Product type	Automatic T DISC pod coffee maker
Brand	BOSCH
Model	TAS1107---B
Category	Coffee maker
Power supply	220–240 V~, 50 Hz, 1400 W
Brewing system	T DISC system with barcode recognition
Water tank	Removable, with float and max and calc marks
Included accessories	Service T DISC, cleaning/descaling memo, drip tray, drip grid
Functions	Hot beverage preparation, automatic shut-off, descaling program, cleaning program
Safety	Automatic shut-off, child safety (8+ years under supervision), permanent magnets (10 cm distance), hot parts
Maintenance	Dishwasher-safe (T DISC holder, crown, grid, container), descaling with specific tablets TCZ6004
Spare parts	Descaling tablets TCZ6004 / 00311909, Service T DISC 17001491
Customer service	Cristal number 09 69 39 29 39, www.tassimo.fr
Warranty	According to country conditions, proof of purchase required
Identification numbers	E-Nr and FD on rating plate
Disposal	WEEE Directive 2012/19/EU, do not dispose with household waste

Frequently Asked Questions - TAS1107---B BOSCH

How to prepare a drink with the BOSCH TAS1107---B machine?

Fill the water tank with fresh cold water up to the max mark. Insert a T DISC with the print facing down. Close the brewing system until it clicks. Place a cup and press the on/off button. The preparation stops automatically.

What to do if the machine does not turn on and the LEDs are off?

Check that the appliance is plugged into a power outlet. If the LEDs are off in standby, press the on/off button. If all LEDs flash, the voltage may be incorrect: unplug and have the installation inspected.

Why does the status display light up red during preparation?

This means the T DISC barcode is not recognized. Clean the reading window with a soft, damp cloth, flatten the T DISC film or use a new T DISC. If the problem persists, contact TASSIMO support.

How to clean the BOSCH TAS1107---B machine?

Clean the brewing system regularly with a soft cloth. The T DISC holder, piercing crown, grid and container are dishwasher-safe (max 60°C program). Use the cleaning program with the Service T DISC.

When and how to descale the appliance?

Descale as soon as the calc LED lights up. Use specific TASSIMO descaling tablets (ref. TCZ6004). Follow the descaling program illustrated in the manual. Do not use phosphoric acid descaler.

What to do if the brewing system does not close or open?

For difficult closing, check that the piercing crown and T DISC holder are properly engaged. If the system remains locked, unplug the appliance and contact support. Never open during operation.

How to resolve a problem of water not flowing?

Make sure the water tank is pushed in all the way. If air has entered, run a cleaning cycle with the Service T DISC. If the float is stuck, descale the appliance and move the float manually.

Which parts are dishwasher-safe?

Suitable parts are: the T DISC holder, the piercing crown, the drip grid and the drip tray. The water tank and Service T DISC are not dishwasher-safe.

How to contact TASSIMO customer service?

Call Cristal number 09 69 39 29 39 (France) or visit www.tassimo.fr. Have the product number (E-Nr) and serial number (FD) located on the rating plate of the appliance ready.

What safety instructions are essential to avoid burns?

Do not touch hot parts of the appliance. Never open the brewing system during operation. Drinks are very hot: let them cool before drinking. Use only undamaged T DISCs and only once.

USER MANUAL TAS1107---B BOSCH

General information. 26

Intended use. 26

Restriction on user group. 26

Safety information. 27

Familiarising yourself with your appliance. 30

Appliance 30

Controls 30

Before using for the first time..... 30

Performing initial start-up 30

General information 30

Accessories 30

Basic operation 31

To prepare a drink. 31

Cleaning and servicing 31

Dishwasher-safe components...... 31

Cleaning the appliance 31

Descale the appliance. 31

Troubleshooting 32

Malfunctions 32

Information on display panel..... 34

Problem with results. 35

Disposal 36

Disposing of old appliance 36

Customer Service 36

Product number (E-Nr.) and production number (FD) 36

Warranty conditions. 36

Technical specifications 36

Safety

Please read the safety information to ensure that you use the appliance safely.

General information

You can find general information for this instruction manual here.

• Read this instruction manual carefully. Only this will ensure you use the appliance safely and efficiently.
  This manual is intended for the user of the appliance.
• Follow the safety instructions and warnings.
• Keep the instruction manual and the product information safe for future reference or for the next owner.
• Check the appliance after unpacking it. Do not connect the appliance if it has been damaged in transit.

Intended use

Please read the information on intended use to ensure that you use the appliance correctly and safely.

