USER MANUAL Comfortcook 99354 TREBS

INTRODUCTIE VAN HET APPARAAT

Read all general safety instructions carefully and keep them for future use.

When using electrical appliances, basic safety precautions should always be followed including the following:

1. Read all instructions.

2. Install in accordance with this supplied user manual.

3. Check whether the nominal power indications on the rating plate match those of your local network

before connecting the device to the mains.

4. Only use the device for its intended use. Only use the supplied accessories.

5. Do not touch hot surfaces.

6. To protect against electric shock do not immerse cord, plugs, or base in water or other liquid.

7. WARNING: this electrical appliance contains a heating function. Surfaces, also different than the

functional surfaces, can develop high temperatures. Since temperatures are differently perceived by different persons, this equipment shall be used with CAUTION. The equipment shall be touch only at intended handles and gripping surfaces, and use heat protection like gloves or similar. Surfaces other than intended gripping surfaces shall get sufficiently time to the cool down before getting touched.

8. To avoid injuries, never touch the heating elements of the device or any other parts of the device that

9. The exterior of the device may become hot during use.

Attention: hot surface – never touch the hot part or the heating elements of the device.

10. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off

11. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

12. The use of accessory attachments not recommended by the appliance manufacturer may cause

13. Do not use this appliance outdoors

14. Do not let cord hang over edge of table or counter, or touch hot surfaces.

15. Do not place on or near a hot gas or electric burner, or in a heated oven.

16. Never use sharp or abrasive objects in combination with this device.

17. Keep the device and power cable out of reach of children.

18. Keep the device and the accompanying power cable away from heat sources or sharp edges that

19. Keep the power cable away from parts of the device that become warm during use.

20. Keep the device away from other devices that radiate heat.

21. Never immerse the device in water or other liquids.

22. Never operate the device with wet hands.

23. Dry always the appliance inlet before use.

24. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.

25. Always attach the plug to the appliance first, then plug the cord in the wall outlet.

26. To disconnect, turn any control to "off," then remove plug from wall outlet.16

27. Always disconnect the product from the mains both after use and before cleaning or

28. After use, always make sure that the device has cooled off completely before cleaning,

maintaining or storing the device.

29. Never pour water onto the heating element.

30. WARNING: keep the device away from flammable materials.

31. Do not cover or block any ventilation openings. When placing the device on a shelf, leave 10 cm free

space around the whole device.

32. Unplug this device during lightning storms or when unused for a long period.

33. WARNING: never insert an object into the product through the vents or openings. High voltage flows

through the product and inserting an object can cause electric shock and/or short circuit internal parts. For the same reason, do not spill water or liquid on the product.

34. Although this device is manufactured with the utmost care and checked several times before leaving

the factory, it is still possible that problems may occur, as with all electrical appliances. If you notice smoke, an excessive build-up of heat or any other unexpected phenomena, you should disconnect the plug from the main power socket immediately.

35. The socket outlet must be installed near the equipment and must be easily accessible.

36. Do not overload ac outlets or extension cords. Overloading can cause fire or electric shock.

37. Keep away from rodents. Rodents enjoy biting on power cords.

38. Always hold the plug when pulling it out of the main supply socket. Do not pull the power cord.

This can cause a short circuit. Never remove the device’s plug from the wall socket by pulling at the cable; switch off and remove the plug with your hand.

39. Avoid placing the device on any surfaces that may be subject to vibrations or shocks.

40. Never remove the casing of this appliance.

41. Do not use or store this product in a place where it is subject to direct sunlight, heat, excessive dust or

vibration or an environment with a high humidity.

42. Never leave the device unattended while connected to the mains.

43. This appliance can be used by children aged from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. This device is not a toy. Cleaning and user maintenance shall not be made by children unless they are old than 8 and supervised.

44. The appliances are not intended to be operated by means of an external timer or separate

remote-control system.

45. Do not allow children access to plastic bags.**

• **Unpack all parts and remove protective material.

