USER MANUAL PAH 1300 C3 PARKSIDE

ABBRUCHHAMMER/DEMOLITION HAMMER/MARTEAU PERFORATEUR PAH 1300 C3

DE AT CH

ABBRUCHHAMMER

User manual Translation of the original instructions

FR BE

MARTEAU PERFORATEUR

GB/IE User manual Page 41

Intended use.... Page 46

Scope of delivery ...... Page 46

Parts list ...... Page 47

Technical data. Page 47

General safety instructions ..... Page 50

General power tool safety warnings . . . . . . . Page 50

Hammer safety warnings .... Page 55

Additional safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 56

Behaviour in emergency situations. . . . . . . . Page 57

Residual risks Page 57

First set-up of the product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 58

Unpacking the product and basic cleaning . . Page 58

Accessories Page 58

Adjusting the auxiliary handle. . . . . . . . . . . . . . . . . . Page 59

Inserting/removing the chisel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 59

Adjusting the flat chisel position. . . . . . . . . . . Page 60

Operation...... Page 61

Using the product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 62

Switching the product on/off .... Page 63

Troubleshooting Page 64

Cleaning and maintenance ..... Page 65

Cleaning and care.... Page 65

Maintenance Page 66

Repair Page 67

Storage.... Page 67

Transportation..... Page 67

Disposal Page 67

Warranty.... Page 69

Warranty claim procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 70

Service Page 71

EU Declaration of conformity..... Page 72

List of pictograms used
	Read the instruction manual.
	DANGER! – Designating a hazard with high risk, which will result in death or severe injury if not avoided (e.g. risk of suffocation)
	WARNING! – Designating a hazard with moderate risk, which can result in death or severe injury if not avoided (e.g. risk of electric shock)
	CAUTION! – Designating a hazard with low risk, which could result in minor or moderate injury if not avoided (e.g. risk of scalding)
	NOTICE! – Warns of possible damage to property/the product if not avoided (e.g. risk of short circuit)
	Danger – risk of electric shock!
	Alternating current/voltage
	Symbol for a Protection Class II product
	Use the product in dry indoor spaces only.
	Guaranteed sound power level in dB
	Switch off the product and disconnect it from the mains before replacing attachments, cleaning and when not in use.
	Wear hearing protection!
	Wear protective gloves!
	Wear eye protection!
	Wear dust protection!
	Wear protective, slip-resistant footwear!
	Health hazard (see marking on the lubrication grease tube for more details)
	Greasing the tool
PE-LD	Recycling code
	Safety informationInstructions for use
	CE mark indicates conformity with relevant EU directives applicable for this product.

DEMOLITION HAMMER

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This product is suitable for chiselling into the following materials:

• Concrete
• Masonry
• Stone
• Plaster
• Tiles

■ Any other use or modification of the product are considered improper use and can result in hazards such as death, life-threatening injuries and damage.
The manufacturer is not liable for any damages caused by improper use.
The product is exclusively intended for domestic use.
The product is not intended for commercial use or for similar uses.
- Observe all applicable local safety regulations, standards and ordinances. The use of noise emitting power tools may be restricted to certain times by national or local regulations.

- Scope of delivery

WARNING!

The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!

1 Demolition hammer
1 Auxiliary handle (pre-assembled)

1 Pointed chisel
1 Flat chisel
1 Grease (Model number: HG06348)
1 Carry case
1 User manual

Parts list

Before reading, unfold the pages containing the illustrations and familiarise yourself with all functions of the product.

(Fig. A)

1	Switch lock	8	Locking collar
2	Switch trigger	9	Dust cap
3	Main handle	10	Chisel holder
4	Mains cord with mains plug	11	Grease
5	Auxiliary handle	12	Pointed chisel
6	Turning knob	13	Flat chisel
7	Adjustment collar	14	Carry case

• Technical data

Demolition hammer PAH 1300 C3
Rated voltage: 230–240 V~, 50 Hz
Rated power: 1300 W
Protection class:	II/☐
Stroke energy: 15 joule
Stroke rate: 3600 min	-1
Chuck connection type: Toolless (suitable for SDS Max)
Chisel adjustment: 12 positions
Recommended ambient temperature during operation: +4 °C to +40 °C

Noise emission values

The measured values have been determined in accordance with EN 62841. The A-rated noise level of the product is typically as follows:

