Product type	Smoke machine with LED lighting
Brand	Ibiza Sound
Model	SPRAYCOLOR1000
Power supply	220-240 V~, 50/60 Hz
Power	1000 W
Fuse	8 A
Heating time	3 to 5 minutes
Max continuous operation time	15 to 20 seconds
Max smoke jet height	Approximately 5 to 8 meters
Smoke volume	850 m³ (estimated)
LED lighting	12 x 3 W RGB, with sound and strobe modes
Tank capacity	1.2 L
Weight	4.2 kg
Dimensions (L x D x H)	290 x 230 x 170 mm
Remote controls	Wired (with red button) and wireless (with receiver)
Channels (wireless remote)	7 channels
Battery for wireless remote	Alkaline E23A / 12 V (not included)
Package contents	Machine, wired remote, wireless remote, power cable, manual
Recommended liquid	High density smoke liquid IBIZA LIGHT (ref. 15-1017)
Regular cleaning	Every 40 hours of use: mixture of 80% distilled water + 20% white vinegar
Usage precautions	Do not direct smoke towards people; keep a safety distance of 5 meters

Frequently Asked Questions - SPRAYCOLOR1000 IBIZA SOUND

How to use the wireless remote control?

Plug the receiver into the WIRELESS REMOTE CONTROL jack. Use the buttons: 1 to produce smoke, 2 to turn on the LEDs, 3 for sound/strobe mode, 4 to change LED colors.

How to fill the smoke liquid tank?

First unplug the machine from the mains. Unscrew the tank cap and fill using a funnel. Do not pour liquid inside the device. Use only high quality smoke liquid.

What to do if the machine does not produce smoke?

Check that the machine is plugged in and that the heating time (3-5 min) has elapsed. Make sure the tank contains enough liquid. If the LED on the wired remote is off, the machine is heating. If it does not light up, check the fuse (8A) and replace if necessary. If the problem persists, contact your dealer.

How to clean the smoke machine?

After 40 hours of use, clean the heating element with a mixture of 80% distilled water and 20% white vinegar. Disassemble the front nozzle and clean it with vinegar. Fill the tank with the mixture and run the machine until empty. Then fill with smoke liquid and use it outdoors to eliminate vinegar odors.

What liquids can be used in the machine?

Use only high quality smoke liquids specifically designed for smoke machines. We recommend the high density smoke liquid IBIZA LIGHT (ref. 15-1017). Never add flammable liquids (oil, gas, perfumes) as they are dangerous.

Can you direct smoke directly at people?

No, it is forbidden to direct smoke directly at people. The smoke can reach a temperature of 40 to 80°C and cause burns. Always maintain a safety distance of at least 5 meters.

What safety distance should be observed?

Place the machine at least 1 meter from any flammable material (curtains, books, etc.) and more than 3 meters from any flame or flammable surface. During use, keep a safety distance of 5 meters from people.

How to replace the battery of the wireless remote?

Place the remote face down. Push the compartment cover in the direction of the arrow to open it. Remove the old battery and insert a new alkaline battery 23A 12V respecting polarity. Close the compartment until it locks.

What to do in case of smoke liquid leakage inside the machine?

Immediately unplug the machine from the mains. If liquid or moisture gets inside, do not use it and contact your dealer. The machine is not waterproof; avoid any liquid contact with internal components.

How to store the machine after use?

After each use, empty the tank and remove the tank hose. Press the remote to evacuate any remaining liquid from the conduits. Clean the machine with a soft cloth. Store it in a dry place away from dust and extreme temperatures.

USER MANUAL SPRAYCOLOR1000 IBIZA SOUND

WITH LED & REMOTE CONTROLS 1000W

Ref.: SPRAY-COLOR-1000

Code: 16-2074

Black industrial air conditioning unit with control panel, display unit, and sensor device (no visible text or symbols)

MANUAL

EN- Instruction Manual - p. 2

PLEASE READ THE MANUAL CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.

AFTER EACH USE, REMOVE THE HOSE FROM THE TANK AND PRESS THE REMOTE CONTROL TO SPRAY FOG UNTIL ALL FOG FLUID HAS BEEN REMOVED FROM THE CONDUITS! FAILURE TO DO SO WILL CLOG THE MACHINE!

UNPACKING INSTRUCTIONS

Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present and have been received in good condition. Notify the freight company immediately and retain packing material for inspection if any parts appear to be damaged from shipping or the carton itself shows signs of mishandling. Keep the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing.

CONTENTS OF THE CARTON

• 1 pc. SPRAY-COLOR-1000
• 1 pc wired remote control
• 1 pc wireless remote control
- 1 pc. user manual
- 1 pc. power cable

EXPLANATION OF SYMBOLS ON THE SILKSCREEN

The triangle containing a lightning symbol is used to indicate whenever your health is at risk (due to electrocution, for example).

An exclamation mark in a triangle indicates particular risks in handling or operating the appliance.

The unit complies with UK standards

For indoor use only

Keep a safety distance of at least 1m from walls or any other inflammable objects and/or surfaces

Protection class I. Requires an earth connection

CAUTION DO NOT OPEN THE HOUSING SHOCK HAZARD

Please read this manual carefully before operating this product.

IMPORTANT SAFETY INSTRUCTIONS AND DANGER WARNINGS

• The smoke machine must be placed at least 100 cm away from flammable materials such as curtains, books, etc. Ensure that the cabinet cannot be accidentally touched.
• Do not block the openings on the top of the cabinet to ensure good ventilation. The smoking machine's heating element generates heat that must be dissipated. Don't place anything on top of the machine.
• For indoor use only.
• Have the unit checked by a qualified person before first use.
• The unit contains live parts. DO NOT open the fog machine.
• If the unit is damaged, do not connect it to the mains.
• Only connect this unit to a 220-240Vac 50/60Hz mains supply with a protective earth connection.
• Always unplug the unit during lightning storms or when not in use.
  • To avoid accidents in public places, comply with local laws and safety regulations/warnings.
• Keep out of the reach of children.

