USER MANUAL PLSBA 40-Li A1 PARKSIDE

Black Parkside electric vehicle charging station with visible battery, control panel, and power supply (no text or symbols on main body)

PDF ONLINE parkside-diy.com

Dual Battery Charger

Translation of the original instructions

NL BE

Accu dubbele oplader

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

Service-Center....13

Importeur.... 13

Scope of delivery/accessories......15

Overview.... 15

Technical data....16

Safety Warnings.... 16

Meaning of the safety information...... 17

Pictograms and symbols.... 17

Symbols used in the instruction manual.... 18

Safe operation of battery chargers..... 18

Preparation.... 19

Information on the batteries....19

Checking the battery charge level..... 19

Inserting and removing the battery into/from the cordless device.... 19

Operation.... 20

Control display....20

Charging the battery.... 20

Used batteries....20

Cleaning, maintenance and storage..... 20

Cleaning....20

Maintenance.... 20

Storage....20

Wall mounting for charger (optional).....20

Disposal/environmental protection......21

Disposal instructions for rechargeable batteries.... 21

Service....21

Guarantee....21

Repair service.... 22

Service Centre.... 23

Importer....23

Spare parts and accessories.... 23

Translation of the original EU declaration of conformity.... 23

Introduction

Congratulations on purchasing your new charger (hereafter referred to as device or power tool).

You have chosen a high-quality device. This device was quality-tested and subjected to a final inspection during production, therefore ensuring proper functioning of your device.

The instruction manual forms part of this device. It contains important information on safety, use and disposal. Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Use the device only as described and for the stated fields of application. Store the instruction manual carefully and ensure that all documents are handed over in the event that the device is passed on to another user.

Proper use

This device is only intended for the following use:

- Charging batteries from the series X 20 V TEAM

Only operate in dry areas.

Any other use that is not expressly permitted in this instruction manual may pose a serious hazard to the user and result in damage to the device. The operator or user of the machine is responsible for any accidents or personal injury and/or material damage to third parties or their property. The machine is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use. The warranty is void in the case of commercial use. The manufacturer is not liable for damage caused by improper use or incorrect operation.

The device is part of the X 20 V TEAM series and can be operated with batteries of the X 20 V TEAM series. Batteries of the X 20 V TEAM series may only be charged using chargers of the X 20 V TEAM series.

Scope of delivery/accessories

Unpack the device and check that everything is present.

Dispose of the packaging material properly.

- Charger

• Translation of the original instructions

The rechargeable battery is not included in delivery.

Overview

The illustrations for the device can be found on the front fold-out page.

1 Battery release
2 Button (Charge level indicator)
3 Charge level indicator
4 Battery
5 Charger
6 Control display
7 Charging slot

Technical data

Dual Battery Charger ...... PDSLG 20 B1

Rated voltage U .... 230–240 V\~, 50 Hz

Rated input power P 220 W

Protection class ...... □ II (double insulation)

Device fuse ....T3.15A

Output 1:

Output voltage 21.5 V =

Output current 4.5 A

Output 2:

Output voltage 21.5 V =

Output current 4.5 A

Charging time

We recommend that you only use this charger to charge the following rechargeable batteries: PAP 20 B1, PAP 20 B3, Smart PAPS 204 A1, Smart PAPS 208 A1, Smart PAPS 2012 A1

The charging time is influenced by factors such as the temperature of the environment and the battery, as well as the mains voltage applied, and may therefore deviate from the specified values.

Charging time (min.) PDSLG 20 B1

PAP 20 A1 PAP 20 B1 35

PAP 20 A2 45

PAP 20 A3 PAP 20 B3

Smart PAPS 204 A1

Smart PAPS 208 A1 120

Smart PAPS 2012 A1 210

Safety Warnings

ATTENTION! When using power tools, observe the following basic safety measures to protect against electric shock, risk of injury and fire.

This device can be used by children aged 8 years and up as well as individuals with reduced physical, sensory or mental abilities or a lack of experience and knowledge if they are supervised or have been instructed in the safe use of the device and understand the resulting hazards. Children must never play with the device. Cleaning and user maintenance must not be carried out by children if they are not supervised.