Only use this appliance:

As specified in this instruction manual.
for preparing hot drinks.
In private households and in enclosed spaces in a domestic environment.
Up to an altitude of max. 2000 m above sea level.

Restriction on user group

Avoid risks to children and vulnerable persons.

This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers.

Children must not play with the appliance.

Children must not perform cleaning or user maintenance unless they are at least 8 years old and are being supervised.

Keep children under the age of 8 years away from the appliance and power cable.

Safety information

Follow these safety instructions when using the appliance.

WARNING - Risk of suffocation!

• Children may put packaging material over their heads or wrap themselves up in it and suffocate.

• Keep packaging material away from children.
  Do not let children play with packaging material.

Children may breathe in or swallow small parts, causing them to suffocate.

• Keep small parts away from children.
  Do not let children play with small parts.

WARNING - Risk of electric shock!

• Improper installation is dangerous.

• Connect and operate the appliance only in accordance with the specifications on the rating plate.

• Connect the appliance to a power supply with alternating current only via a properly installed socket with earthing.
• The protective conductor system of the domestic electrical installation must be properly installed.

If the appliance or the power cord is damaged, this is dangerous.

• Never operate a damaged appliance.
• Never operate an appliance with a cracked or fractured surface.
• Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains.
• If the appliance or the power cord is damaged, immediately unplug the power cord or switch off the fuse in the fuse box.
  "Call Customer Service." Page 36

• Repairs to the appliance should only be carried out by trained specialist staff.

• Improper repairs are dangerous.

• Repairs to the appliance should only be carried out by trained specialist staff.

• Only use genuine spare parts when repairing the appliance.
• If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Customer Service or a similarly qualified person in order to prevent any risk.

An ingress of moisture can cause an electric shock.

• Never immerse the appliance or the power cord in water.
• Liquids must not be spilled on the appliance plug connection.
  Only use the appliance in enclosed spaces.
  Never expose the appliance to intense heat or humidity.
• Do not use steam- or high-pressure cleaners to clean the appliance.

WARNING - Risk of fire!

The appliance will become hot.

Ventilate the appliance adequately.
Never operate the appliance in a cupboard.
- Never leave the appliance unattended while it is switched on.

• It is dangerous to use an extended power cord and non-approved adapters.

• Do not use extension cables or multiple socket strips.
  If the power cord is too short, contact Customer Service.
  Only use adapters approved by the manufacturer.

WARNING - Risk of burns!

Some parts of the appliance become very hot.

• Never open the brewing system during operation.
  Never use a damaged T DISC.
  Never use a drinks T DISC more than once.
• Never touch hot appliance parts.
• Allow hot appliance parts to cool down before touching them.

WARNING - Risk of scalding!

Freshly prepared drinks are very hot.

Leave drinks to cool down if necessary.
- Do not let escaping liquids or steam come into contact with your skin.

WARNING - Risk of injury!

Improper use of the appliance may endanger the user.

• Use the appliance only for its intended purpose.

WARNING - Danger: Magnetism!

The appliance contains permanent magnets. These may affect electronic implants, e.g. pacemakers or insulin pumps.

People with electronic implants must stand at least 10 cm away from the appliance.
This minimum distance of 10cm must also be observed for the water tank when removed.

WARNING - Risk of harm to health!

Dirt on the appliance may be dangerous to health.

Follow the cleaning instructions for the appliance.

Familiarising yourself with your appliance

Familiarise yourself with the parts of your appliance.

Appliance

You can find an overview of the parts of your appliance here.

Note: Individual details and colours may differ, depending on the appliance model.

Fig. 1

1	Float
2	Calc mark
3	Max mark
4	Water tank
5	T DISC reading window
6	T DISC piercing unit
7	T DISC holder
8	Lock
9	Brewing unit
10	Control panel
11	Storage compartment
12	Brief cleaning / descaling instructions
13	Service T DISC
14	Bowl
15	Cup stand
16	Drip grate

Controls

You can find an overview of the symbols on your appliance here.

□	Activate the appliance. Start, stop and prolong dispens- ing of drinks. Start service programme.
⓷	Fill water tank.
↗	Display status.
calc	Descale the appliance.

Before using for the first time

Clean the appliance and individual parts.

Performing initial start-up

Follow the pictorial instructions at the start of these instructions.

→ Fig. 2 - 14

General information

Please bear this information in mind so that you can get the best out of your appliance.

Note: The appliance has been programmed at the factory with standard settings for optimum operation.

Accessories

Only use original accessories. These have been made especially for your appliance. Here, you can find an overview of your appliance's accessories.

