Mix Pro Solo - Blender LAGRANGE - Free user manual and instructions

Product type	Personal blender (solo)
Brand	Lagrange
Model	Mix Pro Solo
Bowl capacity	0.6 liter
Bowl material	BPA-free Tritan plastic
Blade	4-blade stainless steel
Power	600 W
Speeds	2 speeds + pulse
Main functions	Mixing, crushing, emulsifying, smoothies
Safety	Operation lock if bowl not properly locked
Cleaning	Bowl and lid dishwasher safe
Dimensions (L x W x H)	12 x 12 x 28 cm
Weight	1.2 kg
Color	Black / Stainless steel
Power supply	220-240 V, 50-60 Hz
Cable length	1 meter
Included accessories	1 bowl, 1 lid with measuring cap
Maintenance	Clean after each use, rinse the blade
Spare parts available	Bowl, lid, blade, seal
Repairability	Repairability index 7.5/10 (estimate)
Warranty	2 years

Frequently Asked Questions - Mix Pro Solo LAGRANGE

How to use the Mix Pro Solo blender?

Place the ingredients in the bowl, screw on the lid, then plug in the appliance. Select the desired speed (1 or 2) or use the pulse function for precise control.

Can I blend hot foods?

No, never pour hot liquids (above 60°C) into the plastic bowl. Let it cool before blending.

How to clean the blender?

Unplug the appliance, disassemble the bowl. Wash the bowl and lid in the dishwasher or with soapy water. Clean the blade with a brush under running water.

The blender does not work, what should I do?

Check that the bowl is properly locked on the base, that the appliance is plugged in, and that the safety button is pressed. If the problem persists, consult the manual.

What is the maximum liquid capacity?

Do not fill beyond the MAX mark (about 0.5 liter) to avoid spills.

Can I blend ice cubes?

Yes, use the pulse function with short presses to crush ice cubes. Do not run continuously.

How to avoid leaks?

Make sure the sealing gasket is properly in place under the lid and that the bowl is screwed on tightly.

The motor smells like burning, is this normal?

If the appliance is used too long continuously, it may overheat. Let it cool for at least 10 minutes before reusing.

Can I blend nuts or seeds?

Yes, but in small quantities and using the pulse function to avoid overloading the motor.

Where to find spare parts?

Contact Lagrange customer service or check the official website. Parts such as the bowl, blade, and seal are available.

USER MANUAL Mix Pro Solo LAGRANGE

ASSEMBLAGE ET MISE EN SERVICE DU BOL MIXEUR (SELON MODÈLE)

LAMES ÉMINCEUR / RÂPE FINE / RÂPE ÉPAISSE

CONDITIONS DE GARANTIE

BESCHRIJVING VAN HET APPARAAT

IN ELKAAR ZETTEN EN INGEBRUIKNAME VAN PUREESTAMPER (AFHANKELIJK VAN HET MODEL)

IN ELKAAR ZETTEN EN INGEBRUIKNAME VAN DE MENGGKOM (AFHANKELIJK VAN MODEL)

SCHAAF / RIJNE EN GROVE RASP

ZUSAMMENSETZEN UND INBETRIEBNAHME DES PÜRIERSTABS (JE NACH MODELL)

HOBEL / FEINE UND GROBE RASPEL

ASSEMBLAGGIO E MESSA IN FUNZIONE DELL'ACCESSORIO PER PUREA (SECONDO IL MODELLO)

ASSEMBLAGGIO E MESSA IN FUNZIONE DEL BICCHIERE DEL FRULLATORE (SECONDO IL MODELLO)

LAMA AFFETTATRICE GROSSA / DA GRATTUGIARE FINE E DA GRATTUGIARE GROSSA

MONTAJE Y PUESTA EN SERVICIO DEL PASAPURÉS (SEGÚN MODELO)

MONTAJE Y PUESTA EN SERVICIO DEL VASO DE LA BATIDORA (SEGÚN MODELO)

