USER MANUAL IAN 276111 AURIOL

Day of the week display

Low voltage plug Scope of delivery 1 Wake-up light alarm clock 1 Mains supply 3 Batteries LR6 (type AA) (installed) 1 Set of instructions for use Technical Data Light alarm clock: Mains supply: 7.5 V , 500 mA Protection class: Batteries: 3 batteries LR6 (type AA, 1.5 V) (installed) Model no.: HG01105 Chromaticity coordinate: x < 0.270 or x > 0.530 y < -2.3172 x

+ 2.3653 x – 0.1595 Mains adapter: Input: 100–240 V∼ 50 / 60 Hz, max. 300 mA Output : 7.5 V , 0.5 A, low voltage plug Ø 5.5 mm Protection class: Model no.: GQ05-075050-AG General safety instructions Before using the product, please familiarise yourself with all of the safety information and instructions for use! When passing this product on to others, please also include all the documents! The light alarm clock is only suited for use with the included mains supply (model no. GQ05-075050-AG).

FANTS AND CHILDREN! Never leave children unattended with the packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers.7 GB/IE/NI This device may be used by children age 8 years and up, as well as by persons with reduced physical, sen- sory or mental capacities, or lacking experience and/or knowledge, so long as they are supervised or instructed in the safe use of the device and understand the associ- ated risks. Do not allow children to play with the device. Cleaning and user maintenance should not be performed by children without supervision. Before using the product, verify the available mains volt- age corresponds with the operating voltage required for the mains supply (100–240 V∼ 50/60 Hz)! Before using the product, verify the light alarm clock and the mains supply and the cable connection aren‘t damaged! Never operate a damaged device! The appliance must be plugged into an easily accessible socket so it can easily be unplugged in the event of an emergency. This product does not contain any parts that can be ser- viced by the user. The bulbs cannot be replaced. Do not place open fire (e.g. candle) on the device. The product is only suited for use with the included mains adapter (GQ05-075050-AG). To switch the product off completely, unplug the power adapter from the socket. Battery safety information DANGER TO LIFE! Batteries are not intended for children. If accidentally swallowed seek immediate medical attention! CAUTION! EXPLOSION HAZARD! Never recharge non-rechargeable batteries, do not short-circuit and / or open batteries! Never throw batteries into fire or water! Do not exert mechanical loads to batteries! Risk of battery leakage! In the event of a battery leak, immediately remove it from the device to prevent damage! Avoid contact with the skin, eyes and mucous membranes! In the event of contact with battery acid, thoroughly flush the affected area with plenty of clean water and seek immediate medical attention! Only use the same type of batteries! Do not mix used and new batteries! Avoid extreme conditions and temperatures which may impact batteries, e.g. on radiators! Remove the batteries from the device if they have not been used for a long period! Risk of equipment damage! Only use the specified battery type! When inserting the battery ensure that it is inserted the right way round! This is shown in the battery compartment! If necessary, clean the battery and device contacts before inserting the battery! Remove dead batteries from the device immediately! Before use Note: unplugged from the mains the light alarm clock only has two emergency functions (clock and electronic alarm signal). An electric connection is therefore required prior to use. First remove the protective film from the LC display

the light alarm clock. A plastic strip protrudes from the battery cover

the underside of the light alarm clock. Remove this plastic strip to utilise the inserted batteries. Plug the low voltage plug

into the low voltage jack

of the light alarm clock. Then plug the mains supply into an easy to access socket. Your light alarm clock is now in clock mode. The clock starts at 00:00. Setting the display backlight Use the slide switch

to adjust the backlight intensity on the LC-display

. Choose from the settings OFF, LO and HI.8 GB/IE/NI Adjusting the time In clock mode, press the CLOCK button

for approx. 3 seconds to enter setup mode. Press the + button

to change the respective flashing value. TIP: Holding the + button or the − button will rapidly scan forward or backward through the numbers. When no button is pressed for 30 seconds, the light alarm clock with automatically return to clock mode. Briefly press the CLOCK button to confirm the setting. This will take you to the next clock settings option. This allows you to successively adjust the following values:

• 24/12 hour display - in 12 hour mode the time from 12 to 23:59 will show PM next to the time.

• Language for displaying the day of the week - Abbreviations for languages: GE for German, EN for English, FR for French, DU for Dutch, SP for Spanish, IT for Italian. Set the desired language by pressing the CLOCK but- ton. The light alarm clock will then return to clock mode. Alarm functions The light alarm clock features an acoustic and a visual alarm. The visual alarm is a light which appears in the illuminated panel

. The brightness is adjustable. You may further set a lead time. The lead time is the time from the alarm time setting during which the brightness of the light field will gradually increase from zero to the set value (sunrise simulation). Choose from eight different soundscapes, an electronic alarm sound or radio reception as the acoustic alarm. The volume of the acoustic signal can be selected. The signal starts at the set alarm time at a low volume and adjusts to the set value within a few minutes. The alarm features an alternate simple alarm function and snooze function. When selecting the simple alarm function, shut off the alarm with a simple button of a button. When selecting the snooze function the signal will turn off and sound again 10 minutes later. This process can be re- peated any number of times until the alarm finally shuts off. Setting the alarm In clock mode, hold the ALARM button

to change the respective flashing value. TIP: Holding the + button or the − button will rapidly scan forward or backward through the numbers. When no button is pressed for 30 seconds, the light alarm clock with automatically return to clock mode. Briefly press the ALARM button

to confirm the setting. This will take you to the next alarm settings option.