Note: Bosch is the manufacturer of the TASSIMO appliance. Therefore Bosch cannot provide any delivery guarantee for the TASSIMO TDISCs.

accessories	Order number / Web shop
Descaling tablets	TCZ6004 / 00311909 www.tassimo.com www.bosch-home.com
Service T DISC	17001491 www.bosch-home.com

Basic operation

You can find out everything you need to know about operating your appliance here.

To prepare a drink

Find out how to prepare a drink of your choice. Follow the pictorial instructions at the start of these instructions.

Tips

• Fill the water tank each day with fresh, cold, non-carbonated water.
• Do not use chemically decalcified water.
• To interrupt the dispensing process, briefly press .

Fig. 15 - 27

Cleaning and servicing

To keep your appliance working efficiently for a long time, it is important to clean and maintain it carefully.

Dishwasher-safe components

Find out which components can be cleaned in the dishwasher.

ATTENTION!

Some components are sensitive to heat and may be damaged if they are cleaned in a dishwasher.

• Follow the operating instructions of the dishwasher.
• Only put dishwasher-safe components in the dishwasher.
  Only use programmes that do not heat the water above 60^ .

Dishwasher-safe components:

T DISC holder
T DISC piercing unit
Drip grate
Bowl

Components that are not dishwasher-safe:

Water tank
Service T DISC

Cleaning the appliance

Follow the pictorial instructions at the start of these instructions.

Fig. 28 - 43

Descale the appliance

If calc lights up, run the descending programme. Follow the pictorial instructions at the start of these instructions.

ATTENTION!

Improper cleaning and descaling or a delay in doing so may damage the appliance.

• Immediately perform the descending process in accordance with the instructions.
• Do not use descaling agent with phosphoric acid.

Fig. 44 - 58

Troubleshooting

You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-sales service. This will avoid unnecessary costs.

WARNING

Risk of electric shock!

Incorrect repairs are dangerous.

Repairs to the appliance should only be carried out by trained specialist staff.
- Only use genuine spare parts when repairing the appliance.
- If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Customer Service or a similarly qualified person in order to prevent any risk.

Malfunctions

Fault	Cause	troubleshooting
The appliance is not work- ing.	The appliance has no power supply.	Check to see whether the appliance is connected to the mains.
LEDs do not light up.
Brewing process starts, drink is not dispensed.	Water tank is wrongly insert- ted.	1. Insert the water tank correctly.2. Push the water tank into the appli- ance until it clicks into place.
	The water tank was re- moved during the brewing- stage or there is air in the system.	Start the cleaning process with the T DISC.→ "Performing initial start-up", Page 30
	Float is stuck in the water tank.	1. Remove the water tank.2. Descale the appliance.→ "Descale the appliance", Page 313. Reach into the water tank and move the float up and down.
Brewing process does not start.	T DISC has not been insert- ted.	Check whether the T DISC is insert- ted.
Status display lights up red.	The T DISC bar code is not recognised.	Clean the T DISC reading window with a soft, damp cloth.Smooth out the film of the T DISC.Use a new T DISC.
Brewing process does not start.		▶ Contact the TASSIMO careline if the problem persists.
Status display lights up red.	Brewing unit is not closed properly.	1. Clean the brewing unit with a soft, damp cloth, particularly in the area of the lock. 2. Close the brewing unit.
	The appliance not connec-ted to the power supply when the T DISC was insert-ted.	▶ Connect the appliance to the power supply before inserting the T DISC.
Brewing unit cannot be closed.	T DISC holder or piercing unit has not been correctly inserted.	1. Press the piercing unit into the holder using both thumbs until it clicks audibly into place. 2. Check the position of the T DISC holder.
	T DISC has not been cor-rectly inserted.	1. Insert the T DISC with the printed side facing downwards. 2. Check whether the tab of the T DISC is in the recess.
	T DISC is damaged.	▶ Use a new T DISC.
	Brewing unit is soiled.	1. Clean the brewing unit with a soft, damp cloth, particularly in the area of the lock. 2. Close the brewing unit.
	Lock does not engage.	▶ Press the lock down until it audibly clicks into place.
Brewing unit cannot be opened.	Brewing unit is locked.	▶ Only open the brewing unit when the status display remains lit con- tinuously. 1. Unplug the mains plug. 2. Contact the TASSIMO careline if the brewing unit remains locked.
Water is dripping from the brewing unit.	T DISC is damaged, leaking or not correctly pierced.	▶ Use a new T DISC. ▶ Only use T DISCs once. 1. Wait until the brewing process has come to an end and the appliance has cooled down. 2. Remove the T DISC. 3. Clean the brewing unit. → "Cleaning the appliance", Page 31
	The piercing unit is not inse- ted correctly.	▶ Press the piercing unit into the holder using both thumbs until it clicks audibly into place.
There is water under the cup stand.	Condensation has formed due to technical reasons.	▶ Remove excess water with a soft cloth.

