Product type	Professional battery charger
Brand	Bosch
Model	AL 36100 CV Professional
Input voltage	220-240 V ~
Output voltage	36 V
Max. charging current	10 A
Charging temperature range	0 °C - 45 °C
Compatible battery types	Bosch Lithium-Ion batteries (10-30 cells)
LED indicators	Green: fast charging (flashing), charged (solid); Red: temperature out of range (solid), fault (flashing)
Weight (according to EPTA)	3.0 kg
Protection class	I (grounding required)
Main functions	Smart charging with automatic current adjustment, battery protection, automatic shut-off
Care and cleaning	Clean with a soft, clean, dry brush; do not use harsh products
Safety	Do not use on flammable surface; do not cover; check cable and plug before use; use only with compatible batteries
Repairability	Repair only by an authorized Bosch after-sales service with original parts
General information	Instructions available in several languages; customer service accessible via www.bosch-professional.com

Frequently Asked Questions - AL 36100 CV Professional BOSCH

What types of batteries can I charge with the Bosch AL 36100 CV Professional?

This charger is designed to charge exclusively Bosch Lithium-Ion batteries compatible with 36 V. The battery voltage must match the charger voltage, otherwise there is a risk of explosion or fire.

How do I know if my battery is fully charged?

The green LED stays on constantly when the battery is charged. During fast charging, the green LED flashes.

What should I do if the red LED flashes?

A red flashing indicates a fault. Check that the battery is inserted correctly, clean the contacts. If the problem persists, the battery may be defective and must be replaced.

Can I leave the battery in the charger permanently?

Yes, the charger has a maintenance charge that keeps the battery fully charged without damaging it. The green LED remains on.

What is the allowable temperature range for charging the battery?

Charging is only possible between 0 °C and 45 °C. Outside this range, the red LED lights up steadily and fast charging does not occur.

Can the charger be used outdoors?

The charger is intended for indoor use. Avoid moisture and flammable environments. Do not cover the charger.

How do I clean the charger?

Use a soft, clean, dry brush to remove dust. Do not use solvents or abrasive products.

Where can I get my charger repaired?

Have it repaired at an authorized Bosch service center. Do not attempt to open it yourself.

Is the charger compatible with batteries from other brands?

No, use only Bosch Lithium-Ion batteries. Using incompatible batteries can lead to safety risks.

What should I do if the battery life decreases significantly?

This indicates that the battery is worn out and must be replaced. Follow waste disposal instructions.

USER MANUAL AL 36100 CV Professional BOSCH

OBJ_DOKU-36279-003 fm Page 1 Wednesday, July 8, 2015 9:46 AM

3D rendering of a Bosch industrial connector housing with cable (no text or symbols visible)

Robert Bosch GmbH

Power Tools Division

70764 Leinfelden-Echterdingen

GERMANY

www.bosch-professional.com

1609 92A 0GH (2015.07) O/45 WEU

1609 92A 0GH

AL 36100 CV Professional

BOSCH

Product Description and Specifications

Read all safety warnings and all instructions. Fail-ure to follow the

warnings and instructions may result in electric shock, fire and/or serious injury.

Save these instructions for later use.

Use the battery charger only when you fully understand and can perform all functions without limitation, or have received appropriate instructions.

Safety Notes

▶ Only charge Bosch lithium-ion batteries. The battery voltage must match the battery charging voltage of the charger. Otherwise there is danger of fire and explosion.
▶ Keep the battery charger clean.
Contamination can lead to danger of an electric shock.

▶ Before each use, check the battery charger, cable and plug. If damage is detected, do not use the battery charger. Never open the battery charger yourself. Have repairs performed only by a qualified technician and only using original spare parts. Damaged battery chargers, cables and plugs increase the risk of an electric shock.
▶ Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the charger. Keep cord away from heat, oil, sharp edges and moving parts. Damaged or entangled cords increase the risk of electric shock.
▶ Do not operate the battery charger on easily inflammable surfaces (e. g., paper, textiles, etc.) or surroundings. The heating of the battery charger during the charging process can pose a fire hazard.
▶ In case of damage and improper use of the battery, vapours may be emitted. Ventilate the area and seek medical help in case of complaints. The vapours can irritate the respiratory system.
▶ Supervise children during use, cleaning and maintenance. This will ensure that children do not play with the charger.
This tool is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

8|English

Children should be supervised to ensure that they do not play with the appliance.

▶ Cleaning and user maintenance of the battery charger shall not be made by children without supervision.
▶ Do not cover off the battery charger. Otherwise, the battery charger can overheat and no longer operate properly.
▶ In addition, observe the safety instructions for the battery.
This is a class I unit and may only be connected to properly earthed power sources.

Products sold in GB only: Your product is fitted with a BS 1363/A approved electric plug with internal fuse (ASTA approved to BS 1362).

If the plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place by an authorised customer service agent. The replacement plug should have the same fuse rating as the original plug. The severed plug must be disposed of to avoid a possible shock hazard and should never be inserted into a mains socket elsewhere.

Products sold in AUS and NZ only: Use a residual current device (RCD) with a rated residual current of 30 mA or less.

Product Features

The numbering of the product features refers to the illustration of the battery charger on the graphics page.

1 Battery pack*
2 Red battery charge indicator
3 Green battery charge indicator
4 Locking latch

5 Charging compartment

6 Digital LCD display

7 Detail display

*Accessories shown or described are not part of the standard delivery scope of the product. A complete overview of accessories can be found in our accessories program.

Intended Use

The charger is intended for Professional use.

