Product Type	2-in-1 Cordless Brushcutter
Brand and Model	Parkside PPFSA 40Li A1
Power Supply	40 V battery (2 × 20 V), compatible with Parkside X 20 V TEAM
Weight (without cutting attachment)	4.9 kg
Weight (in operation)	5.9 kg
Cutting radius (spool)	340 mm
Cutting radius (blade)	255 mm
Cutting line thickness	2.4 mm
Cutting line length	5 m
Idle speed (3 speeds)	4600 / 5500 / 7000 min⁻¹
Guaranteed sound power level	90 dB(A)
Vibration (spool, right handle)	2.379 m/s² (K=1.5 m/s²)
Vibration (spool, left handle)	2.051 m/s² (K=1.5 m/s²)
Vibration (blade, right handle)	3.668 m/s² (K=1.5 m/s²)
Vibration (blade, left handle)	2.224 m/s² (K=1.5 m/s²)
Operating temperature	-20 to 50 °C
Storage temperature	0 to 45 °C
Warranty	5 years (France and Belgium)
Main functions	Grass cutting, weeds, small brush; 2-in-1 (spool + blade); 3 speeds; automatic line advancement system
Maintenance and cleaning	Clean ventilation slots and protective cover after each use; do not immerse in water; replace spool or blade if worn
Safety	No operation without protection; wear gloves, goggles, safety shoes; keep a distance of 15 m; stop immediately if problem occurs
Spare parts and repairability	Parts available at www.grizzlytools.shop; repair by authorized service; do not open battery
Delivery contents	Brushcutter, connecting tubes, shoulder strap, spool, 2-tooth blade, protective cover, accessory bag, manual

Frequently Asked Questions - PPFSA 40Li A1 PARKSIDE

How to change the cutting line?

Turn off the device and remove the battery. Lock the shaft with the Allen key, unscrew the cap clockwise. Open the cap by pressing the clips, insert the new spool by threading the lines through the eyelets. Close the cap and screw it back on counterclockwise.

Can I use a blade instead of the spool?

Yes, the brushcutter is 2-in-1. Remove the spool, place the 2-tooth blade on the shaft and secure it with the washer, clamping washer and nut using the multi-tool. Wear protective gloves.

How to start the device?

Insert two batteries from the Parkside X 20 V Team range. Put on the shoulder strap. To start, press the locking button (11) and hold the On/Off switch (10). Release the lock. To stop, release the switch.

Which batteries are compatible?

The device operates exclusively with batteries from the Parkside X 20 V TEAM range. Recommended batteries are Smart PAPS 204 A1 and Smart PAPS 208 A1. Only charge them with compatible chargers, e.g. Smart PLGS 2012 A1.

What to do if the device does not start?

First check if the batteries are charged and correctly inserted. If the problem persists, the switch or motor may be defective. Contact after-sales service.

How to adjust the rotation speed?

Press button (9) to cycle through the 3 speeds: low (4600 rpm), med (5500 rpm) and high (7000 rpm). The device automatically switches to ECO mode when not under load.

What are the essential safety precautions?

Always wear gloves, safety goggles, safety shoes and hearing protection. Keep people and animals at least 15 meters away. Do not work in rain or on wet grass. After stopping, the cutting head continues to rotate for a few seconds.

How to clean and maintain the device?

Before any maintenance, turn off the device and remove the battery. Clean the ventilation slots, housing and handles with a damp cloth. Remove grass from the protective cover and cutting device. Never immerse in water.

The device vibrates abnormally, what to do?

Thoroughly clean the cutting head and protective cover to remove grass residues. If vibrations persist, check that the blade or spool is correctly mounted. If the problem continues, contact after-sales service.

Where can I buy spare parts?

Spare parts are available at www.grizzlytools.shop. You can order the protective cover, cap with spool, 2-tooth blade and shoulder strap. Always use original parts.

USER MANUAL PPFSA 40Li A1 PARKSIDE

Mechanical tool with tripod and two separate views showing mechanical components (no text or symbols visible)

2-in-1-Akku-Freischneider 40 V / 2-in-1 Cordless Brush Cutter 40V / Débroussailleuse sans fi l 2 en 1 40 V PPFSA 40 - Li A1

DE AT CH

2-in-1 Cordless Brush Cutter 40V

Translation of the original instructions

NL BE

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

GB / IE Translation of the original instructions Page

Inhalt

Einleitung......4

Bestimmungsgemäße

Verwendung 5

Service-Center......28

Importeur 28

Fehlersuche....29

Original-EG-

gemessen.....88,0 dB(A); K_WA = 1,91 dB

Temperatur max. 50 °C

Ladevorgang 4 - 40 °C

Intended purpose......31

General description......31

Extent of the delivery 31

Functional description....31

Overview....31

Technical data....32

Charging time 33

Safety instructions......33

Symbols and icons 33

General safety instructions for power tools....34

General safety instructions.... 37

Additional safety rules 39

Protective measures against kickbacks....41

Additional safety instructions ..... 41

Residual risks....43

Assembling instructions......43

Connecting the shaft tubes 43

Mounting the protective cover......44

Mounting the handles 44

Mounting/replacing the spool ..... 44

Mounting/replacing the blade......44

Initial start-up 45

Removing/inserting the battery ..... 45

Charging the battery 45

Putting the shoulder strap on......45

Switching on and off 45

Speed control 46

Operation 46

Checking the charge status of the batteries....46

Working instructions......46

Adjusting the shoulder strap eyelet/balancing out the device....47

Working using the thread spool ..... 47

Extending the line 47

Working with the 2-tooth blade......48

If the device vibrates....48

Cleaning and maintenance......48

Cleaning....49

Winding up the spool....49

General maintenance work 49

Removing blockages......49

Transport 49

Storage....49

Disposal and protection of the environment ....50

Replacement parts/Accessories ..50

Trouble shooting ....51

Guarantee 52

Repair Service....53

Service-Center....53

Importer 53

Translation of the original EC declaration of conformity ....223

Exploded Drawing ......232

Introduction

Congratulations on the purchase of your new device. With it, you have chosen a high quality product.