• Select alarm mode: Chose from the following alarm mode display

symbols: : sleep : simple alarm No display : Alarm function deactivated Select alarm signal: Choose from the following alarm signals, indicated by the numbers 01 to 10 with the note sign flashing: Note: 01–08 are indicated by these symbols: 09 is indicated by this symbol: 10 is indicated by this symbol: Select one of the following alarms: 01: Brook 02: Birdsong 03: Relax 04: Tropical rainforest 05: Easy listening 06: Lounge 07: Sea surf 08: Rain9 GB/IE/NI 09: Electronic alarm 10: Radio Acoustic alarm volume: A flashing VO will appear along with a number which can be adjusted from 0 to

18. The higher the number the louder the sound.

Sunlight/Mood light mode: Used to set the colour of the visual alarm. Select from 01 Sunlight mode and 02 Mood light mode. Note: Please be aware that in Mood light mode you can only choose between 5 different levels of brightness. Visual alarm brightness: A flashing number will appear which can be adjusted from 0–18. The higher the number selected, the brighter the illuminated panel

will be. Visual alarm lead time: This sets the duration of the lead time. Choose from the following lead times: OFF (no lead time), 5, 10, 15, 20, 25 or 30 minutes. Note: During the visual alarm lead time a flashing will appear in the LC-display

. With the visual alarm going off at the same time as the acoustic alarm, the symbol will be static. Switching off the alarm If no button is pressed after the alarm automatically activates, the alarm will automatically switch off after one hour and will only reactivate the next time the alarm time occurs. When the alarm sounds, you can switch it off with the SNOOZE button

When using the snooze function, the alarm will sound again in 10 minutes. To completely switch off the alarm with the snooze function activated, hold the SNOOZE button for 3 seconds or press the ALARM button

once. The alarm will then remain off until the next alarm time reoccurs. Note: In clock mode, press the ALARM button

once to quickly switch between the “Alarm on“ / “Alarm on with snooze“ / “Alarm off“. Set radio Station scan The radio will receive FM stations at frequencies between

87.5 MHz to 108 MHz via the cable aerial

. To scan for stations proceed as described below: Press the RADIO button

. The light alarm clock is now in radio mode. The frequency

will be displayed. Hold the + button

for 3 seconds. The radio will start scanning for stations. The station scan will stop on the first station found. When pressing the + button or the − button for 3 sec- onds again, the radio will continue scanning stations. The VOL+ button

so the radio has optimal reception. Press the RADIO button for the light alarm clock to return from radio mode to clock mode. Save station With the light alarm clock in radio mode there are 8 memory locations for saving stations. Hold the RADIO button

for 3 seconds until a station you found has been saved. The display will flash the memory location suggested by the radio. Press the VOL+ button

to select the memory location you wish to use. Press the RADIO button to confirm your selection. To recall a saved station repeatedly press the TEST but- ton

with the light alarm clock in radio mode until the desired memory location appears in the LC-display. When switching the radio off by pressing the RADIO button, the radio will play the last station selected when turned back on. Rapid Test Note: The light alarm clock must be in clock mode for the rapid test.10 GB/IE/NI Press the TEST button

. The light alarm clock will scan the settings for the selected alarms. The advance alarm will not be run. Instead, the light will be adjusted to the set value, then the alarm will sound. Lighting Press the SNOOZE button

. A white guide light will appear in the illuminated panel

Press the SNOOZE button again to switch the light off again. The visual alarm will also work when the light is on. The light will then be deactivated and will reappear after the alarm. Mood light The mood light function activates a dim coloured light in the illuminated panel

to activate the mood light. Repeatedly press the LIGHT + button

to increase the brightness 1–5, and to switch it off. Or press the LIGHT– button

to change the colour scale as follows C1-C9: Mood light off: → red → orange → yellow→ cyan → green → Sky blue → Purple→ automatic colour change → colour chosen during automatic colour changing Activating the mood light does not impact the functionality of the visual alarm. The mood light will be switched off and on again after the alarm. Battery operation The inserted batteries are only to backup the clock display and alarm function. In the event of a power failure the light alarm clock will automatically switch to battery mode. The clock will continue running in battery mode. To save en- ergy, only the electronic alarm will sound. All light functions and the radio are non-operational. Once power returns via the low voltage jack

, all functions of the light alarm clock will be available again. Replacing Batteries Batteries should be replaced at least once a year to ensure reliable function of the light alarm clock. To do so, open the battery cover

on the underside of the light alarm clock by pressing the latch in the direction of the arrow and remove the old batteries. Insert three new batteries type AA, 1.5 V. When insert- ing the battery ensure the correct polarity. This is shown in the battery compartment. Close the battery compartment cover. Cleaning and Care Unplug the mains supply

from the socket before cleaning the device. The device should only be cleaned on the outside with a soft dry cloth. Troubleshooting The device contains delicate electronic components. For this reason it is possible that it can be disrupted by radio transmitting equipment in the immediate vicinity. Electrostatic discharges can lead to malfunctions. In this case, press the RESET button

. This will reset the light alarm clock and perform a brief test of the LC-display

. The light alarm clock is then ready for use again. Please note, resetting will erase all settings. Disposal The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities. Contact your local authorities for information on how to dispose of the product at the end of the product‘s life.11 GB/IE/NI To help protect the environment, please dispose of the product properly, and not in household waste, when it has reached the end of its useful life. Please contact your local authority for information on collection points and their opening hours. Improper disposal of batteries can harm the environment! Defective or used batteries must be recycled in accordance with Directive 2006 / 66 / EC and its amendments. Return bat- teries and / or the device to the provided recycling facilities. Never dispose of batteries in your household waste. They may contain toxic heavy metals and are subject to hazard- ous waste regulations. The chemical symbols of the heavy metals are: Cd = cadmium, Hg = mercury, Pb = lead. Warranty The device has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below. The warranty for this device is 3 years from the date of pur- chase. Should this device show any fault in materials or man- ufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period begins on the date of purchase. Please