• Take care when filling the fluid reservoir. First unplug the power cord. Then unscrew the tank cap and fill the tank using a funnel.

- Choose a location where the tank is easily accessible.

- Place horizontally, don't tilt the machine and don't place it upside down.

- The machine is not waterproof. If moisture, water or fog fluid enter the machine, switch off the power and contact your distributor.

- There are no spare parts inside the unit. If you need to repair it, please contact a dealer or a professional repair shop.

- Don't spray directly at people or fire.

- The temperature of the fog is very high, so keep a distance of more than 300cm (40°C-80°C) between the machine and any other material.

- Do not expose the appliance to dripping or splashing water and do not place objects filled with liquids, such as vases, on the appliance.

• The machine should only be used in temperate climates.

- Do not add flammable liquids such as oil, gas, perfume, etc. to the fog machine.

- Observe all warning signs and operating instructions on all equipment.

• Empty the tank before moving it.

- Do not drink fog liquid, otherwise seek medical advice immediately. Use clean water to wash skin and eyes if fog liquid has come into contact with them.

DISCONNECT DEVICE: The power outlet must be installed near the equipment and be easily accessible.

IMPORTANT NOTES

- Before filling the fog liquid, please unplug the unit from the mains.

- In order to prevent short circuits, please don't let fog liquid flow into the inner part of the machine before filling, you can also take out the liquid bottle and fill in the fog liquid outside the unit.

- The fog machine must be installed on the ground. It's not allowed to slope the unit or place it upside down

• After use, switch the fog machine off and unplug it from the mains

- The fog machine isn't waterproof. If moisture or fog liquid enters inside the machine, you must unplug it immediately from the mains and contact your dealer.

- It's forbidden to spray directly towards persons. Keep far away from flammability and explosive objects

- The fog spray is very hot, please keep a distance of at least 5 meters when using it

- Please don't touch the surface of the fog machine during the use because the housing will reach 40-80°C

- When the machine doesn't work, please check if the fuse is burnt out or not. If it is, replace it by an identical fuse, find out the fault and restart the machine. But please note: the repair must be handled by professional.

OPERATION

WIRELESS REMOTE CONTROL

Plug the supplied receiver into the WIRELESS REMOTE CONTROL socket.

The buttons on the supplied wireless remote control have following functions:

1: Press to spray fog, release to stop fog
2: Press to illuminate the 2 groups of LEDs in different colours
3: Sound mode: The 2 groups of LEDs light up to the rhythm of the music. Press again to produce a strobe effect
4: Keep pressed to switch the LEDs on. At every press, the LEDs light up in a different colour. At the last press, the LEDs are switched off.

WIRED REMOTE CONTROL

When the fog machine is heating up, the LED on the wired remote control is off. When the LED lights up in red, the machine is ready for use. Press the red button to produce fog. Release the button to stop fog.

CLEANING AND USING FREQUENCY OF THE PRODUCT

AFTER EACH USE, REMOVE THE HOSE FROM THE TANK AND PRESS THE REMOTE CONTROL TO SPRAY FOG UNTIL ALL FOG FLUID HAS BEEN REMOVED FROM THE CONDUITS! FAILURE TO DO SO WILL CLOG THE MACHINE!

Please clean the fog machine periodically in order to keep it in good condition.

• The fog liquid should be clear and not polluted. The bottle cap should be screwed tightly after filling in the fog liquid.
• When the fog machine worked 40 hours continuously, please use 80% of distilled water and 20% of white vinegar to clean the impurities which accumulated inside the heating tube
• Remove the nozzle before the fog machine is warming up. Use vinegar to clean it and keep clear
• Pour out the fog liquid and fill the tank with the distilled water/vinegar mix as above. Switch on the power and the machine will warm up.
• Operate the fog machine in a well ventilated area until the distilled water/vinegar mix has been used up. Fill the unit again with fog liquid and operate it in an open space until the vinegar smell has disappeared.

• Fog machines may jam easily because of impurities in the fog liquid. Therefore, a periodical maintenance will lengthen the life time of the machine.
• Please use a dry cloth for cleaning, please clean the machine thoroughly before you store it.

SPECIFICATIONS

Voltage 220V-240V\~50/60Hz
Power 1000W
Fuse ?A
Warm up time 3-5minutes
Max. continuous operating time 15-20 seconds
Max. spray height ....Approx. 5-8m
Fog output..... Approx. 850m ^3
LED source.... 12 x 3W RGB
Remote control battery .... Alkaline E23A / 12V
Tank capacity 1.2L
Weight 4.2Kg
Dimensions 290 x 230 x 170mm

Correct Disposal of this product

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.

NOTICE D'UTILISATION

MACHINE A FUMEE A LED AVEC TELECOMMANDE

APRÈS CHAQUE UTILISATION, RETIREZ LE TUYAU DU RÉSERVOIR ET APPUYEZ SUR LA TÉLÉCOM-MANDE POUR EMETTRE DE LA FUMEE JUSQU'À CE QUE TOUT LE LIQUIDE A FUMEE AIT ÉTÉ ÉLIMINÉ DES CONDUITS ! LE NON-RESPECT DE CETTE CONSIGNE ENTRAÎNERA L'OBSTRUCTION DE LA MA-CHINE !

DÉBALLAGE

DISPOSITIF DE COUPURE

MANUAL DE INSTRUÇÕES

MANUAL DE INSTRUCTIUNI
