General Power Tool Safety Warnings

Read all safety warnings and all in-

structions. Failure to follow the warnings

and instructions may result in electric shock, fire and/or seri-

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-

operated (corded) power tool or battery-operated (cordless)

f Keep work area clean and well lit. Cluttered or dark areas

f Do not operate power tools in explosive atmospheres,

such as in the presence of flammable liquids, gases or

dust. Power tools create sparks which may ignite the dust

f Keep children and bystanders away while operating a

power tool. Distractions can cause you to lose control.

f Power tool plugs must match the outlet. Never modify

the plug in any way. Do not use any adapter plugs with

earthed (grounded) power tools. Unmodified plugs and

matching outlets will reduce risk of electric shock.

f Avoid body contact with earthed or grounded surfaces,

such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is

earthed or grounded.

f Do not expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of electric

f Do not abuse the cord. Never use the cord for carrying,

pulling or unplugging the power tool. Keep cord away

from heat, oil, sharp edges and moving parts. Damaged

or entangled cords increase the risk of electric shock.

f When operating a power tool outdoors, use an exten-

sion cord suitable for outdoor use. Use of a cord suitable

for outdoor use reduces the risk of electric shock.

f If operating a power tool in a damp location is unavoid-

able, use a residual current device (RCD) protected

supply. Use of an RCD reduces the risk of electric shock.

f Stay alert, watch what you are doing and use common

sense when operating a power tool. Do not use a power

tool while you are tired or under the influence of drugs,

alcohol or medication. A moment of inattention while op-

erating power tools may result in serious personal injury.

f Use personal protective equipment. Always wear eye

protection. Protective equipment such as dust mask,

non-skid safety shoes, hard hat, or hearing protection

used for appropriate conditions will reduce personal inju-

f Prevent unintentional starting. Ensure the switch is in

the off-position before connecting to power source

and/or battery pack, picking up or carrying the tool.

Carrying power tools with your finger on the switch or en-

ergising power tools that have the switch on invites acci-

f Remove any adjusting key or wrench before turning

the power tool on. A wrench or a key left attached to a ro-

tating part of the power tool may result in personal injury.

WARNING OBJ_BUCH-777-008.book Page 15 Wednesday, February 8, 2012 8:04 AM16 | English

1 609 929 X88 | (8.2.12) Bosch Power Tools

f Do not overreach. Keep proper footing and balance at

all times. This enables better control of the power tool in

unexpected situations.

f Dress properly. Do not wear loose clothing or jewel-

lery. Keep your hair, clothing and gloves away from

moving parts. Loose clothes, jewellery or long hair can be

caught in moving parts.

f If devices are provided for the connection of dust ex-

traction and collection facilities, ensure these are con-

nected and properly used. Use of dust collection can re-

duce dust-related hazards.

Power tool use and care

f Do not force the power tool. Use the correct power tool

for your application. The correct power tool will do the

job better and safer at the rate for which it was designed.

f Do not use the power tool if the switch does not turn it

on and off. Any power tool that cannot be controlled with

the switch is dangerous and must be repaired.

f Disconnect the plug from the power source and/or the

battery pack from the power tool before making any

adjustments, changing accessories, or storing power

tools. Such preventive safety measures reduce the risk of

starting the power tool accidentally.

f Store idle power tools out of the reach of children and

do not allow persons unfamiliar with the power tool or

these instructions to operate the power tool. Power

tools are dangerous in the hands of untrained users.

f Maintain power tools. Check for misalignment or bind-

ing of moving parts, breakage of parts and any other

condition that may affect the power tool’s operation. If

damaged, have the power tool repaired before use.

Many accidents are caused by poorly maintained power

f Keep cutting tools sharp and clean. Properly maintained

cutting tools with sharp cutting edges are less likely to bind

and are easier to control.

f Use the power tool, accessories and tool bits etc. in ac-

cordance with these instructions, taking into account

the working conditions and the work to be performed.

Use of the power tool for operations different from those

intended could result in a hazardous situation.

f Have your power tool serviced by a qualified repair per-

son using only identical replacement parts. This will en-

sure that the safety of the power tool is maintained.

Safety Warnings for Angle Grinder

Safety Warnings common for Grinding, Sanding, Wire

Brushing or Abrasive Cutting Off Operations

f This power tool is intended to function as a grinder,

sander, wire brush or cut-off tool. Read all safety warn-

ings, instructions, illustrations and specifications pro-

vided with this power tool. Failure to follow all instruc-

tions listed below may result in electric shock, fire and/or

f This power tool is not recommended for polishing. Op-

erations for which the power tool was not designed may

create a hazard and cause personal injury.

f Do not use accessories which are not specifically de-

signed and recommended by the tool manufacturer.

Just because the accessory can be attached to your power

tool, it does not assure safe operation.

f The rated speed of the accessory must be at least equal

to the maximum speed marked on the power tool. Ac-

cessories running faster than their rated speed can break

f The outside diameter and the thickness of your acces-

sory must be within the capacity rating of your power

tool. Incorrectly sized accessories cannot be adequately

guarded or controlled.

f The arbor size of wheels, flanges, backing pads or any

other accessory must properly fit the spindle of the

power tool. Accessories with arbor holes that do not

match the mounting hardware of the power tool will run out

of balance, vibrate excessively and may cause loss of con-

f Do not use a damaged accessory. Before each use in-

spect the accessory such as abrasive wheels for chips

and cracks, backing pad for cracks, tear or excess

wear, wire brush for loose or cracked wires. If power

tool or accessory is dropped, inspect for damage or in-

stall an undamaged accessory. After inspecting and in-

stalling an accessory, position yourself and bystanders

away from the plane of the rotating accessory and run

the power tool at maximum no-load speed for one

minute. Damaged accessories will normally break apart

during this test time.

f Wear personal protective equipment. Depending on

application, use face shield, safety goggles or safety

glasses. As appropriate, wear dust mask, hearing pro-

tectors, gloves and workshop apron capable of stop-

ping small abrasive or workpiece fragments. The eye

protection must be capable of stopping flying debris gen-

erated by various operations. The dust mask or respirator

must be capable of filtrating particles generated by your

operation. Prolonged exposure to high intensity noise may

f Keep bystanders a safe distance away from work area.

