Royal HES 550 - Hedge trimmers EINHELL - Free user manual and instructions

Product type	Electric hedge trimmer
Brand	Einhell
Model	Royal HES 550
Power consumption	550 W
Supply voltage	230 V ~ 50 Hz
Cutting length	465 mm
Blade length	530 mm
Tooth spacing	18 mm
No-load strokes	3200 / min
Sound power level (LWA)	102 dB(A)
Sound pressure level (LPA)	82 dB(A)
Vibration (hand-arm)	3.6 m/s²
Weight	4.1 kg
Double insulation	Yes (class II)
Moisture protection	Do not use in rain
Two-handed operation	Yes, with two-hand safety switch
Blades	Steel, double-sided cutting
Hand guard	Included and mandatory
Recommended extension cord	H07RN-F 3G1.5 with grounding plug
Blade maintenance	Regular cleaning and oiling with biodegradable oil
Included accessories	Wall storage holster
Warranty	2 years

Frequently Asked Questions - Royal HES 550 EINHELL

How to start the Royal HES 550 hedge trimmer?

To start, hold down the power button on the guide handle (front hand) and simultaneously press the switch on the rear handle. Release any button to stop the blades.

What are the essential safety precautions?

Wear safety glasses, hearing protection, gloves and non-slip shoes. Hold the device with both hands, keep children away and do not trim in the rain.

How to maintain the hedge trimmer blades?

Clean the blades with a brush after each use and apply a thin layer of biodegradable oil. Oil regularly to ensure optimal cutting and prevent rust.

Can I use the hedge trimmer on wet hedges?

No, do not trim wet hedges and do not use the device in rain. Moisture increases the risk of electric shock and damages the machine.

How to store the hedge trimmer after use?

Unplug the device, clean the blades, apply oil and store it in a dry place out of reach of children. Use the supplied wall holster to fix it to the wall.

What to do if the power cord is damaged?

Immediately unplug the device and do not use it. The cable must be replaced by a qualified professional to avoid danger. Only use a cable of type H07RN-F.

What extension cord can I use with the Royal HES 550?

Use a certified outdoor extension cord of type H07RN-F 3G1.5 with a safety plug and a grounded coupling protected against splashes.

How to replace the blades?

Damaged blades must be replaced in pairs by an authorized service center. Do not attempt to repair them yourself. Also have the device checked after a fall.

What is the noise level of this device?

The sound pressure level is 82 dB(A) and the sound power level is 102 dB(A). Wear hearing protection if the noise exceeds 85 dB(A).

What to do if the device does not start?

Check that the plug is properly connected and that the fuse has not blown. If voltage is present and the device still does not work, contact Einhell customer service.

USER MANUAL Royal HES 550 EINHELL

1. General safety information

Caution! When using electric tools it is imperative to take the following basic safety precautions in order to reduce the risk of electric shock, injury and fire. Read and take note of these instructions before you use this tool.

1. Keep your work area tidy

2. An untidy work area invites accidents.

3. Check the working conditions

4. Do not expose electric tools to rain. Never use electric tools in damp or wet locations. Make sure there is good lighting. Do not use electric tools near flammable liquids or gases.

5. Guard against electric shock

6. Avoid body contact with earthed components such as pipes, radiators, cookers, refrigerators.

7. Keep children away!

8. Do not allow other persons to touch the tool or cable. Keep all persons out of your work area.

9. Store tools in a safe place

10. When tools are not in use they should be stored in a dry, locked room out of children's reach.

11. Do not overload your tools - Tools work better and safer when used within their quoted capacity range.

12. Use the right tool

13. Never use tools or attachments with insufficient power for the job in hand. Never use tools on jobs for which they were not intended.

14. Wear suitable work clothes

15. Do not wear loose clothing or jewelry as they may get caught in moving parts. Rubber gloves and non-slip shoes are recommended when working outdoors. Wear a hair net if you have long hair.

16. Wear safety goggles

17. and use a dust mask when working on dusty jobs.

18. Do not mis-use the cable

19. Do not carry the tool by its cable or pull on the cable to remove the plug from the socket-outlet. Protect the cable from heat, oil and sharp edges.