Chiselling:

Sound pressure level: L	pA	= 77.8 dB
Uncertainty: K	pA	= 3.0 dB
Sound power level: L	WA	= 98.8 dB
Uncertainty: K	WA	= 2.35 dB
Sound power level, guaranteed: K	WA	= 103 dB

(LWA is measured according to outdoor noise emission directives 2000/14/EC and 2005/88/EC)

Total vibration values

Total vibration values (triaxial vector sum) determined in accordance with EN 62841:

Chiselling:

Main handle: a h,Cheq		= 19.100 m/s2
Uncertainty: K		= 1.5 m/s2
Auxiliary handle: ah,Cheq		= 15.811 m/s2
Uncertainty: K		= 1.5 m/s2

WARNING!

Wear hearing protection!

NOTE

The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and may be used for comparing one tool with another.
The declared total vibration value and the declared noise emission value may also be used for a preliminary assessment of exposure.

WARNING!

The vibration and noise emissions during actual use of the product can differ from the declared values depending on the manner in which the tool is used, especially what kind of workpiece is processed. Try to minimise exposure to vibration and noise. Examples of measures to reduce vibration include wearing gloves when using the tool and limiting working time. All parts of the operating cycle must be taken into account (e.g. times when the product is switched off and when it is running idle in addition to the trigger time).

General safety instructions

● General power tool safety warnings

WARNING!

Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work area safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

Electrical safety

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools.

Unmodified plugs and matching outlets will reduce risk of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.

b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

Power tool use and care

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools diligently. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

Service

a) Have your power tool serviced by a qualified repair person using only identical replacement parts.

This will ensure that the safety of the power tool is maintained.

NOTE

This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!

● Hammer safety warnings

WARNING!

Wear hearing protection! Exposure to loud noise can lead to hearing loss.

Wear a dust mask.

WARNING!

Chiseling operations may deal with materials which can produce harmful or toxic dust. It presents a health hazard for the person operating the power tool and anyone else in the vicinity.
Ensure that you are not likely to hit power, gas or water supply lines when you are working with the power tool. If necessary, check with a service line detector before you start to cut or drill into a surface.

Safety instructions for all operations

■ Wear ear protectors. Exposure to noise can cause hearing loss.
■ Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
- Hold the power tool by insulated gripping surfaces, when performing an operation where the cutting accessory or fasteners may contact hidden wiring.
Cutting accessory or fasteners contacting a "live" wire

may make exposed metal parts of the power tool “live” and could give the operator an electric shock.

Additional safety information

Use suitable detectors to determine if there are hidden supply lines or contact the local utility company for assistance. Contact with electric cables can cause fire and electric shock. Damaging gas lines can lead to explosion. Breaking water pipes causes property damage.
■ Always wait until the power tool has come to a complete stop before placing it down. The application tool can jam and cause you to lose control of the power tool.
- Do not touch any application tools or adjacent housing components shortly after operation. These can become very hot during operation and cause burns.
- Hold the power tool firmly with both hands and make sure you have a stable footing. The power tool can be more securely guided with both hands.

Original accessories/auxiliary equipment

WARNING!

Do not use accessories not recommended by // PARKSIDE'. This may result in electric shock or fire.

■ Only use the accessories and additional equipment that are specified in the operating instructions and compatible with the product.

● Behaviour in emergency situations

Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.

■ Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.
■ Switch the product off if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.

- Residual risks

Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:

■ Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.
Injuries and damage to property due to broken accessory tools or the sudden impact of hidden objects during use.
■ Danger of injury and property damage caused by flying objects.

● First set-up of the product

● Unpacking the product and basic cleaning

1. Take the product out of the packaging and remove all packaging materials and plastic wrappings.
2. Check to make sure that all listed parts are included (see “Scope of delivery”).
3. Check whether the product and all parts are in good condition, if any damage or defect is detected, do not use the product, but follow the procedure described in chapter “Warranty”.
4. Before first use, clean all parts of the product as described in the chapter “Cleaning”.

Accessories

WARNING!

Do not use accessories not recommended by // PARKSIDE'. This may result in electric shock or fire.

