PLANCHA DE VAPOR

STEAM IRON

FER À VAPEUR

FERRO A VAPOR

DAMPFBÜGELEISEN

FERRO A VAPORE

PARNÍ ŽELEZO

DAMP-JERN

PARNA ŽELEZNICA

PEGLA NA PARU

ŻELAZO PAROWE

FIER CU ABURI

ПАРОВЕ ЗАЛІЗО

PLANXA DE VAPOR

ref. SS-6355

CE RoHS 2016/868/EU

ESPAÑOL P. 3

ENGLISH P.11

FRANÇAIS P. 19

PORTUGUESE P. 27

DEUTSCH P. 35

ITALIANO P. 43

ČEŠTINA P. 51

DANSK P. 58

SLOVENSKI P. 65

HRVATSKI P. 72

POLSKI P. 79

ROMÂNĂ P. 87

УКРАЇНСЬКА P. 95

CATALÀ P. 103

Declaration of conformity, Responsibility of Electronic products disposal, Importers Details and After-sales service on the last pages.

Labeled diagram of an iron iron with numbered parts for identification

6. INSTRUCCIONES DE USO

• Always read the instruction book carefully before using.
- This manual can be downloaded from our web page www.sogo.es
- Keep these instructions for future reference.

2. PRODUCT INTRODUCTION

Features and Purpose:

Thank you for choosing our Steam Iron.

The device is a kind of strong steam ironing appliance. It is elegant in design, simple, economical and safe, especially applicable for household, garment, wedding dress etc. These appliances irons well all kind of fabrics especially, woollens, chemical fibre, cotton and blending textiles etc. The steam irons flatten these fabrics quickly and without damaging them. Not only, this but also sterilizes and cleans them, without any need of special maintenance and repair.

Thermostat

The thermostat would keep the temperature at a rated value by means of the control current.

The constant temperature principle of this iron is to ensure that the clothes can be properly ironed during the ironing process by maintaining the temperature stability of the bottom plate of the iron, so as to achieve best ironing effect.

Hot fuse

In case the thermostat damages or fails, the hot fuse of protective device gives protection by cutting off the power supply of machine body when the machine reaches a certain temperature.

3. ⚠️ SAFETY INSTRUCTIONS FOR THE USER

GENERAL

PRECAUTIONS

General precautions during the use of electrical equipment

• Do not use the appliance for any other purpose than described in this manual.
• Do not use or store the appliance outdoors.
  • Always place the appliance on to the flat and even surface.
• This product is intended for indoor, non-industrial, non-commercial and only for household use. Do not use the item

outdoors or for any other purpose. Misuse or improper handling may cause problems in the appliance and cause injury to the user. No liability is accepted for damages arising from improper use or wrong handling.

- Ensure that the voltage indicated on the nameplate matches the mains voltage before plugging in the appliance.

• Always remove the plug from the power socket when the appliance is not in use. Do not leave the appliance unattended when switched on.

- Close supervision is necessary when any appliance is being used by or near children.

- Before cleaning or storing your appliance, always unplug the appliance from the power supply and let it cool down.

- The device is not completely disconnected from the power source, even after it has been turned off. To disconnect it completely, disconnect it from the mains plug.

- The appliances are not intended to be operated by means of an external timer or separate remote-control system.

Restrictions on use to avoid personal injury

- Do not let the appliance operate unattended.

- Do not place or operate this appliance near water sources.

- Do not place or operate the appliance and its power cord on or near hot surfaces (e.g., stove plates) or open flames.

- Do not leave the power cord hanging from sharp edges and keep away from hot objects and flames. Do not wind the cord around the appliance and do not bend it.

- Never use accessories that are not recommended by the manufacturer.

- The use of accessories not recommended or sold by the appliance manufacturer may result in fire, electric shock or injury to persons.

- When you want to remove the plug from the wall contact, please do this at the plug itself and not by pulling on the cable or the appliance itself.

- To avoid electric shock, make sure your hands are dry before plugging or unplugging.

- Do not use the device with wet hands, on damp floors or when the atmosphere is humid, there is a risk of electric shock.

- While using the appliance, make sure that the power cord must not be caught or crushed.

- Do not let the motor unit, cord or plug get wet to protect against risk of electric shock.