▲ WARNING! Injury and property damage due to improper handling of battery. Observe the safety information and notes on charging and proper use as shown in the instruction manual for your battery and charger from the series

X 20 V TEAM. A detailed description of the charging process and further information can be found in these separate operating instructions.

Meaning of the safety information

▲ DANGER! If you do not observe this safety instruction, an accident will occur. The result of which is severe bodily injury or death.

⚠ WARNING! If you do not observe this safety instruction, an accident may occur. The result of which is likely severe bodily injury or death.

CAUTION! If you do not observe this safety instruction, an accident will occur. The result of which is likely minor or moderate bodily injury.

NOTICE! If you do not observe this safety instruction, an accident will occur. The result of which is possible damage to property.

Pictograms and symbols Symbols on the charger

The device is part of the X 20 V TEAM series and can be operated with batteries of the X 20 V TEAM series. Batteries of the X 20 V TEAM series may only be charged using chargers of the X 20 V TEAM series.

Attention!

Read the instruction manual before charging. Familiarise yourself with the controls and how to use the device correctly.

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

The charger is only suitable for use in-doors.

Device fuse

Protection class II (double insulation)

Control LEDs on the charger

Charging time (min.)

Symbols used in the instruction manual

Attention!

Safe operation of battery chargers

- This product can be used by children aged 8 years and up as well as individuals with reduced physical, sensory or mental abilities or a lack of experience and knowledge if they are supervised or have been instructed in the safe use of the device and understand the resulting hazards.

Children must never play with the device.

Cleaning and user maintenance must not be carried out by children if they are not supervised.

- Use this charger only for charging batteries of the series X 20 V TEAM. Charging other batteries may cause injury and risk of fire and explosion.

- Before each use, check the charger, cable and plug, and have repairs carried out by qualified personnel using only original spare parts. Do not use the charger if defective and do not open it yourself. This ensures the safety of the device is not adversely affected.

- Ensure that the mains voltage and mains frequency match the specifications on the rating plate.

- Keep the charger clean and away from moisture and rain. Never use the charger outdoors. Soiling and penetration of water increases the risk of electric shock.

- Avoid mechanical damage to the charger. This can lead to internal short circuits.

• The charger must not be operated on or near flammable surfaces (e.g. paper, textiles). Risk of fire due to heating caused by charging.
• If the power cord of this device is damaged, it must be replaced by the manufacturer or their representative to avoid safety hazards. contact the service centre.
• Remove the mains plug when the battery is fully charged and disconnect the battery from the charger.
• Do not attempt to charge non-rechargeable batteries in the charger.
• Only charge your bat- teries indoors since the charger is not designed for outdoor use. Danger of electric shock.
• In order to minimise the risk of electric shock, pull the charger plug out of the outlet prior to cleaning it.
• If warm, allow the battery to cool before charging.

- Only use accessories recommended by PARKSIDE. Unsuitable accessories may cause electric shock or fire.

Preparation

Information on the batteries

• Switch off the device and remove the battery from the device before carrying out any work.
• The rechargeable battery only reaches its full capacity once it has been charged several times.
• Charge the battery before using it for the first time.

Checking the battery charge level

LEDs Meaning

red, orange, green Battery charged red, orange Battery partially charged

red Battery needs to be charged

1. Press the button (2) next to the charge level indicator button (3) on the battery (4).
   The LEDs of the charge level indicator show how much charge remains in the battery.
2. Charge the battery (4) when only the red LED on the charge level indicator (3) is illuminated.

Inserting and removing the battery into/from the cordless device

⚠ WARNING! Risk of injury due to unintentional start-up. Do not insert the plug into the outlet until the device is fully prepared for use. Only insert the battery into the device once the device is fully prepared for use. NOTICE! Risk of damage! An incorrect battery can damage the device and battery.