• Do not connect the unit to the mains before checking the mains voltage and before all other connections have been made. Save these instructions!17 INTRODUCTION APPLIANCE This Hot-air fryer provides an easy and healthy way of preparing your favorite ingredients/meals. By using hot air circulation and a top grill, it is able to make numerous dishes. The best part is that the Hot-air fryer heats food at all directions and most of the ingredients do not need any oil. The Parts (Fig.1)

1. Never immerse the housing, which contains electrical components and the heating elements, in water or

rinsing under the tap

2. Avoid any liquid enter the appliance to prevent electric shock or short-circuit.

3. Keep all ingredients in the basket or prevent any contact from heating elements.

4. Do not cover the air inlet and the air outlet when the appliance is working.

5. Do not fill the pan with oil as this may cause a fire hazard.

6. Never touch the inside of the appliance while it is operating.

1. Check if the voltage indicated on the appliance fits the local mains voltage and make sure the plug is

inserted into the wall socket properly.

2. Do not use the appliance if there is any damage on the plug, mains cord or other parts.

3. Do not go to any unauthorized person to replace or fix a damaged main cord.

4. Keep the mains cord away from hot surfaces.

5. Do not plug in the appliance or operate the control panel with wet hands.

6. Do not place the appliance against a wall or against other appliances. Leave at least 10 cm free space on

the back and sides and 10cm free space above the appliance.

7. Do not place anything on top of the appliance.

8. Do not use the appliance for any other purpose than described in this manual.

9. Do not let the appliance operate unattended.

10. During hot air frying, hot steam is released through the air outlet openings, keep your hands and face at a

safe distance from the steam and from the air outlet openings.

11. Also be careful of hot steam and air when you remove the pan from the appliance.

12. Any accessible surfaces may become hot during use (Fig.2)

13. Immediately unplug the appliance if you see dark smoke coming out of the appliance. Wait for the smoke

emission to stop before you remove the pay from the appliance.19 Caution:

1. Ensure the appliance in placed on a horizontal, flat and stable surface.

Do not place the appliance on non-heart-resistant surface.

2. This appliance is designed for household use only. It may not suitable to be safely used in environments

such as staff kitchens, farms, motels, and other non-residential environments. Nor is it intended to be used by clients in hotels, motels, bed and breakfasts and other residential environments.

3. If the appliance is used improperly or for professional or semi-professional purposes or if it is not used

improperly or for professional or semi-professional purposes or it is not used according to the instructions in the user manual, the guarantee becomes invalid and we could refuse any liability for damage caused.

4. Always unplug the appliance while not using.

5. The appliance needs approximately 60 minutes to cool down for handle or cleaning safely.

͸Ǥ Make sure the ingredients prepared in the appliance come out golden-yellow instead of dark or brown. Remove always burnt remnants. And do not fry fresh potatoes at a temperature above 180Ԩ

7. Remove all packaging materials, stickers and labels from the appliance.

8. Thoroughly clean the basket and pan with hot water, some washing-up liquid and a non-abrasive sponge.

9. Wipe inside and outside of the appliance with a moist cloth.

10. Place the basket in the pan (Fig.3).

11. Do not fill the pan with oil or any other liquid like frying fat. This is an oil-free fryer that works on air.

Do not put anything on top of the appliance, the airflow will be disrupted and affects the hot air frying result. Using the appliance Automatic switch-off This appliance is equipped with a timer, when the timer has counted down to 0, the appliance produces a bell sound and switches off automatically. To switch off the appliance manually, turn the timer knob anticlockwise to 0. Hot air frying

1. Connect the mains plug into an earthed wall socket and follow all the rules as described before.

2. Carefully pull the pan out of the Hot-air fryer (Fig.4)

3. Put the ingredients in the basket. (Fig.5)

Never fill the basket beyond the MAX indication or exceed the amount indicated in the table food settings, as this could affect the quality of the end result.

4. Slide the pan back into the Hot-air fryer (Fig 6)

Noting to carefully align with the guides in the body of the fryer. Never use the pan without the basket in it. Caution: Do not touch the pan during and some time after use, as it gets very hot. Only hold the pan by the handle. Don’t push the basket release button (Fig. 3) while pulling out the hot basket

5. Determine the required preparation time for the ingredient ( see section ‘Food settings’ in this chapter).

6. To switch on the appliance, turn the timer knob to the required preparation time (Fig.7)

POWER LIGHT will light and the fan will start.

