• Your new unit was manufactured and assembled under strict ROADSTAR quality control. Thank you for purchasing our product. Before operating the unit, please read this instruc- tion manual carefully. Keep it also handy for further future references.

2EnglishEnglish 1 2 WARNINGS The exclamation point within the triangle is a warning sign alerting the user of important instructions accompanying the product. The lightening flash with arrowhead symbol within the triangle is a warning sign alerting the user of “dangerous voltage” inside the unit. To reduce the risk of electric shock, do not remove the cover. No user serviceable parts inside the unit. Refer all servicing to qualified personnel. This unit operates on 230V ~ 50Hz. If the unit is not used for a long period of time, remove the plug from the AC mains. This unit must not be exposed to moisture or rain. The power switch in this unit is mounted on the secondary circuit and does not disconnect the whole unit from the mains in OFF position. Ensure all connections are properly made before operating the unit. This unit should be positioned so that it is properly ventilated. Avoid placing it, for example, close to curtains, on the carpet or in a built-in installation such as a bookcase. Do not expose this unit to direct sunlight or heat radiating sources. TTR-8632UCEN MP3 PLAYER WITH TURNTABLE AND STEREO RADIO. USB/SD PORTS, ENCODING FUNCTION AND REMOTE CONTROL. INSTRUCTION MANUAL Please read this instruction manual carefully and familiarize yourself with your new Audio system before using it for the first time. Please retain this manual for future reference.

Correct Disposal of This Product (Waste Electrical & Electronic Equipment) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.EnglishEnglish

2)INFO in USB stop mode, press to select encoding bitrate.

3) REC in PHONO mode, press to activate recording function.

4)REP/INTRO/RAN in USB mode, press to activate Repeat one/ Repeat All/ Folder/ Intro/ / Random functions. 5)PROGRAM in USB mode, press to active programming function. 6)PLAY/PAUSE in USB mode, press once to start playback. press again to enter pause mode.

7) SKIP/SEARCH forward press once to Skip to next track.

Press & hold for search forward SKIP/SEARCH backward press once to Skip to previous track. Press & hold for search backward.

8) STOP in USB mode, press to stop playback or cancel the stored

10) SOURCE in USB mode, press to select USB/CARD function repeatly.

Before switching on make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. For your own safety read the following instructions carefully before attempting to connect this unit to the mains.

MAINS (AC) OPERATION

This unit is designed to operate on AC 230V 50Hz current only. Connecting it to other power sources may damage the unit. CAUTION To prevent electric shock disconnect from the mains before removing cover. No user serviceable parts inside. Refer servicing to qualified service personnel. SAFETY PRECAUTION Do not allow this unit to be exposed to rain or moisture. Mains Supply: 230V 50Hz - AC only This symbol means that this unit is double insulated. An earth connection is not required. POWER SUPPLY Remove the stereo carefully from the box, retaining the packaging for future use (servicing).

• Set the Function Selector (7) to the RADIO position. The red Power Indicator (5) will light up.

• Select the desired frequency band with the Band Selector (10).

• Tune to the desired radio station by turning the Tuning control (19). ANTENNA

• For FM reception there is a built-in FM antenna wire (28) at the rear of the unit. Move the wire around to obtain the best reception.

• For MW reception the signals are picked up through a built-in ferrite antenna. Your may have to orient the unit to obtain the best reception. FM & FM-STEREORECEPTION

• Stereo reception is possible when the tuned FM station is broadcasting in stereo.

• When in FM STereo mode and the station is broadscasting in Stereo, the STEREO indicator (20) lights up.

• When FM stations are weak and are disturbed, listening can be improved by switching the Band selector to FM (Mono). Reception will then be in MONO.EnglishEnglish

1. Set the Function Selector (7) to the PHONO position.

2. Place a record on the turntable, over the central spindle. Place the EP adapter over the

central spindle when playing 17cm EP records.

3. Set the Speed Selector (25) to 33 or 45 rpm according to the record.

4. Release the tonearm clamp, and remove the protective cap from the stylus.

5. Lift the Tonearm with the Tonearm Lift Lever.

6. Move the tonearm to the beginning of the record, or to the start of a particular track.

7. Gently lower the tone arm onto the record with the Tonearm Lift lever to start playing.

8. When the record is finished the tonearm will automatically stop. Lift the tonearm from

the record and return it to the rest .

9. To stop manually, lift the tonearm from the record and return it to the rest.

10. To select Auto Stop mode, move the Auto Stop Switch (29) to ON position.

Notes: Do not stop or turn the platter manually. Moving or jarring the turntable without securing the Tonearm clamp could result in damage to the Tonearm. Replace the protective cap on the stylus when not in use. ID3(TRACK/ALBUMTITLE)FUNCTION(BY REMOTE HANDSET)

1. Press the “ INFO “ (2) button during playback of MP3/WMA disc, the song title is being

displayed. press the “ INFO “ button again to disable the function. SONGTITLE/FOLDER NAMESEARCHFUNCTION(BYREMOTEHANDSET) You can search the track by the title/floder name in disc during Stop mode:

1. Press the “ FIND “ (1) button once, then press the “skip up” (or skip down) button (7),

you can search the title of each song one by one under alphabet order on Lcd display, then press the “ PLAY/PAUSE “ button (6) to start the playback of the selected track.