Inserting the battery

1. Push the battery (4) along the guide into the battery holder.
   You will hear the battery click into place.

Removing the battery

1. Press and hold the battery release (1) on the battery (4).
2. Pull the battery out of the battery holder.

Operation

Control display

Notes

• The direction in which to read the control display (6) is from bottom to top.
• If the charger (5) is connected to the power outlet and no battery (4) is inserted, all LEDs will light up permanently.

Meaning of the control displays on the charger (☐ lights up; ☐ flashes):

Meaning

ltery needs to be charged

Battery 1/3 charged

Battery 2/3 charged

Battery is fully charged

Charging the battery

NOTICE! Risk of injury from electric shock. Only charge the battery in dry areas. The external surface of the battery must be clean and dry before being connected to the charger.

Notes

- If warm, allow the battery to cool before charging.

Procedure

1. If necessary, remove the battery (4) from the cordless device.
2. Slide the battery (4) into the charging slot (7) of the charger (5).
3. Plug the charger (5) into an power outlet.
4. Once charging is complete, disconnect the charger (5) from the mains supply.
5. Pull the battery (4) charging slot out (7).

Used batteries

- If the operating time is considerably shortened despite charging, this shows that the rechargeable battery is depleted and must be replaced. Only use an original replacement battery of the series X 20 V TEAM, which can be purchased

from the online shop (see Spare parts and accessories, p. 23).

- Always observe the safety information in addition to the regulations and information about environmental protection (see Disposal/environmental protection, p. 21).

Cleaning, maintenance and storage

⚠ WARNING! Electric shock! Protect yourself when performing maintenance or cleaning work. Pull the mains plug and remove the battery.

You should have any repair and maintenance work that is not described in these instructions carried out by our Service Centre. Only use original replacement parts.

Cleaning

Clean the charger with a dry cloth or with a paintbrush. Do not use water or metal objects.

Maintenance

The device is maintenance free.

Storage

How to store the product:

• clean,
• dry,
• protected against dust,
  • out of the reach of children.

The storage temperature for the rechargeable battery and tool is between 0 – 45 °C. Avoid extreme cold or heat during storage, so that the battery does not lose performance.

Remove the battery before storing the device for a long period of time (e.g. winter storage).

Wall mounting for charger (optional)

You can also fix the charger (5) to the wall.

Notes

• When drilling, be careful not to damage any supply lines. Use suitable search devices to find these or consult an installation plan for guidance.

• Contact with electrical cables can lead to electric shock and fire. Contact with a gas line can result in an explosion.

• Damage to a water pipe can lead to property damage and electric shock.

• Screws and dowels are not included in delivery.
• Suitable diameter of screw head: 7-10 mm

Procedure

1. Using dowels, place two screws at the desired position on a wall. Distance between the screws: 152.4 mm (6")
2. Leave the screw heads protruding from the wall. Distance to the wall: ≈10 mm
3. Place the charger with the openings of the wall bracket over the two screws and pull it down as far as it will go.

Disposal/environmental protection

Remove the battery from the device and recycle the device, battery, accessories and packaging in an environmentally-friendly manner.

The device, accessories and packaging should be properly recycled.

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

The symbol of the crossed-out wheeled bin means that this product must not be disposed of as unsorted municipal waste at the end of its useful life.

Directive 2012/19/EU on waste electrical and electronic equipment:

Consumers are legally obliged to recycle electrical and electronic equipment in an environmentally sound manner at the end of its life. In this way, environmentally friendly and resource-saving recycling is ensured. Depending on the implementation in national law, you may have the following options:

• Return to a shop,
• Hand over to an official collection point,
• Return to the manufacturer/distributor.

This does not affect accessories enclosed with the old devices or tools without any electrical components.

Disposal instructions for rechargeable batteries

Do not throw batteries into domestic waste, fire (risk of explosion) or water. Damaged batteries can harm the environment and your health if poisonous fumes or liquids escape.

Dispose of the batteries according to local standards. Defective or used batteries must be recycled. Hand in the batteries at a used battery collection point where they are recycled in an environmentally friendly manner. For more information, please contact your local waste management provider or our service centre. Dispose of batteries in a discharged state. We recommend covering the contacts with an adhesive strip to protect against short circuits. Do not open the battery.

