Product Type	Colour-change ceiling light
Model	IAN 101262
Brand	Livarno Lux
Operating Voltage	230-240 V~, 50 Hz
Protection Class	II (double insulated)
Protection Rating	IP20
Maximum Total Wattage	9 x max. 14 W
Halogen Bulb Type	G4, 12 V~, 14 W (included)
LED Bulbs	54 x 0.06 W (permanently fitted, colour-changing)
Remote Control Frequency	433.92 MHz
Remote Control Battery	23 A, 12 V (included)
Remote Control Range	Not specified (typical indoor range)
Number of Lamp Shades	9
Installation	Ceiling mount, requires professional installation
Indoor Use Only	Yes, dry enclosed spaces
Cleaning	Dry lint-free cloth, no solvents
Warranty	3 years from date of purchase
Included Components	Ceiling light, 9 halogen bulbs, remote control, battery, mounting hardware, tool

Frequently Asked Questions - IAN 101262 Livarno Lux

What is the maximum wattage per bulb?

Each halogen bulb socket supports a maximum of 14 W at 12 V~ with a G4 base.

Can I use LED bulbs instead of halogen?

The light is designed for 12 V~ halogen bulbs with G4 socket. LED replacements may work if they are compatible with 12 V AC and fit, but always check the specifications. The built-in colour LEDs are not replaceable.

How do I change a halogen bulb?

First, disconnect power at the fuse box. Let the light cool completely. Carefully pull out the defective bulb and insert a new one using a clean, lint-free cloth. Use only max 14 W, 12 V~ halogen with G4 socket.

Why is the remote control not working?

Check if the wall switch is on. If yes, try switching the wall switch off and on again, then wait 15-20 seconds before using remote. If still not working, replace the remote battery (type 23 A, 12 V).

How do I install the ceiling light?

Installation must be done by a qualified electrician. Disconnect power, mount the bracket to the ceiling, connect wires (L, N) using the terminal block, attach the light, and install the shades. Detailed steps are in the manual.

What are the colour modes?

The remote control offers multiple modes: slow colour change, rapid colour change, flowing colour, and static colour selection (blue, green, red, or combinations). Press the corresponding buttons as described in the manual.

Can I use a dimmer with this light?

No, the permanently fitted LED bulbs are not suitable for dimmer or electronic switches. Use only the supplied remote control or wall switch.

Is the light suitable for bathrooms?

No, the light has IP20 protection (not water-resistant) and is intended for dry indoor spaces only. Do not install in damp or wet areas.

What batteries does the remote control use?

The remote requires one 23 A, 12 V battery (included). Replace with the same type when needed.

How do I clean the light?

Always disconnect power first. Wipe with a dry, lint-free cloth. Do not use water, solvents, or abrasive cleaners. Ensure no moisture enters the connectors.

USER MANUAL IAN 101262 Livarno Lux

COLOUR-CHANGE CEILING LIGHT

GB IE

COLOUR-CHANGE CEILING LIGHT

Operation and Safety Notes

NL

PLAFONDLAMPMET KLEURENWISSELING

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

DK

GB / IE Operation and Safety Notes Page 5

Introduction

Intended use....Page 6

Scope of delivery....Page 6

Parts description....Page 6

Technical Data Page 6

Safety

Safety notices....Page 7

Preparation

Required tools and material Page 8

Prior to installation....Page 8

Installation

Mounting the light....Page 8

Start-up

Inserting / replacing batteries (remote control) Page 9

Installing the wall bracket (remote control)....Page 9

Switching the luminaire on/off....Page 9

Remote control functions....Page 9

Changing the bulb....Page 10

Cleaning Page 10

Disposal Page 10

Warranty / Service centre

Warranty Declaration......Page 10

Service address......Page 10

Declaration of conformity....Page 11

Manufacturer....Page 11

Colour-change ceiling light

- Introduction

Congratulations on your new product.

You have selected a high quality product.

The instructions for use are a part of the product. They contain important information about safety, use and disposal. Before using the product, please familiarise yourself with all the operating and safety instructions. Only use the product as described and for the indicated purpose. When passing this product on to others, please be sure to include all its documentation. Before using this product for the first time verify the correct voltage and that all parts are properly installed.

