USER MANUAL PDSLK 12 B2 PARKSIDE

Translation of the original instructions

FR BE

12 V / 2 x 4,5 A CHARGEUR DOUBLE

Mode d'emploi

Diagram of a folded panel or cabinet with mesh patterns and a rotation arrow (no text or symbols)

GB/IE User manual Page 32

List of pictograms used ...... Page 34

Introduction Page 36

Intended use. Page 37

Scope of delivery ...... Page 37

Parts list ...... Page 37

Technical data.... Page 38

General safety notes ...... Page 40

First set-up of the product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Unpacking the product and basic cleaning . . . Page 43

Operation.... Page 44

Charging the battery.... Page 44

Wall mounted charger (optional)..... Page 47

Cleaning and maintenance ...... Page 48

Cleaning Page 48

Maintenance Page 49

Disposal Page 49

Warranty.... Page 51

Warranty claim procedure. Page 53

Service Page 55

List of pictograms used
	Read the instruction manual.
	DANGER! – Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)
	WARNING! – Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)
	CAUTION! – Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)
	NOTICE! – Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)
	Direct current/voltage
	Alternating current/voltage
	Protection class II (double insulation)
	Fuse
	Use the product in dry indoor spaces only.
	Safety informationInstructions for use
	CE mark indicates conformity with relevant EU directives applicable for this product.

12V / 2X 4.5A DOUBLE CHARGER

● Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

36 GB/IE

Intended use

The product is exclusively intended for charging batteries from the X 12 V TEAM series.
The product is not intended for commercial use. Any other usage or modification of the product is deemed to be improper and carries a significant risk of accidents.

The manufacturer accepts no responsibility for damage(s) attributable to misuse.

- Scope of delivery

1× 12V / 2× 4.5A Double charger

1× User manual

Parts list

Before reading, unfold the page containing the illustrations and familiarise yourself with all the functions of the product.

1 Rechargeable battery*
2 Release button
3 Charger
4 Charging control LED – Red
5 Charging control LED – Green
6 Mains cord with mains plug

* A rechargeable battery is not included.

Technical data

12V / 2x 4.5A Double charger: PDSLG 12 B2
Input:
Rated voltage: 220–240 V~
Rated frequency: 50–60 Hz
Rated power consumption: 150 W
Output:
Rated voltage: 12 V
Rated current: 4.5 A
Fuse (internal): T3.15A
Protection class:	II/ (double insulation)

Recommended ambient temperature:

During operation: +4 to +50 °C
During storage: 0 to +45 °C

Charging time:

The following batteries are suitable for charging with the charger:

PAPK 12 A4

PAPK 12 C1

PAPK 12 B4

PAPK 12 D1

Charging time PDSLG 12 B2
PAPK 12 A4 60 min
PAPK 12 C1 60 min
PAPK 12 B4 60 min
PAPK 12 D1 80 min

Customers can obtain compatible replacement batteries and chargers from the LIDL online shop www.lidl.de.

General safety notes

This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved.

Children shall not play with the product.

Cleaning and user maintenance shall not be made by children without supervision.

Correct handling of the battery charger

Children must be supervised to ensure that they do not play with the device.
Before each use, check the charger, cable and plug and have them repaired by qualified professionals and only with original parts. Do not use a defective charger and do not open it up yourself. This ensures that the safety of the device is maintained.

■ Ensure that the mains voltage matches the specifications on the charger rating plate. Risk of electric shock.

- Keep the charger clean and away from wet and rain. Do not use the charger outdoors. Dirt and the entry of water increase the risk of electric shock.

- Operate the charger only with the appropriate original batteries. Charging other batteries may result in injuries and risk of re.

- Avoid mechanical damage to the charger. This can result in internal short circuits.

The charger must not be operated on or in the immediate vicinity of flammable surfaces (e.g. paper, textiles). Risk of fire due to heating caused by charging.

