60091 - Pest control Gardigo - Free user manual and instructions

Brand	Gardigo
Model	60091
Product type	Solar bird scarer
Main power supply	4 rechargeable AA batteries (1.2 V, 300 mAh) or mains adapter 5.5 V DC, 300 mA
Solar panel	7 V, 14 mA, 0.1 W
Coverage area	Approx. 61 m²
PIR detection range	8 meters, 110° angle
Number of flash LEDs	10 LEDs
Predator sounds	Gunshot, dog bark, eagle cry (selectable)
Operating modes	Day (sound only), Night (sound and flash, or flash only depending on setting)
Protection rating	IP44 (splash-proof)
Operating temperature	0 °C to +50 °C
Storage temperature	0 °C to +50 °C
Housing material	UV-resistant plastic
Mounting type	Ground spike included
Package contents	Solar scarer, 4 rechargeable AA batteries, ground spike, instruction manual
Care and cleaning	Clean with a damp cloth, do not use solvents
Safety instructions	Do not use by children without supervision; bright flashes may cause seizures in sensitive individuals
Warranty	Warranty void if unauthorized modification
Customer service	[e-mail]
Repairability	Not user-repairable; return to manufacturer

Frequently Asked Questions - 60091 Gardigo

How to install the Gardigo 60091 solar scarer?

Drive the two parts of the ground spike into the ground, then insert the device onto the spike. Place it in an open area for maximum solar exposure. Make sure no obstacles block the 110° PIR detection field.

What type of batteries to use?

Use only rechargeable AA batteries (1.2 V, 300 mAh). Do not use regular alkaline batteries, as they may cause explosion and damage the device.

How to recharge the batteries?

The batteries recharge automatically via the built-in solar panel. In summer, direct sunlight exposure is sufficient. In winter or under cover, recharge with a mains adapter (5.5 V DC, 300 mA) once a week.

What is the range of the device?

The PIR motion detector has a range of approximately 8 meters and a detection angle of 110°. The coverage area is approximately 61 m².

How does motion detection work?

The PIR sensor detects movements in its field. When a bird is detected, the device emits predator cries and activates the flash LEDs at night. Regular frequency changes prevent habituation.

Can I use the device indoors?

Yes, the device is designed for indoor and outdoor use. Indoors, make sure to place it near a window so the solar panel receives light, or use the mains adapter.

What if the device does not work at night?

Check the switch: it should be set to DAY/NIGHT for day and night operation. In night mode, the LED flashes activate. Make sure the batteries are charged and the PIR sensor is not obstructed.

How to clean the device?

Clean the housing with a damp cloth. Do not use abrasive cleaning products or solvents. Avoid directing a water jet directly at the device despite the IP44 rating.

Can I change the predator sounds?

Yes, use the predator sound control button to select between gunshot, dog bark, or eagle cry. Adjust the volume with the corresponding wheel.

What to do if there is a battery problem?

If the batteries do not hold a charge, check that they are rechargeable and not defective. Replace them with new batteries of the same type. If the problem persists, contact customer service at [e-mail].

USER MANUAL 60091 Gardigo

Close-up of a black and white handheld device with a circular head and perforated tip (no visible text or symbols)

DE Gebrauchsanweisung 2
GB Instruction manual 8
FR Notice d'utilisation 13
ES Manual de instrucciones 19
IT Istruzioni per l'uso 25
NL Instructies 31

Gebrauchsanweisung

Dear customer, thank you for deciding on one of our quality products. In this manual we will explain the functions and the handling of our device. Please take your time to read through the manual and follow all safety and operational instructions in order to achieve best results. Keep this manual in a safe place and include it when passing the device on to another person. If you have suggestions or questions about this product please contact your dealer or our service team. We would be delighted if you would recommend us and wish you success with the use of this device.

1. Designated use

The Solar Scarecrow is designed for keeping birds away from your garden. The device emits sounds that are alarming to birds. Additionally, an LED flash can be added to enhance the effect. The device is powered by rechargeable batteries which are charged with the integrated solar cell. Any other use as the mentioned is not permitted! No liabilities will be taken for damages or claims resulting out of not reading and/or not following the user guide and/or any form of modification on or in the product. Under these circumstances, no warranty services will be granted. Liability will not be taken for consequential damages.

2. Important notices

• Please respect of the breeding season of the birds! Before installing the device check the surrounding environment for up to 8 m and make sure that there are no birds breeding. Breeding birds can be disturbed and might not return to their nests. The starving of the chicks would be the consequence.
• The device emits alternating ultrasonic frequencies, covering a large range of small birds.
• The device does not hinder the animals from being in the area. It makes them feel uncomfortable and the birds will move to other areas, which appear more pleasant and quieter. It may take a few days or weeks until the effect fully takes place.
• The dispersion of the sound is related to the local surroundings.
• The product can be mounted quickly and immediately provides an optimum protection against birds. Possible locations are lawns, fruit trees, patios, carports or garages.

- The device can be used outside and is resistant against rain.

