USER MANUAL PSKO 24 B2 PARKSIDE

IE NI QUIET COMPRESSOR Operating and Safety Instructions Translation of Original Operating Manual

1. Explanation of the symbols on the device

GB IE NI Read the operating and safety instructions before start-up and follow them! GB IE NI Wear hearing protection. Excessive noise can result in a loss of hearing. GB IE NI Wear respiratory protection. GB IE NI Warning against hot parts! (A fig. 10) GB IE NI Warning against electrical voltage GB IE NI Warning! The equipment is remote-controlled and may start-up without warning. GB IE NI Observe warnings and safety instructions! GB IE NI Do not expose the machine to rain. The device may only be stationed, stored and operated in dry ambient conditions. GB IE NI Sound power level specified in dB GB IE NI Sound pressure level specified in dB3GB/IE/NI

Manufacturer: scheppach Fabrikation von Holzbearbeitungsmaschinen GmbH Günzburger Straße 69 D-89335 Ichenhausen Dear customer, We hope your new tool brings you much enjoyment and suc- cess. Note: In accordance with the applicable product liability laws, the manufacturer of this device assumes no liability for damage to the device or caused by the device arising from:

• Non-compliance with the operating manual,

• Repairs carried out by third parties, unauthorised specialists.

• Installing and replacing non-original spare parts,

• Application other than specified,

• Failure of the electrical system in the event of the electrical regulations and VDE provisions 0100, DIN 13 / VDE0113 not being observed. Please consider: Read through the complete text in the operating manual before installing and commissioning the device. This operating manual should help you familiarise yourself with your power tool and teach you how to use it for its intended purpose. The operating manual include important instructions for the safe, proper and economic operation of the power tool, for avoiding danger, for minimising repair costs and downtimes and for increasing the reliability and extending the service life of the power tool. In addition to the safety instructions in this operating manual, you must also observe the regulations applicable to the opera- tion of the power tool in your country. Keep the operating manual package with the power tool at all times and store it in a plastic cover to protect it from dirt and moisture. They must be read and carefully observed by all operating personnel before starting the work. The power tool may only be used by personnel who have been trained to use it and who have been instructed with respect to the associated hazards. In addition to the safety instructions in this operating manual and the separate regulations of your country, the generally recognised technical rules relating to the operation of such ma- chines must also be observed. We accept no liability for accidents or damage that occur due to a failure to observe this manual and the safety instructions.

6. Drain screw for condensate

10. Quick coupling (regulated compressed air)

11. Quick coupling (regulated compressed air)

4. Scope of delivery

1x air filter 1x supporting foot 2x wheel 1x compressed air hose 1x assembly material 1x operating manual

The compressor is designed to generate compressed air for compressed-air driven tools which can be driven with an air volume of up to approx. 150 l/min (e. g. tire inflator, blow-out pistol and paint spray gun). Due to the limited air output it is not possible to use the compressor to drive tools with very high air consumption (for example orbital sanders, die grinders and hammer screwdrivers). The compressor may only be operated in a dry and well venti- lated indoor space. The machine may only be used in the intended manner. Any use beyond this is improper. The user/operator, not the manu- facturer, is responsible for damages or injuries of any type re- sulting from this.4 GB/IE/NI Please observe that our equipment was not designed with the intention of use for commercial or industrial purposes. We as- sume no guarantee if the equipment is used in commercial or industrial applications, or for equivalent work.

6. Safety information

General power tool safety warnings m WARNING! Read all safety warnings, instruc- tions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future ref- erence. The term “power tool” in the warnings refers to your mains- operated (corded) power tool or battery-operated (cordless) power tool. Work area safety a. Keep work area clean and well lit. Cluttered or dark areas invite accidents. b. Do not operate power tools in explosive atmos- pheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. c. Keep children and bystanders away while op- erating a power tool. Distractions can cause you to lose control. Electrical safety a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of elec- tric shock if your body is earthed or grounded. c. Do not expose power tools to rain or wet condi- tions. Water entering a power tool will increase the risk of electric shock. d. Do not use the cable for another purpose, for example, carrying or hanging the power tool or pulling the plug out of the socket. Keep the ca- ble away from heat, oil, sharp edges or moving device parts. Damaged or coiled cables increase the risk of an electric shock. e. If you work with a power tool outdoors, only use extension cables that are also suitable for outdoor use. Use of a cord suitable for outdoor use re- duces the risk of electric shock. Only use approved and appropriately identified extension cables for use outdoors. Only use cable reels in the unrolled state. f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply with a trigger current of 30 mA or less. Use of an RCD reduces the risk of electric shock. Personal safety a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medica- tion. A moment of inattention while operating power tools may result in serious personal injury. b. Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce per- sonal injuries. c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f. Dress properly. Do not wear loose clothing or jewellery. Keep hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. Rubber gloves and anti- slip footwear are recommended when working outdoors. Tie long hair back in a hair net. g. If dust extraction and collection devices can be mounted, make sure that they are connected and used properly. Use of dust collection can reduce dust-related hazards. h. Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second. Power tool use and care a. Do not overload the device. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.5GB/IE/NI c. Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjust- ments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d. Store idle power tools out of the reach of chil- dren and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. Un- used power tools should be stored in a dry, elevated or closed location out of the reach of children. e. Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired be- fore use. Many accidents are caused by poorly maintained power tools. f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control. g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation. h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and con- trol of the tool in unexpected situations. Service a. Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Compressor safety warnings m Attention! The following basic safety measures must be observed when using this compressor for protection against electric shock, and the risk of injury and fire. Read and observe the entire operating manual before using the device. Safe work

1. Take care of your tools

- Keep your compressor clean in order to work well and safely. - Follow the maintenance instructions. - Check the connection cable of the power tool regularly and have it replaced by a recognised specialist when damaged. - Check extension cables regularly and replace them when damaged.