20. Don't overreach

21. Avoid abnormal working postures. Make sure you stand squarely and keep your balance at all times.

22. Look after your tools

23. Keep your tools sharp and clean for better and safer performance. Follow the instructions for maintenance work and for changing any attach

ments. Check the plug and cable regularly and, if damaged, have them replaced by an authorized specialist. Check the extension cable regularly and replace it if damaged. Keep handles dry and free from oil and grease.

1. Always pull out the power plug

2. when the tool is not being used, before carrying out any maintenance work and when changing attachments such as blades, bits and cutters of any kind.

3. Remove adjusting keys and wrenches

Make sure that all keys and adjusting wrenches are removed from the tool before switching it on.

1. Avoid unintentional starting

2. Never carry a tool with your finger on the switch if it is connected to the power supply. Make sure that the switch is in OFF position when inserting the power plug.

3. When using an extension cable outdoors

4. check that it is approved for outdoor duty and is marked accordingly.

5. Be alert at all times

6. Watch what you are doing. Use common sense. Do not operate the tool if your mind is not on your work.

7. Check the tool for damage

8. Each time before re-using the tool, carefully check that the guards or any slightly damaged parts are working as intended. Check that the moving parts are in good working order, that they do not jam, and that no parts are damaged. Make sure that all parts are fitted correctly and that all other operating conditions are properly fulfilled. Unless otherwise stated in the operating instructions, damaged guards and parts have to be repaired or replaced by an authorized service center. It is imperative to have damaged switches repaired by an authorized service center. Never use any tool if its switch cannot be turned off and on.

9. Important!

10. For your own safety, use only accessories and attachments which are listed in the operating instructions or recommended or listed by the tool manufacturer. The use of any accessory or attachment other than those recommended in the operating instructions or catalogue may involve a risk of injury for you personally.

11. Replacing the power cable

To prevent injury, damaged power cables may only be replaced by the manufacturer or the customer service center.

GB

1. Have repairs carried out only by a qualified electrician

2. This electric tool complies with the pertinent safety regulations. Repairs are to be carried out only by a qualified electrician or the user may suffer an accident.

3. Nolse

4. The noise level of this electric tool is measured in accordance with ISO 3744 and NFS 31-031 (2000/14 EG). Noise at the workplace may exceed 85dB(A) . In this case, the operator must wear ear-muffs or similar.

Keep these safety instructions in a safe place.

Specific safety information

Please read this safety information and the directions for use carefully and be sure to follow the instructions to the letter.

1.1 Always remove the power plug from the socketoutlet before you perform any work on the hedge trimmer, e.g.
- repairing a damaged cable
- cleaning the blades
- troubleshooting
cleaning and maintenanceor before leaving the tool up
1.2 The hedge trimmer can cause serious injuries! Read the directions for use carefully in order to acquaint yourself with the correct way to handle, set up, service, start and put down the machine. Familiarize yourself with all the machine's control elements and its proper use.
1.3 Always handle the hedge trimmer with both hands.
1.4 When working with the hedge trimmer, wear sturdy shoes and make sure of your fooling
1.5 Never work with the hedge trimmer in the rain or on wet hedges and never leave the hedge trimmer outdoors. The hedge trimmer must not be used if it is wet.
1.6 We recommend that you wear safety goggles and ear-muffs when working with the hedge trimmer.
1.7 Wear suitable working clothes such as rubber gloves and non-slip shoes. Do not wear loose garments. Keep long hair in a hatnet.
1.8 Avoid abnormal postures and make sure of your footing, particularly when working on ladders and steps.
1.9 Be sure to hold the hedge trimmer well away 10

from your body when it is switched on.