During production, this equipment has been checked for quality and subjected to a final inspection. The functionality of your equipment is therefore guaranteed.

The operating instructions constitute part of this product. They contain important information on safety, use and disposal. Before using the product, familiarise yourself with all of the operating and safety instructions. Use the product only as described and for the applications specified. Keep this manual safely and in the event that the product is passed on, hand over all documents to the third party.

Intended purpose

The 40V cordless string trimmer is suitable for cutting grass in the garden, along the flower beds and around tree or fence post when using the spool.

When using the 2-tooth blade, the device cuts grass, weeds or light vegetation. The appliance must only be used by adults.

Young people aged 16 and over may only use the trimmer under adult supervision.

The user or operator is responsible for accidents causing injury to other people or damage to property.

The manufacturer cannot be held liable for damage when the trimmer is not used in conformity with its intended purpose or due to incorrect operation.

This equipment is not suitable for commercial use. Commercial use will invalidate the guarantee.

The device is part of the Parkside X 20 V TEAM series and can be operated using Parkside X 20 V TEAM series batteries. The batteries may only be charged using chargers from the Parkside X 20 V TEAM series.

General description

The illustration of the most important functional components can be found on the front and the back fold-out pages.

Extent of the delivery

Carefully unpack the trimmer and check that it is complete:

- 40V Cordless brush-cutter

- Upper shaft tube

- Lower shaft tube

- Shoulder strap

- Spool

- 2-tooth blade

- Protective cover

- 1x Allen key 1x Multi-function key

- Fabric bag for accessories

- Instruction Manual

The Allen key is kept in the holder on the device head (1).

Battery and charger are not included.

Functional description

Refer to the following descriptions for a functional description of the controls.

Overview

1 Device head

2 Keyhole bore

3 Upper shaft tube

4 Cable holder 5 Handle

6 Lower shaft tube

7 Protective cover

8 Multifunction handle 9 Button

10 On/Off switch

11 Switch lock

12 Eyelet

13 Button

14 Battery charge level indicator

15 Spool cap

15a Rotary knob

16 2-tooth blade

17 Allen key

18 Multi-function key

19 Release button

20 Rechargeable battery 21 Charger

22 Shoulder strap

GB IE

A	23	Mounting screw
A	24	Lock
B	25	Screw
B	26	Line cutter
B	27	Shaft mount
C	28	Receptor
C	29	Handle mount
C	30	Star screw
E	31	Uptake spindle
E	32	Line outlet loop
E	33	Spool
E	34	Groove
E	35	Washer
E	36	Clamping disk
E	37	Nut
E	38	Click lock

Technical data

40V Cordless

brush-cutter ......PPFSA 40-Li A1

Motor voltage U.....40 V==; (2 x 20V)

Idle speed spindle n 7000 min ^-1

3 steps.....4600/5500/7000 min ^-1

Motor Idle speed....3100 min ^-1

Weight (without cutting tool)....4,9 kg

Spool

Cutting circle 340 mm

Line thickness....2.4 mm

Line length 5 m

Thread....M10

Vibration (a_h) at the handle

right....2,379 m/s²; K=1,5 m/s²

left .....2,051 m/s²; K=1,5 m/s²

2-tooth blade

Cutting circle 255 mm

Borehole 25.4 mm

Vibration ( a_b ) at the handle

right....3,668 m/s2; K=1,5 m/s2

left .....2,224 m/s2; K=1,5 m/s2

Weight (operationally ready)......5.9 kg

Sound pressure level

(L_pA) 68,0 dB(A); K_pA = 3 dB

Sound power level (LWA)
guaranteed	90 dB(A)
measured	88,0 dB(A); KWA= 1,91 dB
Temperature	max. 50 °C
Charging process	4-40 °C
Operation	-20 - 50 °C
Storage	0-45 °C

Levels of noise and vibration were determined according to the standards and regulations in the declaration of conformity. Vibration and noise tests have been carried out successfully in accordance with EN 50636-2-91.

Noise and vibration values have been determined according to the standards and regulations mentioned in the declaration of conformity.

The stated vibration emission value was measured in accordance with a standard testing procedure and may be used to compare one power tool to another.

The stated vibration emission value may also be used for a preliminary exposure assessment.

Warning: The vibration emission value may differ during actual use of the power tool from the stated value depending on the manner in which the power tool is used.

Try to keep the exposure to vibrations as low as possible. Examples of measures to reduce vibration exposure are the wearing of gloves when using the tool and limiting the working hours. For this purpose all parts of the operating cycle have to be considered (for example, times when the electric tool is switched off and times when it is switched on but running without any load).

Charging time

The device is part of the Parkside X 20 V TEAM series and can be operated with batteries of the Parkside X 20 V TEAM series.

Batteries of the Parkside X 20 V TEAM series may only be charged using chargers of the Parkside X 20 V TEAM series.

We recommend that you operate this appliance with the following batteries only: Smart PAPS 204 A1, Smart PAPS 208 A1. We recommend charging these batteries with the following chargers: Smart PLGS 2012 A1.

