USER MANUAL TOWER2000 PTC Soler & Palau

• Para aclarar cualquier duda con respecto a los productos S&P diríjase a la Red de Servicios Post Venta si es en territorio español, o a su distribuidor habitual en el resto del mundo. Para su localización puede consultar la página WEB www. solerpalau.com EL FABRICANTE NO SE HACE RESPONSABLE DE LOS DAÑOS PRODUCIDOS A PERSONAS Y/O COSAS DEBIDOS AL IN- CUMPLIMIENTO DE ESTAS ADVERTENCIAS. S&P SE RESERVA EL DERECHO A MODIFICACIONES DEL PRODUCTO SIN PREVIO AVISO.7 ENGLISH ENGLISH Please read these instructions carefully before using this heater in order to avoid damage or any dangerous situations arising. Any use of the product other than that indicated in this manual may cause fi re, electrical danger, or injury and will make the warranty null and void. The warranty does not cover any defect, deterioration, loss, injury, or damage that is due to incorrect use of the product. All legal rights in this regard are guaranteed. No warranty condition can exclude or change the warranty conditions regulated by State laws that may not be excluded or modifi ed for any reason. Before doing anything else, remove the packaging carefully and check the integrity of the product. Should any defects or damage be found, do not use or attempt to repair the equipment, but contact the dealer. Do not leave the packaging within reach of children and dispose of the parts in compliance with current provisions.

1. SAFETY INSTRUCTIONS

• Make sure the power supply corresponds to the details shown on the nameplate.

• This product has been designed as a mobile ceramic heater.

• Flammable objects (curtains, furniture, plants, ...) should not be placed at less than 1 meter from the appliance.

• The heater must not be placed in a recessed place (under a table, desk, …) where it interferes with the free circulation of air, both the inlet and outlet.

• The heater should not be placed immediately under a base of power point.

• Do not use this heater near a bath, shower or a swimming pool.

• Do not use the product in rooms fi lled with explosive gases or vapours generated by solvents and paints or that are infl ammable.

• Do not insert any rigid body through the grilles, this could damage the heater, start a fi re or electric shock.

• Never leave your home with the product still running. If you do go out make sure that the switch is off.

• The device has high surface temperatures, which must not be touched, even after it has been switched off.

• CAUTION: Some parts of this product may be become hot and cause burns. Particular attention should be when children and vulnerable people are present.

• WARNING: In order to avoid overheating, do not cover the heater.

• Children of less than 3 years should be kept away unless continuously supervised.

• Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

• Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

• Children should not play with the product.

• Before carrying out any maintenance work, or during long periods without use, make sure that the device has been disconnected from the mains.8 ENGLISH

• Do not clean the product while it is working and do not immerse it in water.

• Do not handle the heater with wet hands.

• Do not coil the power cable around or on top of the product while it is working.

• If the cable gets damaged it must be replaced by S&P – take the equipment to our offi cial S&P because the work must be done by specialist personnel to avoid any risk of damage.

• The heater must always work vertically, with the controls at the top and the base located on a stable surface.

Description of the product (Figure 1): A LCD screen B Control panel C Ceramic heater element (PTC) D Base oscillation E Safety tilt switch F Feet main switch G Remote control H Receiver remote control - Transport handle - Input air fi lter

3. USE AND OPERATION

• Before connecting the product to the power, make sure that it is located on a stable fl oor and has a fi rm vertical position. Remember that as a safety feature, the product incorporates a safety tilt switch under the base (Fig.1 D-E).

• You can control the ceramic heater through the control panel (Fig.1B) or with the remote control (Fig.1G).

POWER The product has two on and off switches. One is generally located at the base of the appliance (Fig.1F) and the other in the control panel / remote control. To operate the device, both must be on. IMPORTANT: To preserve the life of the heating element (Fig. 1C), the appliance incorporates an automatic cooling sys- tem, so that when you disconnect the appliance using the POWER button of the control panel/ remote control, the fan continues to run for 30 seconds. Do not unplug the heater by directly acting on the main foot switch (Fig.1 F) or pulling the power cable.

MODE You can select up to 3 different operating modes: – FAN mode: Fan cold air. – LOW-HIGH Mode: Manual selection of the heater power. Low : 1.000 W High : 2.000 W The heater works to continuously selected power, regardles of the room temperature. – AUTO Mode: The power heater is self-adjusted automatically depending on the room temperature. When you select this operating mode, using the +/- keys can be programmed (SET) the desired temperature in the room (+15 ~ +35ºC). When the room temperature approaches the comfort temperature programmed by the user, the heater will automatically regulate the power while constantly maintaining temperature in the room. Remember that the comfort temperature is between 21-22ºC.9 ENGLISH Note: The LCD screen shows the real temperature of the room (ROOM TEMPERATURE).

TIMER You can set the heater operating time in fractions of ½ hour, upto a total of 8 hours. Once the time has elapsed, the heater will stop automatically.

OSC You can increase the area of air projection (hot/cold) oscillating the appliance. Note: Make sure the power cable is not twisted between the base and the oscillating body.

• Before carrying out any maintenance work, make sure that the device has been disconnected from the mains and let the heater cool down for a few minutes.

• Periodically, to prevent accumulation of dust, remove the fi lter support of air inlet (posterior part) acting on the two relea- se tabs. Clean the fi lter with cold water and let dry. Once dry, put it down again with your support. Then clean the rest of the appliance and air outlet grille, with a cloth dampened with water. Do not use detergents or abrasive products.

• Do not immerse the device or spray with water.

• If the appliance is not to be used for any length of time, we recommend returning it to its original package and storing it in a dry, dust-free place.

5. RELEVANT INFORMATION FOR THE DISMANTLING, RECYCLING OR ELIMINATION OF THE PRODUCT

AT THE END OF THE USEFUL LIFE In the case of scrapping the appliance, the provisions corresponding to the disposal or recycling of the materials and com- ponents must be respected. List of the main heater materials:

• Internal and external laterals of ABS PC plastic.

• Electronic plates with tin.

• Heating element (aluminium and ceramic).

EEC legislation and our consideration of future generations mean that we should always recycle materials where possible; please do not forget to deposit all packaging in the appropriate recycling bins. If your device is also labeled with this symbol, please take it to the nearest Waste Management Plant at the end of its ser- vicable life.

7. TECHNICAL ASISTANCE

• S&P’s large Technical Service network will guarantee satisfactory technical assistance.

• If a fault is observed in the unit, please contact any of the mentioned technical service offi ces and they will attend to your problem.

• Any modifi cation of the appliance by personnel not belonging to the Offi cial S&P Services will result in your guarantee being void.

• For any queries regarding S&P products please contact any branch of our After Sales Service network if you are in Spain, or your regular dealer in the rest of the world.
