USER MANUAL PLW A5 PARKSIDE

Black Parkside camera mounted on a tripod, no visible text or symbols on the device body

LASER-WASSERWAAGE/LASER SPIRIT LEVEL/ NIVEAU À BULLE LASER PLW A5

DE AT CH

LASER-WASSERWAAGE

Operation and safety notes

NL BE

LASERWATERPAS

Description of parts...... Page 25

Includes...... Page 26

Technical information...... Page 26

General safety instructions......Page 26

Warning! Risk of injury from laser beams! ...... Page 28

Safety instructions for batteries/

rechargeable batteries...... Page 29

Preparing for first use ...... Page 30

Inserting/replacing batteries ...... Page 30

Setting up the product...... Page 31

Operation Page 31

Use with the tripod.... Page 32

Use without a tripod...... Page 32

Maintenance, cleaning and care...Page 33

Disposal Page 33

Warranty Page 35

Warranty claim procedure......Page 35

Service Page 36

List of pictograms used
	Read the instructions!
	Observe the warnings and safety instructions!
	Incl. Batteries
	Direct current/voltage
ON/OFF	Illumination ON/OFF
	Laser beam ON/OFF
	Illumination indicator (LED, cannot be replaced.)
	Protect yourself from laser radiation!
	Never look into the laser beam!
	Safety informationInstructions for use
	Keep out of reach of children
	Do not dispose of in fire
	Do not insert incorrectly
	Do not deform/damage
	Do not open/dismantle
	Do not mix different types or brands
	Do not mix new and used
	Do not charge
	Keep away from water and excessive moisture
	Do not short circuit
	Insert correctly
	CE mark indicates conformity with relevant EU directives applicable for this product.

Laser spirit level

- Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass

the product on to anyone else, please ensure that you also pass on all the documentation with it.

Proper use

The product level is a measuring device and is intended for use in aligning objects horizontally and vertically, e.g. pictures or furniture. Measurements are performed using the laser beam and the spirit levels. The product is intended for use indoors at normal room temperatures only. The product is not intended for commercial use.

• Description of parts

1 Bubble level
2 Batterycompartment
3 Tripod with ball and socket head
3a Threaded screw
4 Clamping screw
5 Bubble level
6 Laser beam aperture
7 Laser beam On/Off switch
8 Illumination On/Off switch
9 Illumination indicator (LED, cannot be replaced)
10 Battery arrangement
11 Positions of magnets
12 Position of laser beam
13 Switch for selecting laser form (cross-hatch "CROSS"/line "LINE")
14 Threaded hole

Includes

1 x Laser spirit level
1 x Tripod
2 x Batteries 1.5 V=, AAA
1 x Instructions for use

• Technical information

Laser class: 2

Accuracy: +/- 1 mm/m

Power supply: 2 x battery 1.5 V ===, AAA

Altitude: up to 2000 m

Ambient temperature: -5^ C-40^ C

Humidity up to 80 %

Working area: up to 2 m

Max. height of

laser projection

(including tripod): 31.5 cm

LASER RADIATION DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT λ = 635 - 660nmVP < 1 mW EN 60825-1:2014/A11:2021

General safety instructions

KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE!

Always keep children away from the packaging material. This is not a toy.

This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Children shall not play with the product. Cleaning and user maintenance shall not be made by children without supervision.

CAUTION! RISK OF INJURY! Please do not use this product if you find that it is damaged in any way.

• Check whether all of the parts are correctly fitted. If the product is not correctly assembled there is a danger of injury.
  ■ Do not expose the product to:

- extreme temperatures,

- strong vibrations,

- high mechanical loads,

- direct solar radiation,

- moisture.

Failure to observe this advice may result in damage to the product.

■ Remove the batteries if the product breaks down or is defective. Otherwise there is the danger that the laser may be inadvertently switched on. This could lead to permanent eye damage.

WARNING! Never open the product housing. This could result in personal injury or damage to the product.

Always have any repairs carried out at the service centre or by an electrical equipment repair specialist.

• Do not use the product in places where there is a danger of fire or explosion, for example near inflammable liquids or gases.
  ■ Any adjustment to increase the power of the laser is not permitted.
  If a bubble level is damaged, avoid contact of any kind with the fluid contained in the bubble. However, should contact occur it is essential that the following advice is observed. First aid measures on:

SKIN CONTACT: Clean the affected area immediately for at least 15 minutes with plenty of soap and water. Contact a doctor if you suffer lasting skin irritation.

EYE CONTACT: Flush the affected eye immediately for at least 15 minutes with plenty of water. When doing this, hold the eye open with a thumb and index finger. Contact a doctor immediately.

INHALATION: Ensure immediately that there is an adequate supply of fresh air. Introduce pure oxygen if breathing problems are experienced.

CONTACT WITH THE INSIDE OF THE MOUTH:

If the victim is conscious, flush out the inside of the mouth immediately with plenty of water. Contact a doctor immediately.

Warning! Risk of injury from laser beams!

WARNING! Do not look directly into the laser beam into the laser aperture. This can result in permanent eye damage if the eye's natural reflex to close does not take place.

■ Never direct the laser beam directly on to the eyes of people or animals.
If the laser beam strikes your eyes, close them immediately and turn your head out of the beam.
- Keep the product safely in a place inaccessible to children. Children often underestimate the possible dangers associated with these products.
■ Never direct the laser beam on to objects that can reflect light. Even looking briefly into the beam can result in eye damage.
■ Always switch off the laser beam if you leave the product unattended.