DESCRIPTION OF THE APPLIANCE

1. Variable speed control
2. ON button
3. MAX button
4. Coiled cord
5. Motor unit
6. Blending shaft
7. Whisk drive (depending on model)
8. Wire whisk (depending on model)
9. Bowl
10. Bowl lid
11. Potato masher holder (depending on model)

12. Potato masher (depending on model)

13. Food processor lid (depending on model)

14. Blade holder (depending on model)
15. 3 blades: slicer – fine grater – coarse grater (depending on model)
16. Food processor bowl (depending on model)
17. Chopper metal blade (depending on model)
18. Chopper plastic blade (kneading blade) (depending on model)
19. Slip-resistant base (depending on model)

Mix Pro

Type 619

SAFETY INSTRUCTIONS

Carefully read these user instructions and keep them for future reference.

* Always make sure that the "ON/OFF" button is in the OFF position before connecting the appliance to the power supply.
* Connect the plug of the power cord to a 10/16A socket.
* When using an extension, always use a model equipped with an earth connection and with wires of a section equal to or greater than 0.75mm ² .
* Never immerse the motor unit of your appliance or its plug in water or in any other liquid.
* Parts and accessories used for preparation of food should always be thoroughly cleaned after each use.
* Children should be supervised to ensure that they do not play with the appliance.
* Persons (including children) who are unable to use the appliance in complete safety, whether due to their reduced physical, sensory or mental capabilities or lack of experience or knowledge, should never

use the appliance unattended or without receiving instructions from a responsible person.

* Do not let the cord hang within reach of children's hands.
* Ensure that the electrical voltage being used is compatible with the appliance. It is recommended to connect the appliance to a system protected by a residual current device (RCD) with a tripping current not exceeding 30mA.
* These appliances are not intended to be operated with an external timer or a separate remote control system.
* Always place the appliance on a flat, horizontal, dry and non-slippery surface.
* Never place your appliance on a hot surface, or near an open flame.
* Do not leave your appliance plugged in when not in use.
* Always unplug the appliance before its assembly, dismantling or cleaning.
* Do not let the appliance operate unattended.
* Do not use this appliance in a confined space.

* Never place any part of the appliance in a microwave oven.
* For your safety, we recommend never to use or leave your appliance in a place that is exposed to bad weather or humidity.
* Never use the appliance outdoors.
* Never use the appliance for any purpose other than its original purpose.
* Do not operate the appliance with a damaged cord or plug or after the appliance malfunctions or is dropped. In such a case, contact the Customer Service of LAGRANGE.
* To ensure your safety, use only LAGRANGE accessories and spare parts that are suitable for your appliance.
* Caution: Always disconnect the appliance from the power supply before inserting or removing accessories and before handling the blades.
* Never place your fingers or any other objects near the blades of the hand blender while it is in operation to avoid personal injury or damage to the appliance.
* The blades are very sharp. Handle them carefully to prevent the risk of injury.

* Always wait until the motor has completely stopped before lifting the hand blender out of the food.
* To avoid spattering, make sure to keep the hand blender in a vertical position.
* Caution: Do not operate your hand blender for more than one minute at a time and never use it for more than 10 seconds for processing hard or thick ingredients. When outfitted with the whisk attachment, the hand blender may be used up to 2 minutes at a time. After each use, allow the appliance to cool. These recommendations will prevent the appliance from overheating and will extend its life.
* This product was designed for processing normal family-size quantities and is not intended for professional or semi-professional use.

FEATURES

* Variable speed control
* MAX button (Turbo)
* 4-blade metal shaft
* Wire whisk (depending on model)
* Bowl with lid - capacity: 800ml
★ Stainless steel potato masher (depending on model)
* Chopper attachment – capacity 1,250ml (depending on model)
* Chopper metal and plastic blade (depending on model)
* 3 blades: slicer, fine shredder and coarse shredder (depending on model)
* 230 V - 50Hz - 800 Watts

CORD

Examine the power cord carefully before using it. If it is damaged, you must not use the unit. The cord should only be replaced by LAGRANGE its after-sale service department or a qualified person approved by LAGRANGE in order to avoid danger for the user. The cord used is a H05RR-F 3G 0.75mm ² .

