RGV 64 TFB - Cooker ROSIERES - Free user manual and instructions
Find the device manual for free RGV 64 TFB ROSIERES in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Gas cooker with hob |
| Brand | Rosieres |
| Model | RGV 64 TFB |
| Dimensions (W x D) | 595 x 510 mm |
| Estimated net weight | 13 kg |
| Power supply | 220-240 V / 50-60 Hz |
| Compatible gas type | Natural gas (G20/G25) or LPG (G30/G31) |
| Number of gas burners | 4 |
| Burner configuration | 1 auxiliary (AUX), 2 semi-rapid (SR), 1 rapid (R) |
| Total gas power | 7.0 kW |
| Natural gas flow rate (G20 20 mbar) | 667 l/h |
| LPG flow rate (G30/G31 28-30/37 mbar) | 509 g/h |
| Safety | Thermocouple safety taps, automatic gas shut-off in case of flame extinction |
| Ignition | Integrated electronic |
| Installation class | 3 |
| Main functions | Gas cooking with 4 burners, electronic ignition, thermocouple safety |
| Maintenance and cleaning | Clean burners and grates with soapy water, avoid abrasive products. Clean electric plates (if present) with a damp cloth and detergent |
| Spare parts and repairability | Injectors for gas conversion available, seals, hoses. Call a professional for any repairs |
| General information | Compliant with WEEE and GAR directives. Domestic use only |
Frequently Asked Questions - RGV 64 TFB ROSIERES
How to light a gas burner on the Rosieres RGV 64 TFB cooker?
Press and turn the control knob to the ignition symbol. If the ignition is electronic, simply push and turn the knob. For models with safety tap, hold the knob pressed for 5 to 6 seconds after the flame is lit. If the burner does not ignite within 5 seconds, turn the knob to 0 and repeat.
What to do if a gas smell is coming from the appliance?
Immediately shut off the gas supply. Do not use an open flame to search for a leak. Call a qualified technician. Do not attempt to relight the appliance.
What types of gas are compatible with the RGV 64 TFB cooker?
The appliance is supplied to operate on natural gas (G20/G25) at 20-25 mbar. It can be converted for LPG (G30/G31) at 28-30/37 mbar by replacing the injectors and adjusting the minimum flame. Refer to the manual for the procedure.
How to adapt the cooker for LPG (butane/propane) use?
Remove the grates and burners. Unscrew the injectors using a 7 mm hex key and replace them with the injectors suitable for LPG (supplied in a bag). Then adjust the minimum flame by turning the adjustment screw with a small screwdriver to obtain a flame of about 3-4 mm.
How to clean the burners and grates of the cooker?
Let the appliance cool down. Remove the grates and burners. Clean them with hot soapy water. For stainless steel, use a specific cleaner. Dry thoroughly before reassembling. Do not use abrasive or corrosive products.
What safety precautions should I follow during use?
Never leave the cooker unattended while cooking. Use cookware suitable for the burner sizes. Do not store objects on the cooking surfaces. If the surface is cracked, turn off the appliance. Ensure good ventilation of the room.
What pan diameters are recommended for the burners?
For the auxiliary burner (AUX): Ø 10-18 cm. For the semi-rapid burner (SR): Ø 12-24 cm. For the rapid burner (R): Ø 16-26 cm. Use flat bottoms and do not exceed the maximum diameter.
What to do if a burner accidentally goes out?
Turn the knob to the closed position (0). Do not attempt to relight immediately. Wait at least 1 minute before relighting to allow gas to dissipate.
What maintenance is required for the electric plate (if present)?
Clean the electric plate with a damp cloth and dish detergent. Do not scrape burnt residues with a knife. After cleaning, turn on the plate for a few minutes to dry it. Avoid plastic or aluminum containers when it is hot.
Where can I find spare parts for the Rosieres RGV 64 TFB cooker?
Spare parts such as injectors, seals and hoses are available from Rosieres after-sales service or authorized dealers. For any repairs, call a qualified technician.
