| Product type | Compressed air hose reel |
| Brand | Toolcraft |
| Model | TO-7449555 |
| References | Order no. 2483185 (15 m hose) and 2498122 (10 m hose) |
| Housing material | Steel |
| Hose material | PVC + Rubber |
| Dimensions (L x W x H) | 37 x 17 x 40 cm (15 m model) |
| Weight | 8.9 kg (15 m model) |
| Working pressure | 10 bar |
| Minimum burst pressure | 40 bar |
| Outlet hose diameter | 3/8" (inches); internal 9 mm, external 16 mm (15 m model) |
| Outlet hose length | 10 m or 15 m depending on model |
| Inlet hose length | 1 m |
| Connection fitting | 1/4" thread (British Standard Pipe) |
| Operating conditions | -5 to +45 °C, 20-80% RH (non-condensing) |
| Main functions | Solid metal housing, adjustable hose stop, hose guide, adjustable guide arm (in 90° increments), adjustable spring force, automatic rewinding |
| Mounting | On wall, column, floor, or ceiling; mounting hardware not included (screws Ø10 mm min.) |
| Maintenance and cleaning | Clean with a dry, lint-free cloth; do not use aggressive products |
| Safety | Use protective equipment (goggles, hearing protection); do not use outdoors or in explosive atmospheres; read the instruction manual |
| Spare parts and repairability | Repairs only by a professional; available parts: replacement hose, spring, seals, stop ring |
| Package contents | Reel, connection hose, instruction manual, drilling template |
| General information | Free PDF manual available at notice-facile.com; free download |
Frequently Asked Questions - TO-7449555 Toolcraft
How to install the compressed air hose reel on a wall?
Use the included drilling template to mark the holes. Drill with a suitable bit (carbide for masonry, metal for steel). Secure the mounting base with screws at least 10 mm in diameter and wall plugs if necessary. Mounting hardware is not included.
How to adjust the hose payout length?
Loosen the two screws on the hose stop ring (5) with a screwdriver, slide the ring to the desired position, then retighten the screws. The lock prevents pulling beyond this length.
How to rewind the hose automatically?
Gently pull the hose to unlock the lock, then let it rewind slowly while guiding the hose with your hand. Never release the end abruptly to avoid injury.
What is the maximum pressure the hose can withstand?
The working pressure is 10 bar and the minimum burst pressure is 40 bar. Do not exceed these values to avoid damage or injury.
Can I use this reel outdoors?
No, use is only permitted indoors in dry, enclosed spaces. Outdoor or damp environment use is prohibited to avoid electrical hazards and corrosion.
How to adjust the rewinding spring force?
Remove the hose stop ring, pull the hose out of the rollers, then turn the reel knob clockwise to increase force or counterclockwise to reduce it. Hold the reel firmly during adjustment.
What to do if the hose does not rewind completely?
Check that the hose is wound evenly and slowly. If the problem persists, the spring force may be too low (increase it) or the stop ring mispositioned. Consult the troubleshooting table in the manual.
How to maintain the reel?
Clean the housing with a dry, lint-free cloth. Regularly check fastenings, for leaks, cracks, or loose parts. Do not use aggressive chemicals.
Where to find the complete instruction manual?
The instruction manual is included in the package. You can also download it for free in PDF format from notice-facile.com by searching for the model Toolcraft TO-7449555.
What screw diameters are needed for wall mounting?
Use screws with a diameter of at least 10 mm. For masonry surfaces, a length of about 60 mm is recommended; for metal, about 25 mm. Wall plugs are necessary for stone walls.
