USER MANUAL SAV 190 C2 SILVERCREST

SILVERCREST® 11 power control -6 13 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100

PDF ONLINE www.lidl-service.com

DOCUMENT SHREDDER / AUFSATZ-AKTENVER-NICHTER / DESTRUCTEUR DE DOCUMENTS PORTATIF SAV 190 C2

GB IE

DOCUMENT SHREDDER

Operating instructions

FR BE

DESTRUCTEUR DE DOCUMENTS PORTATIF

Mode d'emploi

CZ

SKARTOVAČKA

Návod k obsluze

SK

SKARTOVAČKA

Návod na obsluhu

DK

MAKULATOR TIL PAPIRKURV

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

DE AT CH

GB/IE Operating instructions Page 1

Warnings and symbols used 2

Package contents 3

Description of the appliance .... 3

Technical data 3

Safety instructions....3

Setting up 5

Operation 5

Using auto mode 5

Clearing a material blockage 5

Switching the appliance off 6

Note regarding overheating of the appliance 6

Cleaning 6

Faults 6

Disposal....7

Disposal of the appliance 7

Disposal of the packaging 7

KompernassHandelsGmbHwarranty....7

Service 8

Importer 8

Introduction

Congratulations on the purchase of your new appliance. You have selected a high-quality product.

The operating instructions are part of this product. They contain important information on safety, usage and disposal. Before using the product, familiarise yourself with all operating and safety

instructions. Use the product only as described and for the specified areas of application. Please also pass on these operating instructions to any future owner.

Intended use

This shredder is intended exclusively for the shredding of paper in private households. Any other uses of the appliance are considered improper and carry the risk of serious personal injury. Not for commercial use.

Warnings and symbols used

The following warnings and symbols are used in these operating instructions, on the packaging and on the device (where applicable):

	DANGER! A warning with this symbol and the signal word "DANGER", indicates an imminently hazardous situation which will result in death or serious injury if not avoided.
	WARNING! A warning with this symbol and the signal word "WARNING", indicates a potentially hazardous situation which could result in death or serious injury if not avoided.

	CAUTION! A warning with this symbol and the signal word "CAUTION", indicates a potentially hazardous situation which could result in a minor or moderate injury if not avoided.
	ATTENTION! A warning with this symbol and the signal word "ATTENTION", indicates a potential situation which could result in property damage if not avoided.
	Note: A note provides additional information which makes handling the device easier for you.
	Important note
	Instruction manual/operating instructions
~	Alternating current (AC)/alternating voltage

Package contents

• Document Shredder
• Operating instructions

Description of the appliance

① Switch
② Cutter opening
③ Power LED
4 Overheat LED
⑤ Power cable
6 Telescopic arm

Technical data

Mains voltage 220	-240 V~,50 Hz
Nominal current 0.7	A
Rated power	190 W
Protection class	II / ☐(double insulation)
Cutting process for paper	Strip cut, safety level 2
Working width 220 mm
Cutting capacity 6 Sheets (80 g/m ^2 )
Shredding container size(container not supplied):
Length	min. 290 mm,max. 430 mm
Width min. 115 mm

Overheating protection

This appliance is fitted with overheating protection. If the motor overheats due to overloading, the overheat LED ④ lights up and the appliance stops. In this case, disconnect the power cable and wait until the appliance has cooled down to room temperature. You can then reconnect the plug to a mains power socket and take the appliance back into use.

i Note

We recommend that you let the appliance cool down for about 30 minutes after 2 minutes of operation.

When the overheating protection is triggered, a small amount of smoke and a slight odour may occur due to production residue. This is normal and completely harmless. Ensure sufficient ventilation; for example, by opening a window.

Safety instructions

The following safety instructions must always be adhered to when using electrical appliances:

DANGER!

ELECTRIC SHOCK!

■ Do not place the appliance in the direct vicinity of any sources of heat or water. There is a risk of fire or of receiving an electrical shock!
■ To prevent accidents, have defective plugs and/or power cables replaced immediately by an authorised specialist technician or our Customer Service department.
■ Appliances that do not work properly or have been damaged must be checked immediately and repaired by our customer service.
■ Do not expose the appliance to rain, and never use it in a humid or wet environment.