Anyone entering the work area must wear personal

protective equipment. Fragments of workpiece or of a

broken accessory may fly away and cause injury beyond

immediate area of operation.

f Hold the power tool by insulated gripping surfaces on-

ly, when performing an operation where the cutting ac-

cessory may contact hidden wiring or its own cord. Cut-

ting accessory contacting a “live” wire may make exposed

metal parts of the power tool “live” and could give the op-

erator an electric shock.

f Position the cord clear of the spinning accessory. If you

lose control of the power tool, the cord may be cut or

snagged and your hand or arm may be pulled into the spin-

OBJ_BUCH-777-008.book Page 16 Wednesday, February 8, 2012 8:04 AMEnglish | 17

Bosch Power Tools 1 609 929 X88 | (8.2.12)

f Never lay the power tool down until the accessory has

come to a complete stop. The spinning accessory may

grab the surface and pull the power tool out of your control.

f Do not run the power tool while carrying it at your side.

Accidental contact with the spinning accessory could snag

your clothing, pulling the accessory into your body.

f Regularly clean the power tool’s air vents. The motor’s

fan will draw the dust inside the housing and excessive accu-

mulation of powdered metal may cause electrical hazards.

f Do not operate the power tool near flammable materi-

als. Sparks could ignite these materials.

f Do not use accessories that require liquid coolants. Us-

ing water or other liquid coolants may result in electrocu-

Kickback and related warnings

f Kickback is a sudden reaction to a pinched or snagged ro-

tating wheel, backing pad, brush or any other accessory.

Pinching or snagging causes rapid stalling of the rotating

accessory which in turn causes the uncontrolled power

tool to be forced in the direction opposite of the accesso-

ry’s rotation at the point of the binding.

For example, if an abrasive wheel is snagged or pinched by

the workpiece, the edge of the wheel that is entering into

the pinch point can dig into the surface of the material caus-

ing the wheel to climb out or kick out. The wheel may either

jump toward or away from the operator, depending on di-

rection of the wheel’s movement at the point of pinching.

Abrasive wheels may also break under these conditions.

Kickback is the result of power tool misuse and/or incor-

rect operating procedures or conditions and can be avoid-

ed by taking proper precautions as given below.

f Maintain a firm grip on the power tool and position your

body and arm to allow you to resist kickback forces. Al-

ways use auxiliary handle, if provided, for maximum

control over kickback or torque reaction during

start-up. The operator can control torque reactions or

kickback forces, if proper precautions are taken.

f Never place your hand near the rotating accessory. Ac-

cessory may kickback over your hand.

f Do not position your body in the area where power tool

will move if kickback occurs. Kickback will propel the

tool in direction opposite to the wheel’s movement at the

f Use special care when working corners, sharp edges,

etc. Avoid bouncing and snagging the accessory. Cor-

ners, sharp edges or bouncing have a tendency to snag the

rotating accessory and cause loss of control or kickback.

f Do not attach a saw chain woodcarving blade or

toothed saw blade. Such blades create frequent kickback

and loss of control over the power tool.

Safety warnings specific for Grinding and Abrasive Cut-

f Use only wheel types that are recommended for your

power tool and the specific guard designed for the se-

lected wheel. Wheels for which the power tool was not de-

signed cannot be adequately guarded and are unsafe.

f The guard must be securely attached to the power tool

and positioned for maximum safety, so the least

amount of wheel is exposed towards the operator. The

guard helps to protect operator from broken wheel frag-

ments, accidental contact with wheel and sparks that

could ignite clothing.

f Wheels must be used only for recommended applica-

tions. For example: do not grind with the side of the

cut-off wheel. Abrasive cut-off wheels are intended for

peripheral grinding; side forces applied to these wheels

may cause them to shatter.

f Always use undamaged wheel flanges that are of cor-

rect size and shape for your selected wheel. Proper

wheel flanges support the wheel thus reducing the possi-

bility of wheel breakage. Flanges for cut-off wheels may be

different from grinding wheel flanges.

f Do not use worn down wheels from larger power tools.

Wheels intended for larger power tools are not suitable for

the higher speed of a smaller tool and may burst.

Additional safety warnings specific for abrasive cutting

f Do not “jam” the cut-off wheel or apply excessive pres-

sure. Do not attempt to make an excessive depth of cut.

Overstressing the wheel increases the loading and suscep-

tibility to twisting or binding of the wheel in the cut and the

possibility of kickback or wheel breakage.

f Do not position your body in line with and behind the

rotating wheel. When the wheel, at the point of operation,

is moving away from your body, the possible kickback may

propel the spinning wheel and the power tool directly at

f When wheel is binding or when interrupting a cut for

any reason, switch off the power tool and hold the pow-

er tool motionless until the wheel comes to a complete

stop. Never attempt to remove the cut-off wheel from

the cut while the wheel is in motion otherwise kickback

may occur. Investigate and take corrective action to elimi-

nate the cause of wheel binding.

f Do not restart the cutting operation in the workpiece.

Let the wheel reach full speed and carefully re-enter

the cut. The wheel may bind, walk up or kickback if the

power tool is restarted in the workpiece.

f Support panels or any oversized workpiece to minimize

the risk of wheel pinching and kickback. Large work-

pieces tend to sag under their own weight. Supports must

be placed under the workpiece near the line of cut and near

the edge of the workpiece on both sides of the wheel.

f Use extra caution when making a “pocket cut” into ex-

isting walls or other blind areas. The protruding wheel

may cut gas or water pipes, electrical wiring or objects that

Safety warnings specific for sanding operations

f Do not use excessively oversized sanding disc paper.

Follow manufacturers recommendations, when select-

ing sanding paper. Larger sanding paper extending be-

yond the sanding pad presents a laceration hazard and

may cause snagging, tearing of the disc, or kickback.

OBJ_BUCH-777-008.book Page 17 Wednesday, February 8, 2012 8:04 AM18 | English 1 609 929 X88 | (8.2.12) Bosch Power Tools Safety warnings specific for wire brushing operations

f Be aware that wire bristles are thrown by the brush

even during ordinary operation. Do not overstress the

wires by applying excessive load to the brush. The wire

bristles can easily penetrate light clothing and/or skin.

f If the use of a guard is recommended for wire brushing,

do not allow any interference of the wire wheel or

brush with the guard. Wire wheel or brush may expand in

diameter due to work load and centrifugal forces.

Additional safety warnings

Wear safety goggles.

f Use suitable detectors to determine if utility lines are

hidden in the work area or call the local utility company

for assistance. Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-

sion. Penetrating a water line causes property damage or

may cause an electric shock.

f Release the On/Off switch and set it to the off position

when the power supply is interrupted, e. g., in case of a

power failure or when the mains plug is pulled. This pre-

vents uncontrolled restarting.

f Do not touch grinding and cutting discs before they

have cooled down. The discs can become very hot while

f Secure the workpiece. A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.

