USER MANUAL MD 19899 MEDION

Modern coffee maker with digital display and glass jar, no visible text or symbols on the device itself.

Coff ee machine with grinder

MEDION MD 19899

Inhaltsverzeichnis

DE

Labeled diagram of a kitchen blender with numbered parts for identification

QR code image containing encoded data, no visible human-readable text

Labeled diagram of a kitchen blender with numbered parts for identification

QR code image containing encoded data, no visible human-readable text

Labeled diagram of a kitchen blender with numbered parts for identification

QR code image containing encoded data, no visible human-readable text

Labeled diagram of a kitchen blender with numbered parts for identification

QR code image containing encoded data, no visible human-readable text

Labeled diagram of a kitchen blender with numbered parts for identification

QR code image containing encoded data, no visible human-readable text

1. Information about this user manual ....107
   1.1. Explanation of symbols ......107 FR
2. Proper use 107
3. Safety instructions N108
   3.1. General information 108
   3.2. Setting up the appliance.... 110 ES
   3.3. Using the appliance 110
4. Package contents ......111
5. Appliance overview 112
6. Before first use 114
   6.1. Rinsing process....114
   6.2. Setting the time .....114
7. Operating the coffee machine 114
   7.1. Brewing process with coffee beans....115
   7.2. Brewing process with coffee powder 116
   7.3. Drip stop function....116
   7.4. End of the brewing process....116
   7.5. Using the timer....117
8. Tips for tasty coffee 117
9. Cleaning and descaling the appliance....118
   9.1. Allowing the grinder to run empty .....118
   9.2. Descaling the appliance ....119
10. Troubleshooting 120
11. Storing/transporting 120
12. Disposal....121
13. Technical specifications.... 121
14. EU declaration of conformity 121
15. Service information....122
16. Legal Notice....122
    EN

1. Information about this user manual

Thank you for choosing our product. We hope you enjoy using this appli-ance.

Read the safety instructions carefully before using the appliance for the first time. Note the warnings on the appliance and in the user manual.

Always keep the user manual close to hand. If you sell the appliance or give it away, please ensure that you also pass on this user manual. It is an essential component of the product.

1.1. Explanation of symbols

If a block of text is marked with one of the warning symbols listed below, the hazard described in that text must be avoided to prevent the potential consequences described there from occurring.

DANGER!

Warning: risk of fatal injury!

WARNING!

Warning: risk of possible fatal injury and/or serious irreversible injuries!

WARNING!

Warning: risk of electric shock!

WARNING!

Warning: danger due to hot surfaces!

WARNING!

Warning of risk of injury due to moving parts!

CAUTION!

Warning: risk of minor and/or moderate injuries!

NOTICE!

Follow these instructions to prevent damage to the appliance!

More detailed information about using the appliance!

Follow the instructions in the user manual!

2. Proper use

The appliance is suitable both for making coffee and for grinding coffee beans.

This appliance is designed for use in private households and similar household applications, such as

– in kitchens for staff in retail outlets, offices and other commercial areas
– on agricultural estates
– by customers in hotels, motels and other accommodation facilities
– in bed-and-breakfast establishments.

Please note that we shall not be liable in cases of improper use:

▶ Do not modify the appliance without our consent and do not use any auxiliary equipment that we have not approved or supplied.
▶ Only use replacement parts or accessories that we have supplied or approved.
▶ Comply with all the information in this user manual, especially the safety instructions. Any other use is considered improper and can cause personal injury or property damage.

3. Safety instructions

• Keep the appliance and its accessories out of the reach of children.
  ■ This appliance may be used

by children over the age of 8 and by persons with reduced physical, sensory or mental abilities or by those with limited experience and/or knowledge, provided that they are supervised or have been instructed in the safe use of the appliance and have understood the associated risks.