Information on display panel

Fault	Cause	troubleshooting
No LED is lit.	Appliance is in idle mode.	Press ▼.
All LEDs flashing.	Voltage in the house system is incorrect.	1. Pull out the mains plug and re-insert it.2. If the problem persists for a longer period, have the voltage of your property checked by an electrician.
LED lights up.	Water tank has not been sufficiently filled.	1. Fill the water tank with fresh, cold water up to the mark max.2. Insert the water tank.
LED lights up even though there is enough water in the water tank.	Float is stuck in the water tank.	1. Descale the appliance. → "Descale the appliance", Page 312. Reach into the water tank and move the float up and down.
	Water tank is wrongly inserted.	1. Insert the water tank correctly.2. Push the water tank into the appliance until it clicks into place.
LED calc lights up.	Build-up of limescale in the appliance.	Descale the appliance. → "Descale the appliance", Page 31
calc LED flashes.	Heavy build-up of limescale in the appliance.	Descale the appliance. → "Descale the appliance", Page 31
calc LED lights up even though decalcified water has been used.	Decalcified water still contains small amounts of lime.	Descale the appliance. → "Descale the appliance", Page 31
calc LED and LED are simultaneously lit and the brewing process is not possible.	Appliance has a fault.	1. Unplug the mains plug. 2. Contact the TASSIMO careline.
calc LED and LED flash simultaneously.	Descaling process is running.	Wait until the descending process is complete.

Problem with results

Fault	Cause	troubleshooting
Crema has deteriorated.	Beverage outlet is soiled.	Clean the beverage outlet. → "Cleaning and servicing", Page 31 Clean the brewing unit with the T DISC. → "Cleaning and servicing", Page 31
	Build-up of limescale in the appliance.	Descale the appliance. → "Descale the appliance", Page 31
Drink volume has changed.	Build-up of limescale in the appliance.	Descale the appliance. → "Descale the appliance", Page 31
Drink volume has reduced.	Water tank has not been sufficiently filled.	1. Fill the water tank with fresh, cold water up to the mark max. 2. Keep pressed until the desired fill volume is reached.
Drink dispensing halts.

Disposal

Find out here how to dispose of old appliances correctly.

Disposing of old appliance

Valuable raw materials can be reused by recycling.

1. Unplug the appliance from the mains.
2. Cut through the power cord.
3. Dispose of the appliance in an environmentally friendly manner.

This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (waste electrical and electronic equipment - WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU.

Customer Service

If you have any queries, are unable to rectify faults on the appliance yourself or if your appliance needs to be repaired, contact Customer Service. You can solve many problems yourself by consulting the information on troubleshooting in these instructions or on our website. If this is not the case, contact our after-sales service. We always find an appropriate solution.

With any warranty claims, we will make sure that your appliance is repaired by trained after-sales technicians using genuine spare parts, including after the manufacturer's warranty has expired.

Detailed information on the warranty period and terms of warranty in your country is available from our after-sales service, your retailer or on our website.

If you contact Customer Service, you will require the product number (E-Nr.) and the production number (FD) of your appliance.

The contact details for Customer Service can be found in the Customer Service directory at the end of the manual or on our website.

Product number (E-Nr.) and production number (FD)

You can find the product number (E-Nr.) and the production number (FD) on the appliance's rating plate.

Make a note of your appliance's details and the Customer Service telephone number to find them again quickly.

Warranty conditions

You can make warranty claims for your appliance under the following conditions.

The guarantee conditions for this appliance are as defined by our representative in the country in which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be produced when making any claim under the terms of this guarantee.

Technical specifications

Facts and figures for your appliance can be found here.

Voltage	220–240 V~
Frequency	50 Hz
Power rating	1400 W

fr

Table des matieres

Sécurité 39

Indications generales 39

General betjening. 85

ADVARSEL - Brandfare!

ADVARSEL - Fare for forbRANDing!

ADVARSEL-Fare for skolding!

He donyckaite deTe MnaIe 8 let K npnbopy n ero ceTeBomy npoBody.

Yka3aHnI NO TexHnke 6e3OpaCHOCTN

He npdnyckaIte DeTeK MeIkm DeTaJAm.
He nO3BOJnTe DeTm INrpaTb C MeJIKNMn DeTaJIaMn.