Products sold in GB only: Your product is fitted with an

BS 1363/A approved electric plug with internal fuse (ASTA

approved to BS 1362).

If the plug is not suitable for your socket outlets, it should be

cut off and an appropriate plug fitted in its place by an author-

ised customer service agent. The replacement plug should

have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible

shock hazard and should never be inserted into a mains sock-

Products sold in AUS and NZ only: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-

Read all safety warnings and all instruc-

tions. Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

While reading the operating instructions, unfold the graphics

page for the machine and leave it open.

The machine is intended for cutting, roughing and brushing of

metal and stone materials without the use of water.

For cutting with bonded abrasives, a special cutting guide (ac-

cessory) must be used.

When cutting in stone, provide for sufficient dust extraction.

With approved sanding tools, the machine can be used for

sanding with sanding discs.

The numbering of the product features refers to the illustra-

1 Spindle lock button

3 Auxiliary handle (insulated gripping surface)

5 Protection guard for grinding

6 Locking screw for protection guard

7 Mounting flange with O-ring

10 Two-pin spanner for clamping nut*

11 Quick-clamping nut *

12 Carbide grinding head*

13 Protection guard for cutting*

15 Protection guard for for grinding cup*

17 Two-pin spanner, offset, for grinding cup*

24 Cutting guide with dust extraction protection guard *

25 Diamond cutting disc*

26 Handle (insulated gripping surface)

*Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Noise/Vibration Information

Measured sound values determined according to EN 60745.

Typically the A-weighted noise levels of the product are:

Sound pressure level 93 dB(A); Sound power level

(triax vector sum) and uncertainty K

determined according to EN 60745:

OBJ_BUCH-777-008.book Page 18 Wednesday, February 8, 2012 8:04 AMEnglish | 19

Bosch Power Tools 1 609 929 X88 | (8.2.12)

The vibration emission level given in this information sheet

has been measured in accordance with a standardised test

given in EN 60745 and may be used to compare one tool with

another. It may be used for a preliminary assessment of expo-

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working pe-

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep hands warm, organise work patterns.

Declaration of Conformity

We declare under our sole responsibility that the product de-

scribed under “Technical Data” is in conformity with the fol-

lowing standards or standardization documents: EN 60745

according to the provisions of the directives 2011/65/EU,

2004/108/EC, 2006/42/EC.

Reduced starting current

Weight according to EPTA-Procedure 01/2003

M 14 M 14 M 14 M 14 M 14

Reduced starting current

Weight according to EPTA-Procedure 01/2003

kg 5.0 5.1 5.2 5.9 6.0

/II /II /II /II /II The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Only for power tools without reduced starting current: Starting cycles generate brief voltage drops. Interference with other equipment/machines may

occur in case of unfavourable mains system conditions. Malfunctions are not to be expected for system impedances below 0.25 ohm.

Dr. Egbert Schneider

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 19 Wednesday, February 8, 2012 8:04 AM20 | English

1 609 929 X88 | (8.2.12) Bosch Power Tools

Mounting the Protective Devices

f Before any work on the machine itself, pull the mains

Note: After breakage of the grinding disc during operation or

damage to the holding fixtures on the protection guard/power

tool, the machine must promptly be sent to an after-sales

service agent for maintenance for addresses, see section “Af-

ter-sales Service and Customer Assistance”.

Protection Guard for Grinding

Place the protection guard 5 on the spindle collar. Adjust the

position of the protection guard 5 to the requirements of the

operation and lock the protection guard 5 with the locking

f Adjust the protection guard 5 in such a manner that

sparking is prevented in the direction of the operator.

Protection Guard for Cutting

f For cutting with bonded abrasives, always use the pro-

tection guard for cutting 13.

f Provide for sufficient dust extraction when cutting

The protection guard for cutting 13 is mounted in the same

manner as the protection guard for grinding 5.

Cutting Guide with Dust Extraction Protection Guard

The cutting guide with dust extraction protection guard 24 is

mounted in the same manner as the protection guard for

f Operate your machine only with the auxiliary handle 3.

Screw the auxiliary handle 3 on the right or left of the machine

head depending on the working method.

f For operations with the rubber sanding plate 20 or with

the cup brush/wheel brush/flap disc, always mount the

The hand guard 18 is fastened with the auxiliary handle 3.

Mounting the Grinding Tools

f Before any work on the machine itself, pull the mains

f Do not touch grinding and cutting discs before they

have cooled down. The discs can become very hot while

Clean the grinder spindle 4 and all parts to be mounted.

For clamping and loosening the grinding tools, lock the grind-

er spindle with the spindle lock button 1.

f Actuate the spindle lock button only when the grinder

spindle is at a standstill. Otherwise, the machine may be-

Grinding/Cutting Disc

Pay attention to the dimensions of the grinding tools. The

mounting hole diameter must fit the mounting flange without

play. Do not use reducers or adapters.

When using diamond cutting discs, pay attention that the di-

rection-of-rotation arrow on the diamond cutting disc and the

direction of rotation of the machine (see direction-of-rotation

arrow on the machine head) agree.

See graphics page for the mounting sequence.

To fasten the grinding/cutting disc, screw on the clamping nut

9 and tighten with the two-pin spanner; see Section “Quick-

f After mounting the grinding tool and before switching

on, check that the grinding tool is correctly mounted

and that it can turn freely. Make sure that the grinding

tool does not graze against the protection guard or oth-

A plastic part (O-ring) is fitted around

the centring collar of mounting flange 7.

If the O-ring is missing or damaged,

the mounting flange 7 must be replaced

before resuming operation.

f For operations with the flap disc, always mount the

Rubber Sanding Plate

f For operations with the rubber sanding plate 20, al-

ways mount the hand guard 18.

See graphics page for the mounting sequence.

Before mounting the rubber sanding plate 20, put the 2 spac-

er discs 19 onto the grinder spindle 4.

Screw on the round nut 22 and tighten with the two-pin span-

Cup Brush/Disc Brush

f For operations with the cup brush/wheel brush, always

mount the hand guard 18.

See graphics page for the mounting sequence.

The cup brush/disc brush must be able to be screwed onto

the grinder spindle until it rests firmly against the grinder

spindle flange at the end of the grinder spindle threads. Tight-

en the cup brush/disc brush with an open-end spanner.

f When working with the grinding cup, mount the special

protection guard 15.

The grinding cup 16 should never project further out of the

protection guard 15 than necessary for the respective grind-

ing application. Adjust the protection guard 15

See graphics page for the mounting sequence.

Screw on clamping nut 9 and tighten with two-pin spanner 17.