7. Turn the temperature control knob to the required temperature. See section ‘Food settings’ in this chapter

to determine the right temperature (Fig.7). Add 3 minutes to the preparation time when the appliance is cold. Note: if you want, you can also let the appliance preheat without any ingredients inside. In that case,

turn the timer knob to more than 3 minutes and wait until the heating-up light goes out ( after approx. 3 minutes). Then fill the basket and turn the timer knob to the required preparation time. A. The timer starts counting down the set preparation time. B. During the hot air frying process, the heating-up light comes on and goes out from time to time. This indicates that the heating element is switched on and off to maintain the set temperature. C. Excess oil/fat from the ingredients is collected on the bottom of the pan.

8. Some ingredients require shaking halfway through the preparation time (see section “Food settings” in this

chapter). To shake the ingredients, pull the pan out of the appliance by the handle (Fig. 6) and shake it. Then slide the pan back into the fryer. Caution: do not press the button the handle during shaking. (Fig.3) Tip: To reduce the weight, you can remove the basket from the pan and shake the basket only. To do so, pull the pan out of the appliance, place it on a heat-resistant surface and press the button of handle. and lift the basket out of the pan Tip: If you set the timer to half the preparation time, you hear the timer bell when you have to shake the ingredients. However, this means that you have to set the timer again to the remaining preparation time after shaking.

9. When you hear the timer bell, the set preparation time has elapsed. Pull the pan out of the appliance and

place it on a heat-resistant surface. Note: You can also switch off the appliance manually. To do this, turn the time control knob to 0.

10. Check if the ingredients are ready.

If the ingredients are not ready yet, simply slide the pan back into the appliance and set the timer to a few extra minutes.

11. To remove ingredients (e.g. fries), pull the pan out of the Hot-air fryer and place it on a heat-resistant

surface, and press the basket release button and lift the basket out of the pan. Do not turn the basket upside down with the pan still attached to it, as any excess oil/fat that has collected on the bottom of the pan will leak onto the ingredients. The pan and the ingredients are hot after frying so depending on the type of the ingredients in the fryer, steam may escape from the pan.

12. Empty the basket into a bowl or onto a plate.

Tip: to remove large or fragile ingredients, lift the ingredients out of the basket by a pair of tongs (tongs are not included)

13. When a batch of ingredients is ready, the Hot-air fryer is instantly ready for preparing another batch.

Food settings This table below will help you to select the basic settings for the ingredients. Note: keep in mind that these settings are indications. As ingredients differ in origin, size, shape as well as brand, we cannot guarantee the best setting for your ingredients. Because of the hot air technology the air inside heats instantly. Pull the pan briefly out of the appliance during hot air frying barely disturbs the process. There are endless dishes that you can prepare. Prepare complete meals from the Hot air fryer

Because the Hot air fryer bakes with air, you have virtually no taste transfer. This allows you to prepare tasty, complete meals in your Hot Air fryer. Easy as you have little time or desire to cook something new. Grill for example a piece of meat or fish, puff or bake potatoes and cook deep-frozen or fresh vegetables. Without pans, in one hot air fryer you make your own snacks, meat and fish dishes, side dishes, breakfast dishes and desserts.21 The ingredient indication table is only an indication. For more idea dishes you can use the internet. Please find below underneath also some important tips! Tips: - Smaller ingredients usually require a slightly shorter preparation time than larger ingredients. A larger amount of ingredients only requires a slightly longer preparation time, a smaller amount of ingredients only requires a slightly shorter preparation time. - Shaking smaller ingredients halfway through the preparation time optimizes the end result and can help prevent unevenly fried ingredients. - Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the Hot-air fryer within a few minutes after you added the oil. - Do not prepare extremely greasy ingredients such as sausages in the Hot-air fryer. - Snacks that can be prepared in a oven can also be prepared in the Hot-air fryer. - The optimal amount for preparing crispy fries is 300 grams. - Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough also requires a shorter preparation time than home-made dough. - Place a baking tin (not included on this appliance) or oven dish in the Hot-air fryer basket if you want to bake a cake or quiche or if you want to fry fragile ingredients or filled ingredients - You can also use the Hot-air fryer to reheat ingredients. To reheat ingredients, set the temperature to 150

for up to 10 minutes. - For the best results of ‘home made fries’, we advise to use pre-baked (e.g. frozen) fries. steps below. a. Peel the potatoes and cut them into sticks. b. Soak the potato sticks in a bowl for at least 30 minutes, take them out and dry them with kitchen paper. c. Pour ½ tablespoon of olive oil in a bowl, put the sticks on top and mix until the sticks are coated with oil. d. Remove the sticks from the bowl with your fingers or a kitchen utensil (not included) so that excess oil stays behind in the bowl. Put the sticks in the basket. Note: do not tilt the bowl to put all the sticks in the basket in one go, to prevent excess oil from ending up on the bottom of the pan. e. Fry the potato sticks according to the instructions in this chapter

