USER MANUAL G280 LOTUSGRILL

DEU Komponentenliste 1 x Grill Grid 1 x Charcoal Container Cover 1 x Charcoal Container 1 x Ignition Plate 1 x Inner Bowl 1 x Outer Bowl with integrated Battery Case 2 x Latch 1 x On/Off Switch for Heat Regulation with Light Indicator 4 x Battery AA 1,5V DC 1 x Battery Case Cover 1 x Plug-in connector 1 x USB power cable 1 x Carrying Bag 1 x Instruction Manual

einsatzbereit. Um die Hitze zu regulieren, benutzen Sie den Wärmerregler (8) . Der Lüfter bleibt während dem gesamten Grillvorgang angeschaltet. Montage und Gebrauchsanweisung Deutsch 9* Jede normale Holzkohle ist verwendbar. Briketts bringen keine optimale Ergebnisse. WICHTIG VORSICHT VORSICHT DEU WICHTIG Verwendung des USB-Stromkabel Der LotusGrill kann wahlweise mit Batterien oder mit dem mitgelieferten USB-Stromkabel und einem USB-Netzteil (nicht im Lieferumfang) betrieben werden. Sobald der runde Stecker im Grill eingesteckt wird, wird das Batteriefach abgekoppelt. Das USB-Stromkabel kann nicht zum Auaden wieder auadbarer Batterien oder Akkus verwendet werden.Technical Data G280 G340 G435 Weight (approx) 2,8 kg 3,7 kg 6,5 kg Main Dimensions (approx) top Ø 292 mm bottom Ø 220 mm height 210 mm grid Ø 258 mm top Ø 350 mm bottom Ø 260 mm height 234 mm grid Ø 320 mm top Ø 435 mm bottom Ø 350 mm height 257 mm grid Ø 405 mm Material Steel and shock-resistant plastics, Grill grid. Inner bowl, charcoal container and latches: stainless steel. Operated with 4 x 1.5 VV batteries (6 Volt). INSTRUCTION MANUAL 10 Instruction Manual - Do not use spirit or petrol for lighting or re-lighting! - Risk of burns! - Risk of suffocation! - Do not use indoors! - Use only relighters complying to EN 1860-3! - Keep the grill away from children and animals! - Wear gloves when touching the hot grill grid. - Replace batteries only when grill is completely cooled down. - Let the grill cool off entirely before cleaning. - Never pour water into the charcoal container in order to extinguish the charcoal. - The bbq must be placed on a stable support before use. - Use barbecue tongs. We recommend LotusGrill Accessories. - Never leave the hot grill unattended. - When grilling very fatty foods, ensure that the inner bowl is emptied on a regular basis. - Test the batteries each time before ring the grill. - Do not replace exhausted batteries while using the grill. Be attentive! Inaccurate use could cause damage to material. Inaccurate use could cause heavy injuries or even lethal outcome. Inaccurate use could cause small injuries or damage to material. Important symbols and precautionary measures Safety information IMPORTANT IMPORTANT CAUTION Introduction Before using the Charcoal Table Grill for the rst time, read the manual thoroughly. Keep the manual for your reference during the complete product life and pass it on to any other grill users. CAUTION ATTENTION WARNING ATTENTION WARNING ENGThe LotusGrill may be used to grill meals using charcoal. Do not use this grill in unventilated spaces. All guidelines provided in this manual must be observed. The LotusGrill grill is intended for private use only! Intended Use Read the assembly instructions carefully and follow the safety information. Be sure to have enough time at your disposal. Create ample space. Remove grill from packaging! Assembly: General Information Secure handling and disposal of used batteries Please note: Only use commercially approved AA-batteries. Remember to dispose batteries properly according to local regulation, i.e. at a battery collection point. Batteries may not be disposed with domestic waste. English 11 Proper disposal of charcoal Dispose charcoal in proper non-combustible or metal containers only. Do not dispose in plastic or inammable containers. Environmentally friendly disposal of electrical equipment Please dispose your old grill at proper collection points, which the manufacturer can point out to you at request. Do not dispose your old device with domestic waste. Safety information ENGThe LotusGrill has a 2-years-warranty from date of purchase against manufacturing defects, given that it was used according to instructions of use. For proof of warranty, please retain your sales receipt with indicated date of purchase. Abrasion, rust, deformation or staining of parts exposed directly to ame (especially stain- less steel parts) are normal wear after use and are under no circumstance considered to be manufacturing defects. The charcoal container is a wearing part and should be changed from time to time. Warranty Check list of components and chart to make sure all items are included in delivery: - Remove the pre-assembled grill grid and charcoal container. - Take off packaging. Assembly: Preparation The Charcoal Container may contain a thin oil lm on the metal, due to its production process. This oil can cause smoke only in the rst use. First Use 12 Instruction Manual Maintenance and Storage The grill must cool off completely before cleaning. Do not use water to cool off the hot grill. Burns and scalding might occur. Clean grill grid, inner bowl and other dirty parts after each use. The grill must cool off entirely before cleaning, otherwise burning injuries might occur. Grill grid and inner bowl are dishwasher safe or can be cleaned with standard washing-up liquid. We recommend for cleaning of tenacious residues commercially available barbecue cleaners e.g. the LotusGrill Cleaner for BBQ- and Oven. Clean outer bowl (containing electronic unit) only with wet cloth or brush. Do not use acidic, solvent or other ammable liquids. Remove batteries during a longer period of storage. The charcoal container may be cleaned only dry, e. g. with a brush. IMPORTANT ATTENTION Never use water to clean the charcoal container! CAUTION ENGAssembly

Open the battery case (10) at the bottom of the outer bowl (6) . Insert four AA batteries (9) . Mind polarity. Close the battery case.

2. Place the inner bowl

(5) into the outer bowl (6)

(3) completely with charcoal e. g. LotusGrill Beech Charcoal* Put cover on charcoal container (2)

(4) , approx 10 mm (0.4 inches) wide. Place ignition plate (4) into inner bowl (5) . We recommend the LotusGrill Safety Fuel Gel.

5. Turn the round ventilation control button

(8) on outer bowl (6) on. Turn it clockwise to maximum position. In order not to quench the ame, the ventilation needs to be turned on. Do not touch the ame!

6. Light gel until it burns.

(2) on the lled charcoal container (3) and place container on ignition plate (4) . Within a short period of time, the charcoal will be glowing. Place the charcoal container carefully and evenly on the ignition plate!

8. Put the grill grid

(1) on top of the inner bowl (5) . Make sure to insert the four metal legs into the slots of the inner bowl (5) . Both metal loops at the side of the grill grid (1) have to be aligned with the latches (7)

9. Hook the latches into the metal loops, and pull down to lock the device. The grill is now a

connected and compact unit.

10. After approx. 3-4 minutes, LotusGrill is ready for use. Use the On/Off Switch for heat

regulation (8) to regulate heat. The fan stays on during the entire barbecue session. Assembly and Operation Instructions English 13 IMPORTANT IMPORTANT

10. Na circa 3-4 minuten is de LotusGrill

• Even heat distribution over the entire cast grill grid

• The healthy way to barbecue since it drains away any dripping grease

• Grease ca not drip on the charcoal, lowest possible smoke development

• The grill is easier to clean since the grease is drained away

• Easy-to-clean thanks to the high-quality non-stick coating

• Compatible with LotusGrill accessories, e.g., glass hood and grill hood Cast Grill Grid For health-friendly grilling