Note: the response of each animal to our animal repellent may vary. The development of our devices, methods and application tips are based on experience, testing and feedback from our customers. Therefore the devices are successful in most cases.

3. Safety guide

• Electrical appliances, packaging materials, etc. do not belong in the hands of children. If repairs are needed, only original spare parts may be used to avoid serious damage.
• The device may only be used with the stated voltage: 4 x rechargeable AA batteries / 5.5 V DC 300 mA power supply
• It must be determined if the device is suitable for the respective use.
• The use of this device is not designed for use by persons (including children under 8 years) with reduced physical, sensory or mental capabilities, or the lack of experience or lack of knowledge, unless they are supervised or have been instructed in the use of the device by a person responsible for their safety.
• People who suffer from photosensitive epilepsy may experience epileptic seizures or loss of consciousness when exposed to certain flashing lights. If the following symptoms occur dur-

ing operation: dizziness, blurred vision, eye or muscle twitching, loss of awareness, disorientation, any involuntary movement or convulsion, the light should be immediately turned off or the person should leave the area.

• Make sure that only rechargeable batteries are used. Do not use standard batteries! The use of standard batteries may cause an explosion and destroy the device. Rechargeable battery should not be used if the temperature is under 0 °C. They may become damaged and lose the capacity.
• If you do not use the device for an extended period of time, remove the batteries and store them accordingly.
• Keep these instructions in a safe place and pass them on when giving the device to a third person.
• This unit is suitable for indoor and outdoor use.
• Place the device in such a way that it does not become a tripping hazard.

4. Contents

• Solar Scarecrow • 4 x rechargeable AA batteries
- Ground spike • Instruction manual

5. Getting started

It is basically not necessary to charge the batteries externally. The batteries are sufficiently charged by the solar cell in summer when it is exposed to direct sunlight. If you use the deterrent as a preventive measure in February, it is advisable to charge the device manually once a week with a charger due to the short days and reduced

sun exposure. If you use the device under the carport or an area that is not exposed to direct sunlight, you can also charge the device permanently with a charger.

Operation:

The Solar Scarecrow detects the movements of the birds within an angle of 110^ and uses two effects to make life uncomfortable for the birds: variable sound and a LED flash. Sound and flash are activated by the motion detector.

• Open the battery compartment and insert the rechargeable batteries. Make sure they are put in with the correct polarity.
• There are 3 switches in the compartment: DAY/NIGHT/OFF and EAGLE/DOG/GUN-SHOT as well as a volume control.
• Switch the ON/OFF switch to DAY or NIGHT to activate the device.
• Then select the desired sound by setting the EAGLE/DOG/GUNSHOT switch.
• Adjust the volume by turning the volume control.

The following operation settings are possible:

	Daytime use Nighttime use
Switch	day night	day night
LED flash	✗ √ ✗ √
Sound	√ √ √ ✗

You may choose of three enemy sounds: Gunshot, Dog, Eagle

Ground spike: Assemble the earth spike together and place it into the socket on the underside of the device. You can now mount the device in the lawn or flower bed.

6. Specifications

• Battery: 4 x rechargeable AA batteries; 1.2 V, 300 mAh each
• Charging through solar panel or 5.5 V, 300 mA power supply
  • Solar panel: 7 V, 14 mA, 0.1 W
  • Area coverage: up to 61 m²
• PIR: approx. 8 m, 110°
  • Power LED: white 10 x flash
• Loudspeaker
  • Protection rating: IP 44
  • Control elements: 3 (DAY/NIGHT/OFF)
• Operating/Storage temperature: 0 °C to +50 °C and ≤ 90 % R.H.

7. General information

• The CE conformity has been proven and the declarations are deposited with us.
• For safety and conformity reasons it is not permitted to rebuild or modify the device and/or use it in any other way than described above.
• This device has a warranty of two years. As Gardigo has no control of the correct of appropriate installation and use of the device the warranty can only be applied to a fully equipped device in prime condition. We assume neither warranty nor liability for damages or following damages related to this product. This applies especially if it has been modifications or repairs have been made by the customer, if the circuitry has been modified or components have been used other than the original components and/or if the operation of the device has been incorrect, careless or abusive.
• If you have any questions or suggestions about this product, please contact your dealer.

Service hotline: phone [phone] Your Gardigo team

Environmental protection notice

At the end of its life span this product may not be disposed as normal household waste but must be disposed of at a collecting place for recycling of electrical and electronic equipment. The icon on the product, in the manual, or on the packing points to this fact. The materials are recyclable according to their labelling. Through reusing, material recycling, or other forms of utilisation of old devices you make an important contribution to the protection of the environment. Please ask the local administration for the responsible waste disposal centre.

Do not throw batteries or rechargeable batteries into household waste!

Consumers are legally obligated to return used and rechargeable batteries, whether they contain harmful substances* or not, to designated recycling areas, disposal sites, or stores where batteries/rechargeable batteries can be bought. By doing so, you are fulfilling all legal battery recycling and disposal obligations and are contributing to a better environment. Make sure batteries are completely discharged before disposing!

*marked with: Cd = cadmium, Hg = mercuric, Pb = lead