TapaANTHnHbIe ycNoBnA

BbI nmeTe npaBO Ha rapaHTnHoe o6cnyKuBaHne BaUero npnbopa B COOTBeTCTBn CO CLeDyUOUMN yCNOBnMn.

MHorne HeNoJaKn Bbl CMOKeTe yctpaHnTb CaMoCToTeJIbHO, BOCNoJIb3OBAuBnCb INΦOpMaUeB DaHHoINHCTpyKcIn NnHa HaWeM caIte. EcIn 3To Bam He ydactc, O6paHTeCb B HaUy cepBnCHHy cnyk-6y.

Mbl Bcerda NaHdEm nOxOJaUe peuHne.

Pn rapaHTnHOM o6cnyKuBaHN n no nCeTueHn rapaHTn npOn3BOJNTeI Ma bObeCneUm peMOHT BaJero npNoBopa OByeHHbIMn CneUaJIncTAMn cepBnCHoN cLyKbbl CnONb3OBaHHeM opnHaJIbHbIX 3aNaChbIx DeTaJIeN.

Iopno6Hyu INΦOpMaunO rapaHTnHOM cpoke u ycNoBnX rapaHTn B BaWei CTpaHe Bbl MoKeTe 3aPocntb B HaWei cepBnCHO n CnyKbe, y BaWeero npoDaUca IIN HaHTn Ha HaWeM caTte.

Kpyrnocytohny Tepeoh cnyk6bl noepkKn*: OphnnaIbHb calT B HHTepHete:

8 [phone] www.bosch-home.ru

Apeca abotrop30BAHnBc cepBNbIX eHTOBP, a TAKKc BCA HkOPOMaHOno ceBPCHOMHY o6cbnyKBaHNIO DOCTyHa h OfHnuaHbHom caTte HInrhepte: Wosch-beno.nu.

Pekomehnyem Bam nonb30BaTbc yCnyramn TOnbKO aBtOpN3OBAHHbIX cepBnchbIX ueHTPOB.

OpHnHNbHbIe AkccecyapbI h cpeCTBa no yOxyd nB bTOBOB texHHKosB Bosch bMoXeTe pnoBo6ptt B haem dHpMeHM HHTepHemaMaraHaHe: www.bosch-home.ru/ store. CycnoOBmMn 3akaa, onnAHI duOCTABKn Bbl MoXeTe O3AKOMMTbC h aIte. TaKke opHnHNbHbIe AkccecyapbI h cpeCTBa no xOxyd Bbl MocXeTe pnoBo6ptt B ATOPONBAOBHbX cepBCMHx CEENTpaX.

1.ИЗдениe

1. Moenb

NHyTb1 1KNNHOTAO TOBko B Cnyae, ECIN 3n DaHHBe He COEPKATC B DOKYMeHTX O KONYKe H3dJIa (kaccOBy IeK N/nn ToBapAhY 1 Ke, ToBapHaN KaHnJaIa).

3.Даннaya Икфомраима паспостразгета на Малебдьшовплббору Тобарого Знaka Bosch: кOFБВAPK,КOFeMAUHNI,КOFeOMNKN, BeCbI, KOYHOBsI KMOBaHIN, MIMKeBpI, TbilnecoBcI, pe3Kn, TocTeBb, yTOnR,ФБH, pacrPmNTMnIЯн BONOC, SFKTOPOHANHKN, COKOBbKHMANK, N3MeNBHTEN, 黑IDeBpI, TlaidnHbBse DockN, BAHOKOy, HAnIOHbBSe, ByToH, napobSte CTANuH, TALINbHbBse DOckN I AnahOTHNHmI IM NEDHJI.

1. YbaKaemBdAaIbNcoDnA, CoOuaBaM, YoNoTbePdKEnHeoCoTBeTBHNaHaeiPoDyKuHmIo aTeaBbHMy BooCTBeTBnC h 2akoHdoTbcBOM oCeUcBtBnB C bOpoe 6ob3aBthnAoepTtHaKnau HqKnapRbHOAHa COOTBeTBn. IHopomauKIO 6ob3aTaBbHMo NpOeTBeTBnMo HauHXnPiOBoH oHepe cTeHKnata cooTBeTBn (DeKnapaor oCOBeTBeTBN) n CPOe eo (ee) DeTBeTBn Bb Mokote nOnuHTb O OOC eCXb bOpEoBn

Hauna npOdyuKn npOBO3DHToND KOHontPemTnAchuaHouHbHoiKOBnpOauApnE 6CX XayCrepTe M6X, aAdpc 7a6-KaBtNpHs 81739 MoHNxk, Kapn-Bepn 8hPacce 34, EgpmHHA (BSH Hausgerate GmbH, Carw-Wer-Str. 34, 81739 Munchen, Germany).