■ Ensure that the power cable never becomes wet or moist during use.

⚠ WARNING! RISK OF INJURY!

Moving parts

Keep body parts away from moving parts.

There is risk of crushing injuries!

■ This appliance is not suitable for use by children.
- Keep your hands, clothes and hair away from the insertion opening.
■ Disconnect the mains power plug if you do not intend to use the device for an extended period of time.
■ Only one person should operate the shredder at any time.
■ Never leave the appliance unattended during operation.
■ Keep loose clothing, long hair, jewellery, etc. at a safe distance from the cutter opening.
■NEVER insert your fingers into the cutter opening.
- Keep children away from the appliance. They could hurt themselves.

- Keep pets away from the appliance. They could hurt themselves.

■ This appliance is not intended for use by persons (including children) with limited physical, sensory or mental capabilities or lack of experience and/or knowledge unless they are supervised by a person who is responsible for their safety, or receive instructions from this person on how to use the appliance.

■ The packaging material can be a source of danger for children. Dispose of the material immediately after unpacking or keep it in a safe place not accessible to children.

■ Route the power cable in such a way that no one can tread on or trip over it.

■ Do not use the appliance close to inflammable or explosive materials and/or ignitable gases or in dusty environments. Risk of explosion!

■ Always position the appliance close to a power socket. Do not use an extension cable. Ensure that the appliance and the power socket are easily and quickly accessible in the event of an emergency.

! ATTENTION! Property damage!

■ Do not use the appliance outdoors. The appliance could be irreparably damaged!

■ Do not overload the appliance. The paper shredder is designed for brief operating periods.

■ Never use the paper shredder for purposes for which it is not designed or intended.

NOTES ON SAFE USE

■ In case of danger, remove the plug from the socket immediately.

■ Remain alert at all times! Always pay attention to what you are doing and act with common sense. Never use the appliance when you are distracted or don't feel well.

Setting up

i Note

▶ As every shredder is tested for functionality after manufacture, it is possible that you may find paper residue in the cutting blades.

◆ Remove all packaging materials from the appliance.

Place the shredder on a suitable container: place the broad end of the appliance on the edge of the container. Then pull out the telescopic arm ⑥ until it sits securely on the other edge.

◆ Insert the plug into a mains power socket.

Operation

i Note

You can shred up to 6 sheets (80 g/m ^2 paper) at the same time.

! ATTENTON!

move all paper clips or staples serting the paper into the cutter ②. The cutting blades might otherwise ged.

Using auto mode

Set the switch ① to the AUTO for shredding. The power LED ③ lights up green. The motor starts automatically as soon you insert paper and switches off automatically once no further paper is inserted.

i Note

▶ Always insert smaller pieces of paper into the middle of the cutter opening ②. This is where the contact that starts the cutting process is located.

▶ If the appliance overheats, the overheat LED lights up as soon as the paper touches the contact which starts the cutting process. The appliance will not start cutting. Proceed as described in the section Note regarding overheating of the appliance.

Clearing a material blockage

Move the switch ① to the REV ("reverse") position if the paper being shredded causes a blockage. The appliance now goes into reverse and the paper that is being shredded is ejected.

- Pull the paper out of the appliance, then set the switch ① to AUTO. - The appliance is now ready for use.

i Note

▶ Reverse mode is solely for clearing paper jams. Do not use it for removing documents that are already half shredded and are not causing a jam.

Switching the appliance off

To switch the device off, push the switch 1 to the OFF position.

If you do not intend to use the appliance for an extended period, remove the plug from the power socket.

Note regarding overheating of the appliance

If the appliance overheats due to overloading, the overheat LED ④ lights up as soon as a paper sheet touches the contact which starts the cutting process. The appliance stops.

WARNING!

▶ Remove the power plug from the wall socket to avoid unintended restarting of the appliance.

Place the switch ① in the OFF position.

◆ Empty the container.

Allow the appliance to cool until it has cooled to room temperature.

Put the mains plug back into the socket.

