USER MANUAL Easy Fry & Grill XL EY501A TEFAL

B. Bowl handle
C. Removable die-cast grill grid
D. Temperature control knob (80 - 200°C)

E. Power on/off and timer knob (0-60 min)
with auto shut-off
F. Power indicator light
G. Heating-up light

BEFORE FIRST USE

Read the safety instructions and manual first and keep them in a safe place.

1. Remove all packaging material and any stickers from the appliance.
2. Do not remove silicon pads off the grid.
3. Thoroughly clean the bowl and the removable grill grid with hot water, some washing-up liquid and a non-abrasive sponge.

Note: the bowl and the grid are dishwasher safe.

1. Wipe the inside and outside of the appliance with a damp cloth. The appliance works by producing hot air. Do not fill the bowl (A) with oil or frying fat.

PREPARING FOR USE

1. Place the appliance on a flat, stable, heat-resistant work surface away from water splashes.
2. Insert the grid at the bottom of the bowl, up to the stop.
3. Do not fill the bowl with oil or any other liquid.

Do not put anything on top of the appliance. This disrupts the airflow and affects the hot air frying result.

IMPORTANT: To prevent the appliance from overheating, do not place it in a corner or below a wall cupboard. A gap of at least 15cm should be left around the appliance to allow air to circulate.

USING THE APPLIANCE

The appliance can cook a large range of recipes. Cooking times for the main types of food are given in the section 'Cooking Guide'. Online recipes help you get to know the appliance.

1. Connect the power supply cord to an electrical socket.
2. Place the food in the bowl.

Note: Never fill the bowl beyond the MAX level mark or exceed the maximum amount indicated in the table (see into section 'Cooking Guide'), as this could affect the quality of the end result.

1. Slide the bowl back into the appliance.
2. Move the temperature control knob to the required temperature. See section 'Cooking Guide' to select the right temperature. The thermostat varies from 80-200°C.

3

1. To switch on the appliance, turn the timer knob to the required cooking time (see section 'Cooking guide'). The timer can be set for between 0 and 60 minutes.

Add 3 minutes to the cooking time stated in the cooking tables when using the appliance from cold.

To set a short time, turn the timer knob until 10 minutes and then go back to the desired time. Note: If you want, you can also let the appliance preheat without any food inside. In this case, turn the timer knob to more than 3 minutes and wait until the heating-up light goes out (after approx. 3 minutes). Then fill the bowl and turn the timer knob to the required cooking time (see Cooking Guide for timings).

- The timer starts counting down the set cooking time.

• The heating-up light goes on.

- During the hot air frying process, the heating-up light goes on and off from time to time. This indicates that the heating element is switched on and off to thermostatically maintain the set temperature.

1. Excess oil from the food is collected in the bottom of the bowl.
2. Some food will require shaking halfway through the cooking time (see section 'Cooking Guide'). To shake the food, pull the bowl out of the appliance by the handle and shake it. Then slide the bowl back into the appliance, the appliance restarts automatically.
3. When you hear the timer sound, the cooking time set has finished. Pull the bowl out of the appliance and place it on a heat-resistant surface.
4. Check if the food is ready.

If the food is not ready yet, simply slide the bowl back into the appliance and set the timer for a few extra minutes.

1. When the food is cooked, take out the bowl. To remove food, use a pair of tongs to lift the food out of the bowl.

Caution: The bowl should never be turn up side down with the grid.

Caution: After hot air frying, the bowl, the grid and the food are very hot. Do not touch the bowl during use and for some time after use, as it gets very hot. Only hold the bowl by the handle.

1. When a batch of food is ready, the appliance is instantly ready for preparing another batch of food.

USING THE GRILL PLATE

1. Place the grill grid in the bowl of the appliance.
2. Move the temperature control knob to 200°C.
3. Turn the timer knob to 15 minutes. This will launch the preheating phase.
4. When you hear the timer sound, the preheating phase has finished and the temperature has reached 200^ C.
5. Take the bowl out the appliance and place it on a heat-resistant surface.

Caution : the bowl and the grill grid are very hot. Use a pair of tongs to place the food on the grill plate.

4

1. Place the food on the grill plate and put back the bowl into the appliance.
2. Turn the timer knob to the required cooking time (see section 'Cooking guide'.) Cooking starts.

Note : the pieces of meat required to turn them at half cooking.

Excess oil from the food is collected in the bottom of the bowl.

1. When you hear the timer sound, the cooking has finished. Take the bowl out the appliance and place it on a heat-resistant surface.
2. Check if the food is ready. If the food is not ready yet, put it back on the appliance and set the timer for a few extra minutes at 200^ C.
3. When the food is cooked, take out the bowl. To remove food, use a pair of tongs to lift the food out the bowl.

Caution : the bowl should never be turn up side down with the grid.

Caution: After hot frying, the bowl, the grid and the food are very hot. Do not touch the bowl during use and for some time after use, as it gets very hot. Only hold the bowl by the handle.

COOKING GUIDE

The table below helps you to select the basic settings for the food you want to prepare.

Note: The cooking times below are only a guide and may vary according to the variety and batch of potatoes used. For other food the size, shape and brand may affect results. Therefore, you may need to adjust the cooking time slightly.

