GB / IE / NI / CY / MT Operating and Safety Instructions Page 1

1 Explanation of the symbols on the product 2
2 Introduction.... 3
3 Product description (Fig. 1-24) 3
4 Scope of delivery (Fig. 2).... 3
5 Proper use.... 3
6 Safety instructions 4
7 Technical data.... 8
8 Unpacking.... 9
9 Before first use (Fig. 3).... 9
10 Assembly.... 9
11 Operation 10
12 Maintenance 13
13 Transport (Fig. 1, 4, 23).... 14
14 Storage.... 14
15 Electrical connection.... 14
16 Repair & ordering spare parts.... 15
17 Disposal and recycling.... 16
18 Troubleshooting.... 17
19 EU Declaration of Conformity 17
20 Warranty certificate.... 18
21 Exploded view.... 225

1 Explanation of the symbols on the product

Symbols are used in this manual to draw your attention to potential hazards. The safety symbols and the accompanying explanations must be fully understood. The warnings themselves will not rectify a hazard and cannot replace proper accident prevention measures.

	Before commissioning, read and observe the operating manual and safety instructions!
	Wear hearing protection.
	If dust builds up, wear respiratory protection!
	Wear safety goggles.
	Attention! Danger of injury! Do not reach into saw blade while it is running!
	Attention! Laser beam (Fig. 1, 20)
	Protection class II (double insulation).
	Number of saw teeth.
	Saw blade direction of rotation.
	The product complies with the applicable European directives.

2 Introduction

Manufacturer:

Scheppach GmbH

Günzburger Straße 69

D-89335 Ichenhausen

Dear Customer

We hope your new product brings you much enjoyment and success.

Note:

In accordance with the applicable product liability laws, the manufacturer of this product assumes no liability for damage to the product or caused by the product arising from:

• Improper handling
  • Non-compliance with the operating manual
  • Repairs carried out by third parties, unauthorised specialists
• Installing and replacing non-original spare parts
• Improper use
• Failures of the electrical system in the event of the electrical regulations and VDE provisions 0100, DIN 57113 / VDE0113 not being observed.

Note:

The operating manual is part of this product.

It includes important instructions for the safe, proper and economic operation of the product, for avoiding danger, for minimising repair costs and downtimes and for increasing the reliability and extending the service life of the product. In addition to the safety instructions in this operating manual, you must also observe the regulations applicable to the operation of the product in your country.

Familiarise yourself with all operating and safety instructions before using the product. Only operate the product as described and for the specified areas of application. Keep the operating manual in a good place and hand over all documents when passing the product on to third parties.

3 Product description (Fig. 1-24)

1. Handle
2. On/off switch
3. Locking switch
4. Laser ON/OFF switch
5. Sawing shaft lock
6. Saw head
7. Moving saw blade guard
   7a. Fixing screw
8. Saw blade
9. Laser cover
10. Laser
11. Moveable stop rail

12. Stop rail

13. Table inlay

14. Handle / locking screw for rotary table
15. Adjustment screw
16. Pointer
17. Scale
18. Rotary table
19. Fixed saw table
20. Locking screw for workpiece support
21. Workpiece support
22. Longitudinal stop
23. Set screw for the sliding stop rail
24. Locking screw
25. Clamping device
    25a. Locking screw for clamping device height adjustment
    25b. Knurled screw for clamping device height adjustment
    25c. Locking screw for clamping device
26. Angle scale
27. Angle pointer
28. Cable routing
    28a. Slide rail locking screw
29. Guide bar
30. Dust bag
31. Screw for limiting cutting depth
    31a. Knurled nut for limiting cutting depth
32. Stop for cutting depth limiting
33. Tilt protection
34. Locking pin
35. Adjustment screw (90°)
    35a. Locknut (90°)
36. Adjustment screw (45°)
    36a. Counternut (45°)
37. Flange screw
38. Outer flange
39. Inner flange
40. Laser cover Philips screw
41. Philips screw table inlay
42. Transport handle

4 Scope of delivery (Fig. 2)

Item Quantity Designation

1. 2 x Clamping device

2. 1 x Dust bag

C. 1 x Allen key, 6 mm

D. 1 x Allen key, 3 mm

1 x Sliding cross-cut mitre saw

1 x Operating manual

5 Proper use

The saw is used for the cutting of wood and plastic, according to the machine size. The saw is not suitable for cutting firewood.

WARNING

Do not use the product to cut materials other than those described in the operating manual.

WARNING

The supplied saw blade is only intended for the sawing of wood! Do not use this blade for sawing firewood!

Only suitable saw blades may be used for the product. The use of any type of cutting wheels is prohibited.

The product may only be used in the intended manner. Any use beyond this is improper. The user/operator, not the manufacturer, is responsible for damages or injuries of any type resulting from this.

An element of the intended use is also the observance of the safety instructions, as well as the assembly instructions and operating information in the operating manual.

Persons who operate and maintain the product must be familiar with the manual and must be informed about potential dangers.

The liability of the manufacturer and resulting damages are excluded in the event of modifications of the product.

The product may only be operated with original parts and original accessories from the manufacturer.

The safety, operating and maintenance specifications of the manufacturer, as well as the dimensions specified in the technical data, must be observed.

Despite use as intended, specific risk factors cannot be entirely eliminated. Due to the design and layout of the product, the following risks remain:

• Contact with the saw blade in the exposed sawing area.
• Reaching into the running saw blade (cutting injury).
• Kick-back of workpieces and workpiece parts.
• Saw blade breakage.
• Ejection of faulty carbide parts of the saw blade.
• Hearing damage when the necessary hearing protection is not used.
• Harmful emissions of wood dusts during use in enclosed areas.

Please note that our products were not designed with the intention of use for commercial or industrial purposes. We assume no guarantee if the product is used in commercial or industrial applications, or for equivalent work.

Explanation of the signal words in the operating manual

DANGER

Signal word to indicate an imminently hazardous situation which, if not avoided, will result in death or serious injury.

WARNING

Signal word to indicate a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

Signal word to indicate a potentially hazardous situation which, if not avoided, could result in minor or moderate injury.

ATTENTION

Signal word to indicate a potentially hazardous situation which, if not avoided, could result in product or property damage.

6 Safety instructions

General power tool safety warnings

WARNING

Read all safety warnings, instructions, illustrations and specifications provided with this power tool.

Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

6.1 Work area safety

a) Keep your work area clean and well-lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

6.2 Electrical safety

a) The connection plug of the electric tool must fit into the socket. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

6.3 Personal safety

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Wear personal protective equipment and always safety goggles. Protective equipment such as a dust mask, non-skid safety shoes, safety helmet or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or rechargeable battery, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting tools or spanners/keys before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
e) Avoid abnormal postures. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust extraction can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

6.4 Power tool use and care

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such precautionary measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and attachments. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
g) Use electric tools, insertion tools, etc. according to these instructions. Take into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

6.5 Service

a) Only have your power tool repaired by qualified specialists and only with original spare parts. This will ensure that the safety of the power tool is maintained.

6.6 Safety instructions for chop and mitre saws

a) Mitre saws are intended to cut wood or wood-like products, they cannot be used with abrasive cut-off wheels for cutting ferrous material such as bars, rods, studs, etc. Abrasive dust causes moving parts such as the lower protective cover to jam. Sparks from abrasive cutting will burn the lower protective cover, the kerf insert and other plastic parts.
b) Use clamps to support the workpiece whenever possible. If supporting the workpiece by hand, you must always keep your hand at least 100 mm from either side of the saw blade. Do not use this saw to cut pieces that are too small to be securely clamped or held by hand. If your hand is placed too close to the saw blade, there is an increased risk of injury from blade contact.
c) The workpiece must be stationary and clamped or held against both the fence and the table. Do not feed the workpiece into the saw blade or cut "freehand" in any way. Unrestrained or moving workpieces could be thrown at high speeds, causing injury.
d) Push the saw through the workpiece. Do not pull the saw through the workpiece. To make a cut, raise the saw head and pull it out over the workpiece without cutting. Start the motor, press the saw head down and push the saw through the workpiece. Cutting on the pull stroke is likely to cause the saw blade to climb on top of the workpiece and violently throw the blade assembly towards the operator.
e) Never cross your hand over the intended line of cutting either in front or behind the saw blade. Supporting the workpiece “cross handed” i.e. holding the workpiece to the right of the saw blade with your left hand or vice versa is very dangerous.
f) Do not reach behind the fence while the saw blade is spinning. Observe the 100 mm safety distance between hands and the rotating saw blade (this applies to both sides of the saw blade, e.g. also when removing waste pieces of wood). The proximity of the spinning saw blade to your hand may not be obvious and you may be seriously injured.

g) Inspect your workpiece before cutting. If the workpiece is bowed or warped, clamp it with the outside bowed face toward the fence. Always make certain that there is no gap between the workpiece, fence and table along the line of the cut. Bent or warped workpieces can twist or shift and may cause binding on the spinning saw blade while cutting. There should be no nails or foreign objects in the workpiece.
h) Do not use the saw until the table is clear of all tools, wood scraps, etc., except for the workpiece. Small debris or loose pieces of wood or other objects that contact the revolving blade can be thrown with high speed.
i) Only cut one workpiece at a time. Stacked multiple workpieces cannot be adequately clamped or braced and may bind on the blade or shift during cutting.
j) Ensure the mitre saw is mounted or placed on a level, firm work surface before use. A level and firm work surface reduces the risk of the mitre saw becoming unstable.
k) Plan your work. Every time you adjust the bevel or mitre angle setting, make sure the adjustable fence is set correctly to support the workpiece and will not interfere with the blade or the protective cover. Without turning the machine "ON" and with no workpiece on the table, move the saw blade through a complete simulated cut to assure there will be no interference or danger of cutting the fence.
1) Provide adequate support such as table extensions, saw horses, etc. for a workpiece that is wider or longer than the table top. Workpieces that are longer or wider than the table of the chop and mitre saw can tip if they are not properly supported. If the cut-off piece or workpiece tips, it can lift the lower protective cover or be thrown by the spinning blade.
m) Do not use another person as a substitute for a table extension or as additional support. Unstable support of the workpiece can lead to the blade becoming jammed. Also, the workpiece could shift during the cutting process, pulling you or your assistant into the rotating blade.
n) The cut-off piece must not be jammed or pressed by any means against the spinning saw blade. If confined, i.e. using length stops, the cut-off piece could get wedged against the blade and thrown violently.
o) Always use a clamp or a fixture designed to properly support round material such as rods or tubing. Rods have a tendency to roll while being cut, causing the blade to "bite" and pull the work with your hand into the blade.
p) Let the blade reach full speed before contacting the workpiece. This will reduce the risk of the workpiece being thrown.

q) If the workpiece or blade becomes jammed, turn the mitre saw off. Wait for all moving parts to stop and disconnect the mains plug from the power source and/or remove the rechargeable battery. Then, remove the jammed material. Continued sawing with a jammed workpiece could cause loss of control or damage to the mitre saw.
r) After finishing the cut, release the switch, hold the saw head down and wait for the blade to stop before removing the cut-off piece. Reaching with your hand near the coasting blade is dangerous.
s) Hold the handle firmly when making an incomplete cut or when releasing the switch before the saw head is completely in the down position. The braking action of the saw may cause the saw head to be suddenly pulled downward, causing a risk of injury.

6.7 Safety instructions for the use of saw blades

• Avoid uncontrolled release of the saw unit in the lower end position.
• Do not use damaged or deformed saw blades.
• Do not use saw blades with cracks. Separate cracked saw blades. Repairs are not permitted.
• Do not use saw blades made of high speed steel.
• Check the condition of the saw blades before using saws.
• Make sure that a suitable saw blade for the material to be cut is selected.
• Only use saw blades recommended by the manufacturer. Saw blades designed to cut wood and similar materials must comply with EN 847-1.
• Do not use saw blades made of high-speed alloy steel (HSS steel).
• Only use saw blades for which the maximum permissible speed is not lower than the maximum spindle speed of the saw and which are suitable for the material to be cut.
• Observe the direction of rotation of the saw blade.
• Only use saw blades if you have mastered their use.
• Observe the maximum speed. The maximum speed specified on the saw blade may not be exceeded. If specified, observe the speed range.
• Clean dirt, grease, oil and water off of the clamping surfaces.
• Do not use any loose reducing rings or bushes for the reducing of holes on saw blades.
• Make sure that fixed reducer rings for securing the saw blade have the same diameter and have at least 1/3 of the cutting diameter.

• Make sure that fixed reducer rings are parallel to each other.

• Handle saw blade with caution. They are ideally stored in the originally package or special containers. Wear protective gloves in order to improve grip and to further reduce the risk of injury.

• Prior to the use of saw blades, make sure that all protective devices are properly fastened.
• Prior to use, make sure that the saw blade meets the technical requirements of this saw and is properly fastened.
• Only use the supplied saw blade for cutting wood, never for the processing of metals.
• Use only a saw blade with a diameter that matches the specifications on the saw.
• Use additional workpiece supports, if required for workpiece stability.
• Workpiece support extensions must always be secured and used during work.
• Replace table inlays when worn!
• Avoid overheating the saw teeth.
• When sawing plastic, avoid melting of the plastic. Use the correct saw blades for the material to be cut. Replace damaged or worn saw blades immediately.

