USER MANUAL PrimeTech Primus

Technical diagram showing a mechanical assembly with labeled components, including a cylindrical component and a circular housing.

PRODUCT DETAILSPRODUCT OVERVIEW

PROJETIR DE VENTILIS DE ACADEL ELLI, PROJETIR DE VENTILIS DETALLES DEL PRODUCTA INFORMATIC DÉTALLES SUR LE PRODUIT EN DÉTALLES EN PROCESIONATIVA ETUAL DÉTALLES PROJETIR DE VENTILIS EN PROFOCACIÓN O PREDUCENTE

Labeled diagram of a food preservation or storage device with numbered components

Abstract black and white logo design with stylized letters (no text or symbols)

AE44

CE-0048-16

ID: 845CR-0089

DANGER

CARBON MONOXIDE HAZARD

This appliance can produce carbon monoxide which has no odor.

Using it in an enclosed space can kill you.

Never use this appliance in an enclosed space such as a camper, tent, car or home.

FOR YOUR SAFETY

If you smell gas

1. Do not attempt to light appliance.

2. Extinguish any open flame.

3. Disconnect from fuel supply.

4. Evacuate immediately

5. Allow gas to dissipate 5 minutes before relighting the appliance.

Failure to follow these instructions could result in fire or explosion, which could cause property damage, injury or death.

FOR YOUR SAFETY

Do not store or use gasoline or other liquids with flammable vapours in the vicinity of this or any other appliance.

Man in red jacket and cap crouching outdoors near a green tent and portable stove (no visible text or symbols)

FREEDOM TO EXPLORE.

Ever since the establishment of Primus in 1892, our Swedish engineers have been internationally recognised for designing stoves for explorers and adventurers. It is our genuine passion for adventure and technical solutions that has been the reason for the success of Primus innovations for more than 125 years. It is a passion and a calling that we are still on fire about.

No matter what level of adventure you want to embark on, we want to equip you with a functional and reliable stove that will be your valued companion for life. That is why we test every stove, individually, by hand before it leaves our high-tech factory in Europe. In this way, we can maintain the high level of quality and functionality that we demand from our products. So, read this manual carefully and make sure your cooking is as safe, fun and tasty as it should to be.

Enjoy your food - enjoy life in the outdoors!

A FEW WORDS ABOUT SAFETY.

Because you're dealing with highly flammable substances, we'd like to bring a few important points to your attention before you begin.

Important: Read these instructions for use carefully so as to familiarize yourself with the appliance before connecting it to its gas container. Keep these instructions for future reference.
▶ Use only in a well ventilated area.

Check the seals and connections every time you use the stove. (see the section, "Before ignition"). Do not use the appliance if it has damaged or worn seals.
Change the gas container outside and away from people. Checking the gas flows through the regulator and burners must be done outdoors and away from any naked flame.
Ensure that the stove is not used in the proximity of any combustible material, gas or fluids. When being used, the distance from any roof must be at least 500 mm and 500 mm from any wall.
Never leave a lit stove unattended and always ensure that inflammable material is kept away from the stove when it is in use.
Do not modify the appliance. Carefully follow the instructions for fitting spare parts that may be ordered in, if you are going to replace them yourself.
When the stove is going to be stored away, ensure that all its components are clean and dry. The gas cartridge should never be attached to the stove when in storage. Store the gas cartridge in a dry and safe place, and out of direct sunlight or temperatures in excess of 50^ C.
Save this instruction book so that you can return to it when you need it.

IMAGE EXPLANATION

PRODUCT OVERVIEW & PRODUCT DETAILS

(SEE ILLUSTRATIONS ON THE FLAP TO THE LEFT)

1 Valve

2 Pot supports

3 Burner

4 Valve handle

5 Gas cartridge

6 Lid

7 Piezo igniter

8 Lockable pot gripper

9 Ground protector

10 Windscreen

11 Aluminium pot

12 PrimeTech pot

ACCESSORIES & SPARE PARTS

(SEE ILLUSTRATIONS ON THE FLAP TO THE LEFT)

A Pot Gripper, part no. 740400

B O-ring, part no. 732440

C Piezo igniter, part no. 737460

D Jet Nipple, part no. 740690

E PrimeTech Lid, part no. 740710

F PrimeTech Lid, part no. 740720

Gas Cartridge 100g, part no. 220661. 230g, part no. 220761. 450g, part no. 220261.

Seasonal gas variants - summer and winter - are also available as accessories.

This stove is intended for use with Primus gas Propane/Isobutane/Butane in cartridges with designation 2202xx, 2206xx, 2207xx. (Red Power Gas, green Summer Gas or brown Winter Gas).

Gas consumption is 2,6 kW / 198 g/h (CE). 6050 BTU/h (ANSI).
The diameter of the bore in the nozzle of the stove's burner is 0.35 mm.
This gas appliance conforms to the provisions of EN521/ANSI Z21.72-16/CSA 11.2-16.

CHECKING THE STOVE IMPORTANT: If there is a leak on your appliance (smell of gas), take it outside immediately into a well ventilated flame free location where the leak may be detected and stopped. If you wish to check for leaks on your appliance, do it outside. Do not try to detect leaks using a flame, use soapy water. Contact Primus or your local dealership for replacement parts. You will find contact information on the back page of this instruction booklet.

1. Smell or listen for gas leaks from the gas cartridge. ⑤ If you are not certain, you can check by putting some soapy water on the connection to the gas cartridge. If you see any bubbles, there is a gas leak - DO NOT LIGHT the stove!

2. The valve handle 4 on the stove must be closed (turn clockwise to close) before connecting the gas cartridge.

3. Check the seals before connecting a new gas cartridge to the appliance. Do not use the appliance if it has damaged or worn seals.

