RAZE MINI 4 - Loudspeaker Niceboy - Free user manual and instructions

Product Type	Wireless Speaker
Brand	Niceboy
Model	RAZE Mini 4
Bluetooth Version	5.3
Frequency Band	2.4 GHz
Radiofrequency Power	≤ 2.5 mW
Transmission Range	10 meters
Supported Codecs	SBC
Supported Profiles	A2DP, AVRCP, HFP
Power Output	5 W
Impedance	4 Ω
Sensitivity	85 ± 3 dB
Frequency Range	150 Hz – 20 kHz
Battery Type	Li-Ion 800 mAh
Battery Life	8 hours (at 50% volume)
Charging Time	Approximately 2 hours
Waterproof Rating	IPX5
Charging Connector	USB-C
True Wireless Stereo (TWS)	Yes
FM Radio	Yes
Hands-free Calling	Yes
Auto Power Off	After 5 minutes of inactivity

Frequently Asked Questions - RAZE MINI 4 Niceboy

How do I pair the speaker with my phone?

Turn on the speaker by holding the power button for 3 seconds. The blue LED will flash indicating pairing mode. On your device, enable Bluetooth and select "Niceboy RAZE Mini 4" from the list. Successful pairing is indicated by a tone and steady blue LED.

How long does it take to fully charge the speaker?

Full charging takes approximately 2 hours. Use the supplied USB-C cable with a 5V/1A adapter.

Can I connect two RAZE Mini 4 speakers for stereo sound?

Yes, use True Wireless Stereo (TWS). Turn on both speakers, ensure they are not connected to any device. Triple-press the button on one speaker to interconnect them. Then pair with your device.

Is the speaker waterproof?

Yes, it has an IPX5 rating, meaning it is protected against water splashes. Do not submerge.

How do I listen to FM radio?

Connect the USB-C cable (acts as antenna). Double-press the button to enter FM mode. Short-press to auto-scan and save stations.

What is the battery life?

Up to 8 hours at 50% volume. Lower volume extends battery life.

Can I use the speaker for phone calls?

Yes, press the button to answer/end calls. Long-press to reject.

How do I turn the speaker off?

Press and hold the power button for 3 seconds. It will also auto-off after 5 minutes of inactivity.

What Bluetooth version does it support?

Bluetooth 5.3 with a range of 10 meters.

How do I reset the speaker or clear paired devices?

There is no explicit reset mentioned. It automatically connects to the last paired device when turned on. To pair a new device, turn off Bluetooth on the old device or forget the speaker.

USER MANUAL RAZE MINI 4 Niceboy

User Manual / Wireless Speaker

CZ

OBSAH BALENÍ

USB-C charging cable

Instruction manual

PRODUCT DESCRIPTION

1. USB-C charging port
2. On / Off Play / Pause

Answer / End / Reject call / mode switch

1. Operating LED indicator

CHARGING

We recommend that you fully charge the speaker

before using it for the first time to maximize battery life. A full charging takes approximately 2 hours. Low battery is indicated by an audio signal. To charge the speaker's battery, plug the supplied USB-C cable into the charging port (1) and connect it to any charging adapter (5 V voltage and at least 1 A output current) or to a USB port in a PC. Charging is indicated by a red charging LED (3); the LED turns off once the battery is fully charged.

POWER ON / OFF

To turn the speaker on or off, press and hold button (2) for 3 seconds.

*If the speaker is left inactive, it will turn off automatically after 5 minutes to save power.

CONNECTING TO A DEVICE

1. Press and hold the on/off button (2) for 3 seconds to turn the speaker on. The speaker is now in pairing mode for wireless connectivity. Pairing mode is indicated by the flashing of the blue operating LED (3).
2. Activate Bluetooth on your device. Select "Niceboy RAZE Mini 4" in the list of available devices.
3. The device will connect to the speaker. A successful pairing is indicated by a tone and the blue operating LED (3) lighting up.

