Product type	Hot water dispenser
Brand	Royal Catering
Model	RCWK 16A
Nominal voltage	230 V ~ ±10%
Frequency	50 Hz
Nominal power	2200 W
Tank capacity (max level)	16 L
Total tank capacity	17.4 L
Temperature range	55 - 100 °C
Weight	3.75 kg
Tank material	Stainless steel
Heating indicator	BOIL indicator (orange)
Keep warm indicator	KEEP WARM indicator (green)
Overheat protection	Overheat sensor with automatic shut-off
Dispensing tap	Yes, with lever
Removable lid	Yes, with handle
Functions	Heat and keep warm water, wine or beer
Electrical connection	Grounded outlet required
Certification	CE
Maintenance	Regular descaling, clean with damp cloth

Frequently Asked Questions - RCWK 16A Royal Catering

How to start the hot water dispenser RCWK 16A?

Before use, check that the thermostat knob is set to OFF. Fill the tank with water up to the MAX mark, close the lid, plug in the appliance, then turn the thermostat to the desired temperature. The BOIL indicator (orange) lights up during heating. When the temperature is reached, the KEEP WARM indicator (green) lights up.

What is the maximum water capacity of the tank?

The maximum filling capacity is 16 liters (MAX level). The total tank capacity is 17.4 liters.

Can I heat wine or beer with this appliance?

Yes, the appliance is designed to heat and keep warm water, wine or beer. Caution: for beer, watch the foam and do not fill the tank completely to avoid overflow.

How to descale the appliance?

Use a standard descaling product for kettles or coffee machines. Fill the tank with the descaling solution according to the product instructions, let it sit, then empty and rinse thoroughly with clean water. Perform this operation regularly to prevent limescale buildup.

What to do if the appliance stops heating?

First check that the thermostat is not set to OFF. If the problem persists, the appliance may have gone into safety mode due to overheating (if the water level is too low). Let it cool down, empty the tank, then tilt the appliance 180° to reset the reset button located underneath the appliance.

What are the important safety instructions?

Never immerse the appliance in water, use it only on a flat and heat-resistant surface, away from children. Unplug it before cleaning. Do not repair it yourself, call a professional. Respect the mains voltage (230 V ~ 50 Hz) and use a grounded outlet.

How to clean the appliance?

Unplug and let cool completely. Clean the exterior with a damp cloth and mild detergent. Never immerse the appliance. Dry thoroughly before reuse. The tank can be rinsed with clean water after descaling.

Why does the BOIL indicator stay on for a long time?

The heating time depends on the amount of water and the set temperature. If the water is very cold or the selected temperature is high (e.g. 100 °C), the heating time is longer. Make sure the lid is closed properly to optimize heating.

The appliance makes noise during heating, is that normal?

Yes, a slight heating or boiling noise is normal when water heats up. If the noise is excessive, check the water level (do not exceed MAX) and descale if necessary.

Where to find the serial number of the appliance?

The serial number and production year are on the rating plate attached to the appliance. Keep this information for any after-sales service requests.

USER MANUAL RCWK 16A Royal Catering

Product name: Water bolt
Model: RCWK 10A | RCWK 16A | RCWK 20A | RCWK 26A | RCWK 30A
Manufacturer name: expendo Porsio sp. z o.o. sp. ic
Manufacturer address: ul.Delorovaya, 3-65-155 Zelenj Gort | Poland, EU

expondo.de

SYMBOLS

Operation manual must be read carefully.

Never dispose of electrical equipment together with household waste.

This machine conforms to CE declarations.

Caution! Contact with hot surfaces may cause burns.

Drawings in this manual are for illustration purposes only and in some details may differ from the actual machine. The original operation manual is in German. Other language versions are translations from German.

USERMANUAL

SAFETY INSTRUCTIONS

To avoid injury from fire or electric shock, please ensure compliance with safety instructions when using this device. Please read the instructions carefully and make sure that you have understood them well. Keep the manual near the equipment to be able to read it at any time. Always use current sources connected to the ground and providing the necessary voltage (indicated on the label on the device). If you have any doubt, let an electrician check that your outlet is properly grounded. Never use a damaged power cable. Do not open the unit in damp or wet environment, or if your hands or body are damp or wet. Protect the unit from solar radiation. Use the device in a protected location to avoid damaging the equipment or endangering others. Make sure the device is able to cool and avoid placing it too close to other devices that produce heat. Before cleaning, disconnect it from the power source. Use a soft damp cloth for cleaning. Avoid using detergents and make sure that no liquid enters the unit. No internal element of this device needs to be maintained by the user. Opening the device without our approval leads to a loss of warranty.