■ Children must not be allowed to play with the appliance.
■ Cleaning and user maintenance must not be carried out by children, unless they are aged 8 or over and are supervised.
■ Children younger than 8 should be kept away from the appliance and the connection cable.
- Keep all packaging materials used (bag, pieces of polystyrene etc.) out of the reach of children.

■ Never leave the appliance unattended during operation.

3.1. General information

WARNING!

Risk of electric shock/

short circuit!

There is a risk of electric shock/short circuit from live parts.

■ Only connect the appliance to a properly installed and easily accessible socket that is close to where you are using the appliance. The local mains voltage must correspond to the technical specifications for the appliance.
■ The power socket must be easily accessible so you can unplug the appliance from the mains quickly if necessary.
■ Always hold the plug to pull it out and never pull the cable.
■ Do not allow the mains cable to come into contact with hot objects or surfaces (e.g. cooker hob).
■ Check the appliance and the mains cable for damage before using the appliance for

the first time and after each use.

■ Do not use if the appliance or the mains cable is visibly damaged or if the appliance has been dropped.
■ Contact our Service team without delay if the appliance has been damaged during transport.
■ Do not, under any circumstances, make any unauthorised modifications to the appliance or try to open and/or repair a component yourself.
If there is damage to the mains connection cable on this appliance, it must be replaced by the manufacturer, its customer service department or another suitably qualified person. This is necessary to avoid hazards.
■ Never open the housing or slide objects into the ventilation slots.
■ Completely unwind the mains cable.
■ Do not kink or crush the mains cable.

■ Unplug the appliance from DE the socket:

• when you are cleaning or maintaining the appliance
• when you are assembling or disassembling the appliance
• if the appliance is damp or wet
• if you are no longer using the appliance
• when the appliance is un- attended
  – during thunderstorms.

■ The appliance must not be submerged in water or other liquids, nor exposed to running water or used in damp environments, as this may result in an electric shock.
■ Do not let the appliance come into contact with water or other liquids. Keep the appliance, the mains cable and the mains plug away from wash basins, sinks or similar.
■ Do not place any objects filled with liquid (e.g. vases or drinks) on or near the appliance.
■ Do not operate the appliance on wet surfaces.

■ Never touch the appliance or the mains cable/mains plug with damp or wet hands.
■ Use the appliance indoors only.
■ Do not expose the appliance to extreme conditions. Avoid:

– high humidity or wet conditions
- extremely high or low temperatures
- direct sunlight
- naked flames.

3.2. Setting up the appliance

■ Place the appliance on a stable, level surface.
- Never place the appliance on the edge of a table – it could tip over and fall.
■ Do not allow the mains cable to hang over the edge of the worktop.
■ Ensure that the mains cable does not become a tripping hazard and do not use an extension cord.

Chemical additives in furniture coatings may corrode the material of the appliance feet and cause residue on the furniture surface.

■ If necessary, place the appliance on an underlay that is insensitive to heat and water.

WARNING! Risk of fire!

The appliance will become hot during operation. Flammable items in the immediate vicinity of the appliance could catch fire.

■ Do not position the appliance over a hotplate or other heat-generating appliances (grill, deep fat fryer); this applies even if an extraction fan is installed above it.

■ Leave a little space between this appliance and other appliances or the wall to allow air to circulate freely.
■ Do not cover the appliance during operation.
■ Never operate the appliance underneath or in the vicinity of highly flammable items such as curtains, drapes, paper etc.

3.3. Using the appliance

■ Do not operate the appliance with an external timer or a separate remote control system.

■ Never reach into the grinder when the filter compartment is open or the appliance is running.
■ Switch off the power soc and pull out the mains plug after each use, before cleaning and maintenance and during periods when the appliance is left unattended.
■ Please note the special instructions for cleaning and descaling the appliance (see "9. Cleaning and descaling the appliance" on page 118).

4. Package contents

DANGER!

Risk of choking and suffocation!

Packaging film can be swallowed or used properly, creating a risk of choking and suffocation.