Intendeduse

This light is only suitable for indoor use in dry and enclosed spaces. The light can be fastened to any normally inflammable surface. This product is only intended for private household use (LED colour change - not room lighting).

- Scope of delivery

Check immediately after unpacking that the parts are complete and that the product is in proper condition.

1 Colour changing ceiling light, model 3571-096L

9 Halogen light bulb, G4, 14 W

1 Remote control unit

1 Battery, 23 A, 12 V

4 Screws (ceiling bracket)

4 Rawlplugs

1 Tool

1 Set of instructions for use

- Parts description

1 Mounting bracket
2 Connection housing
3 Rawlplug
4 Screws (connection housing)
5 Screws (mounting bracket)
6 Lamp shades
7 Plastic ring
8 Nut
9 Tool
10 Light bulb
11 Bulb socket
12 Plastic housing
13 Protective tube
14 Mains connection cable (external)
15 Terminal block
16 Remote control unit
17 Screws (wall bracket)
18 Wall bracket (remote control)
19 Rawlplug (wall bracket)

- Technical Data

Ceiling light:

Operating voltage: 230-240V\~, 50Hz

Halogen light bulb: 12 V\~, 14 W, G4

LED light bulb: LED 54 x 0.06 W,

coloured

Rated power

maximal: 9 x max. 14 W

Protection class: II/☐

Protection class: IP 20

Remote control receiver:

Rated voltage: 220-240V\~, 50/60Hz

Max. load capacity: 250 W

Frequency: 433.92 MHz

Remote control transmitter:

Operating voltage: 12 V=, 5 mA

Frequency: 433.92 MHz

- Safety

Safety notices

Damage due to failure to comply with these operating instructions will invalidate the guarantee! We assume no liability for consequential damage! We assume no liability for material damage or personal injury due to improper handling or failure to comply with the safety instructions!

DANGER TO LIFE AND ACCIDENT HAZARD FOR TODDLERS AND SMALL CHIL-

DREN! Never leave children unattended with the packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers. Please keep children away from the product at all times.

Avoid the risk of fatal injury from electric shock

■ Protection class II / ☐ this light is specially insulated and must not be connected to an earth conductor.
■ Ensure that a qualified electrician, or a person trained to carry out electrical installations, performs the electrical installation.
We assume no liability for material damage or personal injury due to improper handling or failure to comply with the safety instructions!
■ Never use the light if any defects have been identified.
■ Prior to installation, remove the fuse or switch off the circuit breaker (0 setting) in the fuse box.
■ Ensure that the light does not come into contact with water or other liquids under any circumstances.
Before assembly, ensure that the available mains voltage corresponds to the operating voltage necessary for the light (230–240 V\~).
■ Ensure that no cables are damaged when installing.
- Do not install the lamp on damp if conductive surfaces.

vent fire and injury hazards

Install the light so that it is at least 0.3 m from any illuminated materials. Fire can result from the development of too much heat.

To prevent burns, ensure that the light is switched off and has cooled down before touching it. Lamps develop a lot of heat in the area of the lamp head.

■ Attention! Do not touch bulb components or bulbs during operation as they can reach temperatures > 90 °C.

- Allow the light to cool down completely before replacing a defective bulb.

- Replace defective bulbs with new ones immediately. Use only those bulbs as stated in the chapter on "Technical Data". Before changing bulbs, always first remove the fuse or switch off the circuit breaker.

The LED light bulbs are permanently fitted and are not replaceable.

Do not look directly into the light source (light bulb, LED etc.).

The permanently fitted LED light bulbs are not suitable for dimmer or electronic switches.

Safe working

Only uses 12 V\~ halogen light bulbs with a G4 socket and a maximum output of 14 Watt.

Do not touch the halogen lamps with bare hands. If this accidentally occurs, the light bulb must be wiped with alcohol and a lint-free cloth.

Only use halogen light bulbs with cover glass or low-pressure technology.

■ Mount the light so that it is protected from moisture and dirt.