SAFETY GUIDELINES

1. Please read these instructions carefully and understand them before operating the device! Please observe the safety guidelines carefully in order to prevent damages through improper use!
2. Please keep this manual available for future reference. If this device is passed on to third parties, the manual must be passed on with it.
3. Only use this device indoors and for its intended use.
4. We do not offer any warranty for damages resulting from improper use or incorrect operation.
5. Check before first use whether main voltage type and current comply with the indicated data on the type plate.
6. This device is not intended to be used by persons (including children) with limited physical, sensory or mental aptitude or lack of experience and/or knowledge, unless they are supervised by a person responsible for their safety or have received instruction from this person as to how the device is used.
7. ELECTRICAL SHOCK HAZARD! Do not attempt to repair the unit yourself. In case of device failures, repairs must be done by qualified experts.
8. Please check main plug and power cable regularly. If the power cable for this device is damaged, it has to be replaced by the manufacturer or its customer service or another qualified person in order to prevent hazards.

Rev.14.03.2017

1. Prevent damages to the power cable by avoiding squeezing or bending it or rubbing it on sharp edges. Also keep the power cable away from hot surfaces and open flames.
2. ATTENTION: DANGER TO LIFE! While cleaning, never immerse the device in water or other liquids.
3. Under no circumstances open the housing.
4. The drinks that are warmed up by the device can get very hot. Take appropriate precautions.
5. Clean the device regularly so that dirt cannot settle permanently.

TECHNICAL DATA

Product name	Water boiler
Model RCWK 10A RCWK 16A	RCWK 20A	RCWK 26A	RCWK 30A
Rated voltage [V] / Frequency [Hz]	230~V±10% / 50Hz
Rated power [W] 1600 2200 2200	200	2500	2500
Heating temperature (°C)	55-100	55-100	55-100	55-100	55-100
Tank's capacity (up to the maximum level)(l)	10	16	20	24,5	26
Total tank's capacity (l)	11,5	17,4	21,4	27,1	30
Weight (kg)	2,7	3,75	3,6	3,95	4,5

SCOPE OF APPLICATION

The boiler is designed for water boiling and heating as well as for preparing alcoholic beverages (eg. Milled wine / beer).

Do not use the device to:

• cook soups or other drinks;

warm or heat flammable, noxious, particularly volatile, or any other toxic substances.

WARNING: Pay special attention to the foam production during the preparation of mulled beer - beer level in the tank should be controlled (the tank should not be fully filled with beer).

The user is liable for any damage resulting from non-intended use of the device!

BEFORE FIRST USE

Upon receipt of the goods, check the packaging for integrity and open it. If the packaging is damaged, please contact your transport company and distributor within 3 days, and document the damages as detailed as possible. Do not turn the package upside down! When transporting the package, please ensure that it is kept horizontal and stable.

DISPOSING OF PACKAGING

Please keep all packaging materials (cardboard, plastic tapes and Styrofoam), so that in case of a problem, the device can be sent back to the service centre in accurate condition

INSTALLING THE APPLIANCE

The temperature of environment should not exceed 45^ and the relative humidity should be less than 85% . Ensure good ventilation in the room in which the device is used. The distance between the back of the water boiler and the wall should be at least 20~cm , minimum distance between the sides of the device and the walls should be at least 10~cm on each side and 35~cm between the top of the device and the ceiling. Keep the device away from hot surfaces. Operate the device on flat, stable, clean, refractory and dry surfaces out of the reach of children and people with mental disabilities. Install the device making sure that constant access to the main plug is ensured. The power cable connected to the device must be properly grounded and should correspond to the technical details. Before the first use, remove all elements and clean them along with the entire device.