For convenient changing of grinding tools without the use of

additional tools, you can use the quick-clamping nut 11 in-

stead of the clamping nut 9.

OBJ_BUCH-777-008.book Page 20 Wednesday, February 8, 2012 8:04 AMEnglish | 21 Bosch Power Tools 1 609 929 X88 | (8.2.12) f The quick-clamping nut 11 may be used only for grind-

ing or cutting discs.

Use only a flawless, undamaged quick-clamping nut 11.

When screwing on, pay attention that the side of the

quick-clamping nut 11 with printing does not face the

grinding disc; the arrow must point to the index mark 27.

Lock the grinder spindle with

the spindle lock button 1. To

tighten the quick-clamping

nut, firmly turn the grinding

disc in clockwise direction.

A properly attached, undam-

aged quick-clamping nut can

be loosened by hand when

turning the knurled ring in an-

ticlockwise direction.

Never loosen a tight quick-

clamping nut with pliers. Al-

ways use the two-pin span-

ner. Insert the two-pin span-

Approved Grinding Tools

All grinding tools mentioned in these operating instructions

The permissible speed [min

] or the circumferential speed

[m/s] of the grinding tools used must at least match the values

Therefore, observe the permissible rotational/circumferen-

tial speed on the label of the grinding tool.

Rotating the Machine Head

f Before any work on the machine itself, pull the mains

The machine head can be

rotated with respect to

the machine housing in

90° steps. In this man-

ner, the On/Off switch

can be brought into a

more convenient position

for special working situa-

tions, e. g., for cutting op-

erations using the cutting

guide with dust extrac-

tion protection guard 24 or for left-handed persons.

Completely unscrew the four screws. Rotate the machine

head carefully, without removing it from the housing, to the

new position. Screw in and tighten the four screws again.

Dust/Chip Extraction

f Dusts from materials such as lead-containing coatings,

some wood types, minerals and metal can be harmful to

one’s health. Touching or breathing-in the dusts can cause

allergic reactions and/or lead to respiratory infections of

the user or bystanders.

Certain dusts, such as oak or beech dust, are considered

as carcinogenic, especially in connection with wood-treat-

ment additives (chromate, wood preservative). Materials

containing asbestos may only be worked by specialists.

– As far as possible, use a dust extraction system suita-

ble for the material.

– Provide for good ventilation of the working place.

– It is recommended to wear a P2 filter-class respirator.

Observe the relevant regulations in your country for the

materials to be worked.

f Prevent dust accumulation at the workplace. Dusts can

f Observe correct mains voltage! The voltage of the pow-

er source must agree with the voltage specified on the

nameplate of the machine. Power tools marked with

230 V can also be operated with 220 V.

When operating the machine with power from mobile genera-

tors that do not have sufficient reserve capacity or are not

equipped with suitable voltage control with starting current

amplification, loss of performance or untypical behavior can

occur upon switching on.

Please observe the suitability of the power generator being

used, particularly with regard to the mains voltage and fre-

d OBJ_BUCH-777-008.book Page 21 Wednesday, February 8, 2012 8:04 AM22 | English

1 609 929 X88 | (8.2.12) Bosch Power Tools

Switching On and Off

To start the power tool, press the On/Off switch 2 forward

To lock-on the pressed On/Off switch 2, push the On/Off

switch 2 further forward.

To switch off the power tool, release the On/Off switch 2, or

when it is locked, briefly press the On/Off switch 2 and then

Switch Version without Lock-on (country-specific):

To start the power tool, press the On/Off switch 2 forward

To switch off the machine, release the On/Off switch 2.

f Check grinding tools before using. The grinding tool

must be mounted properly and be able to move freely.

Carry out a test run for at least one minute with no load.

Do not use damaged, out-of-centre or vibrating grind-

ing tools. Damaged grinding tools can burst and cause in-

Restarting Protection (GWS 22-180 JH/

GWS 22-230 JH/GWS 24-180 JH/GWS 24-230 JH/

GWS 26-180 JH/GWS 26-230 JH)

The restarting protection feature prevents uncontrolled re-

starting of the machine after an interruption in the power sup-

To restart the operation, switch the On/Off switch 2 to the

Off position and start the machine again.

Reduced starting current (GWS 22-180 JH/

GWS 22-230 JH/GWS 24-180 JH/GWS 24-230 JH/

GWS 26-180 JH/GWS 26-230 JH)

The electronic reduced starting current limits the power con-

sumption when switching the tool on and enables operation

from a 13 ampere fuse.

Note: When the machine runs at full speed immediately after

switching on, the reduced starting current and the restarting

protection have failed. The power tool should be sent imme-

diately to an after-sales service (for addresses, see section

“After-sales Service and Customer Assistance”.

f Exercise caution when cutting slots in structural walls;

see Section “Information on Structures ”.

f Clamp the workpiece if it does not remain stationary

due to its own weight.

f Do not strain the machine so heavily that it comes to a

f After heavily straining the power tool, continue to run

it at no-load for several minutes to cool down the acces-

f Do not touch grinding and cutting discs before they

have cooled down. The discs can become very hot while

f Do not use the power tool with a cut-off stand.

Note: When not using for extended periods, pull the mains

plug out of the socket outlet. When the mains plug is inserted

and mains voltage is given, the power tool, even when

switched off, still consumes a low amount of current.

f Never use a cutting disc for roughing.

The best roughing results are achieved when setting the ma-

chine at an angle of 30° to 40°. Move the machine back and

forth with moderate pressure. In this manner, the workpiece

will not become too hot, does not discolour and no grooves

With the flap disc (accessory), curved surfaces and profiles

Flap discs have a considerably higher service life, lower noise

levels and lower sanding temperatures than conventional

f For cutting with bonded abrasives, always use the pro-

tection guard for cutting 13.

When cutting, work with moderate feed, adapted to the mate-

rial being cut. Do not exert pressure onto the cutting disc, tilt

or oscillate the machine.

Do not reduce the speed of running down cutting discs by ap-

plying sideward pressure.

The machine must al-

grinding motion. Other-

wise, the danger exists

of it being pushed un-

controlled out of the

When cutting profiles and square bar, it is best to start at the

smallest cross section.

f Provide for sufficient dust extraction when cutting

f Wear a dust respirator.

f The machine may be used only for dry cutting/grinding.

For cutting stone, it is best to use a diamond cutting disc.

When using the cutting guide with dust extraction protection

guard 24, the vacuum cleaner must be approved for vacuum-

ing masonry dust. Suitable vacuum cleaners are available

OBJ_BUCH-777-008.book Page 22 Wednesday, February 8, 2012 8:04 AMEnglish | 23

Bosch Power Tools 1 609 929 X88 | (8.2.12)

Switch on the machine

and place the front part

of the cutting guide on

the workpiece. Slide the

machine with moderate

feed, adapted to the ma-

terial to be worked.