1.10 Make sure there are no other persons or animals within your working area (radius of swing
1.11 Carry the hedge trimmer only by its guide handle.
1.12 Keep cables clear of where you are cutting.
1.13 Before you use the hedge trimmer, examine the power cable for signs of damage and aging.
1.14 Use the hedge trimmer only when the power cable is in good working order.
1.15 Do not remove the power plug from the socket outlet by pulling on the cable. Never carry the tool by its cable. Take care not to damage the cable in any way.
1.16 Protect cables from heat, caustic fluids and sharp edges. Replace damaged cables immediately.
1.17 Examine the cutting system regularly for signs of damage and, if necessary, arrange for the hedge trimmer to be professionally repaired by the ISC Customer Service Center or a specialist workshop.
1.18 If the blades become jammed, e.g. due to thick branches or the like, switch off and unplug the hedge trimmer immediately. Only then are you to remove the cause of the obstruction.
1.19 Keep the hedge trimmer in a dry place out of children's reach.
1.20 During transportation and storage of the hedge trimmer, keep the blades covered at all times with the special guard.
1.21 Take care not to overload the hedge trimmer and do not use it on jobs for which it is not intended, i.e. you are allowed to use the hedge trimmer only to cut hedges, shrubs and perennials.
1.22 Use only cables and connectors approved for outdoor use; power cable HO7RN-F 2x1.0 with integral two-plug plug; extension cable HO7RN-F 3G1.5 with rain-water-protected earthing-pin plug and earthing-contact coupling.

The use of a leakage-current or earth-leakage circuit-breaker is recommended for operating electric tools. Ask your electrician!

1.23 The hedge trimmer requires regular inspection and maintenance. Always replace damaged blades in pairs. If the hedge trimmer suffers any damage from impact (falling on hard ground etc.), have it checked immediately by a specialist.
1.24 Look after your hedge trimmer carefully. Keep it clean and sharp to ensure efficient and safe cutting. Follow the maintenance and cleaning instructions.

1.25 The German Farmers Union, for example, prohibits the use of electric hedge trimmers by persons aged 17 or less. Persons aged 16 and above may only use electric hedge trimmers if supervised by an adult.
1.26 Do not use the hedge trimmer with a damaged or excessively worn cutting system.
1.27 Check your surroundings and take note of any potential dangers which you may not be able hear due to the machine's noise.
1.28 It is advisable not to use the hedge trimmer when other persons, and particularly children, are nearby.
1.29 Children are not allowed to use the hedge trimmer.
1.30 Noise at the workplace may exceed 85 dB(A). In this case, the operator must wear ear-muffs or similar. The noise level of this electric tool is measured in accordance with IEC 59 CO 11; IEC 704; DIN 45635 Part 21 and NFS 31-031 (2000/14 EG).
1.31 Vibrations on the handle were measured in accordance with EN 50144-2-15.

2. Items supplied (see Figure 1)

1 Cutter rail
2. Hand guard
3. Guide handle with button switch
4. Handle with button switch
5. Eyelet for extension cable
6 Power cable
7. Storage case

It is prohibited to use the hedge trimmer without the hand guard.

3. Fitting the hand guard (see Fig. 2)

Mount the supplied finger guard (A) as shown in Fig. 2 and secure with the supplied screws (B).

4. Explanation of rating plate (see Figure 3)

1. Warning
2. Keep away from the rain and damp conditions.
3. Read the operating instructions before you use the hedge trimmer.
4. Pull out the plug immediately if the power cable is damaged or severed.
5. Wear goggles and ear-muffs or similar protection.

5. Technical data

Voltage 230V - 50Hz

Power consumption 550 W

Cutting length 465 mm

Cutter rail length 530 mm

Tooth spacing 18 mm

Cuts/min 3200 /min

Sound power level LWA 102 dB(A)

Sound pressure level LPA 82 dB(A)

Vibration aw 3,6 m/s

Weight 4,1 kg

6. Power supply

The hedge trimmer is designed for use only with single-phase alternating current from a 230V 50Hz AC supply. It is totally insulated, enabling it to be connected also to socket-outlets without a PE conductor. Before you use the hedge trimmer for the first time, check that your mains voltage is the same as the operating voltage specified on the machine's rating plate.

7. Startup and operation

Caution! This hedge trimmer is designed to cut hedges, bushes and shrubs. Any other use which is not expressly permitted in these instructions may cause damage to the hedge trimmer and place the user at serious risk. Your hedge trimmer is equipped with a two-hand safety circuit. This means that it works only when the switch button on the guide handle (Figure 1 / Item 3) is pressed with the one hand while the switch on the handle (Figure 1 / Item 4) is being pressed with the other hand. If you let go of either switching element, the blades will stop moving.

The blades take time to slow down to a standstill. Please make allowance.

• Check that the blades are working properly. High cutting performance and smooth operation are guaranteed by the counter-rotating, dual-edge blades.
• Fasten the extension cable in the corresponding cable holder (see Figure 4) each time before you use the hedge trimmer.
• Use only approved extension cables for outdoor use.

GB

8. Practical tips

• The hedge trimmer can be used to cut shrubs and bushes as well as hedges.
  For the best performance, hold the hedge trimmer with its teeth at an angle of approx. 15^ to the hedge (see Figure 5).
  Cutting in both directions is possible with the counter-rotating dual-edge blades (see Figure 6).
  To trim your hedge to a uniform height, run a length of string along the hedge for guidance and cut off the projecting branches (see Figure 7).
• Cut the sides of the hedge with sweeping movements from the bottom up (see Figure 8).

9. Maintenance and cleaning

• Switch off the hedge trimmer and pull out its power plug before you put it down and clean it.
• For the best cutting performance at all times, clean and lubricate the blades ate regular intervals. Remove deposits with a brush and apply a thin film of oil (see Figure 9).

Use bio-degradable oils.

Clean the plastic housing and parts with a mild household detergent and a damp cloth. Never use aggressive agents or solvents.
- Be particularly careful not to allow any water to get inside the machine.
- The supplied storage case can be fastened to the wall. This is the best place to store your hedge trimmer.

10. Troubleshooting

The machine does not work: Check that the power cable is connected properly and check the malns fuses. If the machine will not work in spite of the voltage supply being OK, please send it to the specified after-sales service address.

11. Disposal

Important!

The hedge trimmer and its accessories are made of an assortment of materials, e.g. metal and plastics. Defective components must be disposed of as special waste. Do not throw in the household refuse bin! Ask your dealer or local authority.

F

Subject to change without notice

WARRANTY CERTIFICATE

The product describes in these instructions comes with a 2 year warranty coverage for the customer. The product begins with the warning of risk or influence the customer receives the products.
For warranty claims to be accepted, the product has to receive the correct maintenance and be put to the proper use as described in this operating instructions. Your statutory rights of warranty are naturally unaffected during these 2 years.
This warranty applies in Germany, or in the respective country of the manufacturer's main regional sales partner, as a supplement to local regulations. Please note the details for contacting the customer: service center responsible for your region in the service sickness list below.

GARANTIE

Dhp in v. de handling genoendre steelver gewir 2aar gerane vor he.
1000000000000000000000000000000000000000000000000000000000000000000000000000000
De gestarile kon ewiel xerowen socialn evoa wlaed ca het toestel na hohenen is aneodrohser en geutrol sucfo de handeloing.
Vanzellsprekind bilden u de wetbiele garantierechten binnen dieze 2 ja behdunen.
De gastricile gestamt vorher grangevied am Banerjeeboukli Dubstun und van de dosoprodolicofische banen van de regikalien hordovadoris als verwällung van de tere pristige gesundheit vreenschrijdt. Gezeven tel ual an asperacosteren en de l'air ne s'esteigene stichtedelst of teil le hordovad erveerde aseverado as la waren.

GARANTIBEVIS

Eschenstraße 6-D-94405 Landau/Isar (Germany)

Info-Tel.[phone]·Telefax 0180-5835830

Service- und Infoserver:http://www.isc-gmbh.info

6 Technische Änderungen verbhalten
Technical changes subject to change
Sousreserve de modificators
Technische wijzigingen vorbehouden
Forbehall for lekniska forindringar
Con reserved to apportare modiliche techniche
Techniquezmynyhrazery
Technique zmery vhyrodene

Nur fur EU-Lander

For EU countries only

Never place any electric tools in your household refuse.

To comply with European Directive 2002/96/EC concerning old electric and electronic equipment and its Implementation in national laws, old electric tools have to be separated from other waste and disposed of in an environment-friendly fashion, e.g. by taking to a recycling depot.

Unit 5 Morpeth Wharf

Twelve Quays

Birkshead, Viral

CH411NG

Tel.[phone],Fax [phone]

APCENCIELELECTRE

A. BB:15

E89000ST GEORGES/Baulche

Resp.SAV:Oliver DEMEAUX

Piesds doliaches: Michel RODIER

Tel.[phone];Fax[phone]

mail: [e-mail]

M)Firbrill Fapolux

Werdleesen 44

NL-4B15 PK Breda

Tel.[phone]

E Comprairial Ephel, S.A.

Troy, Pennsylvania 0.8

Rehorman Industrial

F-28119,Albuquerque,MD

E

Eirneill Pontogai Lda.

Aparto 2100

Rua da Aldeia 225 Aparado 1-11160-1800-734-2900

P410-419AFPC62610(VRQ)Tel.[phone]Fax：[phone]

10.122051134

Einhell Italia s.r.l.

Vie Marconi, 16

Aay Cee Man, Yashin S

TR 34843 Manape - Itebanui

16.02164594185,Fx02164429325

Agisr.o

Stefanikova 10

SK-91101 Trec

Tol.327445270

Lurkha

Investitions, Haugaseiscbatt

Innnsioe-Legeereerai

Beinski-102

KZ-486008 st.Chlmkent

Tel./Fax [phone]

Enhall Distribution SRL

Dulai Cai

BGPen, m29 RD-075100 Bucuresti

Tel.[phone].Fax[phone]

PoterBtp.S.R.O.

Oerly Prohghs

Burtman 10 B

0

CZ-19011 Prane - Bechoviche 911 Tel: [phone]x (2578) 1020x

10.2021010204102021010204

Slav GmbH

Mihail Kalani str. 16 W

BG-9000 Varna

Tel. [phone]

（）FinballCristiaedco

VoikoVos 2

HB-49224 Leparcl

Tol:4531244

Technical & Commercial Company

1. Panastraun & Asklinu Str.

GR 18545 Piraeus

Tel：[phone]Fax：[phone]

BERNIE,MOSSON

Allnyevko 2A
D107071

R0S-127273Mo8e0b Tel:[phone]

1.05.2023761（D#）

Tel.[phone]Bencor center St Bete

Tel: [phone] (Repair Service St. Petersburg)

（）Pribla

MeIalo 8b.23

LT-02190Vilniue

Tel：[phone]Fax：[phone]

（一）股东登记

Rs Benon Rau also

1

Hsina valo 5562103Tort

EE-62102 1#10 Tel. [phone] Fax: 07

1

Halal Trading Co. LLC

POB 9282, Nakheel Rd. Dene, Sh

UAE-Dubai

Tel. [phone], Fax [phone]

（）AboxAbzCo.Ltd

No.111, Basian Passagc, Irarn Khoreini Ays.

IR-11146 Teheran

Tel [phone]Fax [phone]

EinhellBihldp.

Posovri Centar 95

BA-72250Vitez

Tel [phone]Fax [phone]

(24)urase Industrial and Automotive Supply

1. BSSSE

Ducarville

2A-Vereeniging 1939 141-155

Tel [phone],Fax [phone]

(Syayaz Prominvest Ltd)

207-11,Skarinyev.

BY-220D23 Minsk

Tel [phone],Fax [phone]

D

The regrinding or reproduction by any other means, in whole or in part, of documentation and papers accompanying products is permitted only with the express consent of IBC GmbH.

F

IepnepaHbHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnHnH n H

GR

H Gwirniwni h aaiy ane yannayn w kauo 10000000000000000000000000000000000000000000000000000000000000000

#

Nakravine i kankiši ilaša smruševzāna dolekumente i prastoslék
Istvoj Kralješek, Željana Kralješek, Žoško Kojaplicek, mičogne je samo za izilć bojsděvůte strážic 1950 GBC.

EH 11:2004