An up-to-date list of battery compatibility can be found at: www.lidl.de/akku

Charging time (min)	PAP 20 A1 PAP 20 B1	PAP 20 A2	PAP 20 A3 PAP 20 B3	Smart PAPS 204 A1	Smart PAPS 208 A1
PLG 20 A1 PLG 20 A4 PLG 20 C1	60 90	20 120 210
PLG 20 A2 45	60 80 80 165
PLG 20 A3 PLG 20 C3	35 45	60 50 120
PDSLG 20 A1 3	5 45 60 50	120
Smart PLGS 2012 A1	35 40	40 40 50

Safety instructions

Ensure that the safety instructions are observed when operating the trimmer.

Symbols and icons

Symbols on the device

Caution!

Read the instruction manual carefully before using the device.

Wear safety goggles.

Wear head protection.

Wear hearing protection.

Wear safety gloves. Risk of cut injuries.

Wear non-slip safety shoes with fi rm soles.

Wear suitable work clothing.

Do not expose the device to moisture. Do not work in the rain and do not cut

wet grass.

GB IE

Do not wear long hair uncovered. Use a hair net.

Keep hands away! Cutting injuries

Danger due to ejected parts! Keep other people away.

Caution! Kickback - be aware that you may experience kickback while working with the machine.

Locking mechanism for up- take spindle

Maintain a safe distance of at least 15 m from other people.

Keep other people away. You could be injured by ejected for-

eign bodies.

Keep persons in the vicinity away from the device.

Remove the batteries from the device before maintenance and adjustment work

Do not use metal saw blades

Sound power level L_WA indicated in dB

Electrical devices must not be disposed of with domestic waste.

Battery charge level indicator

Speed control

Symbols in the manual

Warning symbols with information on damage and injury prevention

Warning symbols with information on the prevention of personal injury caused by electric shock

Instruction symbols with information on preventing damage

Carefully read through the user manual

Help symbols with information on improving tool handling

General safety instructions for power tools

WARNING! Read all safety notices, instructions, illustrations and technical data that have been provided with this

power tool. Omissions in the compliance with safety directions and instructions can cause electrical shock, fire and/or severe injuries.

Retain all safety directions and instructions for future use.

The term „power tool“ in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool).

1) WORK AREA SAFETY

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

2) ELECTRICAL SAFETY

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operation of the power tool in a damp environment is unavoidable, please use a residual current circuitry. The use of a residual current circuitry reduces the risk of an electric shock.

3) PERSONAL SAFETY

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention white operating power tools may result in serious personal injury.

b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.

c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to

power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.

d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.

e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

g) If dust extraction and collection devices can be installed, make sure that these are connected and used correctly. Use of dust collection can reduce dust-related hazards.

h) Do not allow yourself to be lulled into a false sense of security and do not disregard the safety rules for power tools, even if you are familiar with the power tool after using it many times. Careless action can lead to serious injuries within a fraction of a second.

4) POWER TOOL USE AND CARE

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.

b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.

c) Remove the plug from the wall socket and/or remove the rechargeable battery before you change the device's settings, change accessory parts or put away the power tool. Such preventive safety measures reduce the risk of starting the power tool accidentally.

d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.

e) Look after the power tool and application tool carefully. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.

f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

h) Keep handles and grip surfaces dry, clean and free from oil and

grease. Slippery handles and grip surfaces do not permit safe operation and control over the power tool in unexpected situations.

5) CAREFUL HANDLING AND USE OF BATTERY DEVICES

a) Charge the batteries only in chargers that are recommended by the manufacturer. Risk of fire if a charger that is suitable for a specific type of battery is used with other batteries.

b) In the power tools, use only the batteries designed for the purpose. The use of other batteries may result in injuries and risk of fire.

c) Keep the unused battery away from paper clips, coins, keys, nails, screws and other small metal objects, which could cause bridging of the contacts. A short circuit between the battery contacts may cause burns or fire.

d) If used incorrectly, liquid may leak from the battery. Avoid contact with this. In the event of accidental contact, rinse off with water. If the liquid gets into eyes, seek medical assistance. Leaking battery fluid may cause skin irritations or burns.

e) Do not use damaged or altered batteries. Damaged or altered batteries can be unpredictable and lead to fire, explosion or risk of injury.

f) Do not expose batteries to fire or elevated temperatures. Fire or temperatures over 130 °C can cause an explosion.

g) Follow all instructions for charging and never charge the battery or the battery-powered tool

outside the temperature range stated in the operating instructions. Incorrect charging or charging outside the permitted temperature range may destroy the battery and increase the risk of fire.

6) SERVICE

a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.

b) Never repair damaged batteries. All battery repairs should be carried out by the manufacturer or authorised customer service centres only.

General safety instructions

Access by children as well as sick and frail people is to be prevented. Children must be carefully supervised when in the vicinity of machinery.

Observe the regional and local accident prevention regulations applicable to your location. The same applies to all provisions on occupational health and safety at work. The manufacturer cannot be held liable if its machines are modified without authorisation and if such changes result in damage to people or property.

Warning! Basic precautionary measures are to always be taken when using machines. Please also observe all tips and notices in the additional safety instructions.

1. Do not let third parties access the device. Visitors and observers, especially children and sick and frail peo-

GB IE

ple must be kept away from the work area. Prevent other people from coming into contact with the tools. Only pass the device on to people who are familiar with the device and its handling.

1. Ensure tools are stored securely. Tools that are not in use must be stored in a dry, preferably high location, or locked away out of access.

2. Always use the right tool for every job. For example, do not use small tools or accessories for work that actually has to be done with heavy-duty tools. Use tools only for the purposes for which they were designed.

3. Ensure you wear suitable clothing. The clothing must be fit for purpose and must not hinder you when you are working. Wear clothing with cut resistant inserts.

4. Use personal protective equipment. Wear safety shoes with steel toecaps/steel soles and non-slip soles. Wear a safety helmet if the work entails a risk of falling objects.