• Keep all packaging materials used (film, plastic bags, bags, pieces of polystyrene, etc.) out of the reach of children.
  ■ Do not allow children to play with the packaging material.

Please check your purchase to ensure that all items are included and in perfect condition. If anything is missing or damaged, contact us within 14 days of purchase.

The following items are supplied with your product:

• Coffee machine
• Filter holder
• Permanent filter
• Glass jug with lid
• Measuring spoon
• Short manual

5. Appliance overview

Labeled diagram of a kitchen blender with numbered parts for identification

Fig. 1 – Parts overview

1. Lid of the bean container
2. Grinder setting dial
3. Bean container
4. Hinged lid of water container
5. Control panel/display panel
6. Water level indicator
7. Button to open the filter compartment
8. Hot plate
9. Glass jug
10. Filter holder
11. Drip protection
12. Filter
13. Permanent filter

The type plate is on the bottom of the appliance, not shown.

Fig. 2 - Control panel

1. ☐ button: timer function (start coffee machine at a predefined time)
2. Digital display
3. symbol: timer function switched on
4. button: adjust the required amount of coffee/number of cups during grinding
5. symbol: coffee is brewed
6. ⏻ button: set minutes
7. ⏻ button: set hours
8. ⏻ button: turn on the coffee machine/start the brewing process
9. 🔍 🔍 🔍 symbol: coffee strength
10. 📞 button: set coffee strength
11. Ⓥ button: turn the grinder on and off

6. Before fi rst use

▶ Remove all packaging materials.
Before first use, rinse the glass jug (9), the permanent filter (13) and the filter (12) thoroughly.
Connect the coffee machine to a socket.

6.1. Rinsing process

Clean the coffee machine by running three brewing processes using only tap water, without coffee or disposable or permanent filters (13):

Press the button to switch on the coffee machine.
▶ Press the button to switch off the grinder.
▶ Press the button to start the brewing process.
For hygienic reasons, throw away the water after the rinsing process.

6.2. Sett ing the time

After first connecting to the power supply, the time flashes in the display panel (12:00).

▶ Press the ⏻ (hours) and ⏱ (minutes) buttons to set the time.

As soon as one of the two has been pressed, the time display stops flashing and the time is set.

7. Operating the coffee machine

CAUTION!

Risk of injury!

There is a risk of scalding due to hot surfaces and rising steam.

■ Steam rises during the coffee-making process. Do not reach into the steam.
■ The appliance housing will become hot during operation. Therefore, during operation, only touch the handles provided for this purpose.
If the water container lid is opened during the brewing process, scalding may occur.

NOTICE!

Risk of damage to the appliance!

Material damage due to improper use

■ Only pour cold drinking water into the water container.
■ Do not add any other liquids except water to the water container (except when descaling: see Page 119).
■ Do not pour liquids other than water or coffee into the glass jug.
■ Do not leave any unused water in the water container. Immediately remove any remaining water in order to avoid the formation of limescale or algae.
■ Do not use permanent filters and paper filters at the same time.

▶ Open the lid of the water container and use the scale on the water container to fill the container with the required amount of cold water for the desired number of cups.

Due to evaporation of water during the boiling process, the water level indicator of the water container does not match the water level indicator of the glass jug (9). Only use the water level indicator on the water container for filling.

Fill the water container only according to the amount of coffee you need, as all the water you add will be used for preparing the coffee.

Remove the glass jug (9) from the coffee machine and press the button to open the filter compartment (7).
Place the filter (12) with the recess into the filter holder (10). The filter can only be inserted into the filter holder in one direction.
Insert a paper coffee filter (size 1x4) or the supplied permanent filter (13) into the filter (12). Make sure that the paper coffee filter is correctly placed in the filter.
▶ Fold the paper filter at the seams if necessary.
▶ Close the filter compartment again.
Place the glass jug (9) in the centre of the hot plate (8) and make sure that the drip protection valve (11) on the filter (12) is pushed upwards.

