RAZE Radion 4 - Loudspeaker Niceboy - Free user manual and instructions

Product Type	Wireless Speaker
Bluetooth Version	5.0
Output Power	30W
Impedance	8Ω
Sensitivity	>75dB
Frequency Range	65 Hz – 20 kHz
Bluetooth Range	10 meters
Waterproof Rating	IP67
Battery Type	Li-Ion 5000 mAh
Battery Life	Up to 24 hours (at 50% volume)
Charging Time	Approximately 5 hours
Supported Storage	microSD card, USB flash drive (max 32GB)
Supported Audio Formats	MP3, WMA, WAV, APE, FLAC
FM Radio Frequency	87.5 – 108 MHz
Connectivity	Bluetooth, AUX (3.5mm), USB-C, USB-A
Hands-free Calling	Yes
TWS Pairing	Yes (pair two speakers)
Input Voltage	5V, 1A minimum
Charging Interface	USB-C

Frequently Asked Questions - RAZE Radion 4 Niceboy

How long does the battery last?

The battery lasts up to 24 hours at 50% volume. The built-in Li-Ion 5000 mAh battery provides extended playback time.

Is the speaker waterproof?

Yes, the speaker has an IP67 rating, meaning it is dust-tight and can be submerged in up to 1 meter of water for up to 30 minutes.

How do I pair the speaker via Bluetooth?

Turn on the speaker by holding the power button for 3 seconds. The LED will flash blue, indicating pairing mode. On your device, select 'Niceboy RAZE Radion 4' from the Bluetooth list. A successful connection is confirmed by an audio signal and slower LED flashing.

Can I use the speaker as a power bank?

Yes, the speaker has a USB-A output port that allows you to charge other devices like your smartphone. Just connect your device to the USB-A port.

How do I use the FM radio?

First, connect the included USB-C cable to the charging port to act as an antenna. Press the mode button (5) until FM mode is announced. Then press and hold the play/pause button (6) to automatically scan and save radio stations. Use volume buttons to switch between saved stations.

Can I connect two speakers together for stereo sound?

Yes, you can pair two Niceboy RAZE Radion 4 speakers using True Wireless Stereo (TWS). Power on both speakers, ensure they are not connected to any device, then long press the mode button (5) on one speaker. An audio signal confirms the connection. Then pair with your device as usual.

How long does it take to fully charge the speaker?

It takes approximately 5 hours to fully charge from empty. Use a 5V/1A adapter or a USB port on your computer. The charging LED indicators show progress; both turn off when fully charged.

Can I play music from a USB flash drive?

Yes, insert a USB flash drive (up to 32GB) into the USB-A port. The speaker will automatically switch to USB mode. Use the volume buttons to navigate and the play/pause button to control playback.

What audio formats does the speaker support?

The speaker supports MP3, WMA, WAV, APE, and FLAC formats when playing from microSD card or USB flash drive.

How do I make or answer calls with the speaker?

When connected via Bluetooth, press the play/pause button (6) to answer an incoming call. Press it again to end the call. To decline a call, use your phone. Double-press button (6) to redial the last number.

USER MANUAL RAZE Radion 4 Niceboy

User Manual / Wireless Speaker

CZ

OBSAH BALENÍ

NABÍJENÍ

https://niceboy.eu/cs/declaration/raze-radion-4

INFORMACE PRO UŽIVATELE K LIKVIDACI ELEKTRICKÝCH A ELEKTRONICKÝCH ZAŘÍZENÍ (DOMÁCNOSTI)

NABÍJANIE

https://niceboy.eu/sk/declaration/raze-radion-4

INFORMÁCIE PRE POUŽÍVATELOV K LIKVIDÁCII ELEKTRICKÝCH A ELEKTRONICKÝCH ZARIADENÍ (DOMÁCNOSTI)

USB-C charging cable

Audio cable

Instructions for Use

PRODUCT DESCRIPTION

1. Turn down volume / Previously played track
2. Turn up volume / Next track
3. LED indicator
4. Power on/off
5. Change modes
6. Playback / Pause / Call accept / call decline / hang up / last called number
7. AUX port 3.5 mm jack
8. USB charging - output, input for USB flash disk
9. SD card slot
10. USB-C charging port

CHARGING

We recommend fully charging the speaker before its first use to maximize the battery's lifespan. The speaker takes approximately 5 hours to fully charge. Low battery is announced by an audible signal. To charge the speaker's battery connect the enclosed USB-C cable to the charging port (10) and connect to any charging adapter (voltage 5V and output current minimum of 1A) or to a USB port on your PC. You can follow the charging progress thanks to the 2 charging LED diodes (3), after a full charge is complete both diodes will go out.

POWERING ON/OFF

Press and hold button (4) for 3 seconds to power on/off the speaker. Powering on and off is announced via an audio signal.

CONNECTING TO BLUETOOTH

1. The speaker is ready for Bluetooth connection from the moment it is powered on. Pairing mode is signalled by the LED diodes (3) flashing blue.
2. Activate Bluetooth on your own device. Select "Niceboy RAZE Radion 4" from the list of available devices.
3. Your device will connect to the speaker. Successful pairing is announced by an audio signal and flashing of the LED diodes (3) at five second intervals.

*Once powered on again, the speaker will automatically connect to the device with which it was last paired.

PLAYBACK

Play or pause tracks by pressing button (6). Press and hold the volume controls, located on buttons (1) and (2) to change volume. Press the volume up button to jump to the next track and the volume down button to jump to the previously played track.

AUX MODE

1. Insert the enclosed 3.5 mm jack cable into the audio port (7) and the speaker will automatically switch to the relevant mode.
2. Use the device with which you are connected to the speaker to control music playback.