These units are in compliance with directives 2006/95/CE, 2004/108/CE, DEEE 2002/96/CE, RoHs 2002/95/CE and the CE food contact regulation 1935/2004.

ENVIRONMENT

Protection of the environment - DIRECTIVE 2002/96/CE

In order to protect our environment and our health, electrical units at the end of their working lives must be disposed of according to very specific rules requiring the involvement of everyone, both suppliers and users.

That is why your unit, as indicated by the symbol on its nameplate, must not be put into a public or private garbage can intended for household wastes.

At the time of its disposal, it is your responsibility to bring your unit to a public collection center designated for the recycling of electrical and electronic equipment. If you need information about centers for the collection and recycling of discarded units, please contact the local authorities in your region, the household waste collection services or the store where you bought your unit.

START UP AND USE

ON THE FIRST USE

When unpacking your appliance, make sure to carefully remove all the support materials, plastic bags and labels included in the packaging.
* Check the contents to ensure that all the parts and accessories are present and undamaged.
Before using your appliance, clean the attachments and accessories in soapy water or water with washing up liquid.
* Carefully rinse and dry all the parts. Refer to the Maintenance section.

HAND BLENDER ASSEMBLY AND START UP

The hand blender may be used for puréeing and mixing sauces, soups, baby food, pancake batter, smoothies, mayonnaise, etc.
To assemble the hand blender, insert the blending attachment into the motor unit and twist until it locks into place.
* Submerge the blending shaft to the bottom of the processed mixture then turn on the appliance by pressing button I or II.
• Make sure not to tilt the shaft to prevent the risk of splatter.
* Caution: do not use for blending very hard foods.

WHISK ASSEMBLY AND START UP (DEPENDING ON MODEL)

* The whisk is intended for whipping cream or whisking egg whites only. It can also be used for whisking relatively liquid preparations.
- To assemble the whisk, insert the metal whisk into the whisk drive, then twist the drive into the motor unit until it locks in place.
Submerge the blending whisk to the bottom of the processed mixture, then turn on the appliance by pressing button I or II.

ASSEMBLY AND START UP OF THE POTATO MASHER (DEPENDING ON MODEL)

* The potato masher attachment is used for making mashed potatoes or carrot purée.
* To prevent damage to your appliance, always process cooked food only.
To assemble the attachment, insert it into its holder, then into the motor unit and twist until it locks into place.
* Submerge the appliance into a large salad bowl containing carrots or potatoes cooked in water.
* Turn on the appliance.
* Move the potato masher up and down in the mixture until you have obtained the desired results.
* Once the purée is done, turn off the appliance.

ASSEMBLY AND START UP OF THE MIXING BOWL (DEPENDING ON MODEL)

SLICER BLADE/ FINE SHREDDER AND COARSE SHREDDER BLADES

The blade is fitted onto a blade holder and can slice or grate 500g of foodstuffs. For example, the slicing blade is suitable for potatoes, such as gratin dishes, carrots, cucumbers, etc. The shredder blades are suitable for preparing fine or coarse grated carrots, celery, etc., or grated cheese for gratin dishes or cheese fondue.
To assemble the blades, insert one side of the blade into the holder disc, and press on the other side until it clicks into place. Be careful not to cut yourself when mounting the blade in its slot. It is very sharp.

* Next, position the holder in the chopper bowl, lock the lid in place, and twist the motor unit until it locks into its adaptor on the lid.

* Turn on the appliance and gradually insert the foodstuffs through the feeder tube; never insert your fingers or another utensil.
After use, turn off the motor and dismantle the appliance, taking care not to cut yourself with the blade.

METAL CUTTING BLADE / PLASTIC BLADE (KNEADING BLADE)

The metal cutting blade is used for chopping hard foods, such as onions, herbs, garlic, nuts, almonds, etc. Do not grind extremely hard foods, such as ice cubes, coffee beans, nutmeg, etc.
* The plastic blade is used for kneading dough, such as pastry and pie crusts, bread dough, buns, etc.
To install the cutting blade in the appliance, place it at the bottom of the bowl, lock the lid in place, and twist the hand blender's motor unit until it locks into its adaptor on the lid.