Carefully prepare for assembly and allow yourself adequate time. Organise all parts and any necessary additional tools or materials before starting so they are easy to reach.

■ Always be attentive! Always pay attention to what you are doing and proceed with caution

at all times. Never install the light if you are having difficulty concentrating or do not feel well.

● Preparation

- Required tools and material

The tools and materials specified are not included. This information and these values are non-binding and are only provided as a reference. The nature of the material is determined by the individual local conditions.

• Pencil/making tool
• Voltage tester
• Screwdriver
• Electric drill
• Bit (approx. 0.6 cm)
• Side cutting pliers
• Ladder

- Prior to installation

Important: The electrical connection must be established by a trained electrician or a person trained to perform electrical connections. This person must be familiar with the properties of the light and the connection regulations.

☐ Familiarise yourself with all the instructions and diagrams in this manual, as well as with the light itself, before you install it.
Before installation ensure that the circuit, to which the light will be connected, is not energised. To do so, remove the fuse or switch off the circuit breaker in the fuse box (0 position).
☐ Use the voltage tester to verify the de-energised status.

- Installation

- Mounting the light

☐ Prior to installation, remove the fuse or switch off the circuit breaker (0 setting) in the fuse box.
☐ Remove the screws 4 visible at the side of the connection housing 2 and remove the mounting bracket 1 at the back.
☐ Use the slotted holes intended for the mounting bracket 1 to mark the bores.
☐ Now drill the fixing holes (approx. 6 mm, depth approx. 35 mm). Ensure that you do not damage the supply line.
☐ Insert the rawlplugs 3 into the holes. Fasten the mounting bracket 1 with the provided screws 5.
Open the plastic housing 12. Then feed the mains connection cable (external) 14 through the protective tube 13 on the plastic housing 12. Now connect the connection cable of the light to the mains connection cable (external) 14 using the terminal block 15. Be sure to correctly connect the individual wires of the mains connection cable (external) 14: live wire, black or brown = symbol L, neutral wire, blue = symbol N).
☐ Close the plastic housing 12.
☐ Use the screws 4 to fasten the luminaire to the mounting bracket 1.
☐ Remove the nuts 8 and plastic rings 7 from the lamp bulb sockets 11.
☐ Attach a lamp shade 6 onto each bulb socket 11.
☐ Secure the lamp shades 6 with the plastic rings 7 and the nuts 8 using the tool.
☐ Use a clean, lint-free cloth when inserting the light bulb 10.
□ Carefully insert the light bulb 10 into the socket.
Check for correct fitting.
☐ Reinsert the fuse or switch the circuit breaker back on.

Your light is now ready to use.

- Start-up

- Inserting / replacing batteries (remote control)

Open the battery compartment at the back of the remote control 16.
☐ Remove the spent battery, if necessary.
☐ Insert a new battery into the battery compartment. Only use type 23 A, 12 V—batteries.

Note: Be sure to correctly insert the batteries (polarity). This is indicated on the battery cover.

☐ Close the battery compartment of the remote control 16.

- Installing the wall bracket (remote control)

☐ Hold the wall bracket 18 in the desired location on the wall and mark the drill holes.
□ Now drill the mounting holes.
☐ Insert the rawlplugs 19 into the drill holes.
☐ Secure the wall bracket 18 using the included screws 17.
☐ Tighten the screws to secure the wall bracket 18. Do not overtighten the screws 17.
Place the remote control 16 into the wall bracket 18.

- Switching the luminaire on / off

You have the possibility of operating the luminaire from an ordinary wall switch or switching it on and off using the supplied remote control unit.

Switching the luminaire on / off using the remote control unit:

• The wall switch is in the basic position (OFF).
  □ Activate the wall switch (ON).
  ☐ Press the ON button on the remote control 16 to switch the light on (halogen light bulb and LED).
  ☐ Push the OFF button on the remote control 16 to switch the light completely off.