5

					i
Potatoes & fries
Frozen chips (10 mm x 10 mm standard thickness)	300 - 800 g	15 - 25 min	180°C
Homemade Fries (8 x 8 mm)	300 - 800 g	22 - 27 min	180°C		Add 1 tbsp of oil
Frozen potato wedges	300 - 800 g	22 - 27 min	180°C		Add 1 tbsp of oil
Meat & Poultry
Steak 100 - 500 g		6 - 10 min	180°C
Chicken breast fillets (boneless)	100 - 500 g	12 - 19 min	180°C
Chicken (whole)	1000 g 60 min		200°C
Fish
Salmon fillet 350 g		15 - 17 min	140°C
Prawns	12 pieces 4 min		170°C
Snacks
Frozen chicken nuggets	100 - 600 g	7 - 15 min	200°C
Frozen chicken wings	300 g	16 - 20 min	200°C
Frozen cheese sticks	125 g (5 pieces)	7 - 9 min	180°C
Frozen onion rings	200 g (10 pieces)	8 - 10 min	200°C
Pizza	400 g 7 min		190°C
Vegetables	300 - 700 g	16 - 20 min	200°C
Baking
Muffins	7 pieces	15 - 18 min	180°C		Use a baking tin/oven dish**
Cake	300 g	30 min	160°C

* Shake halfway through cooking.
**place the cake tin/oven dish in the bowl.

6

						i
Grill
		15 min
Meat 250 g		Preexisting: 15 minCooking: 6.8 min	200°C			You can add oil, aromatic herbs andsalt for better taste.At mid-cooking, you can return the food.
Sausages 400 g		Preexisting: 15 minCooking: 10.12 min	200°C			You can add oil, aromatic herbs and saltfor better taste.At mid-cooking, you can return the food.
Vegetables 300 g		Preexisting: 15 minCooking: 10 min	200°C
Fish fillet 200 g		Preexisting: 15 minCooking: 3.5 min	170°C

IMPORTANT: To avoid damaging your appliance, never exceed the maximum quantities of ingredients and liquids indicated in the instruction manual and in the recipes. When you use mixtures that rise (such as with cake, quiche or muffins) the oven dish should not be filled more than halfway.

TIPS

• Smaller food usually requires a slightly shorter cooking time than larger size foods. If you are unsure, you can open the bowl at any point of cooking to check progress.
• Shaking food halfway through the cooking time improves the end result and can help prevent uneven cooking.
• To make your fresh potatoes extra crispy, try adding a small amount of oil before cooking and shake to evenly cover. We recommend 14ml of oil. Do not add oil to frozen potatoes.
  • Snacks that can be cooked in an oven can also be cooked in the appliance.
• The optimal recommended quantity for cooking fries is 700 grams.
• Use ready made puff and shortcrust pastry to make filled snacks quickly and easily.
• Place an oven dish in the appliance's bowl if you want to bake a cake or quiche or if you want to fry delicate ingredients or filled ingredients. You can use an oven dish in silicon, stainless steel, aluminium, terracotta.
• You can also use the appliance to reheat food. To reheat food, set the temperature to 160°C for up to 10 minutes. Cooking time could be adjusted depending on food quantity in order to fully reheat the food.

MAKING HOME-MADE CHIPS

If you want to make home-made chips, follow the steps below.

1. Choose a variety of potato recommended for making chips. Peel the potatoes and cut them into equal thickness chips.
2. Soak the potato chips in cold water for at least 30 minutes, drain them and dry them with a clean, highly absorbent tea towel. Then pat with paper kitchen towel. The chips must be thoroughly dry before cooking.

7

1. Pour 1 tablespoon of oil (vegetable, sunflower or olive) in a dry bowl, put the chips on top and mix until they are coated with oil.
2. Remove the chips from the bowl with your fingers or a kitchen utensil so that any excess oil stays behind in the bowl. Place the chips in the bowl.

Note: Do not tip the container of oil coated chips directly into the bowl in one go, otherwise excess oil will end up at the bottom of the bowl.

1. Fry the chips according to the instructions in the section Cooking guide.

CLEANING

Clean the appliance after every use.

The bowl and the grid have a non-stick coating. Do not use metal kitchen utensils or abrasive cleaning materials to clean them, as this may damage the nonstick coating.

1. Remove the mains plug from the wall socket and let the appliance cool down.

Note: Remove the bowl to let the appliance cool down more quickly.

1. Wipe the outside of the appliance with a damp cloth.
2. Clean the bowl and grid with hot water, some washing-up liquid and a non-abrasive sponge.

You can use a degreasing liquid to remove any remaining dirt.

Note: the bowl and the grid are dishwasher safe.

Tip: If food debris/residue is stuck at the bottom of the bowl and the grid, fill them with hot water and some washing-up liquid. Let the bowl and the grid soak for approximately 10 minutes. Then rinse clean and dry.

1. Wipe inside of the appliance with hot water and a damp cloth.
2. Clean the heating element with a dry, cleaning brush to remove any food residues.
3. Do not immerse the appliance in water or any other liquid.

STORAGE

1. Unplug the appliance and let it cool down.
2. Make sure all parts are clean and dry.

GUARANTEE AND SERVICE

If you need service or information or if you have a problem, please visit the brand website or contact the brand Consumer Care Centre in your country. You can find the phone number in the worldwide guarantee leaflet. If there is no Consumer Care Centre in your country, go to your local dealer.

TROUBLESHOOTING

If you encounter problems with the appliance, visit the brand website (see cover page on this document) for a list of frequently asked questions or contact the Consumer Care Centre in your country.