5. Wear safety goggles. Objects may be thrown towards you. This may result in severe eye injuries.

6. Wear ear protection. Wear personal hearing protection, e.g. ear plug.

7. Hand protection Wear sturdy gloves - leather gloves provide good protection.

8. Operating the device Never work without the guard on the cutting tool. Risk of injury due to ejected objects.

9. Remove all socket wrenches etc. All wrenches/keys and similar must be removed before switching on the device.

10. Always remain attentive. Pay attention to what you are doing. Use common sense. Do not use any

motorised tools when you are tired. You may not operate the device under the influence of alcohol, medication or drugs that impair your ability to react.

1. Duration of use and breaks Prolonged use of this motorised device can lead to problems with the blood circulation in the hands caused by vibrations (Raynaud's syndrome). You can however extend your machine use time by wearing appropriate gloves or by taking regular breaks. Please ensure that if you are susceptible to poor circulation, low outside temperatures or strong gripping forces while working, this may reduce the length of time for which you are able to work.

2. Look out for damaged parts. If the device suffers a heavy impact or is dropped, check it for signs of damage and wear before putting it back into operation. Are individual parts damaged? In the case of slight damage, carefully reflect on whether the tool will still work properly and safely. Ensure moving parts are correctly aligned and set up. Are the parts interlocking properly? Are parts damaged? Is everything correctly installed? Are all other requirements for proper functioning met? Damaged safety equipment etc. must be properly repaired or replaced by authorised persons, unless otherwise indicated in the instruction manual. Defective switches must be replaced by an authorised entity. If repairs are need, contact a customer service centre authorised by us.

3. Always switch the motor off before making adjustments or maintenance work. This especially applies to any work on the spool.

4. Only use approved parts. Only use identical spare parts for mainte-

nance and repairs. Spare parts are available from our online shop (see "Spare parts/Accessories").

Warning! The use of other mower heads as well as accessories and attachments that are not expressly recommended can endanger people and property. The tool may only be used for the intended purpose. Any use other than for the intended purpose is considered improper use. The user is solely responsible for property damage and personal injury resulting from such improper use; the manufacturer bears no liability under any such circumstance. The manufacturer cannot be held liable if its machines are modified or used improperly and if this results in damage to people or property.

Attention! Even if the tool is used properly, there is always a certain level of residual risk that cannot be excluded. Due the nature and design of the tool, the following potential hazards can be deduced:

• Contact with the unprotected spool (cutting injuries)
• Reaching into the running spool (cutting injuries)
• Hearing damage if adequate protection is not worn
• Harmful dust or gas formation when using the device in closed rooms (nausea)

Additional safety rules

To prevent personal injury and damage to property:

1. Caution! Always keep your hands and feet away from the cutting area,

especially when starting the device. Always keep the hand on the additional handle free.

1. Always hold the device with both hands on the multifunction handlebars. Always keep the device at a suitable safety distance from the body and maintain a stable body posture.

2. Always wear safety goggles.

3. Only use the device in daylight or where there is good artificial lighting.

4. Do not use the device in the rain or on wet grass.

5. Check the device for damage before use or after an impact, and repair if necessary.

6. Do not use the device if the safety equipment is damaged or incorrectly installed.

7. Ensure that the motor's ventilation slits, the protective cover and cutting unit are always free of dirt or residual material.

8. During the work process, always ensure that there are no people or animals within a radius of at least 15 m. Immediately switch off the machine if anyone, especially children, gets within range of the machine.

When using the device, stones and other objects can be ejected, which may lead to serious injuries.

1. When the device is in operation, do not get near to the moving parts (within the cutting unit area). The cutting head will keep rotating for a few seconds after the device has been switched off.

2. Before using the device, stones, twigs and any other solid material must be removed from the work area.

Only start the machine as described in the manual. It must not be upside

GB IE

down when starting or in the working position.

Do not cross any gravel roads or paths with the device running.

1. Extreme caution is required when extending the cutting line. There is a risk of cutting injuries. After performing these steps, the device must be brought back into the correct working position before being re-started.

2. Do not use any metallic cutting spools. Note that the device will continue to operate for a few seconds after you let go of the switch.

3. Switch the motor off (on/off switch off) if:

4. Fuelling the device,

5. Not using it,
6. Leaving it unattended,
7. Cleaning it,
8. Transporting it from one location to another,

9. Removing or replacing the cutting unit or adjusting the length of the cutting line by hand.

10. Length of use and breaks

Prolonged use of the motorised device can lead to problems with the blood circulation in the hands caused by vibrations. You can however extend your machine use time by wearing appropriate gloves or by taking regular breaks. Please ensure that if you are susceptible to poor circulation, low outside temperatures or strong gripping forces while working, this may reduce the length of time for which you are able to work.

1. Prolonged use of this motorised device can lead to hearing damage if appropriate hearing protection is not worn.

Wear personal hearing protection, e.g. ear plugs, to reduce the risk of hearing damage.

1. Carry the strimmer by the upper and lower shaft tube when it is switched off, with the cutting unit pointing away from your body in order to avoid injuries. After the device has been switched off, the motor head of the scythe is hot. Make sure that you do not come into contact with the motor head.

2. Regularly check whether the cutting equipment is at a standstill when idling.

3. National regulations may specify an age restriction for the user.

4. Be aware that the following circumstances can lead to damage to the device and serious injuries to the person operating it:

5. improper maintenance,

6. use of non-compliant spare parts,

7. the removal or modification of safety devices.

8. Caution! Local regulations may restrict use of the machine.

9. Always maintain the device and cutting tool in a good condition.

10. Before use, check the device for loose fastenings, fuel leaks and damaged parts, such as cracks in the cutting attachments.