For cutting expecially hard material, e. g., concrete with high

pebble content, the diamond cutting disc can overheat and

become damaged as a result. This is clearly indicated by cir-

cular sparking, rotating with the diamond cutting disc.

In this case, interrupt the cutting process and allow the dia-

mond cutting disc to cool by running the machine for a short

time at maximum speed with no load.

Noticeable decreasing work progress and circular sparking

are indications of a diamond cutting disc that has become

dull. Briefly cutting into abrasive material (e.g. lime-sand

brick) can resharpen the disc again.

Information on Structures

Slots in structural walls are subject to the Standard DIN 1053

Part 1, or country-specific regulations.

These regulations are to be observed under all circumstanc-

es. Before beginning work, consult the responsible structural

engineer, architect or the construction supervisor.

Maintenance and Service

Maintenance and Cleaning

f Before any work on the machine itself, pull the mains

f For safe and proper working, always keep the machine

and ventilation slots clean.

f In extreme conditions, always use dust extraction as

far as possible. Blow out ventilation slots frequently

and install a residual current device (RCD). When work-

ing metals, conductive dust can settle in the interior of the

power tool. The total insulation of the power tool can be im-

Please store and handle the accessory(-ies) carefully.

If the replacement of the supply cord is necessary, this has to

be done by Bosch or an authorized Bosch service agent in or-

der to avoid a safety hazard.

If the machine should fail despite the care taken in manufac-

turing and testing procedures, repair should be carried out by

an after-sales service centre for Bosch power tools.

In all correspondence and spare parts order, please always in-

clude the 10-digit article number given on the type plate of

After-sales Service and Customer Assistance

Our after-sales service responds to your questions concern-

ing maintenance and repair of your product as well as spare

parts. Exploded views and information on spare parts can al-

Our customer service representatives can answer your ques-

tions concerning possible applications and adjustment of

products and accessories.

Robert Bosch Ltd. (B.S.C.)

Fax: +353 (01) 4 66 68 88

Australia, New Zealand and Pacific Islands

Robert Bosch Australia Pty. Ltd.

Customer Contact Center

Republic of South Africa

Hotline: +27 (011) 6 51 96 00

35 Roper Street, New Centre

E-Mail: bsctools@icon.co.za

OBJ_BUCH-777-008.book Page 23 Wednesday, February 8, 2012 8:04 AM24 | Français 1 609 929 X88 | (8.2.12) Bosch Power Tools KZN – BSC Service Centre

Unit E, Almar Centre

E-Mail: bsc.dur@za.bosch.com

Western Cape – BSC Service Centre

Democracy Way, Prosperity Park

The machine, accessories and packaging should be sorted for

environmental-friendly recycling.

Do not dispose of power tools into household waste!

Only for EC countries:

According the European Guideline

2002/96/EC for Waste Electrical and Elec-

tronic Equipment and its implementation

into national right, power tools that are no

longer usable must be collected separately

and disposed of in an environmentally cor-

rect manner. Subject to change without notice. Français

Avertissements de sécurité

AVERTISSEMENT OBJ_BUCH-777-008.book Page 24 Wednesday, February 8, 2012 8:04 AMFrançais | 25

OBJ_BUCH-777-008.book Page 25 Wednesday, February 8, 2012 8:04 AM26 | Français

OBJ_BUCH-777-008.book Page 26 Wednesday, February 8, 2012 8:04 AMFrançais | 27

OBJ_BUCH-777-008.book Page 27 Wednesday, February 8, 2012 8:04 AM28 | Français

/II /II /II /II OBJ_BUCH-777-008.book Page 28 Wednesday, February 8, 2012 8:04 AMFrançais | 29

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 29 Wednesday, February 8, 2012 8:04 AM30 | Français

1 609 929 X88 | (8.2.12) Bosch Power Tools

OBJ_BUCH-777-008.book Page 31 Wednesday, February 8, 2012 8:04 AM32 | Français

ADVERTENCIA OBJ_BUCH-777-008.book Page 34 Wednesday, February 8, 2012 8:04 AMEspañol | 35

OBJ_BUCH-777-008.book Page 35 Wednesday, February 8, 2012 8:04 AM36 | Español

OBJ_BUCH-777-008.book Page 36 Wednesday, February 8, 2012 8:04 AMEspañol | 37

OBJ_BUCH-777-008.book Page 37 Wednesday, February 8, 2012 8:04 AM38 | Español

M 14 M 14 M 14 M 14 M 14

OBJ_BUCH-777-008.book Page 38 Wednesday, February 8, 2012 8:04 AMEspañol | 39

2011/65/UE, 2004/108/CE, 2006/42/CE.

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

OBJ_BUCH-777-008.book Page 40 Wednesday, February 8, 2012 8:04 AMEspañol | 41

OBJ_BUCH-777-008.book Page 41 Wednesday, February 8, 2012 8:04 AM42 | Español

MR P R O D U C T O C E R T I F I C A D O C E R T I F I E D P R O D U C T ATENÇÃO OBJ_BUCH-777-008.book Page 43 Wednesday, February 8, 2012 8:04 AM44 | Português

OBJ_BUCH-777-008.book Page 44 Wednesday, February 8, 2012 8:04 AMPortuguês | 45

OBJ_BUCH-777-008.book Page 45 Wednesday, February 8, 2012 8:04 AM46 | Português

OBJ_BUCH-777-008.book Page 47 Wednesday, February 8, 2012 8:04 AM48 | Português

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 48 Wednesday, February 8, 2012 8:04 AMPortuguês | 49

Bosch Power Tools 1 609 929 X88 | (8.2.12)

OBJ_BUCH-777-008.book Page 50 Wednesday, February 8, 2012 8:04 AMPortuguês | 51

OBJ_BUCH-777-008.book Page 51 Wednesday, February 8, 2012 8:04 AM52 | Português

OBJ_BUCH-777-008.book Page 52 Wednesday, February 8, 2012 8:04 AMItaliano | 53 Bosch Power Tools 1 609 929 X88 | (8.2.12) Eliminação

AVVERTENZA OBJ_BUCH-777-008.book Page 53 Wednesday, February 8, 2012 8:04 AM54 | Italiano

OBJ_BUCH-777-008.book Page 54 Wednesday, February 8, 2012 8:04 AMItaliano | 55

OBJ_BUCH-777-008.book Page 55 Wednesday, February 8, 2012 8:04 AM56 | Italiano

OBJ_BUCH-777-008.book Page 57 Wednesday, February 8, 2012 8:04 AM58 | Italiano

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 58 Wednesday, February 8, 2012 8:04 AMItaliano | 59