7.1. Brewing process with coff ee beans

▶ Open the lid of the bean container.

Place the coffee beans (approx. 200 g) into the bean container and then put the lid back on.

Do not put too many beans in the bean container to prevent the beans from becoming damp. Therefore, do not stuff in the beans.

▶ Press the button to switch on the coffee machine.

▶ Turn the GRINDER SETTING dial (2) to set the grind level (turn left: fine, turn right: coarse).

TIP: Set a fine grind for a light roast; a coarse grind is optimal for a dark roast. The type of roast is usually mentioned on the coffee packaging.

▶ Set the amount of coffee needed for the number of cups (2, 4, 6, 8, 10 or 12 cups) by repeatedly pressing the 📋 button. If you do not set the number of cups, the amount of coffee from the previous brewing process will be used.

Press the button repeatedly to set the coffee strength:

• Strong coffee
• Medium-strength coffee
• Ⓞ Mild coffee

▶ Press the button to start the brewing process.

The ⏻ button lights up. The grinder starts and fills the coffee filter with ground coffee powder.

The brewing process then starts. The 🎨 symbol is shown in the display panel.

At the end of the brewing process, the 🤨 display goes out in the display panel and three acoustic signals sound.

7.2. Brewing process with coffee powder

▶ Press the button to switch on the coffee machine.

Press the button to switch off the grinder. The symbol lights up red when the grinder is deactivated.

▶ Add the appropriate amount of coffee powder to the filter. One heaped teaspoon per cup or one level measuring spoon is recommended.

▶ Close the filter compartment again.

▶ Repeatedly press the Ⓜ button to adjust the amount of water used and therefore the coffee strength:

• Strong coffee
• Medium-strength coffee
• Ⓞ Mild coffee

▶ Press the button to start the brewing process.

The ⏻ button lights up. The ⚙ symbol is shown in the display panel and the brewing process starts.

At the end of the brewing process, the 🎨 display goes out in the display panel and three acoustic signals sound.

7.3. Drip stop function

The drip stop function allows you to serve the finished coffee during the brewing process.

Remove the glass jug (9) from the hot plate (8). The flow of coffee from the filter into the glass jug is interrupted, and the coffee is backed up in the filter.
Place the glass jug back under the filter within 30 seconds. Otherwise, there is a risk that the filter will overflow.

The strength of the coffee removed in the middle of the brewing process may differ from the strength of the coffee after the full brewing process.

7.4. End of the brewing process

You can leave the coffee for a while in the glass jug (9) on the hot plate to keep it warm. Note, however, that the flavour decreases the longer it is left standing.

▶ Do not leave an empty glass jug on the hot plate.

The coffee machine switches off automatically after 35 minutes and three acoustic signals sound. The display panel, except for the time, goes out.

▶ Remove the glass jug.

If you want to de-energise the appliance completely, unplug the mains plug from the socket.

7.5. Using the timer

To use the timer, the time must have been set.

▶ Press the button until the time starts flashing.
▶ Use the ⏻ and ⏻ buttons to set a time at which the brewing process should start. A delay time of up to 24 hours can be set.
To turn the timer on, press the button until the time symbol appears in the display panel.

The coffee machine starts the brewing process at the set time.

To turn off the set timer, briefly press the button until the time symbol in the display panel goes out.

8. Tips for tasty coffee

A clean coffee machine is an absolute must for making tasty coffee. Clean the coffee machine regularly as described in section "9. Cleaning and descaling the appliance" on page 118.
▶ Always use fresh, cold water in the coffee machine.
Store unused coffee powder in a cool, dry place. Re-seal opened packets of coffee powder and store them in the fridge to keep them fresh.
For the best-tasting coffee, buy whole coffee beans and grind them just before brewing.
Do not re-use the coffee powder again, as this will severely affect the taste of the coffee. Reheating coffee is not recommended, as the coffee tastes best immediately after brewing.
Clean the coffee machine if it becomes oily due to excessive extraction. Small oil droplets on the surface of the brewed black coffee are due to the extraction of oil from the coffee powder.
▶ Oiliness can occur more frequently when heavily roasted coffee varieties are used.