11. Take breaks and change your working position regularly.

12. Warning! There are sharp edges on the string trimmer. Gloves need to be worn.

13. In order to detect significant defects, a visual inspection needs to be performed before each use, after the device is dropped or if it suffers any kind of impact.

14. Wear both non-slip foot protection and protective clothing when using the string trimmer.

15. Never use the machine if you are tired, ill or under the influence of alcohol or other drugs.

16. Assume a firm stance and maintain your balance during operation. Also use the carrying strap provided.

Protective measures against kickbacks

In the event of a kickback, the operator will feel a powerful blow from the device. This may lead to losing control of the device and serious injury. You can avoid kickbacks through caution and proper technique.

While working with the 2-tooth blade there is a risk of kickback if the blade edge hits an obstacle (stone, wood).

- Hold the device with both hands.

• Make sure there are no obstacles on the ground and do not use the 2-tooth blade near fences, metal posts or similar.

Use only properly sharpened tools. To cut thick stems, switch the device to position A.

Additional safety instructions

TRAINING

- The appliance is not suitable for use by children. Children should be supervised to ensure that they do not play with the appliance. Cleaning and user maintenance shall not be made by children.

- This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge.

- Local regulations or bylaws may determine the minimum age for using the device.

- The operator or user is responsible for accidents or damage to other persons or their property.

- Children and persons with limited physical, sensory or mental capabilities or inadequate experience and knowledge, or persons who are not familiar with the instructions, should never be allowed to use the machine! Local regulations may specify an age limit for the user.

- Never let children or persons who are not familiar with the instructions mentioned use the machine.

PREPARATION

- Before each use, carry out a visual inspection on missing or wrongly mounted protective devices or parts of the cutting device.

- Before commissioning and after any impacts, check for signs of wear and damages, and have any necessary repairs performed.

GB IE

OPERATION

- Wear safety goggles, stable shoes and long trousers over the entire period of use of the machine.

- The use of the machine under bad weather conditions, especially in case of lightning risk, must be avoided.

- Warning! Do not touch any moving dangerous parts before the battery has been removed and the moving dangerous parts have come to a complete stop.

- Caution, risk of injury from cuts on hands and feet.

- Stop using the machine when persons, above all children, and house pets are in the vicinity.

- Use the machine only in daylight or with good artificial lighting.

- Always keep your hands and feet away from the cutting equipment, above all when you switch the motor on.

- Never install metallic cutting elements.

- Never use the machine with damaged or missing protective equipment.

- Avoid an abnormal body posture. Ensure secure footing at all times to maintain balance when working on slopes.

- Go slowly. Do not walk with the device in your hand.

• Always wear sturdy shoes and long trousers during operation of the machine.

- In the case of an accident or malfunction during operation, the device must be switched off immediately. Injuries must be properly treated or medical assistance sought. Read the „Trouble shooting“ section to correct any malfunctions or contact our Service Centre.

- Do not use any accessories that are not recommended by PARKSIDE. This can result in electric shock or fire.

MAINTENANCE AND STORAGE

- Remove the removable battery before carrying out maintenance or cleaning work.

- Use only spare parts and accessories supplied and recommended by the manufacturer.

- The machine must be checked regularly and maintained. Have the machine repaired in a licensed workshop.

Comply with the device's instructions in the "Cleaning and Servicing" section.

Residual risks

Even if properly operating and handling this electric tool, some residual risks will remain. Due to its construction and build, this electric tool may present the following hazards:

a) Cuts
b) Ear damage if working without ear protection.

c) Damage to your health caused by swinging your hands and arms when operating the appliance for longer periods of time or if the unit is not held or maintained properly.

Warning! During operation, this electric tool generates an electromagnetic field which, under certain circumstances, may impair the functionality of active or passive medical implants. To reduce the risk of serious or lethal injuries, we recommend that persons with medical implants consult their doctor and the manufacturer of their medical implant before operating the machine.

Observe the safety in- formation and notes on charging and proper use as shown in the

instruction manual for your battery and charger from the Parkside X 20 V Team series. A detailed description of the charging process and further information can be found in the separate operating instructions.

Assembling instructions

Remove the rechargeable battery from the device before assembly. Insert the rechargeable battery only once the device is completely assembled. There is a risk of injury!

Connecting the shaft tubes

1. Loosen the shaft tube mounting screw (23) on the upper shaft tube (3).
2. Remove the protective cap from the lower shaft tube (6).
3. Push the lock (24) and slide the lower shaft tube (6) as far as it goes into the upper shaft tube (3).
4. Turn the lower shaft tube (6) with a gentle rotating movement until the lock (24) clicks into place in the bore on the upper shaft tube (3).
5. Tighten the shaft tube mounting screw (23) back into place by hand.

Before you start the device, make sure that the lower shaft tube is firmly and securely in place and located in the correct position.

GB IE

Dismantling:

1. Release the shaft tube mounting screw (23).
2. Push the lock (24).
3. Pull apart the shaft tubes (3 + 6).

B

Mounting the protective cover

Never use the device without the protective cover properly ted. There is a risk of injury.

1. Position the protective cover (7) on the shaft mount (27).
2. Attach the protective cover (7) using the multi-function key (18) and the two small screws (25).

C

Mounting the handles

1. Loosen the star screw (30) and remove the handle mount (29) from the upper shaft tube (3).
2. Place the multifunction handle (8) and handle (5) into the receptor (28) on the upper shaft tube (3).
3. Fasten the handles (5 + 8) to the handle mount (29) and star screw (30). Tighten the star screw (30) by hand.
4. Fasten the device cable to the cable holders (4).

E

Mounting/replacing the spool

1. Switch off the motor and remove the battery from the device.
2. Place the device on the ground in a stable position.

3. Block the uptake spindle (31) using the Allen key (17) as depicted.
   Screw the spool cap (15) clockwise from the uptake spindle (31).