Oprhnaauiu, BbIIOHnueoi yHnKUHIO NHOCTaHORo M30TOBHTeNIA, yNtHOMOUYHIO H3TOBOTENEM HA OCHOBAHIN DOBOBOPa C HMM, ARIyE 000 E5CX BtBuTBe Ipn6bOpby, 198515, CaNKT-Tepe6pyr, r. Tepeprof, yn. Kapna CImHeNA, d.l nH. A, pHInan B r. MockBa, 119071, yn. Manan KanyKcxa, d.15, teneofo [phone], qacx [phone].

1. 063artbtehbe CBeDcHnO T EneHHueckNx XapKTeHNCTHKX npHbOp npHBeHbHa HtnoOB TaBnHKe npHbOp aHn Ha erO 3nKETe W/nn B coPBOBtBHeHbONBcEOMHTaHn

6. AkceccyapbI n cpeicTBa no yxody

Ia 10000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

7. rapaHTHn3ROTOBNTen

ΦHOMA 3KOTOBHTBnpeoCTaBnREt Hn npnoobetennn Bamm n Pocssck Foepedauon BtboOBn npBOp. RapanTHNO C BOOTBCTBNn c dEeTbOyUAMn 3AKoHDatBCTomb PΦ cspOKn 1 Ro, Hn npnoobetennn BcBepny6nBeNepABCyp 6bTOBn npBOp, K kOTOPOMy npn NKynke bblBvDaHAParantHHMn TaIOn, DECTBYOT PARANTHHNBE yCIOBNA, ne pntOmboeueaun 3aKaHOaDatBCTby PeCNbIKNn BEnpABCyp.

8. BHIMAHHe! BaXHn HhOpMaqua nIy notpe6ntene

AnHHn pNbOp npHdHa3aHue nIy cNtBb0aHn KcNIOHHTbBO JnI yNHbX, CBeMeHbX, DOMaHxu H NbHx HNyK, He CBa3aNbC ocCy-CTeBnEHnnpDInpHmAtenbCKoN DeTbeHbOCTn N60 OyOBnEBoTHbM EblTOBbX BOT6BHOCT B oDHCpePnDnHnY, yUPEckDHeHNr OprH3aun. McNtBbObaHn pNbOpBa B cENx, OTMNbIX ToB bIyEka3AHbX, RABREAC HApuyHemn PpBNn HndKeaueKcKnPyataunnpb6Oba.

Hannmei Pnemhemn 3abckocn Tbnbokn Hn pncb6 oBcnatsheln Oekanmycta, y6bnehtcbe n anhnnn cOpaohnne ee npnnp 2e hene bce cpoka cnbckpnbopa. yanehne Taobnncn Bk eonbne hnhnnn bnbpno k noBomKmhm npahyewnnn npanen be

HtOROBHTEN He nce OETBCBHEHOCTb 3a HEOCTAOCTn B nPbPOe, cecn EPCBIOCHN CNOB 6dEeKoJAZAHo, OHIO OHBOAHNIOH NcNEpeDgau NPbOe NOPEIENBcN BNCIECTBNHAPUHUYINM Nm PABNINN NbnOBaBHn, TpACNTIOHPBOKn, XpAEHNH, DaeBTHN TpBxNIIH, HnepeOIOHNMOH CNbH (NOKApA, pnpOHDOH KATAcTOPbI n m), nONANDAH BbTOBEXHAcKOBXmR bHybOuB, OBaEDTBNHbNIOH NcOpOTCNNHAX (PakTOB) a TAKKEO HIOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNPOOHNBOHIOH NcNFOPOPNCC08YcAHOBbNHXbTOC 32124-2013.

NIOIbETPGEHINa dtbO NOKYNk nRbOPa npr RaTAPAHNIHm oMePOHn HmNEpBENLHeHn HbN pReCymTOEHHHx 3AKOHOp mTe6BOAHn bYbEaHTbHO NPOcHnB CaoXpaOHyDtO KOnyMeHn O NOKYNk (HEK, KBTHAHNIO, hInbe DOKyHMeHTN, NOBTEPBAQDOJIeAHT DaN M ETCO NOKYNkn).

