www.grizzlytools.shop. If you have any problems with your order, contact us via our online shop. If you have any other questions, contact the Service Centre, p. 44

Pos. nr. Name Order No.

1 Lance 91110565
2 U-handle 91110567
5 Nozzle cleaning needle 91110572
6 Trigger gun 91110566
10 Rotating washing brush 91110568
11 High-pressure hose (10 m, black) 91110569
12 Hose reel with crank handle (without High-pressure hose)	91105900
17 Cleaning agent tank 91105898
18 Wheels 91105897
19 , 20 Coupling (Water connection), Filter insert 91106182
22 Standard vario-nozzle	91105895
29 Turbo dirt blaster	91105894
30 Cleaning agent URM 500 (500 ml)	30990010
31 Quick connector with garden hose adaptor	91097401
— Suction hose with filter basket	91103738

Translation of the original EU declaration of conformity

Product: Pressure Washer

Model: PHD 170 D2

Serial number: 000001-257000

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

2006/42/EC • 2014/30/EU • 2000/14/EC & 2005/88/EC

• 2011/65/EU & (EU) 2015/863

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

To ensure conformity, the following harmonised standards and national standards and regulations have been applied:

EN 60335-1:2012/A15:2021 • EN 60335-2-79:2012 • EN 62233:2008

EN IEC 55014-1:2021 • EN IEC 55014-2:2021 • EN IEC 63000:2018

EN IEC 61000-3-2:2019/A1:2021 • EN IEC 61000-3-11:2019

In accordance with the Directive 2000/14/EC relating to noise emission, the following is confirmed: Sound power level ( L_WA )

- Measured: 94.0 dB;

– Guaranteed: 96 dB

Followed conformity assessment procedure according to 2000/14/EC, Annex V.

This declaration of conformity is issued under the sole responsibility of the manufacturer:

Authorised representative of documentation

Sommaire

Introduction......46

Garantie (France)......66

- gemeten .....94,0 dB; K_WA=2,32 dB

- medido .....94,0 dB; K_WA=2,32 dB

- garantizado 96 dB

Vibración ( a_h ) ....<2,5 m/s ^2

- misurato: 94,0 dB;

- garantito: 96 dB

- mért ......94,0 dB; K_WA=2,32 dB

Reparationsservice......232

Service-Center 233

Importør......233

FSC® www.fsc.org MIX Paper from responsible sources FSC® C142184

FSC www.fsc.org MIXTE Papier issu de sources responsables FSC® C142184