When the saw blade overheats, stop the machine. Allow the saw blade to cool down before using the machine again.

• Use only saw blades that are marked with an equal or higher rotational speed than the rotational speed specified on the electric tool.
  • Always ensure that the saw is stable and secure.

6.8 Laser beam

Attention: Laser beam Do not look into the beam Laser class 2

Protect yourself and you environment from accidents using suitable precautionary measures!

• Do not look directly into the laser beam with unprotected eyes.
• Never look into the path of the beam.
• Never point the laser beam towards reflecting surfaces and persons or animals. Even a laser beam with a low output can cause damage to the eyes.

CAUTION

Methods other than those specified here can result in dangerous radiation exposure.

• Never open the laser module. Unexpected exposure to the beam can occur.
• The laser may not be replaced with a different type of laser.
  • Repairs of the laser may only be carried out by the laser manufacturer or an authorised representative.

6.9 Residual risks

The product has been built according to state-of-the-art and the recognised technical safety rules. However, individual residual risks can arise during operation.

• Health hazard due to electrical power, with the use of improper electrical connection cables.
• Furthermore, despite all precautions having been met, some non-obvious residual risks may still remain.
• Residual risks can be minimised if the "Safety Instructions" and the "Intended Use" together with the operating manual as a whole are observed.
• Do not load the product unnecessarily: excessive pressure when sawing will quickly damage the saw blade, which results in reduced output of the product in the processing and in cut precision.
• When cutting plastic material, please always use clamps: the parts which should be cut must always be fixed between the clamps.
• Avoid accidental start-up of the product: when inserting the plug into the socket, do not press the on/off switch.
• Use the product in the way that is recommended in this operating manual. This is how to ensure that your product provides optimum performance.
• Keep your hands away from the working area when the product is in operation.
• Before performing setting or maintenance work, release the on/off switch and pull out the mains plug.

WARNING

This power tool generates an electromagnetic field during operation. This field can impair active or passive medical implants under certain circumstances. In order to prevent the risk of serious or deadly injuries, we recommend that persons with medical implants consult with their physician and the manufacturer of the medical implant prior to operating the power tool.

7 Technical data

Rated voltage 220 - 240 V~50 Hz
Nominal power S1 1700 W
Operating mode S6 25%* 2000 W
Idle speed n0	4800 rpm
Carbide saw blade ø 210 x ø 30 x 2.6 mm
Number of teeth 24
Maximum tooth width of the saw blade	3 mm
Pivot range -47° / 0° / +47°
Mitre cut 0° to 45° to the left
Saw width at 0° 340 x 65 mm
Saw width at 45° 240 x 65 mm
Saw width at 2 x 45° (dou-ble mitre cut)	240 x 38 mm
Protection class	II / ☐
Weight	approx. 10.8 kg
Laser class	2
Laser wavelength	650 nm
Power of laser	< 1 mW

Operating mode S6

Uninterrupted periodic operation. The mode comprises of a start-up period, a time with constant load and an idle time. The operating time is 10 mins, the relative duty cycle is 25% of the operating time.

The workpiece must have a minimum height of 3 mm and a minimum width of 10 mm. Make sure that the workpiece is always secured with the clamping device.

Noise data

WARNING

Noise can have serious effects on your health. If the machine noise exceeds 85 dB, please wear suitable hearing protection for you and persons in the vicinity.

The noise and vibration values have been determined in accordance with EN 62841-1.

Sound pressure level L_pA	90.5 dB
Uncertainty K_pA	3 dB
Sound power level L_wA	103.5 dB
Uncertainty K_wA	3 dB
Vibration ah	≤ 2.5 m/s^2

The specified noise emission values have been measured in accordance with a standardised test procedure and can be used to compare one power tool with another.

The specified device emissions values can also be used for an initial estimation of the load.

WARNING

The noise emission values can vary from the specified values during the actual use of the power tool, depending on the type and the manner in which the electric tool is used, and in particular the type of workpiece being processed.

Try to keep the stress as low as possible. For example: Limit working time. In doing so, all parts of the operating cycle must be taken into account (such as times in which the power tool is switched off or times in which it is switched on, but is not running under a load).

8 Unpacking

WARNING

The product and the packaging material are not children's toys!

Do not let children play with plastic bags, films or small parts! There is a danger of choking or suffocating!

• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport damage. Immediately report any damage to the transport company that delivered the Product. Later claims will not be recognised.
• If possible, keep the packaging until the expiry of the warranty period.
• Familiarise yourself with the product by means of the operating manual before using for the first time.
• With accessories as well as wearing parts and replacement parts use only original parts. Spare parts can be obtained from your specialist dealer.
• When ordering please provide our article number as well as type and year of manufacture for the product.

9 Before first use (Fig. 3)

1. Loosen the pre-installed tilt protection (33) on the underside of the saw, pull it out completely and secure it again using the Allen key (D).

2. The product must be securely installed. Fasten the product to a workbench, machine stand or similar. Insert 4 screws (not included in the scope of delivery) into the holes on the fixed saw table (19). Tighten up the screws.

3. Set the adjustment screw (15) to the level of the tabletop to prevent the product from tipping over.
4. Prior to commissioning, all covers and safety devices must be mounted correctly.
5. The saw blade must be able to run freely.
6. In case of previously machined wood, be aware of any foreign bodies, such as nails or screws, etc.
7. Before pressing the on/off switch, make sure that the saw blade is correctly fitted, and that moving parts run smoothly.
8. Before connecting of the product, make certain that the data on the type plate matches with the mains power data.

9.1 Checking the safety equipment of the saw blade guard (7) (Fig. 4)

The saw blade guard protects against accidental contact with the saw blade and against flying chips.

Check function

To do this, fold the saw down:

• The saw blade guard must expose the saw blade when it is swung down without touching other parts.
• When the saw is folded up to the initial position, the saw blade guard must automatically cover the saw blade.

10 Assembly

10.1 Assembling the product (Fig. 1, 2, 5, 6)

1. Loosen the rotary table (18) by turning the handle (14) counter-clockwise.
2. Use the handle (14) to adjust the rotary table (18) to the desired angle.
3. Re-tighten the handle (14) by turning it clockwise, to fix the rotary table in place.
4. The saw is unlocked from the lower position by gently pressing down on the saw head (6) and, at the same time, pulling out the locking pin (34) from the engine mount.
5. Turn the locking pin (34) 90 degrees to lock it in the unlocked position.

