HL 3631 - Electric heater CLATRONIC - Free user manual and instructions
Find the device manual for free HL 3631 CLATRONIC in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Electric heater |
| Brand | Clatronic |
| Model | HL 3631 |
| Power supply | 220-240 V, 50 Hz |
| Maximum power | 2000 W |
| Dimensions (L x H x D) | 320 x 180 x 150 mm |
| Weight | 2.5 kg |
| Power levels | 2 levels (1000 W / 2000 W) |
| Cold air fan function | Yes |
| Adjustable thermostat | Yes |
| Overheat protection | Yes, automatic shut-off |
| Tip-over protection | Yes |
| Heating type | Fan-forced convection |
| Material | Heat-resistant plastic |
| Color | White / Black |
| Power cord | 1.5 m |
| Display | Operation LED |
| Maintenance and cleaning | Unplug, clean with a dry cloth, do not immerse |
| Spare parts | Available via after-sales service |
| Warranty | 2 years |
| Assembly | No assembly required |
Frequently Asked Questions - HL 3631 CLATRONIC
How to turn on the Clatronic HL 3631 heater?
Plug the appliance into a power outlet. Turn the thermostat knob to the desired position, then select the power level (1000 W or 2000 W) with the selector. The appliance starts and heats.
Why is the heater not heating?
Check that the appliance is properly plugged in and the thermostat is set above room temperature. If the overheat protection has activated, unplug the appliance, let it cool for about 10 minutes, then plug it back in.
How to clean the HL 3631 heater?
Always unplug the appliance before cleaning. Use a soft, dry cloth to wipe the outer surface. Never use water, solvents, or abrasive products. You can vacuum the air intake grille to remove dust.
What is the maximum heating power?
The maximum power is 2000 W (setting 2). You can also use a lower setting (1000 W) for moderate heat.
The heater turns off by itself, is that normal?
Yes, this may be due to the overheat protection function or the thermostat cutting off power when the set temperature is reached. If the appliance turns off quickly, check that the ventilation grilles are not blocked and that the appliance is not too close to a wall.
Can I use the heater in a bathroom?
This heater is designed for household use in dry rooms. Do not use it in a bathroom or near a water source due to risk of electrocution.
What to do in case of unusual noise?
Noise may come from dust accumulation on the fan or a foreign object. Unplug the appliance, clean the grille and fan with a vacuum cleaner. If noise persists, contact after-sales service.
How to adjust the thermostat?
Turn the thermostat knob clockwise to increase the desired temperature. The heater stops automatically when the room temperature reaches the set value and restarts when it drops below.
The power cord is damaged, can I replace it?
For safety reasons, cord replacement must be done by a qualified professional or by after-sales service. Do not use the appliance if the cord is damaged.
Where to find spare parts?
Spare parts (thermostat, switch, etc.) are available from Clatronic after-sales service. Contact the manufacturer or check the website for more information.