9. Cleaning and descaling the appliance

DANGER!

Risk of electric shock/short circuit!

There is a risk of electric shock/short circuit from live parts.

■ Remove the plug from the socket before you start cleaning the appliance
■ Never immerse the appliance in water or other liquids.

CAUTION!

Hot surface!

There is a risk of scalding due to hot surfaces and rising steam.

- Allow the appliance to cool down before cleaning.

NOTICE!

Possibility of damage to the appliance!

There is a risk of damage to the appliance if it is used improperly.

■ Never use acidic, abrasive or granular, acetic-acid-, soda- or solvent-based cleaning agents. These may damage the appliance surfaces or the printing on it.
■ Do not clean the coffee machine in the dishwasher.

▶ Wait until the appliance has completely cooled down.

Remove the glass jug (9) from the coffee machine and press the button to open the filter compartment (7).
Remove the used disposable filter or permanent filter (13) using the handle from the filter (12). Hold the filter insert by the handle and remove it from the filter holder (10).
▶ Dispose of the coffee grounds from the permanent filter or the disposable filter with coffee grounds in household waste.
- Rinse the filter insert and the permanent filter under running water.
- Clean the outside of the coffee machine with a damp cloth and, if necessary, a little mild washing-up liquid.
▶ Clean the glass jug (9) by hand with water and some washing-up liquid.

▶ Wipe the hot plate (8) using a damp cloth.

9.1. Allowing the grinder to run empty

If you do not use the coffee machine or store it for a long period of time, the grinder must be emptied, as remaining beans left in the grinder may become mouldy.

Remove the glass jug (9) and filter (12) and make sure the water container is empty.
▶ Tilt the machine so that the remaining beans can fall out of the top of the bean container.
Place the coffee machine back upright and plug in the mains plug.

▶ Open the filter compartment.

WARNING!

Risk of injury!

Rotating parts. There is a risk of injury due to crushing.

■ Never reach into the grinder when the filter compartment is open or the appliance is running.

▶ If necessary, place a small bowl on the hot plate.
▶ Start a brewing process for coffee beans, but without adding water and beans.
As soon as no remaining beans fall down from the grinder, press the ⏻ button to stop the brewing process.

WARNING!

Risk of fire! Risk of damage!

There is a risk of overheating, which may lead to damage to the appliance or to a fire.

- Do not let the brewing process run "dry" for more than 1 minute.

▶ After completing the process, unplug the mains plug.

9.2. Descaling the appliance

Why does the build-up of limescale damage the coffee machine?

If a machine is only rarely descaled, larger deposits can be removed, but they often clog the flow system. We therefore recommend that you descale your coffee machine regularly. Depending on the water hardness and usage behaviour, this may be required every 3-4 weeks. Please note that repair due to the build-up of limescale and the resulting damage are not covered by the warranty.

How can I tell if my filter coffee machine has a build-up of limescale?

• Extended cycle time and reduced amount of coffee in the water filling
• Increased steam generation and noise during the brewing process
• Altered taste

Which descaler should be used for coffee machines?

Household vinegar and mineral-acid-based descalers are not suitable, as they usually do not sufficiently remove limescale deposits and damage seals and hoses.

For gentle and thorough cleaning, we recommend citric-acid-based descalers.

How do I descale my coffee machine?

Fill the water container and add the descaler according to the manufacturer's instructions.
▶ Turn on the coffee machine. Press the button to switch off the grinder. The symbol lights up red when the grinder is deactivated.
▶ Press the button to start the brewing process.
▶ Repeat the process 2 – 3 times using only clear tap water to rinse out the descaling solution completely.