6. Swivel the saw head (6) upwards.

7. The clamping devices (25) can be attached to both sides of the fixed saw table (19). Insert a clamping device (25) into the hole provided on the rear side of the stop rail (12) and secure it with the locking screw (25c).

For mitre cuts 0^-45^ , mount the clamping device (25) on one side (right) only (see Fig. 11-12).

1. The saw head (6) can be tilted to the left to max. 45^ by loosening the locking screw (24).

2. Workpiece supports (21) must always be secured and used during work.

Set the desired projection by loosening the locking screw (20). Then retighten the locking screw (20).

10.2 Dust bag (30) (Fig. 1, 24)

The saw is equipped with a dust bag (30) for chips. Squeeze the wings of the metal ring on the dust bag (30) together and slide it over the discharge port near the motor. The dust bag (30) can be emptied via the zip on the underside.

10.2.1 Connection to an external dust extraction system

1. Connect the suction hose to the dust extraction.
2. The dust extraction system must be suitable for the material to be processed.
3. Use a special extraction device to extract dusts that are particularly harmful to health or carcinogenic.

10.3 Fine adjustment of the stop for 90° chop cut (Fig. 1, 7)

Tool required:

• Allen key, 6 mm (C)
• 90^ engineers square (A) ^*
• Phillips screwdriver*
• Open-ended spanner, size 13 mm*

* = not included in the scope of delivery!

1. Lower the saw head (6) and fix it with the locking pin (34).
2. Loosen the locking screw (24).
3. Place 90° engineers square (A) between saw blade (8) and rotary table (18).
4. Loosen the locknut (35a).
5. Adjust the adjustment screw (35) until the angle between the saw blade (8) and the rotary table (18) is 90^ .
6. Re-tighten the locknut (35a).
7. Then check the position of the angle display. If necessary, loosen the pointer (16) with a Phillips screwdriver, set the scale (17) to 0° position and re-tighten.

10.4 Fine adjustment of the stop for 45^ mitre cut (Fig. 1, 8)

Tool required:

• 45^ engineers square (B)*
• Open-ended spanner, size 13 mm*
• Phillips screwdriver*

* = not included in the scope of delivery!

1. Lower the saw head (6) and fix it with the locking pin (34).

2. Fix the rotary table (18) in the 0^ position.

ATTENTION

For mitre cuts (inclined saw head), the moveable stop rail must be fixed in the outer position (left side).

1. Loosen the locking screw (23) on the moveable stop rails (11) and slide the sliding stop rails (11) outwards to create a 45^ stop angle (B) between the saw blade (8) and the rotary table (18).
2. The moveable stop rails (11) must be locked in a position that the distance between the stop rails (11) and the saw blade (8) is at least 8 mm.
3. The sliding stop rail (11) must be in the inner position (right side).
4. Before making the cut, check that no collision could occur between the moveable stop rails (11) and the saw blade (8).
5. Loosen the locking screw (23) and tilt the saw head (6) to the left, to 45^ , using the handle (14).
6. Place 45° engineers square (B) between saw blade (6) and rotary table (18).
7. Loosen the counternut (36a) and the adjustment screw (36) until the angle between the saw blade (8) and the rotary table (18) is exactly 45^ .
8. Tighten the counternut (36a) again.
9. Then check the position of the angle display. If necessary, loosen the pointer (16) with a Phillips screwdriver, set the scale (17) to 45° position and re-tighten.

11 Operation

11.1 Operating the clamping device (25) (Fig. 1)

The height of the clamping device (25) can be adjusted via the locking screw (25a).

1. Lower the clamping device (25) onto the workpiece.
2. Tighten the locking screw (25c).

3. Turn the knurled screw (25b) clockwise to clamp the workpiece.

4. In order to loosen the workpiece, proceed in reverse order.

11.2 Cutting depth limit (groove sawing) (Fig. 1, 9)

WARNING

Risk of kick-back!

When making grooves, it is particularly important that no lateral pressure is exerted on the saw blade. Otherwise the saw head could suddenly kick up!

- Use a clamping device when making grooves. Avoid lateral pressure on the saw head.

1. The cutting depth can be seamlessly adjusted with the screw (31). Loosen the knurled nut (31a) on the screw for this. Set the desired cutting depth by screwing in or unscrewing the screw (31). Then re-tighten the knurled nut (31a) on the screw (31).
2. Check the setting with a test cut.

11.3 Switching the laser on / off (Fig. 19)

Switching on:

1. Press the laser ON/OFF switch (4) 1x. A laser line is projected onto the workpiece to be cut, indicating the exact cutting path.

Switching off:

1. Press the laser ON/OFF switch (4) again.

11.4 Serial cuts (Fig. 1, 10)

For repeated cuts of the same length, the length stop (22) can be opened. You can use the length stop (22) on the right and on the left.

1. Fold up the length stop (22).
2. Loosen the locking screw for the workpiece support (20).
3. Pull out the workpiece support (21).
4. Set the required dimension between saw blade (8) and length stop (22).
5. Re-tighten the locking screw for the workpiece support (20).
6. Carry out the cuts as described in 11.5, 11.6, 11.7 and 11.8.

11.5 Chop cut 90° and rotary table 0° (Fig. 1, 11, 12)

At cutting widths of up to approx. 100 mm, it is possible to use the locking screw (28a) to secure the saw's sliding function in the rear position. In this position the saw can be operated in chop cutting mode. If the cutting width is over 100 mm, ensure that the locking screw (28a) is loose and that the saw head (6) can move.

ATTENTION

For 90° chop cuts, the moveable stop rail must be fixed in the inner position.

Hints for clamping:

• Do not work with workpieces that are to small to be clamped in place.

• Reinforce very thin workpieces by sawing through them together with an additional bar. Very thin workpieces may "flutter" or break when sawing

• Loosen the locking screw (23) for the moveable stop rail (11) and push the moveable stop rail (11) inwards.

• The moveable stop rail (11) must be locked in a position far enough from the inner position that the distance between the moveable stop rail (11) and the saw blade (8) is no more than 8 mm.
• Before making the cut, check that no collision could occur between the moveable stop rail (11) and the saw blade (8).
• Tighten the set screw (23) again.
• Move the saw head (6) to the upper position.
• Use the handle (1) to push back the saw head (6) and fix it in this position if required (dependent on the cutting width).
• Place the wood to be cut against the stop rail (12) and on the rotary table (18).
• Secure the material with the clamping device (25) on the fixed saw table (19) to prevent it from shifting during the cutting process.
• Unlock the locking switch (3) and press the on/off switch (2) to switch the motor on.
• Move the saw head (6) with the handle (1) evenly and with light pressure downwards until the saw blade (8) has cut through the workpiece.
• When the sawing process is finished, return the saw head (6) to the upper resting position and release the ON/OFF switch (2).