- Be careful, while handling electrical appliances, as the surface of the heating element is subject to residual heat after use. Any misuse may cause potential injury to the user and may damage the appliance.

- Do not touch the outer surface of the appliance as it can get very hot during operation.

- Never immerse the appliance or the plug-in water or any other liquid. In the event of the appliance falling in water, disconnect immediately from the mains supply and take it to an authorized service agent for repair before reusing.

- Do not use the appliance if it has fallen on the floor, if there are visible signs of damage or if it has a leak.

- Do not use the appliance if the cable or plug is damaged. In case of the cord be damaged, it must be replaced only by the manufacturer, its service agent or similarly qualified persons in order to avoid Hazard.

- In case of appliance malfunction, or if it has been damaged in any manner, return the appliance to the nearest authorized service facility for examination, repair or adjustment.

Restrictions on use when used with children and elders

- The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.

- Children should be supervised to ensure that they do not play with the appliance.

- Cleaning and user maintenance shall not be made by children without supervision.

• Children shall not play with the appliance.

- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand.

- Keep the appliance and its cord out of reach of children less than 8 years.

Instructions to follow while using the device

- Make sure the working voltage of the machine accords with your

domestic supply voltage and the machine is connected to power supply mounted with 30mA creepage protection switch. Only the firmly grounded 3-pole socket is applicable for the machine.

• The iron should always be turned to “min”, before plugging or unplugging from outlet. Never yank cord to disconnect from outlet; instead, grasp plug and pull to disconnect.
• Do not allow cord to touch hot surfaces. Let iron cool completely before putting away. Loop cord loosely around iron when storing.
  • Always disconnect iron from electrical outlet when filling with water or emptying and when not in use.
• Close supervision is necessary for any appliance being used by or near children. Do not leave iron unattended while connected or on an ironing board.
• Burns can occur from touching hot metal parts, hot water, or steam. Use caution when you turn a steam iron upside down – there may be hot water in the reservoir.
• If the malfunction indicator goes on, the flat iron is not operating normally. Disconnect from the power supply and have the flatiron serviced by qualified service personnel.
• The iron must be used and rested on a stable surface.
• The plug must be removed from the socked-outlet before the water reservoir is filled with water.
• When placing the iron on its stand, ensure that the surface on which the stand is placed is stable.
• To avoid a circuit overload when using this product, do not operate another high-wattage product on the same electrical circuit.
• An extension cord is not recommended for use with this product, but if one must be used:
• The marked electrical rating of the cord must be at least as great as that of the product.
• Arrange the extension cord so that it does not hang where it can be tripped over or pulled unintentionally.

More specifically

- DO NOT let children or untrained persons use the appliance without supervision.

- DO NOT leave the hot iron touching fabrics or very inflammable surfaces.

- DO NOT leave the appliance unnecessarily plugged in. Disconnect the plug from the mains when the appliance is not being used.

- DO NOT leave the appliance exposed to the weather (rain, sun, etc.).

• DO NOT leave the iron without supervision when it is connected to the power supply.
• DO NOT fill the reservoir with water before removing the plug from the socket.
• PLEASE NOTE! Do not use chemical additive, scented substances or Failure to comply with the above-mentioned regulations leads to the loss of guarantee.

WARNING! - This symbol means:

HOT SURFACE: Do not touch this part when it is hot. Allow it to cool down before servicing.

Do not put perfume, vinegar, starch, descaling agents, ironing aids or other chemicals in the water tank.

4. TECHNICAL SPECIFICATIONS

Voltage Frequency Power
AC 230V 50-60Hz 2600W

5. PARTS DESCRIPTION

1. Sole plate
2. Skirt cover
3. Handle cover
4. Water inlet cover
5. Water tank
6. LED indicator
7. Steam button
8. Guard sleeve
9. Rear cover decorative part
10. Real cover

Labeled diagram of an iron iron with numbered parts for identification

6. INSTRUCTIONS FOR USE

When using the iron for the first time, you may notice a slight emission of smoke and hear some sounds made by the expanding plastics. This is quite normal and it stops after a short time. We also recommend passing the iron over an ordinary cloth before using it for the first time. Suggestions before using the iron for the first time.

