PD3817E - Air-conditioner TRISTAR - Free user manual and instructions

Brand	TriStar
Model	PD3817E
Product type	Evaporative air conditioner (air cooler)
Power supply	Mains 220-240 V ~ 50 Hz
Power	Approx. 65 W
Dimensions (approx.)	30 × 30 × 70 cm
Weight (approx.)	5 kg
Water tank capacity	Approx. 5 litres
Operating time	Up to 8 hours (low speed)
Fan speeds	3 (low, medium, high)
Operating modes	Normal, Sleep
LED lighting	7 colours + automatic cycle
Air filter	Removable, washable with warm water
Evaporation pad	Removable, washable with warm water
External cleaning	Damp cloth, no abrasive products
Safety	Protection against dry operation (shuts off if water level is insufficient)
Repairability	Repairs by qualified professional, genuine parts available
Usage	Indoor, domestic, on a stable surface
Included accessories	Power cord, user manual
Additional information	Minimum clearance of 10 cm around the appliance

Frequently Asked Questions - PD3817E TRISTAR

How to use Sleep mode?

Press the Sleep button to switch between day mode and night mode. Sleep mode adjusts the speed and lighting for optimal comfort during the night.

What to do if the appliance does not cool?

Check that the water tank is filled above the minimum mark and that the filter and evaporation pad are clean and properly in place. Make sure the appliance is on a stable surface and there is no obstruction in front of the air outlet.

How to clean the air filter?

Unplug the appliance, remove the filter from the back, and wash it with warm water using a mild detergent and a soft brush. Rinse and dry thoroughly before reinstalling.

How often should the water tank be refilled?

It is recommended to refill the tank every 3 days maximum, but the frequency depends on usage. At low speed, the operating time is about 8 hours. Empty and clean the tank before each refill.

Can I use the appliance without water?

No, the appliance must always be used with water in the tank to avoid damaging the pump. If the water level is too low, the appliance shuts off automatically.

How to change the LED light color?

Press the Light button to choose a fixed color (red, yellow, blue, green, light blue, orange, purple) or to switch to color cycle mode. A long press returns to the cycle.

The appliance makes noise, is this normal?

A slight fan and water circulation noise is normal. If the noise is abnormal, check that the appliance is level and the filter is not obstructed. A clicking sound may indicate a pump problem.

Where to find spare parts?

All information and spare parts are available on the official website www.tristar.eu. Only use genuine parts for repairs.

Can I use the appliance outdoors?

No, this appliance is designed for indoor use only. Do not use it outdoors as it is not protected against weather.

What to do if the power cord is damaged?

The power cord must be replaced by the manufacturer, its service agent, or a qualified electrician to avoid any risk of electric shock. Do not use the appliance with a damaged cord.

USER MANUAL PD3817E TRISTAR

• By ignoring the safety instructions the manufacturer cannot be held responsible for the damage.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• Never move the appliance by pulling the cord and make sure the cord cannot become entangled.
• To protect yourself against an electric shock, do not immerse the cord, plug or appliance in the water or any other liquid.
• The appliance must be placed on a stable, level surface.
• The user must not leave the appliance unattended while it is connected to the supply.
• This appliance is only to be used for household purposes and only for the purpose it is made for.
• This appliance shall not be used by children aged less than 8 years. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Keep the appliance and its cord out of reach of children aged less than 8 years. Cleaning and user maintenance shall not be made by children unless older than 8 and supervised.

• Empty the tank and refill every third day. Before refilling, clean it with fresh tap water or cleaning agents if required by the manufacturer. Remove any scale, deposits, or film that has formed on the sides of the tank or on interior surfaces, and wipe all surfaces dry.

• Clear the filter regularly.
• Be aware that high humidity levels may encourage the growth of biological organisms in the environment.
• Unplug the appliance during filling and cleaning.

Instruction manual

• Never leave water in the reservoir when the appliance is not in use.
• Empty and clean the air cooler before storage. Clean the air cooler before next use.
• WARNING: Microorganisms can grow in the water reservoir and be blown in the air causing serious health risks when the water is not renewed and the tank is not cleaned regularly and properly.

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local Authority or local store for recycling advice.

This product complies with conformity requirements of the applicable European regulations or directives.