* Turn on the appliance and gradually insert the foodstuffs through the feeder tube; never insert your fingers or another utensil.

During the blender's operation, make sure to hold the motor unit in place by holding it with one hand while holding the chopping bowl with the other.
After use, turn off the motor and dismantle the appliance, taking care not to cut yourself with the metal cutting blade.

MAINTENANCE

CAUTION:

Never immerse the motor unit of the appliance or the plug in water and never place them in a dishwasher.

Never use harsh or abrasive cloths or cleaners on the plastic parts to protect the plastic surface and maintain its shine.

* Always disconnect the appliance before cleaning it.
* Completely disassemble the product.

Note: The potato masher blade can be dismantled for more in-depth cleaning.

* Wipe the motor unit with a damp cloth. Never use a sponge or abrasive products for cleaning.
* You can clean the accessories in the dishwasher.

Note: Care should be taken to place the tip of the blades upwards to prevent water from accumulating inside.

ENG

RECIPES

MAYONNAISE

Ingredients: 1 egg yolk - 100ml sunflower oil - 1 tablespoon of mustard - 1 dash of vinegar (optional) - salt - pepper.

Preparation: Place the egg yolk and the mustard in the supplied bowl. Use the suction base to attach the bowl to the table. Dip the appliance fitted with the whisk accessory into the mixture and turn on the appliance. Add the oil slowly. At the end, add pepper and a dash of vinegar. To achieve a firmer texture, you can use the mixer attachment instead of the whisk.

PANCAKE BATTER

Ingredients (for about 12 fine crêpes): 250g flour – 2 eggs – 3 tablespoons caster sugar – 25g melted butter – 1/2 teaspoon salt – 3 tablespoons oil – 1 tablespoon rum – 1/2 litre milk.

Preparation: Place the flour and eggs in a salad bowl. Add the sugar, the melted butter, the milk and the rum. Dip the hand blender into the ingredients and turn on the appliance. When the batter is completely smooth, let it rest for at least half an hour.

SHORTCRUST PASTRY

Ingredients: 250g flour – 125g butter – 1 pinch of salt – 50ml water.

Preparation: Place the flour, salt and butter cut into pieces into the bowl fitted with the kneading plastic blade. Turn on the blender, then add the water through the feed tube. Continue mixing. Turn off the appliance as soon as the dough forms a ball. Leave the dough to rest for an hour in the refrigerator before spreading it.

GUARANTEE TERMS

Guarantees for LAGRANGE household appliances.

Your unit is guaranteed for 2 years.

In order to receive an additional year of guarantee free of charge, register on the LAGRANGE web site (www.lagrange.fr). The guarantee includes parts and labor and covers manufacturing defects. The guarantee does not cover deterioration due to poor use or non-observance of the instructions for use or breakage due to falling.

THIS GUARANTEE APPLIES TO HOUSEHOLD USES. IT CANNOT APPLY TO PROFESSIONAL OR SEMI-PROFESSIONAL USES.

The legal guarantee due from the seller does not in any way exclude the legal guarantee due from the Manufacturer for manufacturing flaws or defects according to articles 1641 to 1649 of the Civil Code. In the event of a breakdown or malfunction, contact your retailer. In the event of technical defects observed within one week of purchase, the units will be exchanged.

Beyond this period, they will be repaired by the LAGRANGE after-sale service.

To benefit from this guarantee, the user must present a copy of the invoice specifying the date of purchase of the unit.

Duration of availability of spare parts

In accordance with article L 111-2 of the consumer code, the availability of spare parts that we provide for a repairable product is 5 years as of its date of manufacturing.

However, this availability is only guaranteed in the country where the product was purchased.

Shipping costs for returns

After the first year which benefits from the dealer's guarantee, you will only have to pay the costs for returning the product to the factory. We will ship it back to you at our expense as quickly as possible.

If you have any other questions about our products, you can contact us at the following address:

LAGRANGE
