PLEASE READ AND SAVE THIS USE AND CARE BOOK.

POR FAVOR LEA ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.

VEUILLEZ LIRE ET CONSERVER CE GUIDE D'ENTRETIEN ET D'UTILISATION.

BLACK&DECKER®

Dining-In™

Convection Countertop Oven/Broiler

Black rectangular toaster oven with open lid and control knobs (no visible text or symbols)

USA/Canada 1-800-231-9786

Mexico 01-800-714-2503

www.blackanddecker.com

Accessories/Parts (USA/Canada) 1-800-738-0245

When using electrical appliances, basic safety precautions should always be followed, including the following:

Read all instructions.

☐ Do not touch hot surfaces. Use handles or knobs.

☐ To protect against risk of electrical shock, do not immerse cord, plug, or any non-removable parts of this oven in water or other liquid.

☐ Close supervision is necessary when any appliance is used by or near children.

☐ Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts.

☐ Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or is dropped or damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair, or electrical or mechanical adjustment. Or, call the appropriate toll-free number listed on the cover of this manual.

☐ The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.

□ Do not use outdoors.

☐ Do not let cord hang over edge of table or counter, or touch hot surfaces.

☐ Do not place on or near a hot gas or electrical burner, or in a heated oven.

☐ Extreme caution must be used when moving an appliance containing hot oil or other hot liquid.

☐ Turn all controls to OFF before inserting or removing plug from wall outlet.

☐ Do not use appliance for other than intended use.

☐ Oversize foods or metal utensils must not be inserted in this appliance, as they may create a fire or risk of electric shock.

☐ A fire may occur if the toaster oven is covered or touching flammable material including curtains, draperies, walls and the like, when in operation. Do not store any item on top of unit when in operation.

☐ Do not clean with metal scouring pads. Pieces can break off the pad and touch electrical parts resulting in a risk of electric shock.

☐ Extreme caution should be used when using containers constructed of other than metal or glass.

☐ Do not store any material, other than manufacturer's recommended accessories, in this oven when not in use.

☐ Do not place any of the following materials in the oven: paper, cardboard, plastic wrap, and the like.

☐ Do not cover crumb tray or any parts of the oven with metal foil. This will cause overheating of the oven.

☐ To stop toasting, turn toast shade selector to OFF. To stop baking or broiling, turn temperature control OFF and Timer to OFF.

SAVE THESE INSTRUCTIONS.

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not modify the plug in any way.

ELECTRICAL CORD

a) A short power-supply cord is to be provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord.
b) Longer extension cords are available and may be used if care is exercised in their use.
c) If an extension cord is used,
1) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance, and
2) The cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally. If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord.

NOTE: If the power supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

CT06200Pub1000001592 1/31/05 4:21 PM Page 4

Product may vary slightly from what is illustrated.

Exploded view diagram of a microwave oven with labeled parts including front panel, lid, and control panel

1. On indicator light

2. Toast and Bake/Broil temperature control

3. 60-minute bake timer

4. Side handle

5. Toast shade selector

6. Convection switch

† 7. Slide rack (Part # CTO6200-GRILL)

† 8 . Slide-out crumb tray (Part # CTO6200-TRAY)

1. Door handle

2. Extra-deep curved interior

†Consumer replaceable

How to Use

This product is for household use only.

Getting Started

1. Remove packing materials and wash all parts as instructed in the Care and Cleaning section.
2. Insert the crumb tray underneath the bottom heating elements.
3. Plug the unit into a standard outlet.

Using slide Rack

The slide rack must be used for all cooking functions. It may be inserted into either the upper or lower rack slot. It can also be inverted for two additional positions.

Toaster oven has 2 slots with 4 rack positions

Upper slot (use rack positions 1 and 3)

Lower slot (use rack positions 2 and 4)

Slide Rack Positions

1 - bottom down 2 - bottom up
3 - top down 4 - top up

Toasting

1. Insert the slide rack in the bottom rack slot with the curved end toward the back of the oven. It is not necessary to preheat the oven for toasting.
2. Set the toast shade selector as desired. For best results, select the medium setting for your first cycle, then adjust lighter or darker to suit your taste.
3. Be sure to turn temperature control to TOAST. The ON indicator light comes on and slays on during the toasting cycle. When toasting is done, the signal bell sounds. The oven automatically shuts off and the ON indicator light goes out.
4. To momentarily stop toasting at any time, open the oven door. The heating elements and the ON indicator light go out. Close the door to resume toasting. The heating elements and the ON indicator light turn back on.
5. If you want to stop the toasting before the timing cycle is complete, turn the toast shade selector to OFF.
6. Using an oven mitt or pot holder, open the door and slide out the slide rack to remove food.

Caution: The oven is hot. Do not let your skin touch any surface.

Baking

1. Place bake pan containing food to be cooked on the slide rack.

2. Turn the temperature control to the desired temperature setting. a. If not using the bake timer, turn the control (counterclockwise) to SIAY ON and monitor the food. b. If using the 60-minute bake timer, turn the timer to the desired number of minutes.

Note: For best results, always preheat the oven for 5 minutes.