Safety instructions for batteries/rechargeable batteries

■ DANGER TO LIFE! Keep batteries/rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.
■ Swallowing may lead to burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion.

DANGER OF EXPLOSION! Never re-

charge non-rechargeable batteries. Do not short-circuit batteries/rechargeable batteries and/or open them. Overheating, fire or bursting can be the result.

■ Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/rechargeable batteries.

Risk of leakage of batteries/rechargeable batteries

Avoid extreme environmental conditions and temperatures, which could affect batteries/rechargeable batteries, e.g. radiators/direct sunlight.
If batteries/rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE GLOVES! Leaked

or damaged batteries/rechargeable batteries can cause burns on contact with the skin.

Wear suitable protective gloves at all times if such an event occurs.

In the event of a leakage of batteries/rechargeable batteries, immediately remove it from the product to prevent damage.

Only use the same type of batteries/rechargeable batteries. Do not mix used and new batteries/rechargeable batteries.
■ Remove the batteries/rechargeable batteries if the product will not be used for a longer period.

Risk of damage of the product

■ Only use the specified type of battery/rechargeable battery!
- Insert batteries/rechargeable batteries according to polarity marks (+) and (-) on the battery/rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts on the battery/rechargeable battery and in the battery compartment before inserting!
■ Remove exhausted batteries/rechargeable batteries from the product immediately.

● Preparing for first use

- Inserting/replacing batteries (see Fig. A)

☐ Switch off the product.
□ Open the battery compartment 2.
☐ Insert 2 batteries type 1.5V, AAA or replace the used batteries with new ones. Insert the batteries with correct polarity (+/-) in accordance with the battery arrangement 10 inscribed on the housing.
☐ Reclose the battery compartment.

Note: If the laser beam is too weak or no longer visible, it is time to replace the batteries.

Setting up the product

You can use the product with or without a tripod. Follow the steps below to attach and align the product on the tripod:

Turn the tripod 3 with the threaded screw 3a completely into the threaded hole 14 on the underside of the housing. Make sure that the screw is tightened firmly and securely.

☐ Fold out the legs of the tripod 3.

☐ Set the product on the tripod down on the desired surface and align it.

☐ To align the product, first release the clamping screw 4 on the tripod 3 by screwing it anticlockwise.

☐ Now turn and tilt the housing until the air bubbles in the bubble levels 1 and 5 are centrally positioned between the two line markings (see figure B).

Note: If the lighting conditions are inadequate, switch on the illumination for the bubbles using the illumination On/Off switch 8.

☐ Then fix the position of the housing by tightening the clamping screw 4 on the tripod clockwise.

Note: If the position of the product has to be changed, you need to check whether the product requires to be aligned again.

☐ The tripod is not made for carrying loads. For that reason do not load anything onto the product when it is attached to the tripod.

□ Make sure not to bend the tripod's legs.

Operation

WARNING! Do not look directly into the laser beam or into the laser beam aperture 6. This can result in permanent eye damage if the eye's natural reflex to close does not take place. If the laser beam strikes your eyes, close them immediately and turn your head out of the beam.

Use with the tripod

Set the product on the tripod down in the desired place and align it as described in the section "Setting up the product".

☐ Switch on the product with the laser beam On/Off switch 7. The product projects two laser beams that intersect one another at right angles on to a wall.

Note: You may change the laser to a line format ("LINE") or to cross-hatch format ("CROSS") by sliding the switch 13 (see figure C).

☐ If the laser beam is not exactly at the required height, you can use a ruler or another suitable measuring product to mark vertical and horizontal points on the wall. To do this, remark the desired position on the wall at the calculated distance from the laser beam. Ensure that the measuring aid is absolutely vertical and use a spirit level if necessary.

- Use without a tripod

☐ Hold the product with the wide side to a wall.

☐ Switch on the product by pressing the laser beam On/Off switch 7.

Note: If the lighting conditions are inadequate, switch on the illumination for the bubbles using the illumination On/Off switch 8.

☐ Align the product so that the air bubbles in the bubble levels 1 and 5 are centrally positioned between the two line markings (see figure B).

☐ A second person can now mark the desired points.

Note: The product has two magnets 11. They allow you to attach the product to surfaces that attract magnetic objects, e.g. steel shelves.

Note: Electrostatic discharge could lead to functional errors. If such functional errors occur, remove the battery briefly and replace it again.

● Maintenance, cleaning and care

Apart from replacing the batteries, the product is maintenance-free.

• Clean the outside of the product only with a soft, slightly moist cloth. Never use liquids or cleaning agents, as they may damage the product.
  □ Clean the laser optics with a soft, narrow paint brush.
  Store the product in as dry and dust-free conditions as possible.
  ☐ If the product is not to be used for a prolonged period, remove the batteries and store them separately.

●Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibre-board/80–98: composite materials.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste.

Information on collection points and their opening hours can be obtained from your local authority.

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment. The Triman logo is valid in France only.

Faulty or used batteries/rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

- Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (IAN 449825_2310) available as proof of purchase. You will find the item number on the rating plate, an engraving on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail. You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.:[phone]

E-Mail: [e-mail]