To operate this product safely and correctly, the following accessories, i.e. tools and accessory tools, are necessary:

SDS-Max insertion tool
■ Suitable personal protective equipment

Accessories and accessory tools are available through your authorised dealer. When buying always consider the technical requirements of this product (see “Technical data”). If you are not certain, ask a qualified specialist and get advice from your trusted dealer.

- Adjusting the auxiliary handle

(Fig. E)

NOTE

Only operate the product with the auxiliary handle 5 installed.

1. Loosen the turning knob 6.
2. Move the auxiliary handle 5 forward/backward and left/right.
3. Tighten the turning knob once the optimal position is reached.

- Inserting/removing the chisel

(Fig. B, C)

⚠ WARNING! RISK OF INJURY!

Hold the product securely when inserting/removing the chisel 12/13.
The chisel can become very hot during operation. Allow the chisel to cool down.
▶ Wear safety gloves when inserting/removing the chisel.

NOTE

A damaged dust protection cap ^9 must be replaced immediately. Contact the customer service.
Clean the chisel connection end with a dry and clean cloth.

NOTE

Apply a thin layer of grease ^11 on the part of the chisel that is inserted to the chisel holder ^10 .
Place the product on a stable and flat surface.
The dust cap largely prevents the entering of chiseling dust into chisel holder during operation.
▶ Check and ensure that the dust cap is in good condition and does not get damaged when inserting/removing the chisel.

Inserting:

1. Push the locking collar 8 down (direction a) with one hand.
2. Insert the chisel 12/13 into the chisel holder 10 (direction b) with the another hand. The chisel clicks audibly into place.

Removing:

1. Push the locking collar 8 down (direction a) with one hand.
2. Pull out the chisel from the chisel holder 10 (direction c) with the another hand.

- Adjusting the flat chisel position

(Fig. D)

⚠ WARNING! RISK OF INJURY!

Hold the product securely when adjusting the position of the flat chisel 13.

WARNING! RISK OF INJURY!

The flat chisel can become very hot during operation. Allow the flat chisel to cool down.
▶ Wear safety gloves when adjusting the flat chisel position.

NOTE

You can bring the flat chisel into 12 different positions (every 30°).

1. Place the product on a stable and flat surface.
2. Pull out the adjustment collar 7 (direction d) with one hand.
3. Rotate the flat chisel 13 until the desired position is reached.
4. Release the adjustment collar to secure the flat chisel in its position.

Operation

WARNING!

Switch off the product and disconnect it from the mains before replacing attachments, cleaning and when not in use.

WARNING! RISK OF INJURIES!

Always wear protective gloves when working with the product and employ only original parts. Always switch the product off, disconnect it from the mains and let the product cool down before performing inspection, maintenance and cleaning work!

Using the product

(Fig. G)

WARNING! RISK OF INJURY!

The chisel ^12/13 can be jammed during operation. This can transfer powerful force into the main handle 3 and the auxiliary handle 5. Make sure that you stand securely at all times.
Hold the product with both hands during operation.
Switch the product off before connecting it to the power supply.
Do not apply excessive pressure during operation. This will reduce the chiselling power and create excessive vibration back to the main handle and the auxiliary handle.

NOTE

Built-in vibration damper reduces occurring vibration.
The gripping on the main handle 3 and the auxiliary handle 5 increase the safety against slipping off. This provides a better grip and handling of the product.
Always place the mains cord 4 behind the product.

☐ Horizontal working position: Hold the auxiliary handle 5 with one hand and the main handle 3 with the other hand.
☐ Vertical working position: Hold the main handle with both hands.

- Switching the product on/off

(Fig. F)

☐ Switching on: Press down the switch trigger 2.
☐ Switching off: Release the switch trigger.

Continuous operation:

1. Press and hold the switch trigger.
2. Press the switch lock 1 to start continuous operation. The switch trigger locks into place.
3. Press and release the switch trigger to end continuous operation.

Troubleshooting

Problem Possible cause Solution
Chisel 12/13falls out.	Chisel holder 10does not lock.	Reinsert the chisel 12/13 into the chisel holder 10 (see „Inserting/removing the chisel“).
The product does not work.	No mains power.	□ Check the mains cord and mains plug 4.□ If the mains cord 4 is damaged, have it replaced by a qualified specialist.
	Worn-out carbon brushes.	Have the carbon brushes or the motor replaced by a qualified specialist or authorized service center.
	Motor defective.
Problem Possible cause Solution
The performance of the product is poor.	Blunt chisel 12/13.	Replace the chisel 12/13.
	Excessive pressure on the product.	Apply appropriate pressure to the product.
	Chisel 12/13 and chisel holder 10 lack lubrication.	Lightly grease the chisel 12/13 and chisel holder 10 with grease 11.