Min-max Amount (g) Time (min.) Temperature

Spring rolls 100-250 8-10 200 shake Use oven-ready Frozen chicken nuggets 100-300 6-10 200 shake Use oven-ready Frozen fish fingers 100-250 6-10 200 Use oven-ready Frozen bread crumbed cheese snacks 100-250 8-10 180 Use oven-ready Stuffed vegetables 100-250 10 160 Baking Cake 250 20-25 160 Use baking tin (not included) Quiche 300 20-22 180 Use baking tin/oven dish (not included) Muffins 250 15-18 200 Use baking tin (not included) Sweet snacks 250 20 160 Use baking tin/oven dish (not included) Note: add 3 minutes to the preparation time when you start frying while the hot-air fryer is still cold. Note: when you use ingredients that rise (such as with cake, quiche or muffins), the baking tray (not included) should not be filled more than halfway.23 Cleaning and storage Clean the appliance after every use. The basket and oil drip tray as also the inside of the appliance do have a non-stick coating. So do not use metal kitchen utensils or abrasive cleaning materials to clean them, as this may damage the non-stick coating. a. Remove the mains plug from the wall socket and let the appliance cool down. Note: remove the pan to let the hot air fryer cool down more quickly. b. Wipe the outside of the appliance with a moist cloth. c. Clean the pan and basket with hot water, some washing-up liquid and a non-abrasive sponge. You can use degreasing liquid to remove any remaining dirt. Tip: If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot water with some washing-up liquid. Put the basket in the pan and let the pan and the basket soak for approximately 10 minutes. d. Clean the inside of the appliance with hot water and non-abrasive sponge. e. Clean the heating element with a cleaning brush to remove any food residues. f. Unplug the appliance and let it cool down. g. Make sure all parts are clean and dry.

This appliance should not be put into the domestic garbage at the end of its durability, but must be offered at a central point for the recycling of electric and electronic domestic appliances. This symbol on the appliance, instruction manual and packaging puts your attention to this important issue. The materials used in this appliance can be recycled. By recycling used domestic appliances you contribute an important push to the protection of our environment. Ask your local authorities for information regarding the point of recollection. Packaging The packaging is 100% recyclable, return the packaging separated. Product This device is equipped with a mark according to the European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring that this product will be correctly processed into waste, it will help prevent possible negative consequences for the environment and human health. EC declaration of conformity This appliance is designed to come into contact with food and is designed in accordance with EC Directive 89/109/EEC. This device is designed, manufactured and marketed in accordance with the safety objectives of the Low Voltage Directive "No 2006/95/EC", the protection requirements of the EMC Directive 2004/108/EC "Electromagnetic Compatibility" and the requirement of Directive 93/68/EEC. GUARENTEE We provide a 24 month guarantee for this product, commencing from the date of sale, for faults which are attributable to production or material faults. Your legal guarantee entitlements in accordance with § 439 ff. BGB-E remain unaffected by this. The guarantee does not include damages, which were incurred as a result of improper handling or use, as well as malfunctions which only have a minor effect on the function or the value of the device. Consumables, transit damages, inasmuch as we are not responsible for these, as well as damages, which were incurred as a result of any repairs that were not performed by us, are also excluded from the guarantee entitlements. This device is designed for use in domestic situations and has the appropriate performance levels. Any use in commercial situations is only covered under the guarantee to the extent that it would be comparable with the stresses of being used in a domestic situation. It is not intended for any additional, commercial use. In the event of justified complaints, we will repair the faulty device at our discretion or replace it with a trouble-free device. Any pending faults must be reported within 14 days of delivery. All further claims are excluded. To enforce a guarantee claim, please contact us prior to returning the device (always provide us with proof of purchase).
