USER MANUAL KBL 300 Koenic

kronen24
kronetext3
10-0185 registration

（恒土，）

图2

KOENIC

Mini-blender/smoothle maker Comfort

X50300

C

□1

图Jerminal

图

Podernt

1

1

C

10

国Vaeu#eun

2018.5.1

图

联系人：

（一）

1. 实验原理

（q）<1+5

60027

一、本次减持计划的基本情况

1. This appliance is only suitable for private household use and it is not designed for commercial purpose.
2. Danger of electric shock! Do not attempt to repair the appliance yourself. In case of malfunction, repairs are to be conducted by qualified personnel only.
3. Warning! During cleaning or operation do not immerse the electrical parts of the appliance in water or other liquids. Never hold the appliance under running water.
4. This appliance shall not be used by children. Keep the appliance and its cord out of reach of children.
5. This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved.
6. Children shall not play with the appliance.
7. Danger of burns! Do not use the appliance during the cooking process, with boiling liquids or hot fat.
8. Regularly check the power plug and power cord for damage. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a danger or injury.
9. Danger of injury! Care shall be taken when handling the sharp cutting blades, emptying the container and during cleaning.
10. Always disconnect the appliance from the supply if it is left unattended and before assembling, disassembling or cleaning.
11. Switch off the appliance and disconnect from supply before changing accessories or approaching parts that move in use.
12. Never use accessories which are not recommended by the manufacturer. They could pose a safety risk to the user and might damage the appliance. Only use original parts and accessories.
13. The appliance is only intended for short term operation. After an operation time of 3 minutes let it cool for at least 30 minutes. Do not overload the appliance.

English

Safety instructions

1. Clean the appliance thoroughly prior to using it.
2. Warning! Do not fill food over the maximum marking on the containers of the appliance!
3. Always allow the parts of the appliance and its contents to come to a complete stop before cleaning or removing parts.

4. During operation keep hands, hair, clothing and utensils away from the cutting blades to avoid injuries and damage of the appliance.

5. Observe all safety instructions to avoid damage through improper use!

6. Keep this instruction manual for future use. Should this appliance be passed on to a third party, then this instruction manual must be included.
7. Before connecting the appliance to the power supply, check that the power supply voltage and current rating corresponds with the power supply details shown on the appliance rating label.
8. Never use a damaged appliance! Disconnect the appliance from the electrical outlet and contact your retailer if it is damaged.
9. To avoid damaging the cord, do not squeeze, bend or chafe it on sharp edges. Keep it away from hot surfaces and open flames as well. Do not let rotating blades touch the power cord.
10. Lay out the cord in such a way that no unintentional pulling or tripping over it is possible.
11. If an extension cord is used, its capacity needs to be suitable for the power consumed by the appliance.
12. Do not operate the appliance with wet hands or while standing on a wet floor. Do not touch the power plug with wet hands.
13. Do not open the appliance casing under any circumstances. Do not insert any foreign objects into the inside of the casing.

14. Keep the appliance away from any hot surfaces and open flames. Always operate the appliance on a level, stable, clean and dry surface. Protect the appliance against heat, dust, direct sunlight, moisture, dripping and splashing water.

15. Do not place heavy objects on top of the appliance. Do not place objects with open flames, e.g. candles, on top of or beside the appliance. Do not place objects filled with water, e.g. vases, on or near the appliance.

16. Do not pull the power plug out of the electrical outlet by the power cord and do not wrap the power cord around the appliance.
17. Connect the power plug to an easily reachable electrical outlet so that in case of an emergency the appliance can be unplugged immediately. Pull the power plug out of the electrical outlet to completely switch off the appliance. Use the power plug as the disconnection device.
18. Disconnect the power plug from the electrical outlet when not in use and before cleaning.
19. If the power cord should overheat, stop using the appliance and disconnect the appliance from the electrical outlet.
20. Do not place the appliance on hot plates (gas, electric, coal cooking range, etc.). Keep the appliance away from hot surfaces and open flames. Always operate the appliance on a level, stable, clean, heat-resistant and dry surface.
21. Never leave the appliance unattended during use.
22. Dry the appliance and all accessories before connecting to the power supply and prior to attaching the accessories.