1. lid
2. lid handle
3. water tank handle
4. water tank
5. power cord
6. "KEEP WARM" indicator (water is kept warm at the present temperature)
7. "BOIL" indicator (water is being heated)
8. device base and reset button:

1. thermostat knob - temperature setting

1	55°C
2	65°C
3	80°C
4	90°C
5	100°C
HIGH	100°C

1. base with drip tray

2. drain cap

Before switching the device to the power supply, make sure that the thermostat knob is switched off, this means, in the "OFF" position. Make sure that the drain cap is closed (it should be at the maximum on the right or left side). Fill the tank with water. Make sure that the maximum water level in the tank stays at or below the "MAX" mark, which can be found on the inner wall of the tank. Cover the tank with the lid and turn the lid clockwise until it is closed. Then insert the power cord into power outlet and set the thermostat as desired.

When water is being heated an orange indicator lamp ("BOLL") is on. As water temperature reaches the pre-set value, the orange indicator lamp goes off and a green indicator lamp ("KEEP WARM") goes on. When the temperature of water in the tank drops, the thermostat goes on automatically and water is re-heated to the pre-set temperature (the green indicator lamp goes off and the orange one goes on). To drain water from the tank, put an appropriate utensil on the drip tray (like a glass or a cup) and turn the tap to the left or right. When the utensil is filled with the desired amount of water, turn the tap again to the left or right.

When the device is not used, switch it off; this means, turn the thermostat to the "OFF" position. To drain water remaining in the tank wait until it has cooled down. Make sure to check the water level when the device is in operation - top up with fresh water when necessary. Please note! Risk of burns! Proceed with extreme caution.

Please note! The device features an overheating detector. It will activate when water evaporates or when water level is below the allowable level and the device is still on. If this happens a protection will trip and switch the device off. In such cases wait until the device cools down then drain water from the tank, turn the device 180^ (upside down) and press the reset button (marked as "Reset button"). Now the device can be used again.

Please note! When the thermostat knob is set in the "HIGH" position, the device will work continuously (water will boil all the time)! This device is not designed for continuous operation!

Assembly / disassembly of the device's elements:

Assemble all device components before turning it on. To attach the drip tray to the device place the drip tray strainer in the base and fix the base on the two fasteners.

TRANSPORTATION AND STORAGE

During transport, the machine should be protected from shaking and falling and not turned on its head. Store it in a properly ventilated place with dry air and without any corrosive gas.

CLEANING AND MAINTENANCE

Always unplug the device when cleaning it and after each use.
Use a cleaner without corrosive substances to clean surface.
Dry all parts well after cleaning before the device is used again.
- Store the device in a dry, cool location, free from moisture and direct exposure to sunlight.

SCALE REMOVAL

When hard water is used, scale may build up in the water tank. These deposits may extend the time necessary to heat water in the tank and lead to damage of the device. To avoid deposits in the tank use filtered water. Remove scale from the tank on a regular basis using commercially available products designed to remove scale from kettles, coffee machines etc.

REGULAR CONTROL OF THE DEVICE

Check regularly to see if any elements of the device are damaged. If it should be damaged, please stop using the device immediately and contact your customer service to solve the problem. What to do in case of a problem?

Please contact your customer service and prepare the following information:
- Invoice number and serial number (the latter is to be found on the technical plate on the device).
If relevant, a picture of the damaged, broken or defective part.
- It will be easier for your customer service clerk to determine the source of the problem if you give a detailed and precise description of the matter. Avoid ambiguous formulations like "the device does not heat up", which may mean either that it does not heat enough or that it does not heat at all. The more detailed your information, the better the customer service will be able to solve your problem rapidly and efficiently!

CAUTION: Never open the device without the authorization of your customer service. This can lead to a loss of warranty!

INSTRUKCJA

WARNIK DO WODY

RCWK 16A

RCWK 20A

RCWK 26A

RCWK 30A

Manufacturer name:
expo do Polska sp. z o.o.

Manufacturer address:

EN We hereby certify that the appliances listed in this manual are CE compliant.

For the disposal of the device please consider and act according to the national and local rules and regulations.

CONTACT

expondo Polska sp. z o.o. sp. k.

ul. Dekoracyjna 3

65-155 Zielona Góra | Poland, EU

e-mail: [e-mail]