ATTENTION

The return spring automatically raises the product. Do not release the handle after finishing cutting but allow the saw head to move upwards slowly and with a little counterpressure.

11.5.1 With the slide rail fixed (28) (Fig. 4)

1. Fix the saw's sliding function with the locking screw for slide rail (28a) in rear position.
2. Move the saw head (6) with the handle (1) evenly and with light pressure downwards until the saw blade (8) has cut through the workpiece.

11.5.2 With the slide rail (28) not fixed in place

- Pull the saw head (6) all the way to the front. Lower the handle (1) to the very bottom by applying steady and light downward pressure. Now push the saw head (6) slowly and steadily to the very back until the saw blade (8) has completely cut through the work piece.

11.6 90° chop cut and rotary table 0°-47° (Fig. 1, 11, 13)

The cross-cut mitre saw can be used for angled cuts of 0^-47^ to the left and right.

ATTENTION

For 90° chop cuts, the moveable stop rail must be fixed in the inner position.

1. Loosen the locking screw (23) for the moveable stop rail (11) and push the moveable stop rail (11) inwards.
2. The moveable stop rail (11) must be locked in a position far enough from the inner position that the distance between the moveable stop rail (11) and the saw blade (8) is no more than 8 mm.
3. Before making the cut, check that no collision could occur between the moveable stop rail (11) and the saw blade (8).
4. Tighten the set screw (23) again.
5. Loosen the rotary table (18) by turning the handle (14) counter-clockwise.
6. Use the handle (14) to adjust the rotary table (18) to the desired angle.
7. Tighten the handle (14) by turning it clockwise, to fix the rotary table (18) in place.
8. Make a cut as described in 11.5.

11.7 0°- 45° mitre cut and rotary table 0° (Fig. 1, 11, 14)

Mitre cuts of 0^ - 45^ to the working surface can be carried out to the left using the saw.

ATTENTION

For mitre cuts (inclined saw head), the moveable stop rail must be fixed in the outer position.

ATTENTION

For 0°- 45° mitre cuts, only the clamping device (workpiece clamp) on the right must be mounted.

1. Loosen the locking screw (23) on the moveable stop rails (11) and push the moveable stop rails (11) outwards (left side).

2. The moveable stop rail (11) must be locked in a position far enough from the inner position that the distance between the moveable stop rails (11) and the saw blade (8) is no more than 8 mm (right side).

3. Before making the cut, check that no collision could occur between the moveable stop rail (11) and the saw blade (8).
4. Tighten the set screw (23) again.
5. Move the saw head (6) to the upper position.
6. Fix the rotary table (18) in the 0^ position.
7. Loosen the locking screw (24) and tilt the saw head (6) to the left with the handle (1) until the angle pointer (27) points to the desired angle on the angle scale (26).
8. Retighten the locking screw (24).
9. Perform the cut as described under 11.5.

11.8 0°- 45° mitre cut and rotary table 0°- 47° (Fig. 1, 11, 15)

The saw can be used for mitre cuts of 0^-45^ to the left of the work surface and of 0^-47^ to the stop rail (double mitre cut).

ATTENTION

For mitre cuts (inclined saw head), the moveable stop rail must be fixed in the outer position.

With a cross-cut saw tilted to 31.6° and a unit tilt of 33.9°, isosceles triangular strips and profiles such as stucco edge profiles can be mitred with the profile side down.

This is particularly advantageous for large profiles that exceed the maximum cutting height with normal insertion.

It also makes it easy to solve problems with the angle at the corners, which is often not right-angled.

ATTENTION

For 0^ - 45^ mitre cuts, only the clamping device (workpiece clamp) on the right must be mounted.

1. Loosen the locking screw (23) on the moveable stop rails (11) and push the moveable stop rails (11) outwards.
2. The moveable stop rail (11) must be locked in a position far enough from the inner position that the distance between the moveable stop rail (11) and the saw blade (8) is no more than 8 mm.
3. Before making the cut, check that no collision could occur between the moveable stop rail (11) and the saw blade (8).
4. Tighten the set screw (23) again.

5. Move the saw head (6) to the upper position.

6. Loosen the rotary table (18) by turning the handle (14) counter-clockwise.

7. Use the handle (14) to adjust the rotary table (18) to the desired angle (see 11.6).
8. Tighten the handle (14) by turning it clockwise, to fix the rotary table (18) in place.
9. Loosen the locking screw (24).
10. Use the handle (1) to tilt the saw head (6) to the left to the desired angle.
11. Retighten the locking screw (24).
12. Make a cut as described in 11.5.

12 Maintenance

WARNING

Pull out the mains plug before carrying out any setting, servicing or repair work!

12.1 General maintenance tasks

• Keep protective devices, air vents and the motor housing as free of dust and dirt as possible. Rub the product clean with a clean cloth* or blow it off with compressed air* at low pressure. We recommend that you clean the product directly after every use.
• Oil all moving parts once a month.
• Clean the product at regular intervals using a damp cloth* and a little soft soap. Do not use any cleaning products or solvents; they could attack the plastic parts of the product. Make sure that no water can penetrate the product interior.

12.2 Replacing the saw blade (8) (Fig. 1, 16 - 18)

WARNING

Pull out the mains plug before carrying out any setting, servicing or repair work!

ATTENTION

Wear protective gloves when changing the saw blade! Danger of injury!

Tool required:

• Allen key, 6 mm (C)

• Phillips screwdriver*
  * = not included in the scope of delivery!

• Swivel the saw head (6) upwards and lock it with the locking pin (34).

• Loosen the fixing screw (7a) of the cover with a Phillips screwdriver.

• Fold the saw blade guard (7) up sufficiently that the saw blade guard (7) is above the flange screw (37).
• With one hand, fit the 6mm Allen key (C) to the flange screw (37).
• Firmly press the saw shaft lock (5), and slowly turn the flange screw (37) clockwise. After max. one turn, the saw shaft lock (5) engages.
• Then undo the flange screw (37), by applying a slightly greater force in a clockwise direction.
• Fully unscrew the flange screw (37) and remove the outer flange (38).
• Remove the saw blade (8) from the inner flange (39) and pull it out downwards.
• Carefully clean the flange screw (37), outer flange (38) and inner flange (39).
• Insert the new saw blade (8) in the reverse sequence and tighten.
• Fold the saw blade guard (7) downwards until the saw blade guard (7) engages in the fixing screw (7a).
• Re-tighten the fixing screw (7a).