Switching the light on / off with the wall switch

☐ The wall switch is in the basic position (OFF).
□ Activate the wall switch (ON). The halogen light bulbs are on.
☐ Activate the wall switch within approx. 1 second by repeatedly pushing off and on. This will switch through the various switch positions (halogen light bulbs and LED).
☐ The light can be switched off with the wall switch or the remote control 16.

- Remote control functions

ON/OFF Halogen light bulb and LED on or off End colour change / colour selection

Colour

Changing slow colour change LED:

Press 1 x = rotate left

Press 2 x = rotate right

rapid colour change LED:

Press 3 x = rotate left

Press 4 x = rotate right

Press 5 x = flowing colour

change LED

Lamp Halogen light bulb on or off

Colour

Selection Press 1 x: blue LED

Press 2 x: green LED

Press 3 x: red LED

Press 4 x: green / blue LED

Press 5 x: green / red LED

Press 6 x: red / blue LED

Press 7 x: green/red/blue LED

Troubleshooting:

If the remote control 16 does not respond after switching the light on, first press the wall switch to switch the light off. Then wait approx. 15-20 seconds and activate the wall switch again.

If after switching on the luminaire again via the remote control unit 16 the luminaire still does not respond, check the batteries in the remote control unit 16.

- Changing the bulb

CAUTION! RISK OF ELECTRIC SHOCK!

To replace the bulb, first disconnect the light from the mains circuit. To do so, remove the fuse or switch off the circuit breaker in the fuse box (0 position).

CAUTION! DANGER OF BURN INJURIES!

Allow the light to cool completely.

☐ Replace the bulb 10 only after it has fully cooled.
☐ Carefully pull the defective light bulb 10 out of the socket.
☐ Use a clean, lint-free cloth to replace a bulb.
☐ Only use max. 14 Watt, 12 V\~ halogen light bulbs with a G4 socket.
☐ Now carefully insert the new light bulb 10 into the socket. Check for correct seating.
☐ Reinsert the fuse or switch the circuit breaker back on.

- Cleaning

CAUTION! RISK OF ELECTRIC SHOCK!

Disconnect the light from the mains circuit before cleaning. To do so, remove the fuse or switch off the circuit breaker in the fuse box (0 position).

☐ Only clean with a dry, lint-free cloth. Do not use solvents, spirit or similar substances. They could damage the light.
☐ Allow the light to cool off completely.
☐ The care of lights is limited to the surfaces. Never allow moisture to enter terminal compartments or conductive components.

- Disposal

The package and packaging materials consist entirely of environmentally friendly materials. They can be disposed of at your local recycling facility.

The symbol of the wheelie bin with the line through it means that, in the European Union, the product has to be disposed of in a separate refuse collection. This applies to the product and to all components bearing this symbol. Do not dispose of products bearing this symbol in your normal household waste, but instead they must be taken for recycling to a collection site for electrical and electronic appliances.

Recycling helps to reduce the consumption of raw materials and protects the environment.

Batteries must not be disposed of as household refuse! Advice is available from your local council. Return the batteries and / or the device through the appropriate collection facilities.

● Warranty / Service centre

- Warranty Declaration

This product has a 3 year guarantee from the date of purchase extended only to the original buyer, not transferable. Please keep your receipt as proof of purchase. The guarantee applies to material or manufacturing defects only. It does not cover wear items or damage caused by improper use. Any modifications will void the guarantee. This warranty does not limit your legal rights. Please phone the service centre for guarantee claims. This is the only way to return your product free of charge.

Serviceaddress

Please have your receipt and the article number (e.g. IAN 12345) ready as your proof of purchase when enquiring about your product.

- Declaration of conformity C€

This product fulfils the requirements of the applicable European and national directives (Electromagnetic Compatibility 2004/108/EC, Low Voltage Directive 2006/95/EC, Ecodesign Directive 2009/125/EC, RoHS Directive 2011/65/EU, R&TTE Directive 1999/5/EC). Conformity has been demonstrated. The relevant declarations and documents are held by the manufacturer.

Manufacturer

Selection 1 x tryk: LED blå

2 x tryk: LED grøn

3 x tryk: LED rød

4 x tryk: LED grøn / blå

59929 Brilon (Germany)

Last Information Update · Tilstand af