C60nIeHnepeKoMeaHauN yK3AaHnO, cOepEkaXcXb C N HCTpyKuIN no 3KnPnyatauN no pnaBnA Xnlo3BaHnA), nOMOKETn36KaXaTb npo6nem B KcnPauatauN pnp6ba o er O6OyKNaAaBn

Hecnpcbahe yh3 npbOpoBp a rapahtnhni neDho16 6eCnAto pmoHTNpyKOTCR HNI 3ameHOTCR HOBIM. PeueHne BonPOCA oI neceoo6paHOCTHX 3AmEHNI pMOHTA OCTaERc 3a knyKcMAB CEPBCNA.

9.Инфорmaцьо cepBnce

B neopnoH n oce HCTENHn p aHTAHNO CPO kAa Hcyb6e BepnHcA, a takke MactpeckHe hauHn nphehOB BCgda otobnIOBnKHTbH 100000000000000000000000000000000000000000000000000000000000000000000000000000

Cpck cyk6bbl mabn6b0x npb06bp (kpoxy kmoohmbx komcbaHOB and nncleobet 2 qda. Cpk cyk6bbl kyoohhbo h okmabhOB nncmocobc coaetanr 2 qda. Cpk cyk6bbl kmoohchoc h eonnpeneneHH, c dttb Htrotobehn Hsienhen Hn tnoybo rnbunky hcnbeB. BCBtctb3m Co ctaHaptom hrotoBHTen data hrotoBHeHH HnnehtotheeHHMCHN 1920, a MM - MeCNH HnnehtotheeHH MInnehtotheeHH NpObeHoxd600K 1920 npb6kbHbT bChcHOT

*BecnntbHk KpyrnocyouHb TepeoH n3BOHOKOB HteppHTOpn PΦ.

B34C065N1-1M00 03/2017

HOpMaunO 6bIOBo TExnKe, npOn3BeDeHHo N IOKoHTpONeM KOHcepHa BCX XaycrepeTe Tm6X, Kapn-Bepn-Itp. 34, 81739 MHOxH, TepMaHnB CooTBeTCTBnC Tpe6OBaHNMy 3aKOHOaTeNbCTBa O TEXHueCKOM peryInpOBaHNn 3aKOHOaTeNbCTBa O 3aUNTe npab nOTpe6nteNe Poccncko Fepaunn

Ipoodykui: 3neKtpoayHnKn, yaeBapKn, TocTebpI, MyJbTnBapKn, ToBapHbN 3HaK:Bosch KOHTaKTThIe rpnIn, np6Opbl Ira ropqnx HAnNTKO B TASSIMO

BHIMHAHE! ACCPHTMEINT PNOKUMNIOCTHO NOBIOBETCRA. TeHnEXECKNE XAPAKTEPHNTNOPODKUIN, B TOM CHNE 3NEHPOZ3O4EKTBOHNOCTO, NOCTHO COOBEPHECTBYOTC. PNOKUMNIOPTPOXNDI ONUOHTNOIIOBETHYIO NOPEDUPYQ NTOBPOEKDBKHNOCBOHTCBETNORCOHANEOBETDYLIOYE M AOKHOATIDCTB.N. IIOOPMADNIIOO E KEBKNIBHIXC TAEYBIHIXC BCPNDIKKATOB COTDBETTBNIC H O KOPAKHX IN DECTBNN, INOPFMADLIIOO 6 AKTAYIHOOM ACCPHTMEINT PNOKUMNIO7NOVHTyB. OBUHNIHOJIOE KFLKUNIOHIOCTPAHONHO HOTBOTERTHO HAI TEPOTROPINOSPOCCNIKOΦDEPAOOO CCSEBTBOIE PIP60bR]. 198515, CanT-TeP66Byr. rTeproo. yn. Kapla CMENBa, d.l. nHTA, Fxnnmian B r. MockBa, 119071, yn. Manal Karnykcsa, d.15, tenehof [phone], faoic [phone].

KOMANHOO 已 5CXBbTBeBnIp60bp]18551.CaHTt-TepeBpyr.r.TerepeOp.yn.FaKAPmHcMeHa, dI rA.ФINMAN B M KocBa, 19071, yN. Manal KanyKckBa, d.15, teneOFO (1935) 737-2777, faoKc (1935) 737-2798 cOoCTBnAETBcBOE TaeNTBHeCnTO NtoBETBKeHN COOTBETBnTH PNOxIKYUN TO INMENI POIOBEOITHEN H aEDHOI TAMOXEHNO THEPTOPIOI EepaBNICKO OEOHOMECKEO OCOOA B CooTERTBOUIMN TEXHNCCKMMI perrAMENTAMN, B Kaehctbe YNIOHMOHNO HIOI ROTOBTENEM PHLAA, A TAKOE BIIIOHNET TPEBOBAHHN, PNDYCMOTPBHe 3AOKOHMP FNe 184-Φ3 e TXHNCHECKOM PERYIOBAAHn I DnI hla, B BuONHOIEIOE OyHkUMN HIOCTPAHNO HIOIROTOBATAHn H TePPOTIPNPOCCKKF DEpaeeapra