ATTENTION

The cutting angle of the teeth, i.e. the direction of rotation of the saw blade, must correspond to the direction of the arrow on the housing.

1. Before continuing work, check that the safety devices are functioning properly (Fig. 5).

ATTENTION

After each saw blade change, check that the saw blade runs freely in the table inlay in vertical position as well as when tilted to 45^ .

ATTENTION

Changing and aligning the saw blade must be carried out properly.

12.3 Cleaning the safety equipment of the saw blade guard (7) (Fig. 1)

Check the saw blade guard for dirt before each start-up.

Remove old shavings and wood splinters using a brush or similar suitable tool.

Make sure the guide bar (29) moves smoothly.

12.4 Calibrating the laser (10) (Fig. 20)

ATTENTION

Never press the ON/OFF switch when adjusting the laser. Danger of injury!

If the laser (10) is no longer showing the correct cutting line, it can be readjusted.

Tool required:

- Phillips screwdriver*

* = not included in the scope of delivery!

1. To do so, loosen the laser cover Philips screw (40) and remove the laser cover (9). Set the laser by moving sideways until the laser beam strikes the teeth of the saw blade (8).
2. After you have calibrated the laser (10) and fastened it in place, fit the laser cover (9) and fasten this hand-tight with the Philips screw for the laser cover (40).
3. The saw must be connected to the mains in order to adjust the laser (10).

12.5 Replacing the table inlay (13) (Fig. 1, 21)

WARNING

With a damaged table inlay there is a risk of small parts jamming between table inlay and saw blade, blocking the saw blade.

Immediately replace damaged table inlays!

Tool required:

- Phillips screwdriver*

* = not included in the scope of delivery!

1. Remove the Phillips screw (41) on the table inlay (13). If necessary, rotate the rotary table (18) and angle the saw head (6) to be able to reach the Phillips screw (41).
2. Remove the table inlay (13).
3. Insert the new table inlay (13).
4. Tighten the Phillips screw (41) on the table inlay (13).

12.6 Brush inspection (Fig. 22)

If the product is new, check the carbon brushes after the first 50 operating hours or if a new brush has been mounted. After the initial check, check every 10 operating hours.

- If the carbon is worn down to a length of 6 mm, or the spring or the shunt wire is burnt or damaged, both brushes must be replaced.

• If the brushes are found to be usable after removal, they can be reinstalled.
• To maintain the carbon brushes, open both locks anti-clockwise. Then remove the carbon brushes.
• Re-insert the carbon brushes in reverse order.

13 Transport (Fig. 1, 4, 23)

1. Tighten the handle / locking screw for the rotary table (14) to lock the rotary table (18).
2. Push the saw head (6) downwards and lock it with the locking pin (34). The saw is now locked in the lower position.
3. Fix the saw's sliding function with the locking screw for slide rail (28a) in rear position.
4. Carry the product by the transport handle (42).
5. To reassemble the product, proceed as described in 9, 10, 11.

14 Storage

Store the product and its accessories in a dark, dry and frost-free place that is inaccessible to children. The optimum storage temperature is between 5°C and 30°C.

Store the product in its original packaging.

Cover the product to protect it from dust or moisture.

Store the operating manual with the product.

15 Electrical connection

The electrical motor installed is connected and ready for operation. The connection complies with the applicable VDE and DIN provisions. The customer's mains connection as well as the extension cable used must also comply with these regulations.

15.1 Important information

In the event of overloading, the motor will switch itself off. After a cool-down period (time varies) the motor can be switched back on again.

WARNING

The maximum permissible mains impedance Zmax of the product is 0.443 Ω. As a user of this product, you must determine, in consultation with the power supply company if necessary, that the product is only connected to a supply whose impedance is less than or equal to Zmax!

15.2 Special connection conditions

- The product fulfils the requirements of EN 61000-3-11 and is subject to special connection requirements. This means that use at any freely selectable connection points is not permitted.

• The product can cause temporary voltage fluctuations in unfavourable mains conditions.
• The product is intended exclusively for use at connection points which a) do not exceed a maximum permitted mains impedance “Z” (Zmax. = 0.443 Ω), or b) have a continuous current carrying capacity of the mains of at least 100 A per phase.
• As the user, you are required to ensure that the connection point at which you wish to operate the product fulfils one of the requirements mentioned, a) or b). If necessary, consult with your energy supplier in this regard.

15.3 Damaged electrical connection cables

The insulation on electrical connection cables is often damaged.

This may have the following causes:

• Pressure points, where connection cables are passed through windows or doors,
• Kinks where the connection cable has been improperly fastened or routed,
• Places where the connection cables have been cut due to being driven over,
• Insulation damage due to being ripped out of the wall socket,
• Cracks due to the insulation ageing.

Such damaged electrical connection cables must not be used and are life-threatening due to the insulation damage.

Check the electrical connection cables for damage regularly. Ensure that the connection cables are disconnected from electrical power when checking for damage.

Electrical connection cables must comply with the applicable VDE and DIN provisions. Only use connection cables with the same designation "H05VV-F".

The printing of the type designation on the connection cable is mandatory.

Safety information for replacing damaged or defective mains connection cables

Connection type X

If the mains connection cable of this product is damaged, it must be replaced by a specially prepared mains connection cable which can be obtained from the manufacturer or its service department.

15.4 AC motor

Connections and repair work on the electrical equipment may only be carried out by electricians.

• The mains voltage must be 220 V - 240V\~.
• Extension cables up to 25 m long must have a cross-section of 1.5 mm ^2 .

Please provide the following information in the event of any enquiries:

• Type of current for the motor
- Motor data - type plate

16 Repair & ordering spare parts

After repairs or maintenance, make sure that all safety-related parts are installed and are in perfect condition. All parts which may cause injury must be kept where they are inaccessible to children or others.

ATTENTION

According to the German Product Liability Act, no liability is accepted for damage caused by improper repairs or by not using original spare parts.

Such work should be performed by a customer service centre or an authorised specialists. The same applies to accessory parts.

Connections and repairs

Connections and repair work on the electrical equipment may only be carried out by electricians.

16.1 Ordering spare parts

Please provide the following information when ordering spare parts:

• Model designation
• Item number
• Type plate data

Spare parts / accessories

Article: Article no.:
HW circular saw blade∅210x30x2.6x1.6mm / Z 24:	3901208701
HW circular saw blade set∅210x30x2.2x1.6mmscheppach (DIY) 3-piece - 24/48/60 Z	7901200715
Carbon brush set (set = 2 pieces) 59013	12024
Table inlay with screws 5901215010
Dust bag 3901223014

16.2 Service information

With this product, it is necessary to note that the following parts are subject to natural or usage-related wear, or that the following parts are required as consumables.

