USER MANUAL PG 8530 SEVERIN

Caution: This symbol indicates that the grill surface and accessible housing surfaces heat up during operation. Do not touch any part of the appliance except the handles during and after operation. ∙ Before cleaning, disconnect the appliance from the mains fi rst, then remove the thermostat plug and let the grill cool down. ∙ To avoid the risk of electric shock, the power cord with thermostat plug must not be immersed in liquid or even allowed to come into contact with it. ∙ Clean the grill plate with hot soapy water. Ensure that the grill plate with the thermostat connection is absolutely dry before the grill is used again. ∙ For detailed information on cleaning the appliance, please refer to the section Cleaning and care. ∙ This appliance is intended for domestic or similar applications, such as - in staff kitchens in shops, offi ces and other similar working environments, - in agricultural working environments, - by customers in hotels, motels etc. and similar accommodation, - in bed-and breakfast type environments. ∙ This appliance may be used by children (at least 8 years of age) and by persons with reduced physical, sensory16 or mental capabilities, or lacking experience and knowledge, provided they have been given supervision or instruction concerning the use of the appliance and fully understand all dangers and safety precautions involved. ∙ Children must not be permitted to play with the appliance. ∙ Children must not be permitted to carry out any cleaning or maintenance work on the appliance unless they are supervised and at least 8 years of age. ∙ The appliance and its power cord must be kept well away from children under 8 at all times. ∙ Caution: Keep any packaging materials well away from children – these are a potential source of danger, e.g. of suffocation. ∙ Caution: Do not, under any circumstances, cover the grill plate completely with aluminium foil, barbecue dishes or other items, as the resulting build-up of heat could cause irreparable damage to the grill. ∙ Before the appliance is used, the main body as well as any attachment fi tted should be checked thoroughly for any defects. Should the appliance, for instance, have been dropped onto a hard surface, it must no longer be used: even invisible damage may have adverse effects on the operational safety of the appliance. In this case, please contact our customer service. ∙ Ensure that the grill and base stand are placed in a safe and stable position. The power cord should be routed in such a way that no one is likely to trip over it. ∙ During operation, the barbecue grill must be placed on a level, heat-resistant surface, impervious to splashes and stains. When grilling food with a high fat or moisture content, splashes are not always avoidable. ∙ Do not position the grill next to a wall or corner, and ensure that no infl ammable materials are stored near it. ∙ Before the grill is used, always check that the fat collection tray is correctly fi tted in the barbecue grill. ∙ The barbecue grill must be supervised at all times during operation. ∙ Do not allow the power cord to touch any hot parts of the appliance. ∙ Always remove the plug from the wall socket - after use, - in case of any malfunction, and - during cleaning.17 ∙ The use of an extension-lead reel causes a loss of power, possibly combined with a subsequent heat build-up in the cable. It is therefore necessary to unwind the cable completely from the reel. A reel may be used in a protected outdoor area, but it must be of a type approved for this purpose. ∙ Caution: Do not move the grill when it is in use. Before carrying, transporting or storing the grill, ensure that is has suffi ciently cooled down. ∙ Ensure that the grill is not stored outdoors, or in any other location where it might be subjected to extremes of temperature or high humidity. ∙ No responsibility is accepted if damage results from improper use, or if these instructions are not complied with. ∙ This product complies with all binding CE labelling directives. Overview and parts included (see diagram A at the beginning of this manual)

7. Vertical support (long)

9. Vertical support (short)

12. Opening for thermostat connection

14. Plug-type thermostat with temperature

control and power cord

Before using for the fi rst time ∙ Remove any packaging materials and stickers from the appliance and grill plate. ∙ Clean the grill plate with warm soapy water and dry thoroughly. ∙ Wipe all other parts with a damp cloth and dry thoroughly. Grill assembly ∙ Prior to assembly, check that all parts are complete in accordance with the section Overview and parts included. ∙ To assemble, refer to the illustrations B at the beginning of this manual:

1. Push the feet (10A) into the base (10B)

until they are heard locking into place.

2. Fit the fi xing plate (16) to the base, and

secure it with the screws (17).

3. Screw the threaded bolt (a) halfway

into the short vertical support (9). Fit the decorative ring (8) and then attach the longer vertical support (7) to the bolt, and screw it tight.

4. Turn the base (assembled in steps

1 and 2) over and insert the vertical support (with the shorter part facing down) into the base.

5. Insert the screw (b) into the vertical

support (7) and attach the storage tray.

6. Fit the grill pan (5) to the vertical

7. Insert the fat collection tray (4) into the

8. Fit the grill plate (3) into the pan so that

the thermostat connection on the plate fi ts into the opening on the pan.

9. Insert the thermometer (T) into the

opening in the hood (1) and secure it with the knurled nut (N).

10. Secure the handle (2) to the hood with

the hook (c), screw (d) und washer.

11. Insert the plug-type thermostat (14) into

its connection socket.

12. By means of the hook, the hood (1) can

be hung from the grill pan.