● Cleaning and maintenance

WARNING!

Switch off the product and disconnect it from the mains before replacing attachments, cleaning and when not in use.

- Cleaning and care

NOTE

Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.
Let the product cool down before cleaning.

NOTE

▶ Never allow fluids to get into the product.
The product must always be kept clean, dry and free from oil or grease. Remove debris from it after each use and before storage.
▶ Regular and proper cleaning will help ensure safe use and prolong the life of the product.

□ Clean the product with a dry cloth. Use a soft brush for areas that are hard to reach.
☐ In particular clean the air vents after every use with a cloth and soft brush.
The air vents must always be clear.
□ Clean the chisel holder 10 regularly. Lightly grease the chisel holder with grease 11.

Maintenance

⚠ WARNING! RISK OF INJURY!

If the mains cord ^4 is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

☐ Check the product and accessories (e.g. tools) for wear and damage before and after each use. Replace them with new ones if necessary. Observe the technical requirements (see “Technical data”).
□ Greasing: Lightly grease the chisel 12/13 and the chisel holder 10 with grease 11.

Repair

☐ This product does not contain any parts that can be repaired by the user. Contact an authorised service centre or a similarly qualified person to have it checked and repaired.

Storage

☐ Switch off the product. Let the product cool down.

□ Clean the product (see “Cleaning”).

☐ Store the product and its accessories in a dark, dry, frost-free, well-ventilated place.

□ Always store the product in a place that is inaccessible to children.

The ideal long term storage (longer than 3 months) temperature is between +20 and +26 °C.

☐ Store the product in its carry case 14.

- Transportation

☐ Switch off the product. Let the product cool down.

□ Transport the product in its carry case 14.

☐ Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles.

☐ Secure the product to prevent it from slipping or falling over.

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fi breboard/80–98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility.

Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

So that your request can be processed quickly, please observe the following instructions:

For all inquiries, please have the receipt and item number (IAN 480068_2410) ready as proof of purchase.

The article number can be taken from the identification label on the product, engraving on the product, the front cover of your manual (at the bottom left), or the sticker on the back or bottom of the product.

If malfunctions or other defects arise, first contact the service department indicated below by phone or email.

You can then send a product recorded as defective to the communicated service address postage-free, making sure to enclose proof of purchase (receipt) and information on the details of the defect and when it occurred.

You can download and view this and numerous other manuals at parkside-diy.com. This QR code takes you directly to parkside-diy.com. Choose your country and use the search screen to search for the operating instructions. Entering the item number (IAN) 480068_2410 takes you to the operating instructions for your item.

PDF ONLINE parkside-diy.com

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

E-Mail: [e-mail]

EUDeclarationofconformity

EU DECLARATION OF CONFORMITY (No 480068\_2410)

IAN: 480068_2410

Product identification:

"PARKSIDE" Demolition Hammer

Model Number: HG10128

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

Directive 2006/42/EC

Directive 2000/14/EC

Directive 2014/30/EU

Directive 2011/65/EU and all related amendments

References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared:

N° / Parts

Directive 2006/42/EC

EN 62841-1:2015/A11:2022

EN IEC 62841-2-6:2020/A11:2020

Directive 2014/30/EU

EN IEC 55014-1:2021

EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A1:2021

EN 61000-3-3:2013/A2:2021

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment:

N° / Parts

EN IEC 63000:2018

Conformity Assessment procedure / name&adress notified body where appropriate: Annex VI, TÜV SÜD Industrie Service GmbH (NB 0036), Westendstraße 199, 80686 München, Germany Measured sound power level on an equipment representative for this type: 98.8 dB(A) Guaranteed sound power level for this equipment: 103 dB(A)

Keeper of the technical documentation: OWIM GmbH & Co.KG

Signed for and on behalf of:

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Translation of the original declaration of conformity

Neckarsulm 17.01.2025

Place

Date

ppa. Stea'n Haensel Authorised Signatory ppa. Jens Buc hreim Authorised Signatory

EN

CE
