Product type	Cooker hood
Brand	AEG
Model	DGB2531M
Minimum installation distance	65 cm (unless the hob specifies otherwise)
Operating modes	Extraction (external venting) or recirculation (internal recirculation)
Grease filters	Washable metal filters, dishwasher or hand wash
Cleaning intervals for grease filters	Every 2 months at minimum
Charcoal filter (recirculation version)	Non-washable, replace every 4 months
Controls	Light switch (on/off) and motor speed selector (3 speeds)
Lighting	Integrated spotlight, replacement by a qualified professional only
Electrical supply	220-240 V, 50 Hz
Insulation class	Class II (if symbol present) or earthing required
General maintenance	Clean exterior with a damp cloth and mild detergent; interior with denatured alcohol
Spare parts	Use only genuine AEG spare parts
After-sales service	Contact authorised service center with model, PNC, and serial number

Frequently Asked Questions - DGB2531M - 942 022 066 AEG

How to install the DGB2531M hood?

Installation must be carried out by a qualified professional. Maintain a minimum distance of 65 cm between the cooking surface and the bottom of the hood. For the extraction version, provide an exhaust duct to the outside. For the recirculation version, install a charcoal filter (not included). Follow the detailed instructions in the manual.

At what distance should the hood be placed above the hob?

The minimum distance is 65 cm, unless the hob requires a greater distance. In that case, follow the greater distance.

How to clean the grease filters?

The metal grease filters should be cleaned every 2 months at minimum. Wash them by hand with mild detergent or in the dishwasher. After washing, dry them and replace them. Any discoloration does not affect their effectiveness.

When should the charcoal filter be replaced?

The charcoal filter is only used in recirculation mode. It is not washable and must be replaced every 4 months or more often with heavy use. A flashing 'C' indicator on the display signals replacement.

How to reset the filter alarm?

When the display shows a flashing 'F' (grease filter) or 'C' (charcoal filter), press P1 and P4 simultaneously for 2 seconds to reset the counter. This must be done after cleaning or replacement.

What to do if the hood does not turn on?

First, check that the hood is plugged in and the power outlet works. Check the fuse or circuit breaker. If the problem persists, contact authorised service.

Can I use the hood without a charcoal filter?

Yes, if the hood is installed in extraction mode (external venting), the charcoal filter is not needed. In recirculation mode, the charcoal filter is essential to recirculate air in the room.

How to change the hood bulb?

The integrated spotlight can only be replaced by the manufacturer, its service agent, or a qualified person to avoid any hazard. Do not attempt to replace it yourself.

The hood is noisy, is that normal?

Some noise is normal, especially at high speed. If the noise becomes excessive, check that the filters are clean and correctly installed. A clogged filter can increase noise. If the problem persists, contact service.

Where to find spare parts for my AEG hood?

Use only genuine AEG spare parts. You can order them at www.aeg.com/shop or from authorised service. Provide the model, product code (PNC), and serial number.

USER MANUAL DGB2531M - 942 022 066 AEG

Simple line drawing of a kitchen chimney with three dots on the base (no text or symbols)

CONTENTS

1. SAFETY WARNING.... 3
2. USE......4
3. MAINTENANCE....4
4. CONTROLS....5
5. LIGHTING.... 5

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

Visit our website for:

Visit our website to:

Get usage advice, brochures, trouble shooter, service information:

www.aeg.com

Register your product for better service:

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

ENVIRONMENT CONCERNS

Recycle the materials with the symbol ⚪ Put the packaging in applicable containers to recycle it. Help protect the environment and human health and to recycle waste of electrical and electronic appliances.

Do not dispose appliances marked with the symbol 📄 with the household waste. Return the product to your local recycling facility or contact your municipal office department for household waste or the shop where you purchased this product.

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

⚠ Warning / Caution-Safety information

i General information and tips

Environmental information

Subject to change without notice.

1. SAFETY WARNING

The minimum distance between the hob surface on which the pans stand and the lower part of the hood must be 65 cm, unless otherwise specified in the installation instructions. If the hob installation instructions specify a greater distance, it must be taken into account.

The air collected must not be conveyed into a duct used to blow off smokes from appliances fed with an energy other than electricity (central heating systems, thermosiphons, water-heaters, etc.).

Comply with the official instructions provided by the competent authorities in merit when installing the disposal duct. In addition, exhaust air should not be discharged into a wall cavity, unless the cavity is designed for that purpose.

The room must be well aerated in case a hood and some other heat equipment fed with an energy other than electricity (gas, oil, coal heaters, etc) operate at the same time.

In fact the intake hood, disposing of air, could create a vacuum in the room. The vacuum should not exceed 0,04mbar. This prevents the gas exhausted by the heat source from being intaken again. It is therefore advisable to ensure the room contains air taps able to ensure a steady flow of fresh air.

Check the data label inside the appliance; if the symbol (☐) is printed, read the following: this appliance has such technical particulars that it belongs to class II insulation, therefore it must not be earthed.

Check the data label inside the appliance; if the symbol (☐) is NOT printed, read the following: ⚠️ ATTENTION: This appliance must be earthed. When making the electrical connections, check that the current socket has a ground connection.