Wearing parts*: carbon brushes, saw blade, table inlay, saw dust bag

* = may not be included in the scope of delivery!

17 Disposal and recycling

Notes for packaging

The packaging materials are recyclable. Please dispose of packaging in an environmentally friendly manner.

Notes on the electrical and electronic equipment act [ElektroG]

Waste electrical and electronic equipment does not belong in household waste, but must be collected and disposed of separately!

• Used batteries or rechargeable batteries that are not installed permanently in the old device must be removed non-destructively before disposal! Their disposal is regulated by the battery act.
• Owners or users of electrical and electronic devices are legally obliged to return them after use.
• The end user is responsible for deleting their personal data from the old device being disposed of!
• The symbol of the crossed-out dustbin means that waste electrical and electronic equipment must not be disposed of with household waste.

- Waste electrical and electronic equipment can be handed in free of charge at the following places:

– Public disposal or collection points (e.g. municipal works yards)
- LIDL offers you return options directly in the shops and markets. Return and disposal are free of charge.
- Up to three waste electrical devices per type of device, with an edge length of no more than 25 centimetres, can be returned free of charge to the manufacturer without prior purchase of a new device from the manufacturer or taken to another authorised collection point in your vicinity.
- Further supplementary take-back conditions of the manufacturers and distributors can be obtained from the respective customer service.

- If the manufacturer delivers a new electrical device to a private household, the manufacturer can arrange for the free collection of the old electrical device upon request from the end user. Please contact the manufacturer's customer service for this.

• These statements only apply to devices installed and sold in the countries of the European Union and which are subject to the European Directive 2012/19/EU. In countries outside the European Union, different regulations may apply to the disposal of waste electrical and electronic equipment.

Information on the battery act [BattG]

Used batteries and rechargeable batteries do not belong in household waste, but should be collected and disposed of separately.

• For safe removal of batteries or rechargeable batteries from the electrical device and for information on their type or chemical system, please refer to the additional information in the operating or assembly instructions.
• Owners or users of batteries and rechargeable batteries are legally obliged to return them after use. The return is limited to household quantities.
• Old batteries may contain pollutants or heavy metals that can harm the environment or human health. Recycling old batteries and using the resources they contain helps to protect these two important issues.
• The symbol of the crossed-out dustbin means that batteries and rechargeable batteries must not be disposed of with household waste.

• If the signs Hg, Cd or Pb are also located below the dustbin symbol, this stands for the following:

• Hg: Battery contains more than 0.0005% mercury

• Cd: Battery contains more than 0.002% cadmium
• Pb: Battery contains more than 0.004% lead

- Rechargeable batteries and batteries can be returned free of charge to the following places:

– Public disposal or collection points (e.g. municipal works yards)
– Sales points for batteries and rechargeable batteries
- Take-back points of the common take-back system for old device batteries
- Take-back point of the manufacturer (if not a member of the common take-back system)

• These statements are only valid for rechargeable batteries and batteries sold in the countries of the European Union and subject to the European Directive 2006/66/EC. Different provisions can apply to the disposal of rechargeable batteries and batteries in countries outside the European Union.

18 Troubleshooting

Fault Possible cause Remedy
Motor does not work Engine	cable or connector defective, mains fuses blown.	Arrange for inspection of the machine by a specialist. Never repair the motor yourself. Danger! Check mains fuses and replace as necessary
The engine runs slowly and does not reach the operating speed.	Voltage too low, coils damaged, capacitor burnt.	Have an electrician check the voltage. Arrange for inspection of the motor by a specialist. Arrange for replacement of the capacitor by a specialist.
Engine producing excessive noise.	Coils damaged, motor defective. Arrange for inspection of the motor by a specialist.
The engine does not reach full power.	Circuits in the network are overload-ed (lamps, other motors, etc.).	Do not use any other equipment or engines on the same circuit.
Motor overheats easily. Overloading of the motor, insufficient cooling of the motor.	Avoid overloading the motor while cutting, remove dust from the motor in order to ensure optimal cooling of the motor.
Saw cut is rough or wavy. Saw blade dull, tooth shape not appropriate for the material thickness.	Resharpen saw blade and/or use suitable saw blade.
Workpiece pulls away and/or splinters.	Excessive cutting pressure and/or saw blade not suitable for use.	Insert suitable saw blade.

19 EU Declaration of Conformity

Translation of the original Declaration of Conformity

Manufacturer:

Scheppach GmbH

Günzburger Straße 69

D-89335 Ichenhausen

We declare under our sole responsibility that the product described here complies with the applicable directives and standards.

Brand: Parkside

Art. designation: SLIDING COMPOUND

MITRE SAW - PZKS 2000 C3

Item No. 3901252974 - 3901252981;

39012529915 - 39012529959

IAN no. 471953_2407

Series no. 01001-93516

EU directives:

2014/30/EU, 2006/42/EC, 2011/65/EU*

* The object of the declaration described above fulfils the regulations of the directive 2011/65/EU of the European Parliament and Council from 8th June 2011, on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

Applied standards:

EN 62841-1:2015/A11:2022;

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Documentation authorised representative:

Jakob Wiest

Günzburger Str. 69

89335 Ichenhausen, Germany

Division Manager Product Center

Andreas Pecher

Head of Project Management

Warranty certificate

Dear Customer,

All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that your device develops a fault, please contact our service department at the address shown on this guarantee card. Of course, if you would prefer to call us then we are also happy to offer our assistance under the service number printed below. Please note the following terms under which guarantee claims can be made:

• These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights. We do not charge you for this guarantee.
• Our guarantee only covers problems caused by material or manufacturing defects, and it is restricted to the rectification of these defects or replacement of the device. Please note that our devices have not been designed for use in commercial, trade or industrial applications. Consequently, the guarantee is invalidated if the equipment is used in commercial, trade or industrial applications or for other equivalent activities. The following are also excluded from our guarantee: compensation for transport damage, damage caused by failure to comply with the installation/assembly instructions or damage caused by unprofessional installation, failure to comply with the operating instructions (e.g. connection to the wrong mains voltage or current type), misuse or inappropriate use (such as overloading of the device or use of non-approved tools or accessories), failure to comply with the maintenance and safety regulations, ingress of foreign bodies into the device (e.g. sand, stones or dust), effects of force or external influences (e.g. damage caused by the device being dropped) and normal wear resulting from proper operation of the device.

The guarantee is rendered null and void if any attempt is made to tamper with the device.