If the connection cable of this device is damaged, it must be replaced by the manufacturer or their customer service or by a similarly qualified person in order to avoid hazards.

The battery of your device is only partially precharged upon delivery and must be fully charged before being used for the first time. Insert the battery into the base and connect the charger to the mains.

■ Remove the mains plug when the battery is fully charged and disconnect the battery from the charger.

- Do not attempt to charge non-rechargeable batteries in the charger.

- Do not use any accessories that are not recommended by the manufacturer. This can result in electric shock or fire.

● First set-up of the product

● Unpacking the product and basic cleaning

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see "Scope of delivery").
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter “Warranty”.
4. Before first use, clean all parts of the product as described in the chapter “Cleaning and maintenance”.

Operation

● Charging the battery

WARNING!

- Charge the battery 1 in a dry room only. Prior to inserting the battery into the charger 3, check that the outer surface of the battery is clean and dry. There is a risk of injury due to electric shock.

CAUTION!

- Do not expose the battery 1 to extreme conditions such as heat or impact. Risk of injury from escaping electrolytic solution! After eye/skin contact, rinse the affected areas with water or a neutraliser and consult a doctor.

NOTES

The rechargeable battery 1 only reaches its full capacity once it has been charged several times.

NOTES

- Charge the battery before using it for the first time.

■ Only use chargers from the X 12 V TEAM series to recharge the battery.

If a fully recharged battery lasts for considerably shorter operating times, the battery is used up and needs to be replaced. Only use an original replacement battery from the X 12 V TEAM series.

- Let the battery cool down before charging.

The battery may be charged at any time without reducing the lifetime of the battery.

- Interrupting the charging process does not damage the battery.

The charging control LEDs (green 5 and red 4) on the left side are assigned to the left charging slot.

The charging control LEDs (green 5 and red 4) on the right side are assigned to the right charging slot.

☐ Charge the battery 1 before use when it is at medium or low charging level.
The charging control LEDs (green 5 and red 4) indicate the status of the charger 3 and the battery:

LED Status
Green LED lights up without battery inserted	Charger ready for use
Green LED lights up Battery fully charged
Red LED lights up Battery charging
Red and green LED flash Error

1. Remove the battery 1 from the battery device.
2. Insert the battery into the charger 3.
3. Connect the mains plug 6 to a socket-outlet.
4. When the battery is fully charged: Remove the battery from the charger. Disconnect the mains plug from the socket-outlet.

● Wall mounted charger (optional)

WARNING!

When drilling, be careful not to damage any supply lines. Use suitable search devices to find these or consult an installation plan for guidance. Contact with electrical cables can lead to electric shock and fire. Contact with a gas pipe can result in an explosion. Damage to a water pipe can lead to property damage and electric shock.

NOTE

You can also mount the charger 3 on the wall.

1. Attach 2 screws 54 ~mm apart to the desired position on a wall using dowels. The screw head can have a diameter of 7 to 9 ~mm . Leave the screw heads protruding at a distance of approx. 10 ~mm from the wall.

2. Attach the charger 3 with the openings of the wall bracket to the two screws. Pull the charger down until it stops.

● Cleaning and maintenance

Cleaning

NOTE

• Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.
  ■ Never allow fluids to get into the product.
  The product must always be kept clean, dry and free from oil or grease. Remove debris from it after each use and before storage.
  ■ Regular and proper cleaning will help ensure safe use and prolong the life of the product.

□ Clean the product with a dry cloth. Use a soft brush for areas that are hard to reach.

Maintenance

■ The product is maintenance free.

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

50 GB/IE

to protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 470785_2407) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

PDF ONLINE parkside-diy.com

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 470785_2407 takes you to the operating instructions for your item.

54 GB/IE

Service

GB Service Great Britain

Tel.:[phone]

E-Mail:[e-mail]

IE Service Ireland

Tel.:[phone]

E-Mail:[e-mail]
