| Product type | Mono amplifier |
| Brand | Rockford Fosgate |
| Model | Prime R1000-1D |
| Rated power (RMS) @ 4 Ω | 500 Watts x 1 |
| Rated power (RMS) @ 2 Ω | 1000 Watts x 1 |
| Dimensions (H x W x D) | 6.10 x 19.49 x 29.30 cm |
| Approximate weight | 2.5 kg |
| Supply voltage | 9 to 16 V DC |
| Fuse rating (amplifier) | 3 x 30 A ATC |
| Battery fuse rating (external) | 90 A |
| Minimum load impedance | 2 Ω (mono) |
| Signal-to-noise ratio (at 1 W) | ≥ 80 dB (A-weighted) |
| Signal-to-noise ratio (at rated power) | ≥ 100 dB (A-weighted) |
| Frequency response | 20 Hz – 130 Hz ±1 dB |
| Low-pass filter | 12 dB/octave Butterworth, adjustable 40 – 130 Hz |
| Punch Bass | Adjustable from 0 dB to +12 dB at 45 Hz |
| Level remote control | Included (connection cable) |
| Signal input | Stereo RCA (tolerance 150 mV – 8 V) |
| Input impedance | 20 kΩ |
| Maintenance and cleaning | Clean with a soft, dry cloth. Do not use liquids or aerosols. |
| Safety | Disconnect the battery before any intervention. Use appropriate fuses. Do not expose to water. |
| Spare parts and repairability | Fuse parts accessible. For any repair, contact a Rockford Fosgate approved center. |
| Warranty | 1 year (United States), according to manual conditions |
Frequently Asked Questions - Prime R1000-1D Rockford Fosgate
How to install the Prime R1000-1D amplifier?
Before any installation, disconnect the negative battery terminal. Mount the amp in a ventilated area away from the engine. Use 4 AWG power cables. Connect the B+ terminal via a 90 A fuse located within 45.7 cm of the battery. The ground (GND) must be fixed on a clean metal surface. The REM wire must be connected to a switched 12 V source (car stereo ignition wire).
How to adjust the gain of the amp?
Turn the gain knob fully to the left (minimum position). Increase the car stereo volume to 3/4 of maximum without distortion. Then slowly turn the amp gain to the right until you get a satisfactory sound level without clipping. Once set, do not increase further.
The protection light (yellow) turns on, what to do?
The yellow light indicates a short circuit or too low impedance. Check the speaker connections: ensure no bare wire touches ground and that total impedance is not below 2 Ω. The amp shuts off automatically; correct the fault before turning it on again.
What is the minimum supported impedance?
The minimum recommended impedance is 2 Ω in mono configuration. A lower load may trigger protection and damage the amp.
How to connect the Punch level remote control?
The remote is supplied with the cable. Attach the mounting rail near the dashboard, route the cable to the amp and plug it into the designated jack. Once connected, the remote allows adjusting the volume remotely. Slide the remote onto the rail until it clicks.
What does the blue light constantly on mean?
The blue light (Power) indicates that the amp is powered on and working normally. If it does not light up, check the fuses, power connections, and battery voltage.
What type of power cable to use?
Rockford Fosgate recommends a 4 AWG power cable for the B+ and GND connections. The remote wire (REM) can be of a smaller gauge (18 AWG). Always use quality cables, red for power, black for ground.
How to adjust the low-pass filter?
Turn the filter knob fully to the left (40 Hz). Increase gradually to the desired frequency. For a subwoofer, 80 Hz is a good starting point. The filter is Butterworth 12 dB/octave.
The amp produces engine noise, what to do?
Keep RCA cables and speaker cables away from power cables. Check grounds: the amp ground must be on a clean, paint-free surface. Add an extra ground wire between the battery and chassis if necessary. If the noise persists, test the alternator and battery.
Where to find the serial number?
The serial number is printed on the outside of the original packaging. Write it down in the space provided at the beginning of the manual. It is used for warranty and in case of theft.