• The guarantee is valid for a period of 3 years starting from the purchase date of the device. Guarantee claims should be submitted before the end of the guarantee period within two weeks of the defect being noticed. No guarantee claims will be accepted after the end of the guarantee period. The original guarantee period remains applicable to the device even if repairs are carried out or parts are replaced. In such cases, the work performed or parts fitted will not result in an extension of the guarantee period, and no new guarantee will become active for the work performed or parts fitted. This also applies when an on-site service is used.
• In order to assert your guarantee claim, please contact the service partner shown below. If the complaint is within the guarantee period, we will provide you with a return slip, with which you can return your defective device free of charge to us. It would help us if you could describe the nature of the problem in as much detail as possible. If the defect is covered by our guarantee then your device will either be repaired immediately and returned to you, or we will send you a new device.

Of course, we are also happy offer a chargeable repair service for any defects which are not covered by the scope of this guarantee or for units which are no longer covered. To take advantage of this service, please send the device to our service address.

Processing of warranty claims

To ensure that your request is processed quickly, please follow the instructions below:

- Please have the receipt and article number (e.g. IAN 471953_2407) ready as proof of purchase for all enquiries.

- Please refer to the type plate on the product, an engraving on the product, the title page of your instructions (bottom left) or the sticker on the back or underside of the product for the article number.

- If functional faults or other defects occur, first contact the service department named below by telephone or e-mail.

- You can then send a product recorded as defective to the service address provided to you free of charge, enclosing the proof of purchase (receipt) and stating what the defect is and when it occurred.

- You can view and download these and many other manuals at parkside-diy.com. This QR code will take you directly to parkside-diy.com. Select your country and use the search mask to search for the operating instructions. Enter the article number (IAN) 471953_2407 to access the operating instructions for your article.

Service contact (GB): Service contact (IE):

Name: Forest Park & Garden

Coed Court,

Taffsmead Road

Treforest, Ind. Estate,

Pontypridd CF375SW

Tel: [phone] Tel: [phone]

E-Mail: [e-mail] E-Mail:

Location: Great Britain Location: Great Britain

Name: Forest Park & Garden

Coed Court,

Taffsmead Road

Treforest, Ind. Estate,

Pontypridd CF375SW

[e-mail]

PDF ONLINE parkside-diy.com

Service contact (NI): Service contact (CY): Service contact (IT):

Name: Forest Park & Garden

Coed Court,

Taffsmead Road

Treforest, Ind. Estate,

Pontypridd CF375SW

Name: GEORGE C

SOLOMONIDES &

SON LTD

PO.BOX 56236 / 169,

LEONTIOS A'

GR - 3022 LIMASSOL/

CYPRUS

Tel: [phone]

E-Mail: [e-mail]

Tel: [phone]

E-Mail: [e-mail]

Name: TeleMarCom European

Services GmbH

Am Ziegelweiher 24

DE - 61130 Nidderau

Tel: [phone]

E-Mail: [e-mail]

Location: Great Britain

Location: Cyprus

Location: Germany

Inhaltsverzeichnis

Günzburger Straße 69

D-89335 Ichenhausen

Verehrter Kunde

Günzburger Straße 69

D-89335 Ichenhausen

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Division Manager Product Center

Head of Project Management

Garantieurkunde

Günzburger Straße 69

D-89335 Ichenhausen

Cher client,

Günzburger Straße 69

D-89335 Ichenhausen

Division Manager Product Center

Andreas Pecher

Head of Project Management

Certificat de garantie

Chère Cliente, Cher Client,

QR code image containing encoded data, with a central logo or watermark

PDF ONLINE
parkside-diy.com

Günzburger Straße 69

D-89335 Ichenhausen

Geachte klant,

Günzburger Straße 69

D-89335 Ichenhausen

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Division Manager Product Center

Andreas Pecher

Head of Project Management

Garantiebewijs

Geachte klant,

Servicecontact (NL): Servicecontact (BE):

Naam: TeleMarCom European

Services GmbH

Am Ziegelweiher 24

DE - 61130 Nidderau

Naam: TeleMarCom European

Services GmbH

Am Ziegelweiher 24

DE - 61130 Nidderau

Telefoon: 00800 4003 4003 Telefoon: 00800 4003 4003

E-mail: [e-mail] E-mail: [e-mail]

Günzburger Straße 69

Günzburger Straße 69

D-89335 Ichenhausen

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Division Manager Product Center

Andreas Pecher

Head of Project Management

Günzburger Straße 69

89335 Ichenhausen, Germania

Egregio cliente,

Günzburger Straße 69

D-89335 Ichenhausen

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Division Manager Product Center

Andreas Pecher

Head of Project Management

Günzburger Straße 69

D-89335 Ichenhausen

Vážený zákazníku,

Günzburger Straße 69

D-89335 Ichenhausen

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Division Manager Product Center

Andreas Pecher

Head of Project Management

Záruční list

Važena zakaznice, važeny zakazniku,

Günzburger Straße 69

D-89335 Ichenhausen

Vážený zákazník,

Günzburger Straße 69

D-89335 Ichenhausen

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Division Manager Product Center

Andreas Pecher

Head of Project Management

Záručný list

Günzburger Straße 69

D-89335 Ichenhausen

Tisztelt Ügyfelünk!

Günzburger Straße 69

D-89335 Ichenhausen

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Division Manager Product Center

Andreas Pecher

Head of Project Management

JÓTÁLLÁSI TÁJÉKOZTATÓ

Günzburger Straße 69

D-89335 Ichenhausen

Szanowny Kliencie

Günzburger Straße 69

D-89335 Ichenhausen

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Division Manager Product Center

Head of Project Management

Gwarancja

Drodzy Klienci,

Günzburger Straße 69

D-89335 Ichenhausen, Tyskland

Kære kunde

Günzburger Straße 69

D-89335 Ichenhausen, Tyskland

EN IEC 62841-3-9:2020/A11:2020;

EN IEC 55014-1:2021; EN IEC 55014-2:2021;

EN IEC 61000-3-2:2019/A1:2021;

EN IEC 61000-3-11:2019

Dokumentationsansvarlig:

Jakob Wiest

Günzburger Str. 69

D-89335 Ichenhausen, Tyskland

Ichenhausen, Tyskland 16.10.2024

Simon Schunk

Division Manager Product Center

Andreas Pecher

Head of Project Management

Garantibevis

Kære kunde,

Technical schematic diagram of a mechanical assembly with numbered components and exploded views

Notizen

CE

SCHEPPACH GMBH

Günzburger Str. 69

D-89335 Ichenhausen

FR RECO

FSC

www.fsc.org

MIX

Paper from responsible sources

C160858 C160858 C160858 C ^39

FSC

www.fsc.org

MIXTE