4. Open the spool cap (15) by firmly pressing the quick-release catch (38) inwards on both sides of the spool cap (15), and remove the spool cap cover.

5. Insert the two ends of the line of the new spool (33) through the line outlet loop (32).
6. Place the spool (33) into the spool cap (15) and allow the cover to latch back into the spool cap (15).
7. Screw the spool cap (15) anticlockwise back onto the uptake spindle (31). Remove the Allen key (17).
8. Pull on both ends of the line to release the lines from the grooves.
9. Trim the thread line to approx. 15 cm to release strain on the engine when starting and warming up.

i

The washer (35), clamping disk (36) and nut (37) are not required

for mounting the spool.

E

Mounting/replacing the blade

Risk of injury! Caution - sharp edges!

Wear gloves.

1. Switch off the motor and remove the battery from the device.
2. Place the device on the ground in a stable position.
3. Place the 2-tooth blade (16) onto the uptake spindle (31). The blade can be used on both sides.
4. Fasten the blade using the multifunction key (18) and the washer (35), clamping disk (36) and nut (37).
5. Remove the Allen key (17).

Initial start-up

Before operating the device, you must

- Insert both rechargeable batteries,

- Put the shoulder strap on

Caution! Risk of injury! Do not use the device without the protective cover. Wear appropriate clothing as well as eye and hearing protection when working with this device.

Prior to each use, ensure that the machine is working correctly. The on/off switch and the switch lock must not be locked. After releasing the switch, you must turn off the motor. Do not use the device if a switch is damaged.

Observe noise protection rules and other local regulations.

Removing/inserting the battery

1. To remove the battery (20) from the device, press the release button (19) on the battery and pull the battery (20) out.

2. To insert the battery (20), push the battery (20) along the guide rail into the device. You will hear it click into place.

Charging the battery

If warm, allow the battery to cool before charging.

Charge the battery (20) when only the red LED on the charge level indicator (14) is illuminated.

1. If necessary, remove the battery (20) from the device.
2. Slide the battery (20) into the charging slot of the charger (21).
3. Plug the charger (21) into a socket.
4. Once charging is complete, disconnect the charger (21) from the mains supply.
5. Remove the battery (20) from the charger (21).

Putting the shoulder strap on

Always wear the shoulder strap when working with the device. Always turn the device off before taking off the shoulder strap. Accident hazard. The shoulder strap is equipped with a quick release device so that the device can be released quickly from the shoulder strap in a dangerous situation.

1. Put the shoulder strap (22) on.
2. Adjust the length of the strap so that the snap hook is approximately 10 cm below your hip.
3. Attach the snap hook to the eyelet (12) on the shaft tube of the device. Unhook the device before starting the engine and fasten it to the carrying harness once the engine is running. Place the body protection on your hip between your body and the device.

Switching on and off

The device may only be used with two batteries of the Parkside X 20 V Team series.

Ensure your stance is stable and hold the appliance tightly with both hands and away from your body.

GB IE

Before switching the device on, make sure that it is not touching any objects.

1. To turn the device on, press the switch lock (11) and then press the on/off switch (10).
2. Release the switch lock again.
3. To turn it off, release the on/off switch (10). The device cannot be switched to continuous operation.

After the device has been switched off, the cutting unit continues to rotate for some time. Allow the cutting unit to come to a complete stop. Keep hands and feet at a safe distance! Risk of injury!

Remove grass cuttings regularly from the spool cap to make sure that cutting is not impaired.

Speed control

You can vary the speed by pressing the button (9).

The current selection is indicated by the illumination of the small light.

$$ \text { h i g h } = 7 0 0 0 \min ^ {- 1} $$

$$ \mathrm{med} = 5 5 0 0 \mathrm{min} ^ {- 1} $$

$$ \text { low } = 4 6 0 0 \min ^ {- 1} $$

The device switches to ECO mode when the mounted tool is not under load. This reduces the motor speed. When loaded, the device automatically switches back.

Operation

Checking the charge status of the batteries

The battery charge level indicator (12) shows the state of charge of the battery (20).

Press the button (13) for the charge level indicator on the device. The charge level of the battery is indicated by illumination of the corresponding LED lights (3 LEDs per charge level indicator).

3 LEDs illuminated (red, orange and green): Battery charged

2 LEDs illuminated (red and orange): Battery partially charged

1 LED illuminated (red): Battery needs to be charged

Charge the battery (20) when only the red LED on the charge level indicator (14) is illuminated.

Working instructions

Work safely, giving due consideration to the next steps!

• When strimming, pay attention to country-specific regulations and/or those of your local municipality.
• Do not do strimming work during general rest periods.
• Solid items such as stones, metal parts and similar are to be removed. These can be ejected and lead to personal injury or damage to property.
• When strimming high bushes or hedges, the working height should be at least 15cm. This means that animals like hedgehogs are not put at risk.

• Always hold the device tightly and securely with both hands!
- Only cut grass and weeds! Watch out for roots or tree stumps, there is a risk of tripping.
• Work carefully and do not endanger anyone while you are strimming.
- You should only work in good lighting conditions with sufficient visibility!
- Keep an eye on the cutting head!
• Never trim above shoulder height!
- Never replace the plastic cord with steel wire - risk of injury and destruction!
• Never work on a ladder!
• Only work on firm and stable surfaces!
- Avoid an abnormal work posture. Ensure that your footing is secure and keep your balance at all times.
- Change your working position at regular intervals in order to prevent becoming tired on one side of your body.
- If the cutting head becomes jammed, turn the device off immediately, remove the spark plug connector and then remove the cause of the blockage.