Switch the appliance on by moving the switch ① into the AUTO position.

Cleaning

DANGER!

▶ Always pull out the plug before cleaning the appliance. There is a risk of electric shock!

WARNING!

▶ The cutters in the appliance are very sharp! Risk of injury!

ATTENTON!

Do not spray any oil or other lubricants into the cutter opening ②. These can irreparably damage the appliance.

Remove any residue left in the cutting opening ② or cutting blades with a suitable tool, e.g. a pair of tweezers. Ensure that the appliance is unplugged before doing this!

- Clean the appliance with a moist cloth. For stubborn dirt, add a little mild detergent to the cloth.

Faults

If the paper jams:

This means that you have attempted to feed too much paper into the appliance (max. 6 sheets 80 g/m ^2 paper).

Move the switch ① into the REV position if the paper causes a blockage. The appliance now goes into reverse and the material that is being shredded is ejected.

◆ Pull the paper out of the appliance and then set the switch ① to AUTO.

◆ The appliance is now ready for use.

If the appliance suddenly stops working:

This means that the appliance is overheated and the automatic safety cut-out has activated itself. The overheat LED ④ lights up red.

WARNING!

▶ Remove the power plug from the wall socket to avoid unintended restarting of the appliance.

◆ Place the switch ① in the OFF position.

◆ Empty the container.

Allow the appliance to cool until it has cooled to room temperature.

Put the mains plug back into the socket.

Switch the appliance on by moving the switch ① into the AUTO position.

If the appliance cannot be switched on:

◆ Check that the plug is correctly connected to a wall socket.

◆ Try a different wall socket.

The appliance is possibly defective. Have the appliance checked by qualified specialists.

Check whether the overheat LED 4 has come on. If it has come on, the overheating protection has been triggered. Proceed as described in the section Note regarding overheating of the appliance.

Disposal

Applies only to France:

The product, its packaging and the operating instructions are recyclable. They

are subject to an extended manufacturer responsibility and will be collected separately.

Disposal of the appliance

The adjacent symbol of a crossed-out dustbin means that this appliance is subject to Directive 2012/19/EU. This directive states that this appliance may not be disposed of in the normal household waste at the end of its useful life, but must be taken to specially set-up collection locations, recycling depots or disposal companies.

The disposal is free of charge for the user. Protect the environment and dispose of this appliance properly.

If your old appliance has stored any personal data, you are responsible for deleting it yourself before returning it.

Your local community or municipal authorities can provide information on how to dispose of the worn-out product.

Disposal of the packaging

The packaging materials have been selected for their environmental friendliness and ease of disposal and are therefore recyclable. Dispose of packaging materials that are no longer needed in accordance with applicable local regulations.

Dispose of the packaging in an environmentally friendly manner. Note the labelling on the packaging and separate the packaging material components for disposal, if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings: 1-7: plastics, 20-22: paper and cardboard, 80-98: composites.

KompernassHandels GmbHwarranty

Dear Customer,

This appliance has a 3-year warranty valid from the date of purchase. If this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not restricted in any way by the warranty described below.

Warranty conditions

The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase.

If any material or manufacturing fault occurs within three years of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred.

If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.

Warranty period and statutory claims for defects

The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.

Scope of the warranty

This appliance has been manufactured in accordance with strict quality guidelines and inspected meticulously prior to delivery.

The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches or parts made of glass.

The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product are to be strictly followed. Uses and actions that are discouraged in the operating instructions or which are warned against must be avoided.

This product is intended solely for private use and not for commercial purposes. The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres.

Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

■ Please have the till receipt and the item number (IAN) 466463_2404 available as proof of purchase.

■ You will find the item number on the type plate on the product, an engraving on the product, on the front page of the operating instructions (below left) or on the sticker on the rear or bottom of the product.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

■ You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

You can download these instructions along with many other manuals, product videos and installation software at www.lidl-service.com.

This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the item number (IAN) 466463_2404.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Servicelreland

Tel.: [phone]

E-Mail: [e-mail]

IAN 466463_2404

Importer

Please note that the following address is not the service address. Please use the service address provided in the operating instructions.

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com