13. View of the grill with hood after

assembly. Note! Without its base stand, the appliance can also be used as a table grill. Heating-up for the fi rst time ∙ Insert the plug into a suitable earthed power outlet. ∙ Let the grill heat up without any food for about 10 minutes, with the hood closed, at maximum power. This will remove the smell typically encountered when fi rst switching on a grill. A little smoke may be emitted; this is quite normal, but ensure there is adequate ventilation by opening windows or balcony doors. ∙ Clean the grill plate as described in the Cleaning and care section. Thermometer The hood thermometer shows the current temperature inside the cooking chamber. Grill plate ∙ The grill plate has a long-life ceramic- type coating, allowing for high- temperature grilling without (or with very little) fat/oil. ∙ Before grilling such foods as vegetables or fi sh, use a pastry brush or kitchen paper to apply a little heat-resistant fat/ oil to the grill plate (frying fat, or coconut, palm, sunfl ower or rape/canola oil). ∙ Oils that are not heat resistant can burn into the ceramic-type surface and permanently damage its non-stick properties. ∙ For detailed information on cleaning the appliance, please refer to the section Cleaning and care. Grilling ∙ Check that the barbecue grill has been correctly assembled and is standing securely. ∙ Insert the plug into a suitable earthed power outlet. ∙ Turn the thermostat control knob to position MAX. The indicator light comes on, and the grill plate heats up. ∙ Once the temperature is high enough, open the hood and put the food on. ∙ Grilling is possible with the hood open or closed. With it closed, higher temperatures are reached and – because of an effect similar to a baking oven – indirect grilling takes place. ∙ The temperature can be adjusted as necessary, up or down, with the temperature control. ∙ Once the grilling process is fi nished: ∙ Turn the thermostat control knob back to19 position MIN. ∙ Remove the plug from the power outlet fi rst, and then disconnect the thermostat plug. ∙ Allow the grill to cool down. Cleaning and care ∙ Ensure that the grill is thoroughly cleaned after use. ∙ Before cleaning, disconnect the appliance from the mains fi rst, then remove the thermostat plug and let the grill cool down. ∙ Do not use metallic pads, steel wool or abrasive cleaning agents. ∙ Wipe the grill plate with kitchen paper. To remove persistent food residues, the plate must be detached and then cleaned in soapy water with a soft sponge - it may also be left to soak for a while. The grill plate and especially the thermostat connection must be thoroughly dried. ∙ To avoid the risk of electric shock, do not clean the power cord or thermostat plug with any liquid and do not immerse them. The thermostat connection may be wiped with a slightly damp lint-free cloth. ∙ If necessary, the hood and grill pan may be cleaned with a cloth soaked in soapy water; wipe thoroughly dry afterwards. ∙ The fat collection tray can be cleaned in soapy water. ∙ The individual components are not dishwasher-safe. Disposal Devices marked with this symbol must be disposed of separately from your household waste, as they contain valuable materials which can be recycled. Proper disposal protects the environment and human health. Your local authority or retailer can provide information on the matter. Guarantee This product is guaranteed against defects in materials and workmanship for a period of two years from the date of purchase. Under this guarantee the manufacturer undertakes to repair or replace any parts found to be defective, providing the product is returned to one of our authorised service centres. This guarantee is only valid if the appliance has been used in accordance with the instructions, and provided that it has not been modifi ed, repaired or interfered with by any unauthorised person, or damaged through misuse. This guarantee naturally does not cover wear and tear, nor breakables such as glass and ceramic items, bulbs etc. This guarantee does not affect your statutory rights, nor any legal rights you may have as a consumer under applicable national legislation governing the purchase of goods. If the product fails to operate and needs to be returned, pack it carefully, enclosing your name and address and the reason for return. If within the guarantee period, please also provide the guarantee card and proof of purchase.20 Barbecue-gril Chère cliente, Cher client, Avant d’utiliser cet appareil, veuillez lire soigneusement les instructions suivantes et conserver ce manuel pour future référence. L’appareil doit être utilisé exclusivement par des personnes familiarisées avec les présentes instructions. Importantes consignes de sécurité ∙ Cet appareil est conçu uniquement pour une utilisation à l’intérieur mais aussi en zones extérieures protégées. ∙ Le barbecue-gril doit être branché sur une prise de terre installée selon les normes en vigueur. Il doit être utilisé avec un disjoncteur différentiel supplémentaire à courant de déclenchement nominal ne dépassant pas 30 mA. ∙ Assurez-vous que la tension d’alimentation correspond à la tension indiquée sur la fi che signalétique. ∙ Examinez régulièrement le cordon pour vous assurer de son parfait état. N’utilisez pas l’appareil si le cordon est endommagé. ∙ A fi n d’éviter tout risque de blessures, et pour rester en conformité avec les exigences de sécurité, les réparations de cet appareil électrique ou de son cordon d’alimentation doivent être effectuées par notre service clientèle. Si des réparations sont nécessaires, veuillez envoyer l’appareil à notre service après-vente (voir appendice). ∙ L’appareil n’est pas destiné à être utilisé avec un programmateur externe ou une télécommande indépendante. ∙ Attention : N’utilisez, en aucun cas, du charbon de bois ou tout autre FR21 combustible solide ou liquide pour faire fonctionner le gril. ∙ Ce barbecue-gril doit être utilisé uniquement avec la fi che thermostat d’origine.