Adjusting the shoulder strap eyelet/balancing out the device

Select the correct position for the shoulder strap eyelet for the spool and blade. Without touching it by hand, the device attached to the shoulder strap should be as follows

① The spool should rest lightly on the ground.

② The blade should be balanced around 20 cm above the ground.

1. Loosen the screw on the shoulder strap eyelet (12). Slightly tighten the screw again.
2. Depending on the cutting tool, balance the device according to the criteria mentioned above by moving the eyelet (12) along the upper shaft tube (3).
3. Tighten the screw when the device is in the desired position.

Working using the thread spool

• In small grass areas hold the device at an angle of about 30^ and swing the cutting head evenly to the right and left with a semi-circular movement.
• The best results are obtained with a maximum grass length of 15 cm. If the grass is taller, it is recommended to mow several times.
• To cut around trees, fence posts or other obstacles, slowly move the device around the obstacle and cut with the thread ends.
• Avoid any contact with fixed obstacles (rocks, walls, picket fences, etc.). The thread would wear out quickly. Use the edge of the protective cover to keep the device at the correct distance.

Attention! Do not lay the cutting head on the ground during operation!

Extending the line

Your device is equipped with a dual-line auto-tap feature, i.e. the two strings are extended when you tap the cutting head on the ground.

1. Hold the device in operation over a grassy area and lightly tap the cutting

GB IE

head a few times on the ground. This causes the thread to lengthen.

1. The line cutter (26) inserted into the protective cover (7) cuts the line to the desired length.

If the line ends cannot be lengthened:

• Turn off the device.
• Press the spool insert as far as it will go and pull firmly on the end of the string.

If no line ends are visible:

- Replace the spool (see chapter on 'Replacing/mounting the spool').

Attention! Thread remnants can be projected and lead to injuries.

Working with the 2-tooth blade

Always wear the shoulder strap and suitable protective clothing when working with the device. Wear eye, hearing and head protection.

Ensure that the blade is installed correctly. Replace damaged or blunt tool parts.

There is a risk of injury.

Only use the cutting blade to work on open, even areas. Carefully inspect the area to be cut and remove all foreign bodies. Avoid hitting stones, metal or other obstacles. The blade can be damaged and there is a risk of kickback by the device.

• When working, hold the cutting head above the ground and slowly swivel the device back and forth like a scythe in an equal arch.
• Do not hold the cutting head at an angle.
• Do not use the device to cut wild growth or brushwood.
• Regularly check the blades for damage and replace as needed.

Recommended speed settings: low/med: Grass / Lawn high: Scrub / Thicket

If the device vibrates

Clean the device and remove any grass residue in the cutting head and protective cover (see the chapter on 'Maintenance and Care')

Cleaning and maintenance

Warning! Risk of injury from moving dangerous parts!

Contact our Service Centre about repairs and servicing not described in this manual. Only use OEM parts. Risk of injury!

Turn off the appliance and, before doing any servicing, remove the battery.

The following cleaning and servicing should be done regularly. This will ensure a long and reliable service life.

Cleaning

Do not spray the appliance with water and do not immerse it in water. Electric shock hazard!

• Keep clean the ventilation slots, motor housing and handles of the appliance. Use a damp cloth or a brush. Do not use cleaning agents or solvents. You may otherwise irreparably damage the appliance.
  • After every trimming session, remove grass and soil from the protective cover and the trimming assembly.
• Be careful with the line cutter. It can cause serious lacerations.

Winding up the spool

As an alternative to a new spool, you can purchase a 2.4 mm-thick, 5 m-long nylon thread in specialist shops and wind this yourself onto the spool.

1. Pull the new line through both line outlet loops (32) of the spool cap (15).
2. Make a longitudinal adjustment with both ends of the line so that the spool cap (15) is positioned at about the centre.
3. Turn the rotary knob (15a) in the direction of the arrow indicated on the bottom of the spool cap (15) to wind the line onto the spool (33).

General maintenance work

- Check the appliance before each use for obvious defects such as loose, worn or damaged parts.

- Check the covers and protective devices for damage and correct fi t. Replace these if necessary.

Check the line cutter (26). Never use the device without a line cutter or with a defective line cutter. If the line cutter is damaged, be sure to contact one of our customer service centres.

Removing blockages

Switch the device off and remove both batteries before you work on the cutting unit.

Wear protective gloves in order to avoid cutting yourself.

Transport

• When it is being transported, the device must be switched off and the batteries removed.
• Carry the device with one hand on the upper shaft tube and the other hand on the lower shaft tube (3+6), in order to avoid coming into contact with dangerous parts when transporting it (e.g. hot engine, cutting unit).
• When transporting the blade, use the transport protection.
• Maintain a safe distance from other people when transporting the device.

Storage

• Store the trimmer in a dry place well out of reach of children.
• Do not stand the trimmer on its protective cover. Suspend it by its upper handle in such a manner that the protective cover does not come into contact with other objects. This is because the pro-

GB IE

tective cover could become deformed, thereby changing its dimensions and its safety properties.

- The storage temperature for the rechargeable battery and the device is between 4 °C and 40 °C. Avoid extreme cold or heat during storage to ensure the battery output is not adversely affected.

Disposal and protection of the environment

Remove the rechargeable battery before disposing of the device.

The device, accessories and packaging should be properly recycled.

Instruction on how to dispose of the rechargeable battery can be found in the separate instruction manual for your battery and charger.

Machines do not belong with domestic waste.

• Return the unit to a recycling centre. The plastics and metals in the unit can be sorted and appropriately recycled. Ask our Service Centre for details.
• Defective units returned to us will be disposed of for free.
• Throw the cut grass on the compost. Do not throw it in the normal household waste.

Replacement parts/Accessories

Spare parts and accessories can be obtained at www.grizzlytools.shop

If you have issues ordering, please use the contact form. If you have any other questions, contact the "Service-Center" (see page 53).