Press and hold the volume controls, located on buttons (1) and (2) to change volume. Play or pause tracks by pressing button (6).

FM MODE

Connect the enclosed USB-C cable to the charging port (10) and it will act as an antenna. Press button (5) and FM mode will be announced with an audio signal; press and hold button (6) to automatically search and save radio stations. You can stop the automatic search function by pressing and holding the same button (6). While out of the search function you can switch between radio stations by pressing buttons (1) and (2). Play or pause playback by pressing button (6).

MICRO SD CARD, USB FLASH DISK

The speaker will automatically switch over to the relevant mode once an SD card or USB disk has been inserted. Play or pause playback by pressing button (6).

Press and hold the volume controls, located on buttons (1) and (2) to change volume. Press the volume up button to jump to the next track and the volume down button to jump to the previously played track.

TELEPHONE CALLS

Press button (6) to accept and then end telephone calls. Incoming calls may be declined on your device. Press button (6) twice to call the last number in your call list.

TRUE WIRELESS (TWS) CONNECTION

With the help of True Wireless (TWS) you can connection two Niceboy RAZE Radion 4 speakers to one device and simultaneously play music through both.

1. Power on both Niceboy RAZE Radion 4 speakers and ensure they are not connected to any other Bluetooth device (mobile, laptop, etc.)
2. Long press button (5) on one of the speakers. An audio signal will announce the successful connection of both speakers and both speakers.
3. Now you may open the Bluetooth settings on your own device. Select "Niceboy RAZE Radion 4" from the list of available devices. Successful pairing is announced by an audio signal.

PARAMETERS

Bluetooth version: 5.0

Frequency band: 2.4GHz

Radio frequency power: ≤ 2,5mW

Supported codecs: SBC, A2DP, AVRCP, HFP

Power: 30W

Electrical impedance: 8Ω

Sensitivity: >75dB

Frequency range: 65 Hz – 20 kHz

Bluetooth transmission distance: 10 meters

FM frequency: 87.5MHz \~ 108MHz

Supported data carrier: micro SD card, USB flash disk, max. 32GB

Supported audio formats: MP3, WMA, WAV, APE, FLAC

Battery: Li-Ion 5000 mAh

Battery life: 24 hours (at 50% volume)

Watertightness: IP67

SAFETY INFORMATION

Listening to music at excessive volume can damage your hearing. Do not subject the equipment to fluids and moisture. Do not expose the device to excessively high/low temperatures, and do not attempt to disassemble it. Protect the device from sharp objects and falls from height. Batteries - Improper handling (prolonged charging, short circuit, breakage by other objects, etc.) may result in fire, overheating or battery leakage.

The battery or accumulator that may be included with the product has a life of six months because it is a consumable item.

Information on all frequency bands in which the radio equipment operates and intentionally transmits radio waves as well as the maximum radio frequency power transmitted in the frequency band in which the radio equipment is operated is included in the instructions and safety information.

NICEBOY s.r.o. hereby declares that the type of radio equipment Niceboy RAZE Radion 4 complies with Directives 2014/53 / EU, 2014/30 / EU, 2014/35 / EU, and 2011/65 / EU. The full content of EU Declaration of Conformity is available on the following websites: https://niceboy.eu/en/declaration/raze-radion-4

USER INFORMATION FOR DISPOSING ELECTRICAL AND ELECTRONIC DEVICES (HOME USE)

This symbol located on a product or in the product's original documentation means that the used electrical or electronic products may not be disposed together with the communal waste. In order to dispose of these products correctly, take them to a designated collection site, where they will be accepted for free. By disposing of a product in this way, you are helping to protect precious natural resources and helping to prevent any potential negative impacts on the environment and human health, which could be the result of incorrect waste disposal. You may receive more detailed information from your local authority or nearest collection site. According to national regulations, fines may also be given out to anyone who disposes of this type of waste incorrectly. User information for disposing electrical and electronic devices.

(Business and corporate use)

In order to correctly dispose of electrical and electronic devices for business and corporate use, refer to the product's manufacturer or importer. They will provide you with information regarding all disposal methods and, according to the date stated on the electrical or electronic device on the market, they will tell you who is responsible for financing the disposal of this electrical or electronic device. Information regarding disposal processes in other countries outside the EU. The symbol displayed above is only valid for countries within the European Union. For the correct disposal of electrical and electronic devices, request the relevant information from your local authorities or the device seller.

DE

LIEFERUMFANG

TÖLTÉS

PUNJENJE

Preporučljivo je prije prve upotrebe potpuno napuniti zvučnik radi maksimiziranja životnog vijeka baterije. Punjenje do kraja traje oko 5 sata. Uređaj zvučnim signalom signalizira nisku napunjenost baterije. Kako biste napunili bateriju u zvučniku, priključite USB kabel na ulaz za punjenje (10) i povežite ga s bilo kojim adapterom za punjenje (napon 5V i bar 1A izlazne struje) odnosno na USB priključak u vašem računalu. Tok punjenja signaliziraju 2 LED diode za punjenje (3). Kada je baterija napunjena do kraja, diode se ugase.

UKLJUČIVANJE/ISKLJUČIVANJE

Kako biste uključili ili isključili zvučnik, pritisnite i držite tipku (4) 3 sekunde. Prilikom uključivanja i isključivanja čuje se akustički signal.

POLNJENJE

TRUE WIRELESS (TWS) POVEZAVA

ALIMENTAREA

CONECTAREA TRUE WIRELESS (TWS)

Cu ajutorul tehnologiei True Wireless (TWS) puteti conecta reciproc doua boxe Niceboy RAZE Radion 4 si sa redati muzica concomitent.

ЗАРЯДКА

ЗАРЕЖДАНЕ

Praha 4, Czech Republic, ID: 294 16 876.

Made in China.