Bosch Power Tools 1 609 929 X88 | (8.2.12)

d OBJ_BUCH-777-008.book Page 60 Wednesday, February 8, 2012 8:04 AMItaliano | 61

WAARSCHUWING OBJ_BUCH-777-008.book Page 63 Wednesday, February 8, 2012 8:04 AM64 | Nederlands

OBJ_BUCH-777-008.book Page 64 Wednesday, February 8, 2012 8:04 AMNederlands | 65

OBJ_BUCH-777-008.book Page 65 Wednesday, February 8, 2012 8:04 AM66 | Nederlands

OBJ_BUCH-777-008.book Page 66 Wednesday, February 8, 2012 8:04 AMNederlands | 67

M 14 M 14 M 14 M 14 M 14

OBJ_BUCH-777-008.book Page 67 Wednesday, February 8, 2012 8:04 AM68 | Nederlands

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

OBJ_BUCH-777-008.book Page 69 Wednesday, February 8, 2012 8:04 AM70 | Nederlands

schikte stofafzuiging.

OBJ_BUCH-777-008.book Page 70 Wednesday, February 8, 2012 8:04 AMNederlands | 71

ADVARSEL OBJ_BUCH-777-008.book Page 72 Wednesday, February 8, 2012 8:04 AMDansk | 73

OBJ_BUCH-777-008.book Page 73 Wednesday, February 8, 2012 8:04 AM74 | Dansk

OBJ_BUCH-777-008.book Page 75 Wednesday, February 8, 2012 8:04 AM76 | Dansk

M 14 M 14 M 14 M 14 M 14

OBJ_BUCH-777-008.book Page 76 Wednesday, February 8, 2012 8:04 AMDansk | 77

2004/108/EF, 2006/42/EF.

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 77 Wednesday, February 8, 2012 8:04 AM78 | Dansk 1 609 929 X88 | (8.2.12) Bosch Power Tools Kopsten

f Montér til arbejde med kopsten den specielle beskyt-

OBJ_BUCH-777-008.book Page 78 Wednesday, February 8, 2012 8:04 AMDansk | 79

Bosch Service Center

VARNING OBJ_BUCH-777-008.book Page 80 Wednesday, February 8, 2012 8:04 AMSvenska | 81

OBJ_BUCH-777-008.book Page 81 Wednesday, February 8, 2012 8:04 AM82 | Svenska

OBJ_BUCH-777-008.book Page 82 Wednesday, February 8, 2012 8:04 AMSvenska | 83

OBJ_BUCH-777-008.book Page 83 Wednesday, February 8, 2012 8:04 AM84 | Svenska

OBJ_BUCH-777-008.book Page 84 Wednesday, February 8, 2012 8:04 AMSvenska | 85

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

OBJ_BUCH-777-008.book Page 86 Wednesday, February 8, 2012 8:04 AMSvenska | 87

Bosch Service Center

OBJ_BUCH-777-008.book Page 88 Wednesday, February 8, 2012 8:04 AMNorsk | 89 Bosch Power Tools 1 609 929 X88 | (8.2.12) Norsk

ADVARSEL OBJ_BUCH-777-008.book Page 89 Wednesday, February 8, 2012 8:04 AM90 | Norsk

OBJ_BUCH-777-008.book Page 90 Wednesday, February 8, 2012 8:04 AMNorsk | 91

Overflatesliping (grovsliping): a

OBJ_BUCH-777-008.book Page 92 Wednesday, February 8, 2012 8:04 AMNorsk | 93

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 93 Wednesday, February 8, 2012 8:04 AM94 | Norsk

1 609 929 X88 | (8.2.12) Bosch Power Tools

OBJ_BUCH-777-008.book Page 95 Wednesday, February 8, 2012 8:04 AM96 | Norsk

lers fare for at den

VAROITUS OBJ_BUCH-777-008.book Page 97 Wednesday, February 8, 2012 8:04 AM98 | Suomi

OBJ_BUCH-777-008.book Page 98 Wednesday, February 8, 2012 8:04 AMSuomi | 99

OBJ_BUCH-777-008.book Page 100 Wednesday, February 8, 2012 8:04 AMSuomi | 101

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 101 Wednesday, February 8, 2012 8:04 AM102 | Suomi

1 609 929 X88 | (8.2.12) Bosch Power Tools

d OBJ_BUCH-777-008.book Page 103 Wednesday, February 8, 2012 8:04 AM104 | Suomi

OBJ_BUCH-777-008.book Page 105 Wednesday, February 8, 2012 8:04 AM106 | EëëçíéêÜ

OBJ_BUCH-777-008.book Page 106 Wednesday, February 8, 2012 8:04 AMEëëçíéêÜ | 107

OBJ_BUCH-777-008.book Page 107 Wednesday, February 8, 2012 8:04 AM108 | EëëçíéêÜ

OBJ_BUCH-777-008.book Page 108 Wednesday, February 8, 2012 8:04 AMEëëçíéêÜ | 109

OBJ_BUCH-777-008.book Page 109 Wednesday, February 8, 2012 8:04 AM110 | EëëçíéêÜ

M 14 M 14 M 14 M 14 M 14

ìÝã. ìÞêïò óðåéñþìáôïò Üîïíá

OBJ_BUCH-777-008.book Page 110 Wednesday, February 8, 2012 8:04 AMEëëçíéêÜ | 111

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 111 Wednesday, February 8, 2012 8:04 AM112 | EëëçíéêÜ

1 609 929 X88 | (8.2.12) Bosch Power Tools

OBJ_BUCH-777-008.book Page 113 Wednesday, February 8, 2012 8:04 AM114 | EëëçíéêÜ

UYARI OBJ_BUCH-777-008.book Page 115 Wednesday, February 8, 2012 8:04 AM116 | Türkçe

OBJ_BUCH-777-008.book Page 116 Wednesday, February 8, 2012 8:04 AMTürkçe | 117

OBJ_BUCH-777-008.book Page 117 Wednesday, February 8, 2012 8:04 AM118 | Türkçe

OBJ_BUCH-777-008.book Page 119 Wednesday, February 8, 2012 8:04 AM120 | Türkçe

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 120 Wednesday, February 8, 2012 8:04 AMTürkçe | 121

Bosch Power Tools 1 609 929 X88 | (8.2.12)

OBJ_BUCH-777-008.book Page 122 Wednesday, February 8, 2012 8:04 AMTürkçe | 123

OBJ_BUCH-777-008.book Page 124 Wednesday, February 8, 2012 8:04 AMPolski | 125

OBJ_BUCH-777-008.book Page 125 Wednesday, February 8, 2012 8:04 AM126 | Polski

OBJ_BUCH-777-008.book Page 126 Wednesday, February 8, 2012 8:04 AMPolski | 127

OBJ_BUCH-777-008.book Page 128 Wednesday, February 8, 2012 8:04 AMPolski | 129

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 129 Wednesday, February 8, 2012 8:04 AM130 | Polski

1 609 929 X88 | (8.2.12) Bosch Power Tools

d OBJ_BUCH-777-008.book Page 131 Wednesday, February 8, 2012 8:04 AM132 | Polski

Robert Bosch Sp. z o.o.