10. Troubleshooting

Fault/fault code Cause Solution
The appliance is not working.	The power supply is interrupted.	Plug the mains plug into the socket and switch the appliance on.Check whether the voltage information on the type plate matches the local supply voltage.
	The water container is empty.	Fill the water container.
The coffee is too weak.	The selected number of cups does not correspond to the amount of water.	Increase the amount of coffee; see the dosing instructions in section “7.2. Brewing process with coffee powder” on page 116.
	The grind level is set too coarse.	Adjust the grind level to be more fine.
The coffee isn’t hot enough.	The appliance may have a build-up of limescale.	Descale the appliance.
No coffee reaches the glass jug.	The glass jug (9) is not correctly placed under the coffee outlet.	Place the glass jug in the centre of the hot plate (8), so that the drip protection valve (11) is pushed upwards.

11. Storing/transporting

When you are not using the appliance, pull out the mains plug, clean the appliance and store it in a dry, dust-free and frost-free environment that is not exposed to direct sunlight.

Do not store the appliance within the reach of children.

▶ To avoid damage during transport, we recommend that you use the original packaging.

12. Disposal

PACKAGING

Your appliance has been packaged to protect it from damage in transit. The packaging is made of materials that can be recycled in an environmentally friendly manner.

Observe the following labels on the packaging materials regarding waste separation with the abbreviations (a) and numbers (b):

1–7: plastics/20–22: paper and cardboard/80–98: composite materials

(France only)

The “Triman” symbol tells the consumer that the product can be recycled, is covered by an extended system of manufacturer’s responsibility and must be sorted by material type in France.

APPLIANCE

All old appliances marked with the symbol shown must not be disposed of in normal household waste.

In accordance with Directive 2012/19/EU, the appliance must be properly disposed of at the end of its service life.

This involves separating the materials in the appliance for the purpose of recycling as well as minimising the environmental impact and negative effects on human health.

Take old appliances to an electrical scrap collection point or a recycling centre.

Contact your local waste disposal company or your local authority for more information on this subject.

13. Technical specifications

Power supply 220–240 V \~ 50 Hz

Output 900–1050 W

Filling quantity of water Approx. 1.5 l / approx. 12 cups

Coffee bean capacity Approx. 200 g

14. EU declaration of conformity

MEDION AG hereby declares that this appliance complies with the fundamental requirements and the other relevant provisions of:

• EMC Directive 2014/30/EU
• Low Voltage Directive 2014/35/EU
• ErP Directive 2009/125/EC
• RoHS Directive 2011/65/EU.

15. Service information

Please contact our Customer Service team if your device ever stops working the way you want or expect it to. There are several ways for you to contact us:

• In our Service-Community, you can meet other users, as well as our staff, and you can exchange your experiences and pass on your knowledge there.
  You will find our Service-Community at community.medion.com.
  • Alternatively, use our contact form at www.medion.com/contact.
• You can also contact our Service team via our hotline or by post.

Opening times Hotline number UK
Mon – Fri: 08.00 – 20.00Sat – Sun: 10.00 – 16.00	0333 3213106
Service address
MEDION Electronics Ltd.120 Faraday Park, Faraday Road, DorcanSwindon SN3 5JF, WiltshireUnited Kingdom

QR code image containing encoded data, no visible human-readable text

You can download this and many other sets of operating instructions from our service portal at www.medionservice.com.

We have stopped providing printed copies of our warranty terms and conditions as part of our commitment to sustainability, but you can access the warranty terms and conditions on our service portal.

You can also scan the QR code on the side of the screen, to download the operating instructions onto your mobile device from the service portal.

16. Legal Notice

Copyright 2024

Date: 26. April 2024

All rights reserved.

These operating instructions are protected by copyright.

Mechanical, electronic and any other forms of reproduction are prohibited without the written permission of the manufacturer.

Copyright is owned by the company:

MEDION AG

Am Zehnthof 77

45307 Essen

Germany

Please note that you cannot use the address above for returns. Please always contact our Customer Service team first.

DE

FR

NL

ES

IT

EN