The Green Dot is the registered trademark of Der Grüne Punkt - Duales System Deutschland GmbH and is protected as a trademark worldwide. The logo may only be used by customers of DSD GmbH holding a valid trademark usage contract or by engaged waste management companies within the Federal Republic of

Germany. This also applies to reproduction of the logo by third parties in a dictionary, an encyclopedia or an electronic database containing a reference manual.

The product and packaging materials are recyclable, subject to extended manufacturer responsibility. Dispense it separately, following the illustrated packaging symbols, for better waste treatment. The Triman logo is valid in France only.

A Class III appliance is designed to be supplied from a separated extra-low voltage power source. The voltage from a SELV supply is low enough that under normal conditions a person can safely come into contact with it without risk of electrical shock. The extra safety features built into Class I and Class II appliances are therefore not required. Specifically, class III appliances are designed without an earth conductor and should not be connected to the earth grounding of the SELV power source. For medical devices, compliance with Class III is not considered sufficient protection, and furthermore, stringent regulations apply to such equipment.

Separate collection / Check your local municipal guidelines.

Cleaning and maintenance

Always disconnect the power cord from the socket before any cleaning.
- Clean the outside with a damp cloth. Never use harsh and abrasive cleaners, steel wool or a scouring pad as this will damage the device. Do not immerse in water or other liquid.
- Removable air filter and evaporation pad. Remove them from the back of the unit, then wash them in warm water with a mild detergent and a soft brush. Take care not to pierce the pad and filter.
- Please ensure that the unit and all of its parts are cleaned regularly to reduce the risk of limescale and bacteria forming. The evaporation pad must be installed flatly, in order to avoid leaking.
- If the fan will not be used for a long period of time, drain the condensate water and store it in a dry place.
- This electrical appliance was manufactured in accordance with the relevant safety requirements. Repairs should only be carried out by qualified persons using original spare parts, otherwise this may result in considerable danger to the user.

PARTS DESCRIPTION

1. Air outlet
2. Water tank
3. ON/OFF
4. Sleep mode
5. Fan button
   6.Light button
6. Power cord

BEFORE THE FIRST USE

Take the appliance and accessories out the box. Remove the stickers, protective foil or plastic from the device.
- Remove the heat shrinkable film from the filter.
- Place the device on a flat stable surface and ensure a minimum of 10cm free space around the device. This device is not suitable for installation in a cabinet or for outside use.
- Put the power cable into the socket. Note: Make sure the voltage which is indicated on the device matches the local voltage before connecting the device.

• Fill the water tank.

Do not use the cooling / evaporator function if the water tank is empty or if the water level is below the minimum mark, it can severely damage the pump.

USE

• Press Power button ON/OFF 3 seconds to power on the air cooler.

Instruction manual

• Low/Middle/High: Press the Fan button to select the desired airflow speed. There are three levels to choose from (low, middle and high speed).
• Sleep: Pressing "SLEEP" button to set up day working model or night sleeping model.
• When you're done press the power button again to turn off your air cooler.
• Only use the original power adapter and cord supplied in package.
• Choose your light color by pressing "Light" Button. You can choose solid colors or a color-cycle mode. When the Color-Cycle is on one color, and pressing "Light" button once, the LED will twinkle three times, and will stop on this one color; then pressing "Light" button once again, the LED regain into Color-Cycle mode.
  Color including: Red, Yellow, Blue, Green, Light Blue, Orange & Purple.

TIPS

1. Place the air cooler on a raised surface such as a table, desk or counter top. This is the best way to cool your personal area faster.
2. Let the filter absorb water for at least 3 minutes after filling tank and before use. By doing this it will speed up the cooling process.
3. Try to stay within a few feet of your air cooler. You'll feel the most benefit when sitting directly in front.
4. Air cooler will run for approximately 8 hours on a single fill on Low fan speed. Even if water tank is empty, filter is still damp and the air cooler is still cooling.

ENVIRONMENT

This appliance should not be put into the domestic garbage at

the end of its durability, but must be offered at a central point for the recycling of electric and electronic domestic appliances. This symbol on the appliance, instruction manual and packaging puts your attention to this important issue. The materials used in this appliance can be recycled. By recycling of used domestic appliances you contribute an important push to the protection of our environment. Ask your local authorities for information regarding the point of recollection.

Support

You can find all available information and spare parts at www.tristar.eu!