English

Congratulations!

Thanks for your purchase of this KOENIC product. Please read this manual carefully and keep it for future reference.

Intended use

The appliance is exclusively intended to mix and blend foodstuffs. This appliance is only suitable for private household use and it is not designed for commercial purpose. Every other type of use can lead to damage to the appliance or injury.

Before first use

• Remove all packaging materials.
• Check for completeness and transport damage. In case of damages or incomplete delivery please contact your dealer.
  Clean the appliance (Cleaning and care).

Content

2×Bottle lid
2×Bottle
1 x Blade assembly
1 x Base with motor
1 x Instruction manual
1 × Warranty card

Technical data

Rated voltage: 220-240 V\~, 50/60 Hz

Rated power: 300 W

Protection class: Class II

Components

A Carrying handle
B Bottle lid
C Bottle
D Blade assembly
Drive shaft
F Power cord with plug
G Base with motor

English

Attention

Always ensure the appliance is disconnected from the power supply before it is fully and correctly assembled!

Danger of hand injury! Handle the blade with care as it is very sharp!

Note

Pre-cut the food into small and even pieces.

For solid food, cut into approximately 15 mm cubes to get the best result.

For ice cubes, crush max. 4 pieces per time. Ice cube size: max. diameter 20 mm.

Note

When pureeing food, make sure to use enough liquid (juice, milk, etc.) to obtain a smooth mixture. Adjust the consistency of the mixture by adding more liquid or soft solids

Attention

The appliance is not suitable for:

Grinding or mashing heavy foods (e.g. potatoes or meat).
Stirring thick mixtures (e.g. dough).
- Processing hot liquid as it can be ejected out of the appliance due to sudden steaming.

Blending

Operation time: After an operation time of 3 minutes let it cool for at least 30 minutes. Do not overload the appliance.

1 Fill the prepared ingredients into the bottle. Observe the maximum marking on the bottle.

When adding food, add liquid ingredients first before adding solid pieces. This way all ingredients are mixed evenly.

2 Attach the blade assembly to the bottle.

Attention: Make sure the blade assembly is locked tight, otherwise the appliance will not start.

3 Connect the plug to a suitable outlet.
4 Turn the bottle upside down.
Mount it onto the base.
5 To do so, align the arrow markings on the blade assembly and on the base.
6 Switching on: Press the bottle downward and rotate clockwise to lock it in place. The appliance starts automatically.

Pulse function: Rotate the bottle to P on the base and hold it to start juicing; Release the bottle to stop juicing. Use this function for a maximum of 3 minutes to avoid overheating the motor!

Attention: Make sure the bottle is locked in place, otherwise the appliance will not start.

7 After use: Rotate the bottle anti-clockwise to unlock and remove.
8 Disconnect the plug.
9 Remove the blade assembly and enjoy the drink.

English

10 If not serving immediately, attach the bottle lid and store inside the fridge.
For outdoor occasions, the carrying handle provides great convenience.

Cleaning and care

Warning

Before cleaning, always switch off the appliance and disconnect the plug from power.

12 Cleaning the motor unit: Use a soft, slightly damp cloth.

Warning

Make sure that no moisture is entering the appliance during cleaning.

Never immerse the motor unit in water or other liquids.

Cleaning the bottle, bottle lid and blade assembly: Use warm water and a mild cleaning agent.

Warning

Danger of hand injury! Handle the blade with care as it is very sharp!

• Never use corrosive detergents, wire brushes, abrasive scourers, metal or sharp implements to clean your appliance.
  Dry the appliance thoroughly after cleaning.
• Store the appliance in a cool, dry location, away from children and pets.

Disposal

The crossed-out wheeled bin logo requires the separate collection of waste electric and electronic equipment (WEEE). Electric and

electronic equipment may contain dangerous and hazardous substances. Do not dispose of this appliance as unsorted municipal waste. Return it to a designated collection point for the recycling of WEEE. By doing so, you will help to conserve resources and protect the environment. Contact your retailer or local authorities for more information.