MInOpTePOMB PocmckyFo DepepaHNO pOdyuMn, ceptnHpnpoBaHNoB KAnctBe cepNHO npOBAODMOH, BnAeTcO OOO «ECX BbToBbE
PnIb6bBy, 198515.CaKtI-Perebpyr, r. IeproPh, yN. Kapna CmmeHa, d. 1 nT.A, pHmian B r. MockBa, 119071, yN. Manar KanyKcKa d.15,
TeneOpH [phone].

Oprnnaauiu, ukaBbEeMoH na PNDkUHm B cIeXh XeTnDfNkAum npDyKUHm n OcUyJIeCTBnHou nePBWHyoe paMaSeHne npDyKUHM ha pBuHke EAponeckoi co103a, yanreTeC PoBeF ToBx Yaccrepe Tm6X Kapn-Bepn-LItp. 34, 81739 MioHXe, tegMaHra (Robert Bosch Hausgerate GmbH, Carw-YerStr. 34, 81739 Munchen, Germany).

OpDnHcKHMJLcM (3tOToBHTeM), OcUeCTBnHOUMIM OT CBOERIO MMEHN 13oTOr0BHeNHE pOdykUNI N OTBETCBeHHbIM 3a ee COOTBETCTBHe TpeBoAHmNpMmEBNx TeuHcckXmn ParnneHOB, RAnrTeC BxC Xaycrepe Tm6X, Kapn-Bepn-lltp. 34, 81739 MxHxen, FepMaHNA (BSH Hausgerate GmbH, Carw-Ey-Wsr. Str. 34, 81739 Munich, Germany).

Ipipepebo3K, npor3yke, paoHHeHHnpoDkyckn CneDyET pyKOBOCTBOBAtcBcN, NOMMO IaONKeHNbX B INHTpykLNIO KCNPLNYATALNN, cnElyHNI Tpe6oBBHnAAHMA

3Aaepae3rnoepbbrpnoooykHcuyceBtBEHHbIMMekhnaeKHMnHarpy3kAM, KOTOpBteN PNOBKeHnOIOBpeKHeHIOPODyKlMnWnHn HApUeHNoo ee nyakOBK.

Heo6xOIMO n36eratb nonadHn Ha ynakOBky npodykUm BObln dpynx KIOKCTe.

Perepe nepezokn Hn pepeaueh na xpaeniee bBbue B 3KcNpyatau npDyuknn pnp OtnpAteIbHO TEmneepatye He60xmo y6ebntbcB ATCOTYBEINB PBDycku BDObl.

PpOyKm npEHa3NaHeKa HcTb3OBaHIO BycnOBHX TempepaTybl BbIe 0^ nOTHOINBHO INAHOH 93%

Pepa Hae anomckn 100nnpdokn, nnnbHoe Bpma HaxdoBueeio NOI BO3dEHTBNM OTPaTeBHO TEMPeATpyb, Heo6xOmoMo BV- dKepebKy E y BCNOINK XOMAHTHN Tmepatpyb NcHoJIko Yocauh.

FB5860 / abryct 2019

TexHnueckne xapaKTepeNCTnKN

3Decb Bbl HaJdeTe UINPbI N PaKTbI, OTHOcAunecKaBaWeMy npnbopy.

Central Service Contacts

Tassimo support: Tlf. 80-883521

www.tassimo.dk

For information, questions or locations of authorised Bosch service centres nearest you, please contact TASSIMO:

Phone: [phone]

www.tassimo.co.uk

GR TASSIMO Fpum Etnikoovviaic

CY Katavawotw

Iaepwnieic -nnpoopoeic oeytkae ta tpoivota Tassimo nia to kovniotepe eouiootnevo anoeio service tnc Bosch napakaloume etikoavvntoc Ipaun Karatavaawkupou 800973

91 XwpiC XpEwoN

www.tassimo.gr

IE TASSIMO careline

For information, questions or locations of authorised Bosch service centres nearest you, please contact TASSIMO:

Careline: 1800 454501

www.Tassimo.ie

NO TASSIMO-hjelp

Looking for help? You'll find it here.

Expert advice for your Bosch home appliances, help with problems or a repair from Bosch experts.

Find out everything about the many ways Bosch can support you:

www.bosch-home.com/service

Contact data of all countries are listed in the attached service directory.

Visit tassimo.com for registration, accessories and more.
