| Product type | Petrol walk-behind lawn mower |
| Brand | Fuxtec |
| Model | FX-RM4646SL |
| Engine | OHV 4-stroke, single cylinder |
| Displacement | 146 cc |
| Rated power | 2.2 kW at 3000 rpm |
| Max. engine power | 2.6 kW |
| Recommended fuel | Unleaded petrol SP98 |
| Fuel tank capacity | 0.8 L |
| Grass catcher capacity | 50 L |
| Cutting width | 457 mm |
| Adjustable cutting height | 25 - 75 mm (7 positions) |
| Net weight | 31 kg |
| Drive | Rear wheel drive with clutch |
| Discharge | Rear and side (optional) |
| Mulching function | Yes (mulching blade included) |
| Sound pressure level | 83.1 dB(A) (k=3) |
| Guaranteed sound power level | 96 dB(A) |
| Vibrations (handle) | 5.856 m/s² (K=1.5) |
| Cleaning system | Easy Clean: water hose connection |
| Safety | Engine brake lever, protective covers |
| Warranty | 24 months |
| Spare parts available | Blade, belt, air filter, spark plug, etc. |
Frequently Asked Questions - FX-RM4646SL Fuxtec
What type of oil to use for the Fuxtec FX-RM4646SL lawn mower?
Use SAE30 engine oil for 4-stroke engines. The level should be checked before each use and the oil changed every 25 hours or each season.
How to start the lawn mower?
Make sure the tank contains petrol and the engine is filled with oil. Pull the brake lever towards the handle, then gently pull the starter cord until you feel resistance, then pull sharply. On the ECO model, press the primer bulb 3 to 5 times before starting.
How to adjust the cutting height?
Use the height adjustment lever located in the center of the mower. It offers 7 positions from 25 to 75 mm. Raise the wheels for a low height, lower them for a high height.
How to clean the lawn mower after use?
Use the Easy Clean system: connect a water hose to the fitting on top of the housing and run water slowly while the cutting mechanism rotates. This removes grass and mud residues.
How to replace the cutting blade?
First empty the fuel tank. Remove the center blade screw, replace the blade and screw, then tighten to 45 Nm. Wear protective gloves. Check the blade balance after sharpening.
How to drain the engine oil?
Let the engine cool, disconnect the spark plug wire. Tilt the mower to 45° and use a suction pump to remove the oil through the fill neck. Add approximately 0.5 L of new SAE30 oil up to the max level on the dipstick.
How to use the mulching function?
Open the rear flap and insert the mulching kit into the designated opening. Close the flap. The mulching blade is already installed. Mulching finely chops the grass and redistributes it onto the lawn.
What is the recommended periodic maintenance?
Before each use: check oil and fuel. Every 25 hours: change oil and clean air filter. Every 50 hours: replace air filter. Annually: replace spark plug (gap 0.6 mm). Refer to the maintenance schedule in the manual.
How to store the lawn mower in winter?
Empty the fuel tank and carburetor (run the engine dry). Clean the mower thoroughly. Store it in a dry place. Remove the battery if equipped with electric start. Keep the battery at 10-25°C and recharge it every 6 months.
What to do if the engine does not start?
Check fuel and oil levels. Make sure the brake lever is pulled. If the spark plug is fouled or flooded, clean or replace it (gap 0.6 mm). Check the air filter and the electrical contact of the brake lever. Consult the troubleshooting table in the manual.