1. Certain parts of the iron have been lightly greased therefore the iron could give off a little smoke when plugged in for the first time. This will cease after a short while.
2. Before using the iron for the first time, remove the plastic protector from the base (if it has one) clean the base with a soft cloth.
3. Keep the base very smooth. Do not run it over metal objects (such as against the ironing board, buttons, zips, etc.)
4. Pure wool fibres (100% wool) can be ironed with the appliance in the steam position by preference, select a high steam position and use a dry ironing cloth.

How to fill the water tank

1. Unplug the iron.
2. Fill the tank through the filling hole.
3. Use tap water. If you have hard water, it is advisable to use only distilled or demineralized water.
4. Do not use chemically de-limed water or perfumed
5. Do not store the iron with water in the tank.

Steam ironing

1. Fill the iron as described in the section "how to fill the water tank".
2. Plug the iron into the mains.
3. Steam ironing is only possible with the higher temperatures, otherwise, water may escape through the soleplate. This steam iron doesn't have temperature control knob, but still, it always maintains in keeping higher temperatures.
4. Wait until the pilot light goes out, which indicates that iron has reached to its highest temperature.
5. Turn the steam button to the required position.
6. When ironing is finished and during breaks in ironing, place the iron in its upright position.
7. Disconnect the iron from the mains supply. Pour of any remaining water and leave the iron to cool off.

FUNCTIONS

This steam iron doesn't have thermostat knob, but it means that these irons, Irons the cloth with same and constant temperature. These irons regulates and maintains the temperature according to the fabric and this functionality is called Constant temp technology.

CONSTANT TEMP TECHNOLOGY

Irons without a thermostat knob are equipped with advanced technology that automatically adjusts the temperature to keep the constant temperature while ironing. This type of technology suit various fabric types. This eliminates the need for manual temperature setting, providing a more seamless and user-friendly ironing experience.

1. Temperature control circuit: The temperature control circuit is the core part of the electric iron, which can automatically adjust according to the temperature signal captured by the temperature sensor.
2. Temperature sensor Temperature sensor is used to detect the temperature of the base plate equipment, mainly thermocouple and thermistor two types. A thermocouple uses the thermoelectric effect of two different metal wires to measure temperature, and a thermistor uses the effect of temperature on the resistance value of a material to measure temperature. In electric irons, the temperature sensor is usually fixed to the inside of the bottom plate to ensure the accurate detection of temperature

The key technologies typically used in these irons include:

1. Smart Temperature Control: The iron is embedded with temperature sensors that continuously monitor the heat level and adjust it accordingly, ensuring optimal and constant temperature for effective ironing without the risk of burning or damaging the fabric. When the base temperature is lower then pre-set temperature, temperature control circuit start heating elements and when base temperature is higher than pre-set temperature, temperature control circuit stop heating elements, this helps to keep the temperature of the bottom plate fluctuating at the set constant temperature.
2. CONSTANT TEMP Technology: A patented technology often found in high-end irons, CONSTANT TEMP maintains a consistent and safe temperature that is suitable for all ironable fabrics, from delicate like silk to tough fabrics like denim.
3. Steam Control: These irons often feature advanced steam generation and distribution systems that work in harmony with the temperature sensors, delivering the right amount of steam based on the fabric being ironed.
4. Rapid Heating Elements: These irons are equipped with rapid heating elements that ensure the iron reaches the optimal temperature quickly, reducing waiting times and improving efficiency.

Overall, in these irons without a thermostat knob, user doesn't need to select the temperature according to the fabric. These irons offer a hassle-free ironing experience, combining multiple smart technologies to deliver consistent, safe, and effective results across various types of fabrics. Ultimately user can have experience of high-end results with hassle free and perfect ironing experience.

Advantages of CONSTANT TEMP TECHNOLOGY:

1. Save electricity The constant temperature principle of the electric iron can control the working time of the heating element, avoiding waste of energy in the continuous heating process, and can play a role in saving energy.
2. Productive The principle of constant temperature makes the electric iron to maintain a stable temperature during the ironing process which not only gives better ironing effects, but also improve ironing speed and work efficiency.
3. Safer side The constant temperature principle of the electric iron helps in avoiding the dangers of too high or too low temperature to the user and clothing to improve the user safety.