*When switched on again, the speaker automatically connects to the last paired device.

PLAYBACK

To start or pause a track, short-press button (2). Control what music the speaker plays using the device the speaker is connected to.

PHONE CALLS

To answer and afterwards end a phone call, press button (2). Long-press the same button to reject an incoming call.

FM MODE

Connect the enclosed USB-C cable to the charging port (1) and it will act as an antenna. 2x press button (2) and FM mode will be announced with an audio signal; short press button (2) to automatically search and save radio stations. You can stop the automatic search function by short pressing the same button (2).

TRUE WIRELESS (TWS) CONNECTION

True Wireless (TWS) technology enables you to connect two Niceboy RAZE Mini 4 speakers and play music simultaneously in stereo.

1. Turn both Niceboy RAZE Mini 4 speakers on and make sure they are not connected to any Bluetooth device (mobile, notebook etc.).

2. 3x short-press button (2) on one of the speakers. A tone will indicate a successful interconnection of the speakers.

3. You can now open Bluetooth settings on your device. Select "Niceboy RAZE Mini 4" in the list of available devices. A tone will indicate a successful pairing..

PARAMETERS

BT version: 5.3

Frequency band: 2.4 GHz

Radiofrequency power: ≤ 2.5 mW

Transmission range: 10 meters

Supported codecs: SBC

Supported profiles: A2DP, AVRCP, HFP

Power output: 5 W

Impedance: 4 Ω

Sensitivity: 85±3 dB

Frequency range: 150 Hz – 20 kHz

Battery: Li-Ion 800 mAh

Battery life: 8 hours (at 50% volume)

Waterproofness: IPX5

SAFETY INFORMATION

Listening to music at very high volume can damage your hearing. Do not expose the device to fluids or humidity. Do not expose the device to extreme temperatures or try to disassemble it. Protect the device from sharp objects and falls from height. Batteries – improper handling (prolonged charging, short circuit, breakage by other objects, etc.) may result in fire, overheating or battery leakage.

The battery or accumulator that may be included with the product has a service life of six months, as it is a consumable. The manual is available for download in electronic form at www.niceboy.eu in the support section. NICEBOY s.r.o. hereby declares that radio device type Niceboy RAZE Mini 4 complies with Directives 2014/53/EU, 2014/30/EU, 2014/35/EU, and 2011/65/EU. The full EU Declaration of Conformity is available at the following website: https://niceboy.eu/en/raze-mini-4

INFORMATION FOR USERS ON DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIPMENT (HOUSEHOLDS)

The above symbol on the product or accompanying documentation means that used up electrical or electronic products must not be disposed of as communal waste. To dispose of the product correctly, bring it to designated waste collection points, where it will be disposed of free of charge. Proper disposal of the product helps preserve valuable natural resources and prevent potential negative impact on the environment and human health caused by improper waste disposal. For more information, contact local authorities or the nearest waste collection point. Improper disposal of this type of waste may result in a fine pursuant to national legislation.

Information for Users on Disposal of Electrical and Electronic Equipment (Corporate Use). To properly dispose of electrical and electronic equipment for corporate use, contact the manufacturer or importer of the product. They will provide you information on disposal methods for the product and will inform you on who is obligated to fund the disposal of the electrical device based on the date the product was put on the market. Information on Disposal in Countries outside the European Union. The above symbol only applies in EU countries. To properly dispose of electrical and electronic equipment, request more information from your local authority or the seller of the product.

DE

LIEFERUMFANG

PRAVA BREZŽIČNA POVEZAVA (TWS)

Codecuri acceptate: SBC

Profiluri acceptate: A2DP, AVRCP, HFP

Putere de ieşire: 5 W

Impedanță: 4 Ω

Sensibilitate: 85±3db

Prague 4, Czech Republic, ID: 294 16 876.

Made in China.

RoHS CE 📧 ✉