Position Position Description Order No. instruction exploded manual drawing

7 44-47 Protective cover 91106170
15+33 48 Spool cap + Spool 13800235
16 49 2-tooth blade	13800234
22 Shoulder strap	91106171

Trouble shooting

In the event of an accident or malfunction, remove the battery from the device immediately! Failure to comply may result in injuries from cuts.

Problem Possible cause Corrective action
Appliance won't start	Battery (20) discharged	Recharge battery (20) (Observe the separate operating instructions for the rechargeable battery and charger)
	Battery (20) not in	Insert battery (20) (Observe the separate operating instructions for the rechargeable battery and charger)
	On/Off switch (10) defective	Send in to Service Centre for repair
	Motor defective
Intermittent operation	Internal loose contact	Send in to Service Centre for repair
	On/Off switch (10) defective
Much vibration Loud noise	Trimming assembly dirty	Clean trimming assembly (see „Cleaning and maintenance”)
	Motor defective Send in to Service Centre for repair
Bad trim	The line spool (33) does not have enough cutting line	If necessary, extend the cutting line (see chapter “Device adjustments”)Replace the spool (see “Cleaning and Maintenance”).
	Both or one of the cutting line is not protruding out of the spool (15)	Remove the spool and feed the cutting line through the openings to the outside, then reinstall the spool.
	Trimming assembly dirty	Clean trimming assembly (see „Cleaning and maintenance”)
	Battery (20) not fully charged	Recharge battery (20) (Observe the separate operating instructions for the rechargeable battery and charger)

Guarantee

Dear Customer,

This device comes with a 5-year warranty from the date of purchase.

In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.

Terms of Guarantee

The warranty period begins upon the date of purchase. Please retain the original receipt. This documentation will be required as proof of purchase.

If a material or manufacturing defect occurs within five years from the date of purchasing of this product, the product will be repaired or replaced by us for free – according to our choice. This warranty service requires you to present the defective device and proof of purchase (sales receipt) within five years and describe briefly in writing the nature of the defect and when it occurred.

If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The equipment has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery.

The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts (e.g. spool, blade) or to cover damage to breakable parts (e.g. switch).

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.

The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improper handling, use of force, or interventions not undertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure quick handling of you issue, please follow the following directions:

- Please have the receipt and item number (IAN 376667_2104) ready as proof of purchase for all enquiries.

- Please find the item number on the rating plate.

- Should functional errors or other defects occur, please initially contact the service department specified below by telephone or by e-mail. You will then receive further information on the processing of your complaint.

- After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and

specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the equipment inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

Repair Service

For a charge, repairs not covered by the guarantee can be carried out by our service branch, which will be happy to issue a cost estimate for you.

We can handle only equipment that has been sent with adequate packaging and postage.

Attention: Please send your equipment to our service branch in clean condition and with an indication of the defect.

Equipment sent carriage forward or by bulky goods, express or other special freight will not be accepted.

We will dispose of your defective devices free of charge when you send them to us.

Service-Center

GB Service Great Britain Tel.: [phone]

E-Mail: [e-mail]

IAN 376667_2104

IE Service Ireland Tel.: [phone]

(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))

E-Mail: [e-mail]

IAN 376667_2104

Importer

Please note that the following address is not a service address. Please initially contact the service centre specified above.

Service-Center......82

Importateur 82

(L_pA) 68,0 dB(A); K_pA = 3 dB

Service-Center......106

Importeur 106

1 led brandt (rood):

Service-Center......129

Importer 129

(L_pA) 68,0 dB(A); K_pA = 3 dB

(L_nA) 68,0 dB(A); K_nA = 3 dB

Service-Center......174

Dovozca....174

1 Apparathoved
2 Nøglehulsboring

3 øverste skaftrør

(L_pA) 68,0 dB(A); K_pA = 3 dB

Lydeffektniveau (L _WA )

garanteret 90 dB(A)

målt......88,0 dB(A); K_WA=1,91 dB

Temperatur ...... maks. 50 °C

Opladning 4 - 40 °C

Drift....-20 - 50 °C

Opbevaring 0-45 °C

Service-Center......220

Importador 220

(L_pA) 68,0 dB(A); K_pA = 3 dB

We hereby confirm that the 40V Cordless brush-cutter, PPFSA 40-Li A1 series Serial number 000001 - 055120
conforms with the following applicable relevant version of the EU guidelines:
2006/42/EC • 2014/30/EU2000/14/EC & 2005/88/EC2011/65/EU* & (EU)2015/863
In order to guarantee consistency, the following harmonised standards as well as national standards and stipulations have been applied:
EN 60355-1:2012/A2:2019 • EN 62841-1:2015EN ISO 11806-1:2011 • EN 50636-2-91:2014EN 55014-1:2017/A11:2020 • EN 55014-2:2015 • EN IEC 63000:2018
We additionally confirm the following in accordance with the 2000/14/EC emissions guideline:Sound power level:Guaranteed: 90 dB(A)Measured: 88,0 dB(A)Compliance evaluation process carried out in accordance with Appendix VI, 2000/14/ECRegistered Office: TÜV SÜD Industrie Service GmbH,Westendstrasse 199, 80686 München, Germany (NB 0036)
This declaration of conformity is issued under the sole responsibility of the manufacturer:
CE Grizzly Tools GmbH & Co. KGStockstädter Straße 2063762 GroßostheimGermany10.12.2021	Christian FrankDocumentation Representative

* The object of the declaration described above satisfies the provisions of Directive 2011/65/EU of the European Parliament and the Council of 8 June 2011 on limiting the use of certain harmful substances in electrical and electronic appliances.

IAN 376667_2104