AUTO SHUT OFF FUNCTION

An electronic safety device will automatically switch off the iron if it has not been moved for a while (30s in horizontal position and 8min in vertical position), and the auto shut off indicator will flash. To restart the iron, pick up the iron or move it significantly, the auto shut off indicator goes out and ironing indicator come on, correspondingly the iron is ready for use.

ANTI-CALC SYSTEM

A special resin filter inside the water reservoir softens the water and prevents scale build-up in the plate. The resin filter is permanent and does not need replacing.

Please note: Do not use chemical additives, scented substances or decalcifies. Failure to comply with the above-mentioned regulations leads to the loss of guarantee.

ANTI-DRIP SYSTEM

With the anti-drip system, you can perfectly iron even the most delicate fabrics. Always iron these fabrics at low temperatures. The plate may cool down to the point where no more steam comes out, but rather drops of boiling water that can leave marks or stains. In these cases, the Anti-drip system automatically activates to prevent vaporization, so that you can iron the most delicate fabrics without risk of spoiling or staining them.

LED light indicator: This Iron has Led light indicator. When the unit is functioning LED light lit on and once switched off the appliance LED light goes out.

7. CLEANING AND MAINTENANCE

1. Disconnect the appliance from the mains, before cleaning.
2. Do not use solvents or abrasive products to clean the iron, clean with a damp cloth.

TROUBLESHOOTING

Problems Solution
Iron emits an odor or smoke	Iron gives off an odour when turned on for the first time. Oils used during manufacture need to be burnt off allow ten minutes for odour to disappear
The steamer does not produce steam	·Check the water level and the water tank inlet cover is properly covered.·Press the steam activation button harder.
The steamer does not heat up	·Check main plug is inserted correctly.·Check power supply.·Check power button.
Water spills from the water tank	·Make sure water is not over the MAXIMUM level.·Make sure water tank inlet cover is properly closed.
The steamer is producing a loud humming or pumping sound	Check water level; if there is no water or it is low, refill the water tank.
The steamer does not seem to be removing creases easily	Hold the steamer in an upright position and stretch the fabric downward to ensure best results.
Unsure when to use the fabric brush	·Use when steaming is to directly touch the fabric.·When steaming delicate fabric, such as silk to reduce the risk of water dripping onto the garment while steaming.

ORTANT:

Labeled diagram of an iron iron with numbered parts for identification

6. MODE D'EMPLOI

SISTEMA ANTI-CALCÁRIO

Labeled diagram of an iron iron with numbered parts for identification

Labeled diagram of an iron iron with numbered parts for identification

6. ISTRUZIONI PER L'USO

SISTEMA ANTI-CALCOLO

Labeled diagram of an iron iron with numbered parts for identification

6. NÁVOD K POUŽITÍ

Labeled diagram of an iron iron with numbered parts for identification

6. BRUGSANVISNING

Labeled diagram of an iron iron with numbered parts for identification

6. NAVODILA ZA UPORABO

Labeled diagram of an iron iron with numbered parts for identification

6. UPUTE ZA UPORABU

Technical diagram of an iron iron with numbered parts labeled for identification.

6. INSTRUKCJE UŻYTKOWANIA

Technical diagram of an iron iron with numbered parts labeled for identification.

6. INSTRUCCIONS D'ÚS

DÉCLARATION DE CONFORMITÉ

DECLARATION OF CONFORMITY

This device complies with EU Low Voltage Directive 2014/35/EC.

Electromagnetic Compatibility Directive 2014/30/EU. Directive 2015/863/EU on the restriction of the use of certain hazardous substances in electrical.

Directive 2009/125/EC on the eco-design requirements applicable to energy-related products.

This symbol on the product or on the packaging indicates that this product can't be disposed as normal rubbish or household waste. All the electrical, electronic equipment's and battery-operated units must recycle in proper manner and according to the local municipal laws. You can recycle them by taking them to government authorized disposal centres or specialized bins which you can find in any nearby big super markets, electronics or electro domestics products stores or malls who have these types of facilities available.

Designed by: SOGO based on European quality standards Imported by: Sanysan Appliances S.L, NIF: B98753056, C/ Barcas 2, 2, 46002 Valencia, Spain Product manufactured in CHINA. After-sales service: www.sogosat.com [e-mail] / 0034 902 222 161