OBJ_BUCH-777-008.book Page 133 Wednesday, February 8, 2012 8:04 AM134 | Česky 1 609 929 X88 | (8.2.12) Bosch Power Tools Česky

VAROVÁNÍ OBJ_BUCH-777-008.book Page 134 Wednesday, February 8, 2012 8:04 AMČesky | 135

OBJ_BUCH-777-008.book Page 135 Wednesday, February 8, 2012 8:04 AM136 | Česky

OBJ_BUCH-777-008.book Page 137 Wednesday, February 8, 2012 8:04 AM138 | Česky

2004/108/ES, 2006/42/ES.

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 138 Wednesday, February 8, 2012 8:04 AMČesky | 139

Bosch Power Tools 1 609 929 X88 | (8.2.12)

OBJ_BUCH-777-008.book Page 140 Wednesday, February 8, 2012 8:04 AMČesky | 141

POZOR OBJ_BUCH-777-008.book Page 142 Wednesday, February 8, 2012 8:04 AMSlovensky | 143

OBJ_BUCH-777-008.book Page 143 Wednesday, February 8, 2012 8:04 AM144 | Slovensky

OBJ_BUCH-777-008.book Page 144 Wednesday, February 8, 2012 8:04 AMSlovensky | 145

OBJ_BUCH-777-008.book Page 146 Wednesday, February 8, 2012 8:04 AMSlovensky | 147

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 147 Wednesday, February 8, 2012 8:04 AM148 | Slovensky

1 609 929 X88 | (8.2.12) Bosch Power Tools

OBJ_BUCH-777-008.book Page 148 Wednesday, February 8, 2012 8:04 AMSlovensky | 149 Bosch Power Tools 1 609 929 X88 | (8.2.12) Brúsny hrniec

OBJ_BUCH-777-008.book Page 149 Wednesday, February 8, 2012 8:04 AM150 | Slovensky

OBJ_BUCH-777-008.book Page 150 Wednesday, February 8, 2012 8:04 AMSlovensky | 151

FIGYELMEZTETÉS OBJ_BUCH-777-008.book Page 152 Wednesday, February 8, 2012 8:04 AMMagyar | 153

OBJ_BUCH-777-008.book Page 153 Wednesday, February 8, 2012 8:04 AM154 | Magyar

OBJ_BUCH-777-008.book Page 154 Wednesday, February 8, 2012 8:04 AMMagyar | 155

OBJ_BUCH-777-008.book Page 156 Wednesday, February 8, 2012 8:04 AMMagyar | 157

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 157 Wednesday, February 8, 2012 8:04 AM158 | Magyar

1 609 929 X88 | (8.2.12) Bosch Power Tools

d OBJ_BUCH-777-008.book Page 159 Wednesday, February 8, 2012 8:04 AM160 | Magyar

OBJ_BUCH-777-008.book Page 161 Wednesday, February 8, 2012 8:04 AM162 | Ðóññêèé 1 609 929 X88 | (8.2.12) Bosch Power Tools Ðóññêèé

OBJ_BUCH-777-008.book Page 163 Wednesday, February 8, 2012 8:04 AM164 | Ðóññêèé

OBJ_BUCH-777-008.book Page 164 Wednesday, February 8, 2012 8:04 AMÐóññêèé | 165

OBJ_BUCH-777-008.book Page 166 Wednesday, February 8, 2012 8:04 AMÐóññêèé | 167

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 167 Wednesday, February 8, 2012 8:04 AM168 | Ðóññêèé

1 609 929 X88 | (8.2.12) Bosch Power Tools

OBJ_BUCH-777-008.book Page 169 Wednesday, February 8, 2012 8:04 AM170 | Ðóññêèé

OBJ_BUCH-777-008.book Page 170 Wednesday, February 8, 2012 8:04 AMÐóññêèé | 171

OBJ_BUCH-777-008.book Page 173 Wednesday, February 8, 2012 8:04 AM174 | Óêðà¿íñüêà

OBJ_BUCH-777-008.book Page 174 Wednesday, February 8, 2012 8:04 AMÓêðà¿íñüêà | 175

OBJ_BUCH-777-008.book Page 176 Wednesday, February 8, 2012 8:04 AMÓêðà¿íñüêà | 177

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 177 Wednesday, February 8, 2012 8:04 AM178 | Óêðà¿íñüêà

1 609 929 X88 | (8.2.12) Bosch Power Tools

OBJ_BUCH-777-008.book Page 179 Wednesday, February 8, 2012 8:04 AM180 | Óêðà¿íñüêà

AVERTISMENT OBJ_BUCH-777-008.book Page 182 Wednesday, February 8, 2012 8:04 AMRomână | 183

OBJ_BUCH-777-008.book Page 183 Wednesday, February 8, 2012 8:04 AM184 | Română

OBJ_BUCH-777-008.book Page 184 Wednesday, February 8, 2012 8:04 AMRomână | 185

OBJ_BUCH-777-008.book Page 185 Wednesday, February 8, 2012 8:04 AM186 | Română

M 14 M 14 M 14 M 14 M 14

Lungime maximă filet arbore de polizat

OBJ_BUCH-777-008.book Page 186 Wednesday, February 8, 2012 8:04 AMRomână | 187

prevederilor Directivelor 2011/65/UE, 2004/108/CE,

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

OBJ_BUCH-777-008.book Page 188 Wednesday, February 8, 2012 8:04 AMRomână | 189

OBJ_BUCH-777-008.book Page 189 Wednesday, February 8, 2012 8:04 AM190 | Română

Conform Directivei Europene 2002/96/CE

OBJ_BUCH-777-008.book Page 191 Wednesday, February 8, 2012 8:04 AM192 | Áúëãàðñêè

OBJ_BUCH-777-008.book Page 192 Wednesday, February 8, 2012 8:04 AMÁúëãàðñêè | 193