Technical Data

Battery Charger AL 36100 CV
	Professional
Article number	2 607 225 X..
Input voltage	V=220 - 240
Output voltage	V=	36
Charging current (max.)	A	10
Allowable charging temperature range	°C 0-45
Charging time for battery capacity, approx.	(80%) 100%
-1.3 A h	min (11) 24
-2.0 A h	min (16) 36
-2.6 A h	min (16) 30
-4.0 A h	min (19) 37
-4.5 A h	min (22) 35
-6.0 A h	min (29) 42
Number of battery cells	10 - 30
Weight according to EPTA-Procedure 01/2003	kg	3.0
Protection class	± /1

Please observe the article number on the type plate of your battery charger. The trade names of individual battery chargers may vary.

Operation

Starting Operation

Observe the mains voltage! The voltage of the power source must correspond with the data on the type plate of the battery charger.

Insert the battery until the locking mechanism clicks. To remove the battery, operate locking lever first.

Charging Procedure

The charging procedure starts as soon as the mains plug of the battery charger is plugged into the socket outlet and the battery 1 is inserted into the charging compartment 5.

Due to the intelligent charging method, the charging condition of the battery is automatically detected and the battery is charged with the optimum charging current, depending on battery temperature and voltage.

This gives longer life to the battery and always leaves it fully charged when kept in the charger for storage.

English|9

Note: The charging procedure is only possible when the battery temperature is within the allowable charging temperature range, see "Technical Data" section.

Meaning of the Indication Elements

Flashing Green Battery Charge Indicator 3

The rapid-charging procedure is indicated by flashing of the green charge control LED.

Note: The rapid-charging procedure is only possible when the battery temperature is within the allowable charging temperature range, see section "Technical Data".

Continuous Lighting of the Green Battery Charge Indicator 3

Continuous lighting of the green battery charge indicator 3 indicates that the battery is fully charged.

Afterwards, the battery can be re-

moved for immediate use.

With no battery inserted, continuous lighting of the green charge control LED indicates that the mains plug is plugged into the socket and that the battery charger is ready for operation.

Continuous Lighting of the Red Battery Charge Indicator 2

Continuous lighting of the red LED indicates that the battery temperature is not within the rapid-charging temperature range of 0 °C – 45 °C. As soon as the allowable temperature range is

reached, the battery charger automatically switches to rapid charging.

Flashing Red Battery Charge Indicator 2

If a different malfunction of the charging procedure is present, this will be indicated through flashing of the red charge control LED.

The charging procedure cannot be started and the battery cannot be charged (see section "Troubleshooting").

Charging Advice

With continuous or several repetitive charging cycles without interruption, the charger can warm up. This is not meaningful and does not indicate a technical defect of the battery charger.

A significantly reduced working period after charging indicates that the battery is used and must be replaced.

Observe the notes for disposal.

Troubleshooting - Causes and Corrective Measures

Battery Charger

Cause Corrective Measure
Flashing Red Battery Charge Indicator 2No charging procedure possible
Battery not (properly) inserted	Properly insert battery into battery charger till the locking mechanism clicks
Battery contacts contaminated	Clean the battery contacts (e.g. by inserting and removing the battery several times) or replace the battery
Battery pack defective Replace the battery
Battery charge indicator 2 does not light up
Mains plug of battery charger not plugged in (properly)	Insert mains plug (fully) into the socket outlet
Socket outlet, mains cable or battery charger defective	Check the mains voltage; have the battery charger checked by an authorised after-sales service agent for Bosch power tools

If you are unable to resolve the problem using the Troubleshooting guide then please contact your dealer in the first instance.

Maintenance and Service

▶ Occasionally clean the charger using a soft, clean and dry brush.

When the charger is no longer operative, please refer to an authorised after-sales service agent for Bosch power tools.

After-sales Service and Application Service

www.bosch-professional.com

In all correspondence and spare parts orders, please always include the 10-digit article number given on the type plate of the garden product.

Great Britain

Robert Bosch Ltd. (B.S.C.)

P.O. Box 98

Broadwater Park

North Orbital Road

Denham

Uxbridge

UB 9 5HJ

At www.bosch-pt.co.uk you can order spare parts or arrange

the collection of a product in need of servicing or repair.

Tel. Service: [phone]

E-Mail: [e-mail]

Bosch Power Tools 1 609 92A 0GH | (8.7.15)

10 | Français

Ireland

Origo Ltd.

Unit 23 Magna Drive

Magna Business Park

City West

Dublin 24

Tel. Service: [phone]

Fax: [phone]

Australia, New Zealand and Pacific Islands

Robert Bosch Australia Pty. Ltd.

Power Tools

Locked Bag 66

Clayton South VIC 3169

Customer Contact Center

Inside Australia:

Phone: [phone]

Fax: [phone]

Inside New Zealand:

Phone: [phone]

Fax: [phone]

Outside AU and NZ:

Phone: [phone]

www.bosch.com.au

Republic of South Africa

Customer service

Hotline: [phone]

Gauteng - BSC Service Centre

35 Roper Street, New Centre

Johannesburg

Tel.: [phone]

Fax: [phone]

E-Mail: [e-mail]

KZN - BSC Service Centre

Unit E, Almar Centre

143 Crompton Street

Pinetown

Tel.: [phone]

Fax: [phone]

E-Mail: [e-mail]

Western Cape - BSC Service Centre

Democracy Way, Prosperity Park

Milnerton

Tel.: [phone]

Fax: [phone]

E-Mail: [e-mail]

Bosch Headquarters

Midrand, Gauteng

Tel.: [phone]

Fax: [phone]

E-Mail: [e-mail]

Disposal

Battery chargers, accessories and packaging should be sorted for environmental-friendly recycling.

Do not dispose of battery chargers into household waste!

Only for EC countries:

According to the European Guideline 2012/19/EU for Waste Electrical and Electronic Equipment and its implementation into national right, battery chargers that are no longer usable must be collected separately and disposed of in an environmental correct manner.

Subject to change without notice.