4. The threads on both the gas cartridge 5 and the valve must be intact if they are damaged in any way or awry, replace the gas cartridge; or if the valve is damaged, DO NOT USE the stove.
5. Inspect the hose (so that it is neither kinked nor squashed. Avoid twisting the flexible hose) as well as the connection to the burner that it is not damaged.

PREPARE THE STOVE. IMPORTANT: Take

care to ensure that the stove is standing on a stable, flat surface with no combustible material nearby. Check its stability! If you tip the stove while there are pots on it, you risk being scalded by hot liquids.

1. Note that some parts will be very hot, so handle the stove carefully. Don't place the stove on sensitive ground without the supplied ground protector 9.
2. Unfold the pot supports ② for the pot or pan that will be used. If the pot does not fit in the windshield, be careful when handling it. It may be very hot!
3. Do not keep the pot gripper attached to the pot during cooking since it might get hot. Tip: Do not hold too tightly. Hold it lightly while opening it.
4. The pots (and pans if supplied) are made of thin aluminium in order to save weight. This material gets hot very quickly. Never overheat it and never heat up an empty pot or pan.

LIGHTING THE STOVE. IMPORTANT: UNDER

NO CIRCUMSTANCES MOVE the stove when it is lit, either with or without pots. If, due to the wind, the flames are forced down under the burner, turn the stove off and move it to a more sheltered location.

1. Rotate the gas supply handle for the burner about one turn anti-clockwise, and press the lever if the stove is equipped with a piezo ignition. Otherwise use suitable lightning equipment.
2. If the burner does not ignite after five attempts with the ignition button, turn off the supply (clockwise as far as it will go) and wait five seconds for the unignited gas to dissipate. Turn on the gas supply and try again.
3. Once the gas has been lit, you can adjust the flame and the supply of heat with the supply handle. The gas should burn directly upwards with a steady flame.
4. Put the pot or frying pan on the stove after the gas has been lit.
5. Do not touch while it's still warm!

TURN OFF THE STOVE. IMPORTANT: Do not pack up the stove before the burner and the pan supports have cooled down. Check that burner is extinguished before disconnecting the gas container.

1. Turn the stove off by twisting the gas supply handle clockwise to the stop position.
   The valve is closed and the gas flow is stopped when the flame goes out. Do not use excessive force in turning off the supply; you may risk having problems when you try to turn on the supply next time.
2. When you are completely finished with the stove, and the burner 3 has been turned
   off, unscrew the gas cartridge 5 from the valve 1 and roll the flexible hose. (Bending the hose will not damage it.)

MAINTENANCE OF THE STOVE.

IMPORTANT: Regular cleaning and overhaul will extend the life of your stove. Do not try to repair screw threads or valves on the gas cartridges or the regulator yourself. If the stove needs to be repaired, please contact Primus. You will find contact information on the back page of this instruction booklet.

1. The reminder of the stove should be wiped clean with a cloth and a mild cleanser, e.g. dish-washing liquid.
2. Reassamble the stove when fully dry.

IMPORTANT INFORMATION CONCERNING GAS CARTRIDGES.

▶ Attempting to attach gas cartridges that are not designed for the stove can be dangerous.
This appliance shall only be used with either Primus 100 g, 230 g or 450 g single-use cartridges (marked 2202xx, 2206xx and 2207xx respectively).

PRODUKTÜBERSICHT & PRODUKTINFORMATIONEN

PRODUKTÖVERSIKT & PRODUKTDETALJER

(SE ILLUSTRATIONEN PÅ UTVIKET TILL VÄNSTER)

1 Ventil

2 Kärlstöd

3 Brännare

4 Handtag

5 Gasbehållare

6 Lock

7 Piezotändare

8 Griptång

9 Markskydd

10 Vindskydd

11 Aluminiumkastrull

12 PrimeTech-kastrull

TILLBEHÖR & RESERVDELAR

(SE ILLUSTRATIONEN PÅ UTVIKET TILL VÄNSTER)

Abstract black and white logo design with stylized letters (no text or symbols)

AE44

CE-0048-16

ID: 845CR-0089

DANGER

OXYDE DE CARBONE

Man in red jacket and cap crouching outdoors near a green tent and portable stove (no visible text or symbols)

LA LIBERTÉ D'EXPLORER.

PRODUKTOVERSIGT & PRODUKTDETALJER

(SE ILLUSTRATIONER PÅ FLAPPEN TIL VENSTRE)

1 Ventil

2 Grydeholde

3 Brænder

4 Ventilhåndtag

5 Gaspatron

6 Låg

7 Piezo-tænder

8 Grydegreb

9 Bundbeskytter

10 Vindskærm

11 Aluminiumsgryde

12 PrimeTech gryde

TILBEH∅R & RESERVEDELE

(SE ILLUSTRATIONER PÅ FLAPPEN TIL VENSTRE)

A Grydegreb, del nr. 740400

B O-ring, del nr. 732440

TÆNDING AF KOGEAPPARATET.

SLUKNING AF KOGEAPPARATET.

PRODUCTOVERZICHT & PRODUCTINFORMATIE

(ZIE DE AFBEELDING OP DE FLAP LINKS)

1 Ventiel

2 Pan steun

3 Brander

4 Ventiel greep

5 Gaspatroon

6 Deksel

7 Piëzo ontsteker

8 Pangreep

9 Grond bescherming

10 Windscherm

11 Aluminium pan

12 PrimeTech pan

TOEBEHOREN & RESERVEONDERDELEN

(ZIE DE AFBEELDING OP DE FLAP LINKS)

TENNE KOKEAPPARATET. VIKTIG:

VEDLIKEHOLD AV OVNEN. VIKTIG:
