Nana BabyCare Digital Sterilizer - Bottle sterilizer CECOTEC - Free user manual and instructions

Product type	Digital baby bottle sterilizer
Brand	Cecotec
Model	Nana BabyCare Digital Sterilizer
Reference	01904
Power supply	220-240 V~, 50/60 Hz
Sterilization power	600 W
Drying power	155 W
Maximum capacity (bottles)	6 bottles
Capacity with teat holder	4 bottles + 2 teats or pacifiers
Operating modes	Sterilization, Drying, Automatic (sterilization + drying)
Sterilization mode duration	10 minutes (fixed)
Drying mode duration	30, 40 or 50 minutes (adjustable)
Automatic mode duration	40, 50 or 60 minutes (adjustable)
Recommended ambient temperature	15-30 °C
Recommended ambient humidity	30-80 %
Supplied parts	Sterilizer, bottle tray, teat and pacifier holder, transparent lid, tongs, measuring cup, instruction manual
Maintenance	Clean with a soft cloth. Descale with vinegar. Clean the air filter regularly.
Safety	Automatic shutdown at end of cycle, overheat protection, hot surface warning
Intended use	Household use only

Frequently Asked Questions - Nana BabyCare Digital Sterilizer CECOTEC

How many bottles can I sterilize at once?

The tray can hold up to 6 bottles. With the teat holder, you can place up to 4 bottles and 2 teats or pacifiers.

Does the Drying mode sterilize bottles?

No, the Drying mode does not sterilize. It is only used to dry freshly washed bottles. Use Sterilization or Automatic mode to sterilize.

What to do if the device does not turn on?

Check that the device is plugged into a working outlet and that you have pressed the on/off icon. If the problem persists, contact customer service.

Can I adjust the duration of Sterilization mode?

No, the duration of Sterilization mode is fixed at 10 minutes (2 minutes heating + 8 minutes sterilization). Only Drying and Automatic modes allow duration adjustment.

How to clean the air filter?

The filter is located in the lower part of the sterilizer. Remove the filter cover, take out the foam, and clean it with a soft brush or cloth. Put it back and close the cover. Clean it at least once a week to maintain drying efficiency.

Why is there a plastic smell during the first uses?

It is normal to smell a slight plastic odor the first few times. It disappears after a few cycles. Make sure to use the device in a well-ventilated area.

Can I use accessories not supplied?

Using accessories not recommended by Cecotec may cause fire, electric shock, or injury. Use only supplied or recommended accessories.

How to descale the sterilizer?

To remove limescale deposits, add water with a little vinegar on the heating base, let it sit for 10 minutes, then run a sterilization cycle without accessories. Then clean with a soft cloth.

What to do if the duration does not change when I press the icon?

Make sure you press the mode icon (Sterilization, Drying, or Automatic) and not the time indicator. Time adjustment is only available for Drying and Automatic modes.

Does the device turn off automatically?

Yes, at the end of each cycle, the device emits a sound signal and returns to Standby mode. You must press the on/off icon to turn it off completely.

USER MANUAL Nana BabyCare Digital Sterilizer CECOTEC

Safety instructions 6

1. Parts and components 31
   2.Before use 31
2. Operation 32
   4.Cleaning and maintenance 34
   5.Troubleshooting 34
3. Technical specifications 35
4. Disposal of old electrical and electronic appliances 35
5. Technical support and warranty 35
6. Copyright 36

SOMMAIRE

Read these instructions thoroughly before using the appliance. Keep this instruction manual for future reference or new users.

• Keep out of reach of children. Unplug it from the power supply if you are not going to use it for a long period of time.
• Children must not play with the appliance.
• If the power cable is damaged, it must be replaced by the official Cecotec Technical Support Service or similar qualified personnel to avoid risks.
• The appliance must not be used by children. Keep the appliance and its power cable out of the reach of children.
• The first few times you use this appliance, there is likely to be a slight plastic smell, this is normal.
• This appliance can be used by people with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or appropriate instruction concerning the use of the appliance in a safe way and understand the hazards involved.
• This appliance is designed for domestic use only and is not intended for bars, restaurants, farmhouses, hotels, motels, and offices.
• Do not use outdoors.
• Never switch on the appliance if there is no water inside.
• Hot water can cause severe burns.
• Do not immerse the power cord, plug or appliance in water or other liquids.
• Warning: make sure the appliance is switched off before removing it from the base.
• Do not touch the hot surfaces of the appliance. Use gloves or oven gloves.

• Switch off the steriliser after use.

• The use of accessories which have not been recommended by Cecotec may cause fire, electric shock, or injury.

• Do not let the cable protrude over the edge of the table or worktop or come into contact with hot surfaces.
• Use the appliance on a flat, heat-resistant surface. Do not move the appliance during operation or when there is hot water inside.
• Do not place the appliance near or under a gas or electric cooker, nor place it inside an oven.
• Only connect the appliance to an earthed socket outlet. Make sure that the power cable is correctly connected to the power supply.
• First connect the cable to the appliance and then to the power socket. Switch off the appliance before unplugging it.
• A short power-supply cord is provided to reduce the risks of becoming entangled in or tripping over. Do not use a longer power cord or extension lead.
• Avoid spillage on the conductor cable.
• The surface of the heating element is subject to residual heat after use.
• In case of misuse, personal injury and/or material damage may occur.
• Keep the appliance out of the reach of babies or children.
• Unplug the power cable when not in use.
• Clean the filter at least once a week to prevent the drying effect from diminishing.

INSTRUCTIONS DE SECURITE

A. Air outlet grille
B. Heating plate

1. Touch display

A. Time indicator
B. Drying mode icon
C. Automatic mode icon
D. Sterilisation mode icon
E. Power icon

1. Air inlet filter

NOTE:

The graphics in this manual are schematic representations and may not exactly match the device.

2. BEFORE USE

• This appliance is packaged in a way as to protect it during transport. Take the appliance out of its box and remove all packaging materials. You can keep the original box and other packaging elements in a safe place. This will help you prevent damage to the appliance when transporting it in the future. In case the original packaging is disposed of, make sure all packaging materials are recycled accordingly.
• Make sure all parts and components are included and in good conditions. If there is any piece missing or in bad conditions, contact the official Cecotec Technical Support Service immediately.

Box content

• Nana BabyCare DigitalSterilizer
• Tongs
• Jug
• Instruction manual

3. OPERATION

Plug the appliance into the mains. Press the power icon to switch on the appliance. It will beep and "- - " will appear on the display, indicating that the appliance has entered standby mode.

Sterilisation mode

This mode is suitable for sterilising baby bottles. Please note that the bottles will be wet after sterilisation due to the steam generated. The total time of the mode is 10 minutes. Time is not modifiable in this mode.

1. Add water to the heating plate at the base of the steriliser up to the "MAX" mark using the jug supplied with the appliance.
   WARNING: water must never exceed the "MAX" mark. Make sure that no water enters through the air outlet grille to avoid damaging the appliance.
2. Put the bottle tray in place. With the tray alone, you can place up to 6 bottles in the steriliser.
3. If desired, place the teats and dummy holder in position. With the teat holder you can place up to 4 bottles and 2 teats or dummies in the steriliser (Fig. 2).
4. Put the lid in place.
5. Press the sterilisation mode icon The corresponding indicator light will light up.
6. The time indicator will show a 10-minute countdown. The steriliser will heat the water for 2 minutes and then sterilise the bottles in the remaining 8 minutes. Once the sterilising cycle has finished, the appliance will beep and return to standby mode.
7. Before taking out the bottles, press the power icon to switch off the appliance and unplug it from the mains.
8. Remove the lid carefully, as it will be hot.
9. Pull out the bottle tray by the handle and let the bottles cool down before removing them or use the help of the tongs.
10. Dry all parts of the steriliser with a soft cloth.

Drying mode

This mode is suitable for drying the recently washed bottles.

NOTE: this mode does not sterilise the bottles.

1. Put the bottle tray in place. With the tray alone, you can place up to 6 bottles in the steriliser.
2. If desired, place the teats and dummy holder in position. With the teat holder you can place up to 4 bottles and 2 teats or dummies in the steriliser (Fig. 2).
3. Put the lid in place.
4. Press the drying mode icon. The corresponding indicator light will light up.
5. The time indicator will show 50 minutes. Press the drying mode icon again to change the time to 30 minutes. Press it a third time to change the time to 40 minutes. If you press the drying icon again, it will return to the initial time of 50 min.

6. Once the desired time has been set, the drying process will start automatically, and the time indicator will count down.

7. Once the drying cycle has finished, the appliance will beep and return to standby mode.

8. Before taking out the bottles, press the power icon to switch off the appliance and unplug it from the mains.
9. Remove the lid carefully, as it will be hot.
10. Remove the bottles from the tray using the tongs. Please note that they will be hot.

Automatic mode

This mode is suitable for sterilising and drying baby bottles in just one step.