Service

Guarantee

Dear Customer,

This product is provided with a 3 year guarantee from the date of purchase. In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.

Terms of Guarantee

The guarantee period begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase. If a material or manufacturing defect occurs within three years of the date of purchase of this product, we will repair or replace – at our choice – the product for you free of charge. This guarantee requires the defective product and proof of purchase to be presented within the three-year period with a brief written description of what constitutes the defect and when it occurred.

If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of pur-

chase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The product has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery.

The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts or to cover damage to breakable parts.

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.

The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improper handling, use of force, or interventions not undertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure efficient handling of your query, please follow the directions below:

• Please have the receipt and product number (IAN 479366_2410) ready as proof of purchase for all enquiries.
• Please refer for the product number to the type plate on the product, an engraving on the product, the title page of the operating instructions (bottom left) or the sticker on the back or underside of the product.
• Should functional errors or other defects occur, please initially contact the service centre specified below by telephone or use the contact form available on parkside-diy.com in the category Service.
• After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the

consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the appliance inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

PDF ONLINE parkside-diy.com

You can view and download these and many other manuals on parkside-diy.com. This QR code will take you directly to parkside-diy.com. Select your country and search for the operating instructions via the search mask. You can open your operating instructions by entering the article number (IAN) 479366_2410.

Repair service

For repairs that are not covered by warranty, contact the service centre. They will gladly create a cost estimate for you.

- We can only work on devices which are sent in properly packed and with postage paid.

Note: Please send your device cleaned and with an indication of the defect to the address named for the service centre.

- The following are not accepted: devices sent in without prepaid postage, sent as bulky goods, sent as an Express shipment, or devices sent as any other form of special freight.

- We will dispose of defective devices you ship to us free of charge.

Service Centre

Service Great Britain

Tel.: [phone]

Contact form on

parkside-diy.com

IAN 479366_2410

Service Malta

Tel.: [phone]

Contact form on

parkside-diy.com

IAN 479366_2410

Importer

Please note that the address below is not a service address. Contact the service centre named above first.

Spare parts and accessories

You can get spare parts and accessories from www.grizzlytools.shop. If you have any problems with your order, contact us via our online shop. If you have any other questions, contact: Service Centre, p. 23

Pos.

Name Order No.

nr.

5 Charger

PDSLG 20 B1; 4,5 A; EU 80002908

PDSLG 20 B1; 4,5 A; UK 80002909

Translation of the original EU declaration of conformity

Product: Dual Battery Charger

Model: PDSLG 20 B1

Serial number: 000001 - 120000

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

2014/35/EU • 2014/30/EU • 2011/65/EU & (EU) 2015/863

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

To ensure conformity, the following harmonised standards and national standards and regulations have been applied:

EN 60335-1:2012/A15:2021 • EN 60335-2-29:2021/A1:2021

EN IEC 63000:2018 • EN 62233:2008

EN IEC 55014-1:2021 • EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A1:2021 • EN 61000-3-3:2013/A2:2021

This declaration of conformity is issued under the sole responsibility of the manufacturer:

Authorised representative of documentation

Sommaire

Introduction...... 24

Garantie (France)....32

Service-Center....34

Importateur.... 35

Consignes relatives aux conditions de stockage :

Opmerkingen over accu's....41

Laadstatus van de accu controleren.....42

Apparaatbeveiliging ....T3.15A

Output 1:

Opmerkingen over accu's

Service-Center....55

Importador.... 55

Service-Center....65

Importatore.... 65

Ricambi e accessori.... 65

Service-Center....75

Dovozce....75

QR code image with a central logo, likely linking to a digital resource or website.

PDF ONLINE parkside-diy.com

Service-Center....85

Importér....85

Reparationsservice.... 114

Service-Center....114

Importør.... 115

QR code image containing encoded data, with a central logo or watermark

PDF ONLINE parkside-diy.com

FSC® www.fsc.org MIX Paper from responsible sources FSC® C142944

FSC www.fsc.org MIXTE Papier issu de sources responsables FSC® C142944