When making the electrical connections, check that the voltage values correspond to those indicated on the data plate inside the appliance itself. In case your appliance is not fitted with a supply cord and a plug or with other means for disconnection from the supply mains having a contact separation in all poles that provide full disconnection under overvoltage category III conditions, that means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. If your unit features a power lead and plug, position this so the plug is accessible.

Always switch off the electricity supply before carrying out any cleaning or servicing operations on the appliance.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

⚠ Warning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards.

The appliance must be installed by a qualified person in compliance with the instructions provided.

Avoid using materials which could cause spurts of flame (flambées) near the appliance.

Do not flambé under the range hood.

When frying, take particular care to prevent oil and grease from catching fire. Already used oil is especially dangerous in this respect. Do not use uncovered electric grates.

To avoid possible risks of fire always comply with the indicated instructions when cleaning grease filters and when removing grease deposits from the appliance.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way by a person responsible for their safety and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

Caution: accessible parts may become hot when used with cooking appliances.

This kitchen hood is intended for installation in domestic kitchens above cooktops, cooking devices and similar kitchen equipment.

2. USE

FILTERING OR DUCTING VERSION ?

The hood may be in filtering or in ducting version. Decide from the outset which type is to be installed.

For better efficiency, we recommend installing the hood in the ducting version (if possible).

Ducting version

The hood purifies the air and evacuates it to the outside through an exhaust duct.

Filtering version

The hood purifies the air and recycles the clean air back into the room.

3. MAINTENANCE

Thorough servicing guarantees correct and long-lasting operation.

Any fat deposits should be removed from the appliance periodically depending on amount of use (at least every 2 months). Avoid using abrasive or corrosive products. To clean

painted appliances on the outside, use a cloth dipped in lukewarm water and neutral detergent. To clean steel, copper or brass appliances on the outside, it is always best to use specific products, following the instructions on the products themselves. To clean the inside of the appliance, use a cloth (or brush) dipped in denatured ethyl alcohol. Clean grease filters in relation to use, at least every 2 months to prevent the risk of fire. Hand wash or clean in a dishwasher using a neutral detergent. If washing in the dishwasher, possible discoloration of the filters does not in any way compromise their functioning.

Hand holding a small electronic component with an arrow indicating direction (no text or symbols)

The activated charcoal filter is not washable and cannot be regenerated, and must be replaced approximately every 4 months of operation, or more frequently for particularly heavy usage.

Diagram showing two hands operating a vehicle under load with wheels, no text or symbols present

4. CONTROLS

Model DGB2531M:

Switch A: LIGHT; position 0: light off; position 1: light on.

Switch B: MOTOR SPEED: makes it possible to select the motor operating speed; position 0: motor off.

C: Motor on light.

A B C

Model DGB3850M:

Button P1: first speed motor ON/OFF switch.

Button P2: Change motor speed (1-2-3-4-1-2-3-4....).

Button P3: Timer. Activate and deactivate timer (5 minutes). If the timer is active, the number correspondent at the speed flashing. Button P4: Lights. Turns the lights on/off.

Button P1 + P4 : Filter Alarm Reset. When display shown an “F” letter flashing, the grease filters must be cleaned (40 hours of operation). When display shown an “C” letter flashing, the charcoal filters must be replaced (160 hours of operation) and the grease filters must be cleaned.

Obviously, if the hood is not a filtering model and does not have a charcoal filters, clean the grease filters both when display shown "F" and when display shown "C". The filter alarm can be seen when the motor is off and for about 30 seconds. To RESET the hour counter, keep simultaneously the buttons P1 and P4 pressed for 2 seconds while the alarm can be seen.

P1 P2 P3 P4 ① ② ③ ④

5. LIGHTING

If the light spot is damaged, it must be replaced only by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

INHALT

www.aeg.com/productregistration

Hand holding a device with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

4. BEDIENELEMENTE

Model DGB2531M:

Hand holding a small object with a downward arrow, no text or symbols visible

Diagram showing a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

4. COMMANDES

Modèle DGB2531M:

www.aeg.com/productregistration

1. VEILIGHEIDSWAARSCHUWINGEN

AFVOER OF RECIRCULATIE?

Hand holding a device with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

4. BEDIENINGEN

Model DGB2531M:

Hand holding a device with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

4. MANDOS

Modelo DGB2531M:

www.aeg.com/productregistration

Hand holding a small electronic device with a downward arrow indicating compression (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

4. COMANDOS

Modelo DGB2531M:

www.aeg.com/productregistration

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

4. COMANDI

Modello DGB2531M:

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, illustrating wheel movement (no text or symbols)

4. KOMMANDON

Modell DGB2531M:

KUNDESERVICE OG VEDLIKEHOLD

Vi anbefaler kun bruk av originale reservedeler.

Sørg for å ha følgende opplysninger for hånden när du kontakter det autoriserte servicesenteret: Modell, Produktkode (PNC), Serienummer.