1. The heating elements will cycle on and off to maintain the temperature. To momentarily stop cooking, open the oven door; the heating elements and the ON indicator light go out. Close the door to resume cooking. To continue cooking, close the door. The heating elements and the ON indicator light turn back on. Check food for doneness at minimum time.

2. When finished cooking, turn the temperature control to OFF.

3. If using the 60-Minute bake timer, you will hear a bell sound once it reaches the set time. The ON indicator light goes out and the oven automatically shuts off. When finished cooking, turn the temperature control to OFF. If cooking is done before the bell sounds, turn the timer to 0 (OFF). The ON indicator goes out. Turn the temperature control to OFF.

4. Using an oven mill or pot holder, open the door and slide out the slide rack to remove the bake pan.

Caution: The oven is hot. Do not let your skin touch any surface.

Convection Cooking

Touse for convection cooking press the convection switch to the ON position. Watch time carefully as many foods will bake in less time in this mode. Turn switch to OFF after use.

Broiling

1. Insert the broil rack in the bake pan and place both on the slide rack.
2. Insert the slide rack in the top rack slot.
   Note: The oven does not need to be preheated for broiling.
3. Turn the temperature control to BROIL and the 60-minute bake timer control counterclockwise to STAY ON. Closely monitor the food.

a. If using the 60-minute bake timer, turn the timer to the desired number of minutes. You will hear a bell sound once it reaches the set time. The ON indicator light goes out and the oven automatically shuts off. When finished broiling, turn the temperature control to OFF.

b. If broiling is done before the bell sounds, turn the timer to 0 (OFF). The ON indicator goes out. Turn the temperature control to OFF.

1. To momentarily stop broiling, open the oven door, the heating elements and the ON indicator light go out. Close the door to resume broiling. The heating elements and the ON indicator turn back on. Check food for doneness at minimum cooking time.
2. When finished broiling, using an oven mitt or pot holder, slide out slide rack to remove bake pan.
   Caution: The oven is hot. Do not let your skin touch any surface.
3. Be sure when broiling is finished to turn the temperature control to OFF and 60-minute bake timer to 0 (OFF).

Care and Cleaning

This product contains no user serviceable parts. Refer service to qualified service personnel.
1. Turn off unit, unplug from wall outlet and let it cool before cleaning.
2. Clean the glass door with a nylon pad and sudsy water. Do not use a spray glass cleaner.
3. To remove slide rack, open the door, pull the rack forward and out. Wash in warm, sudsy water or in a dishwasher.

To remove stubborn spots, use a polyester or nylon pad.

To replace the slide rack, open the door completely, slide into the rail and close the door.

1. Wash the bake pan, broil rack and pizza pan in warm, sudsy water or in the dishwasher. To minimize scratching, use a polyester or nylon pad.
   Note: Bake pan is not nonstick.
2. To remove the crumb tray, grasp the handle at the front of the oven and pull it out. Dispose of crumbs and wash the tray in warm, sudsy water. Remove stubborn spots with a nylon mesh pad. Be sure to dry thoroughly before inserting the tray back into the oven.

Interior

1. Unplug the oven and let it cool, then wipe with a soapy sponge or nylon pad after each use.
2. Do not use a chemical oven cleaner. Do not use any abrasive cleansers or scouring pads. Dry with paper towel or soft cloth.

Exterior

Let the oven cool completely before cleaning any outer surface. Wipe with a damp cloth or sponge and dry with paper towel or soft cloth.

Cooking Containers

Metal, ovenproof glass or ceramic bakeware without glass lids can be used in your oven.

Follow manufacturer's instructions. Be sure the top edge of the container is at least

1" (2.54 cm) away from the upper heating elements.

Labeled diagram of a microwave oven showing interior components and parts with numbered annotations

Labeled diagram of a microwave oven showing interior components and parts with numbered annotations

For service, repair or any questions regarding your appliance, call the appropriate "800" number on the cover of this book. Do not return the product to the place of purchase. Do not mail the product back to the manufacturer nor bring it to a service center. You may also want to consult the website listed on the cover of this manual.

One-Year Limited Warranty

(Applies only in the United States and Canada)

What does it cover?

- Any defect in material or workmanship; provided; however, Applica's liability will not exceed the purchase price of the product.

For how long?

• One year after the date of original purchase.

What will we do to help you?

- Provide you with a reasonably similar replacement product that is either new or factory refurbished.

How do you get service?

- Save your receipt as proof of the date of sale.

- Check our on-line service site at www.prodprotect.com/applica, or call our toll-free number, 1-800-231-9786, for general warranty service.

- If you need parts or accessories, please call 1-800-738-0245.

What does your warranty not cover?

• Damage from commercial use

• Damage from misuse, abuse or neglect

- Products that have been modified in any way

- Products used or serviced outside the country of purchase

• Glass parts and other accessory items that are packed with the unit

- Shipping and handling costs associated with the replacement of the unit

- Consequential or incidental damages (Please note, however, that some states do not allow the exclusion or limitation of consequential or incidental damages, so this limitation may not apply to you.)

How does state law relate to this warranty?

- This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or province to province.