1. Add water to the heating plate at the base of the steriliser up to the "MAX" mark using the jug supplied with the appliance.
   WARNING: water must never exceed the "MAX" mark. Make sure that no water enters through the air outlet grille to avoid damaging the appliance.
2. Put the bottle tray in place. With the tray alone, you can place up to 6 bottles in the steriliser.
3. If desired, place the teats and dummy holder in position. With the teat holder you can place up to 4 bottles and 2 teats or dummies in the steriliser (Fig. 2).
4. Put the lid in place.
5. Press the automatic mode icon. The corresponding indicator light will light up.
6. The time indicator will show 60 minutes. Press the drying mode icon again to change the time to 40 minutes. Press it a third time to change the time to 50 minutes. If you press the drying icon again, it will return to the initial time of 60 min.
7. Once the desired time has been set, the sterilising process will start automatically, and the time indicator will count down.
8. The steriliser will heat water for 2 minutes, sterilise the bottles for 8 minutes and dry them for 30, 40 or 50 minutes, depending on the total time selected.
9. At the end of the complete cycle, the appliance will beep and return to standby mode.
10. Before taking out the bottles, press the power icon to switch off the appliance and unplug it from the mains.
11. Remove the lid carefully, as it will be hot.
12. Remove the bottles from the tray using the tongs. Please note that they will be hot.
13. Remove the bottle tray and dry any remaining water on the heating plate at the base of the steriliser.

NOTE: you can stop any programme by pressing the power icon at any time. The steriliser will return to standby mode, and you will have to start the whole programme again if you want.

4. CLEANING AND MAINTENANCE

• Before cleaning, unplug the appliance from the mains and allow all parts to cool down to room temperature.
• Clean all parts with a soft cloth. Do not immerse the body of the steriliser in water and do not allow water to enter the air outlet grille.
• Do not use scouring pads or metal objects to clean the appliance, as this may scratch the coating.
• If the appliance has limescale deposits, add water with a little vinegar to the heating plate. Let stand for 10 minutes, select sterilisation mode and complete one cycle without accessories. Then, clean the steriliser with a soft cloth.
• Clean the filter on the bottom part of the steriliser body at least once a week to prevent the drying effect from diminishing (Fig. 3). To do this, remove the lid by pulling the flap, remove the sponge filter from inside and shake it out or clean it with a soft brush or cloth. After cleaning, put the filter back in position and close the lid.
• Store and use the appliance in a dry place, avoid contact with water or moisture on the outside of the steriliser.

5.TROUBLESHOOTING

Problem Possible causes Possible solutions
The appliance does not switch on	The appliance is not correctly connected to the mains supply.	Check that the appliance is properly connected and that the socket is working.
	You did not press the power icon.	Switch on the appliance by pressing the power icon.
It is not possible to modify the time	You are pressing the time indicator instead of an icon corresponding to a mode.	Press the selected mode icon repeatedly, the time on the display will change.
	This parameter is not adjustable for the selected mode.	Check which modes allow time adjustment in the “Operation” section.

WARNING:

Do not attempt to repair the appliance by yourself. If the problem persists after performing the checks described above, please contact authorised personnel, the shop where you purchased the product or the official Cecotec Customer Service

6. TECHNICAL SPECIFICATIONS

Product: Nana BabyCare DigitalSterilizer

Product reference: 01904

Voltage: 220-240 V~

Frequency: 50/60 Hz

Drying power: 155 W

Sterilisation power: 600 W

Recommended room temperature and humidity for use: 15 - 30^ / 30% -80%

Technical specifications may change without prior notification to improve product quality.

Made in China | Designed in Spain

7. DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC APPLIANCES

This symbol indicates that, according to the applicable regulations, the product and/or batteries must be disposed of separately from household waste. When this product reaches the end of its shelf life, you should dispose of the cells/batteries/accumulators and take them to a collection point designated by the local authorities.

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

Compliance with the above guidelines will help protecting the environment.

8. TECHNICAL SUPPORT AND WARRANTY

Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the time of delivery of the product under the terms, conditions, and deadlines established by the applicable regulations.

It is recommended that repairs be carried out by qualified personnel.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact the official Cecotec Technical Support Service at [phone].

ENGLISH

9. COPYRIGHT

The intellectual property rights over the texts in this manual belong to CECOTEC INNOVACIONES, S.L. All rights reserved. The contents of this publication may not, in whole or in part, be reproduced, stored in a retrieval system, transmitted, or distributed by any means (electronic, mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC INNOVACIONES, S.L.

1. PIECES ET COMPOSANTS

Img.1

5. PROBLEEMOPLOSSING