OBJ_BUCH-777-008.book Page 193 Wednesday, February 8, 2012 8:04 AM194 | Áúëãàðñêè

OBJ_BUCH-777-008.book Page 195 Wednesday, February 8, 2012 8:04 AM196 | Áúëãàðñêè

M 14 M 14 M 14 M 14 M 14

OBJ_BUCH-777-008.book Page 196 Wednesday, February 8, 2012 8:04 AMÁúëãàðñêè | 197

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

OBJ_BUCH-777-008.book Page 198 Wednesday, February 8, 2012 8:04 AMÁúëãàðñêè | 199

OBJ_BUCH-777-008.book Page 199 Wednesday, February 8, 2012 8:04 AM200 | Áúëãàðñêè

UPOZORENJE OBJ_BUCH-777-008.book Page 201 Wednesday, February 8, 2012 8:04 AM202 | Srpski

OBJ_BUCH-777-008.book Page 202 Wednesday, February 8, 2012 8:04 AMSrpski | 203

OBJ_BUCH-777-008.book Page 203 Wednesday, February 8, 2012 8:04 AM204 | Srpski

OBJ_BUCH-777-008.book Page 204 Wednesday, February 8, 2012 8:04 AMSrpski | 205

OBJ_BUCH-777-008.book Page 205 Wednesday, February 8, 2012 8:04 AM206 | Srpski

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

OBJ_BUCH-777-008.book Page 207 Wednesday, February 8, 2012 8:04 AM208 | Srpski

OBJ_BUCH-777-008.book Page 208 Wednesday, February 8, 2012 8:04 AMSrpski | 209

OPOZORILO OBJ_BUCH-777-008.book Page 210 Wednesday, February 8, 2012 8:04 AMSlovensko | 211

OBJ_BUCH-777-008.book Page 211 Wednesday, February 8, 2012 8:04 AM212 | Slovensko

OBJ_BUCH-777-008.book Page 212 Wednesday, February 8, 2012 8:04 AMSlovensko | 213

OBJ_BUCH-777-008.book Page 213 Wednesday, February 8, 2012 8:04 AM214 | Slovensko

M 14 M 14 M 14 M 14 M 14

OBJ_BUCH-777-008.book Page 214 Wednesday, February 8, 2012 8:04 AMSlovensko | 215

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

OBJ_BUCH-777-008.book Page 216 Wednesday, February 8, 2012 8:04 AMSlovensko | 217

OBJ_BUCH-777-008.book Page 217 Wednesday, February 8, 2012 8:04 AM218 | Hrvatski 1 609 929 X88 | (8.2.12) Bosch Power Tools Rezanje kamna

UPOZORENJE OBJ_BUCH-777-008.book Page 218 Wednesday, February 8, 2012 8:04 AMHrvatski | 219

OBJ_BUCH-777-008.book Page 219 Wednesday, February 8, 2012 8:04 AM220 | Hrvatski

OBJ_BUCH-777-008.book Page 220 Wednesday, February 8, 2012 8:04 AMHrvatski | 221

OBJ_BUCH-777-008.book Page 222 Wednesday, February 8, 2012 8:04 AMHrvatski | 223

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 223 Wednesday, February 8, 2012 8:04 AM224 | Hrvatski

1 609 929 X88 | (8.2.12) Bosch Power Tools

OBJ_BUCH-777-008.book Page 225 Wednesday, February 8, 2012 8:04 AM226 | Hrvatski

OBJ_BUCH-777-008.book Page 228 Wednesday, February 8, 2012 8:04 AMEesti | 229

OBJ_BUCH-777-008.book Page 230 Wednesday, February 8, 2012 8:04 AMEesti | 231

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 231 Wednesday, February 8, 2012 8:04 AM232 | Eesti

1 609 929 X88 | (8.2.12) Bosch Power Tools

d OBJ_BUCH-777-008.book Page 233 Wednesday, February 8, 2012 8:04 AM234 | Eesti

BRĪDINĀJUMS OBJ_BUCH-777-008.book Page 235 Wednesday, February 8, 2012 8:04 AM236 | Latviešu

OBJ_BUCH-777-008.book Page 236 Wednesday, February 8, 2012 8:04 AMLatviešu | 237

OBJ_BUCH-777-008.book Page 237 Wednesday, February 8, 2012 8:04 AM238 | Latviešu

OBJ_BUCH-777-008.book Page 239 Wednesday, February 8, 2012 8:04 AM240 | Latviešu

M 14 M 14 M 14 M 14 M 14

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

PT/ESI OBJ_BUCH-777-008.book Page 240 Wednesday, February 8, 2012 8:04 AMLatviešu | 241

Bosch Power Tools 1 609 929 X88 | (8.2.12)

OBJ_BUCH-777-008.book Page 242 Wednesday, February 8, 2012 8:04 AMLatviešu | 243

OBJ_BUCH-777-008.book Page 243 Wednesday, February 8, 2012 8:04 AM244 | Latviešu

OBJ_BUCH-777-008.book Page 245 Wednesday, February 8, 2012 8:04 AM246 | Lietuviškai

OBJ_BUCH-777-008.book Page 246 Wednesday, February 8, 2012 8:04 AMLietuviškai | 247

OBJ_BUCH-777-008.book Page 247 Wednesday, February 8, 2012 8:04 AM248 | Lietuviškai

OBJ_BUCH-777-008.book Page 248 Wednesday, February 8, 2012 8:04 AMLietuviškai | 249

M 14 M 14 M 14 M 14 M 14

OBJ_BUCH-777-008.book Page 249 Wednesday, February 8, 2012 8:04 AM250 | Lietuviškai

Senior Vice President

Dr. Eckerhard Strötgen

Engineering Director

OBJ_BUCH-777-008.book Page 251 Wednesday, February 8, 2012 8:04 AM252 | Lietuviškai

OBJ_BUCH-777-008.book Page 253 Wednesday, February 8, 2012 8:04 AM254

Engineering Director

PT/ESIDr. Egbert Schneider

Senior Vice President

M 14 M 14 M 14 M 14 M 14

“ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺓﺪﻌﻟﺍ” ﺢﻠﻄﺼﻤﺑ ﺪﺼﻘﻳ

Engineering Director

PT/ESIDr. Egbert Schneider

Senior Vice President

OBJ_BUCH-777-008.book Page 273 Wednesday, February 8, 2012 8:04 AM1 609 929 X88 | (8.2.12) Bosch Power Tools

OBJ_BUCH-777-008.book Page 274 Wednesday, February 8, 2012 8:04 AM