2. Press again “ FIND “ button, the folder name is being displayed. then press the “skip

up” (or skip down) button to select the desired folder, and press the ” PLAY/PAUSE“ button (6) to start the playback of all tracks inside that selected folder. REMARK: - In case no name had been assigned for the track, “ none “ or “ unknown “ is being displayed” on the display. - The LCD display supports English language only. MP3/WMATRACK FORMAT REQUIREMENT: - MP3 bit rate : 32 kbps~256 kbps and wma bit rate : 32 kbps ~ 320 kbps - The performance of playing MP3 disc is various from the quality of recording disc and the method of recording.EnglishEnglish REPEAT/INTRO/RANDOMMODE(BYREMOTECONTROL) Press the Repeat/Intro/Random button (4) on the remote control before or during playback, a single track, single folder (MP3 only) or all the tracks can be played in different mode as follows:

Repeat play You can listen the desired tracks or folder repeatedly by this function. Intro play You can listen the beginning (10 seconds) of each track in a cd by this function & saving your time to search the desire song Random play You can listen all the tracks or folder in a random order by this function USB/SDPROGRAMMING(BYREMOTECONTROL) Up to 32 tracks can be programmed for MP3 file and play in any order. before use, be sure the system is at stop mode before programming:

1. Set in USB mode with the Source button (10).

2. Press the “PROGRAM” button (5), “ PROG “ will appear on LCD display. Moreover, it

will indicate program no. and digits for track no. to be programmed.

3. Select a desired track by pressing SKIP or buttons (7).

4. Press the “ program “ button to store the trace into memory.

5. Repeat steps 3 and 4 to enter additional tracks into the memory if necessary.

6. When all the desired tracks have been programmed, press “ PLAY/PAUSE “ button

(6) to play the disc in assigned order.

7. To cancel the programmed file, press “STOP” button on remote handset until “ PROG

“ is disappear on LCD display (2). PLAYBACK OF MP3/WMA SONG VIA USB STORAGE MEDIA OR MEMORY CARD CONNECTING The system is able to decode and playback all MP3 /WMA file which stored in the memory media with USB connecting port or SD/MMC memory card.

1. Set Function selector (7) at USB mode and then press SOURCE button (10) to select

“ USB or CARD” mode.

2. Plug-in the USB plug with the face up & make sure it going into completely or insert

the memory card in the direction of the arrow as shown in the label on the underside of the MEMORY CARD slot cover. Insert straight without bending. Connecting the USB upside down or backwards could damage the audio system or the storage media (usb thumb drive / sd/mmc card). Check to be sure the direction is correct before connection.

3. The system will start reading the storage media automatically after connecting, and

LCD display (2) will show the total number of MP3/WMA files and total number of folder being detected.

REMARK - The system can detect and read the file under mp3 and wma format only though the usb port. - If connect the system to MP3 player via the usb socket, due to variances inMP3 encoding format, some mp3 player may not be able to play via the usb socket. this is not a maul-function of the system.EnglishEnglish

ENCODING OF PHONO INTO MP3 FILE

The system is able to ENCODE music from TURNTABLE to MP3 format and recording at memory media with USB connecting port. REMARK: - The recording speed is 1:1 and according to the actual plying time of the track - The system will creat a “ AUDIO “ folder and then store the encoding track in it. - The recording format is preset at – MP3 bit rate : 128 kbps, sampling rate : 44.1khz - No song title will be recorded during encoding mode - To interrupt the recroding, press the “ RECORD “ button again during record mode. - Recording will be completed only entire song being encoded, if terminate the encoding process intermediately, there is no track being recorded nor stored to the USBor SD/MMC card. COPYING OF MP3/WMA FILE FROM USB TO MMC By pressing the “ RECORD “ button (3) the system will copy the files from to the USB to the MMC card, and the system will switch to copying mode only if MP3/WMA file is being read. REMARK: - The system will store the file to USB source first if both USB and SD slot are being occuplied by storage media. - If press the “ Record “ button during playback of USB or SD source, the file will copy from USB to SD or SD to USB.

1) Set the Function button to “ PHONO “ mode and then press the “ RECORD “ button (3)

2) The LCD display with show the word “ USB “ and then flashing, and then display “

“ & “ “ and flashing after few seconds. Now the system is starting the encoding mode.

3) Start playback at PHONO for the track which you want to record to USB.

4) After finishing of recoding, press and hold the “ RECORD “ button (3) until the LCD

stops flashing and returns to “ PHONO “ mode. B) ENCODING BITRATE (BY REMOTE HANDSET) You can select the desired BITRATE during ENCODING from PHONO to USB, the selectable range from 32 / 64 /96 /128 / 192 / 256 Kbps.

1) Set in “ PHONO “ function (7) & remain in stop mode.

3) Press skip or buttons (7) to select the desired bitrate for encoding.

4) Press again the “ INFO “ to confirm the setting and the lcd display (2) resume to “

To remove the USB / MEMORY CARD, turn off the power or switch the function mode to either AUX or TUNER first. For USB port – un-plug it by pulling out the USB socket directly, for memory card – press the memory card inward & then release, now the card being partially eject and you can remove it by hand. LINEOUTCONNECTION You can connect the system to your home Hi-fi system by connecting the LINE OUT socket (27) to the auxiliary input socket with a RCA cable (not included).