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, illustrating wheel movement (no text or symbols)

4. KONTROLLER

Modelle DGB2531M:

www.aeg.com/productregistration

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, illustrating wheel movement (no text or symbols)

4. OHJAIMET

Mallit DGB2531M:

Hand holding a small electronic component with a downward arrow indicating force or direction (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, illustrating wheel movement (no text or symbols)

4. BETJENING

Model DGB2531M:

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

Hand holding a small electronic component with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands adjusting a vehicle chassis with wheels, no text or symbols present

4. JUHIKUD

Mudel DGB2531M:

FILTRĒJOŠAIS VAI UZSŪCOŠAIS VEIDS?

Hand holding a small electronic device with a downward arrow indicating compression (no text or symbols)

Diagram showing a vehicle's rear lift with wheels and directional arrows indicating motion or movement, accompanied by hands pointing to the lift.

4. VADĪBAS ELEMENTI

Modelis DGB2531M:

Hand holding a small object with a downward arrow, no text or symbols visible

Diagram showing two hands operating a vehicle chassis with wheels, illustrating the mechanism (no text or symbols present)

4. VALDYMAS

Modelis DGB2531M:

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

Hand holding a small electronic component with an arrow indicating direction (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

4. KEZELŐSZERVEK

DGB2531M modell:

www.aeg.com/productregistration

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

4. PŘÍKAZY

Model DGB2531M:

www.aeg.com/productregistration

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols present)

Diagram showing two hands operating a vehicle chassis with wheels, illustrating wheel movement (no text or symbols)

4. OVLÁDAČE

Model DGB2531M:

Prepínač A: SVETLO; poloha 0: svetlo vypnuté;; poloha 1: svetlo zapnuté.

Hand holding a small electronic component with a downward arrow indicating compression (no text or symbols)

Diagram showing a vehicle under load with three wheels and two hands, illustrating wheel movement (no text or symbols)

4. COMENZI

Model DGB2531M:

www.aeg.com/productregistration

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

4. STEROWANIE

Model DGB2531M:

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

4. NAREDBI

Model DGB2531M:

Sklopka A: SVJETLO; položaj 0: svjetlo ugašeno; položaj 1: svjetlo upaljeno.

Sklopka B: BRZINA RADA MOTORA: omogućuje izbor brzine rada motora; položaj 0: motor isključen.

C: motor uključen.

A B C 0 1 2 3

Model DGB3850M:

Tipka P1: sklopka Uključi/lsključi, prva brzina motora.

Tipka P2: Promijeni brzinu motora (1-2-3-4-1-2-3-4....).

www.aeg.com/productregistration

Nabavili dodatno opremo, potrošni material in originalne rezervne dele za svojo napravo:

www.aeg.com/shop

SKRB ZA VARSTVO OKOLJA

Reciklirajte materiale, ki jih označuje simbol 📋. Embalažo odložite v ustrezne zabojnike za reciklažo.

Pomagajte zaščititi okolje in zdravje ljudi ter reciklirati odpadke električnih in elektronskih

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

4. UPRAVLJALNI GUMBI

Model DGB2531M:

Stikalo A: LUČ; položaj 0: luč izklopljena;

Hand holding a small electronic component with a black arrow indicating direction (no text or symbols)

Diagram showing hands operating a vehicle with three wheels and directional arrows indicating motion (no text or symbols)

4. XEIPISTHPIA

Μοντέλα DGB2531M:

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, illustrating wheel movement (no text or symbols)

4. KONTROLLER

DGB2531M Modelleri:

Hand holding a small electronic component with a black arrow indicating direction (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

4. УПРАВЛЕНИЯ

Модел DGB2531M:

www.aeg.com/productregistration

Hand holding a tool with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

www.aeg.com/productregistration

Hand holding a small electronic component with a downward arrow indicating compression (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, illustrating wheel movement (no text or symbols)

4. КОНТРОЛИ

Модел DGB2531M:

www.aeg.com/productregistration

Hand holding a small electronic component with a downward arrow indicating compression or disassembly (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

4. KOMANDIMET

Modeli DGB2531M:

www.aeg.com/productregistration

Hand holding a small electronic component with a downward arrow indicating compression (no text or symbols)

Diagram showing two hands operating a vehicle chassis with wheels, no text or symbols present

4. КОМАНДЕ

Model DGB2531M:

Sklopka A: SVETLO; položaj 0: svetlo ugašeno; položaj 1: svetlo upaljeno.

Sklopka B: BRZINA RADA MOTORA: omogućuje izbor brzine rada motora; položaj 0: motor isključen.

C: motor uključen.

A B C 0 1 2 3

Model DGB3850M:

Tipka P1: sklopka Uključi/lsključi, prva brzina motora.

Tipka P2: Promeni brzinu motora (1-2-3-4-1-2-3-4....).

Diagram showing two hands operating a vehicle chassis with wheels and directional arrows indicating motion (no text or symbols)

Hand holding a card with a downward arrow indicating compression or dislocation (no text or symbols)

تجنب }); Manufacturer (الله) : تلقي، قديت، Manufacturer (الله) : تجنيب

www.aeg.com/productregistration

ال Effective Diagonal Iso Attributable to the Internet