2. Pull the connector out of the socket

- When the power tool is not in use or prior to mainte- nance and when replacing tools such as saw blades, bits, milling heads.

3. Check the power tool for potential damage

- Protective devices or other parts with minor damage must be carefully inspected to ensure that they function correctly and as intended prior to continued use of the power tool. - Check whether the moving parts function faultlessly and do not jam or whether parts are damaged. All parts must be correctly mounted and all conditions must be fulfilled to ensure fault-free operation of the power tool. - Damaged protective devices and parts must be properly repaired or replaced by a recognised workshop, insofar as nothing different is specified in the operating manual. - Do not use any faulty or damaged connection cables.

- For your own safety, only use accessories and additional equipment that are indicated in the operating manual or have been recommended or indicated by the manufac- turer. Use of other tools or accessories that those rec- ommended in the operating manual or in the catalogue could represent a personal danger to you.

5. Replacing the connection line

- If the connection line is damaged, it must be replaced by the manufacturer or an electrician to avoid danger. There is a risk of electric shock.

- Directly after inflating tyres, check the pressure with a suitable pressure gauge, for example at your filling sta- tion.

7. Street-legal compressors in construction site operation

- Ensure that all hoses and fixtures are suitable for the maximum permissible working pressure of the compres- sor.

- Only set up the compressor on a flat surface.

9. In case of pressures above 7 bar, it is recommended to

equip supply hoses with a safety cable (e. g. a wire rope).

10. Avoid over-stressing the piping system by using flexible

hose connections to prevent kinking. Additional safety warnings Observe the corresponding operating manuals of the respective compressed air tools / compressed air attachments! The following general warnings must also be observed. Safety warnings for working with compressed air and blasting guns

• Ensure there is sufficient distance to the product, at least

2.50 m, and keep the compressed air tools / compressed

air attachments away from the compressor during operation.

• The compressor pump and lines can become very hot during operation. Touching these parts will burn you.

• The air which is sucked in by the compressor must be kept free of impurities that could cause fires or explosions in the compressor pump.

• When releasing the hose coupling, hold the hose coupling piece with your hand. This way, you can protect yourself against injury from the rebounding hose.6 GB/IE/NI

• Wear safety goggles and a respirator when working with the compressed air pistol. Dusts are harmful to health! In- juries can be easily caused by foreign objects and blown away parts.

• Do not blow at people with the blow-out pistol and do not clean clothes while being worn. Danger of injury! Safety warnings when using spraying attach- ments (e. g. paint sprayers)

• Keep the spray attachment away from the compressor when filling so that no liquid comes into contact with the compressor.

• Never spray in the direction of the compressor when using the spraying attachments (e.g. paint sprayers). Moisture can lead to electrical hazards!

• Do not process any paints or solvents with a flash point be- low 55 °C. Risk of explosion!

• Do not heat up paints or solvents. Risk of explosion!

• If hazardous liquids are processed, wear protective filter units (face guards). Also, adhere to the safety information provided by the manufacturers of such liquids.

• The details and designations of the Ordinance on Hazard- ous Substances, which are displayed on the outer packaging of the processed material, must be observed. Additional pro- tective measures are to be undertaken if necessary, particu- larly the wearing of suitable clothing and masks.

• Do not smoke during the spraying process and/or in the work area. Risk of explosion! Paint vapours are easily com- bustible.

• Never set up or operate the equipment in the vicinity of a fire place, open lights or sparking machines.

• Do not store or eat food and drink in the work area. Paint vapours are harmful to your health.

• The work area must exceed 30 m³ and sufficient ventilation must be ensured during spraying and drying.

• Do not spray against the wind. Always adhere to the regula- tions of the local police authority when spraying combustible or hazardous materials.

• Do not process media such as white spirit, butyl alcohol and methylene chloride with the PVC pressure hose. These media will destroy the pressure hose.

• The work area must be separated from the compressor so that it cannot come into direct contact with the working medium. Operation of pressure vessels

• Anyone who operates a pressure vessel must keep this in good working order, operate and monitor it correctly, per- form the necessary maintenance and servicing works imme- diately and implement safety measures as required accord- ing to the circumstances.

• The regulatory authority can instruct necessary monitoring measures in individual cases.

• A pressure vessel must not be operated if it exhibits a defect that poses a danger to personnel or third parties.

• Check the pressure vessel for rust and damage each time before use. The compressor shall not be operated if the pres- sure vessel is damaged or rusty. If you discover damage, please contact the customer service workshop. Keep these safety instructions in a safe place. Residual risks Comply with the stipulated maintenance and safety instructions in the operating instructions. Remain attentive at all times when working, and keep third par- ties at a safe distance from your work area. Even when the device is being used properly, there will always be certain residual hazards that cannot be completely ruled out. The following potential hazards can arise due to the type and design of the device:

• Unintentional starting up of the product.

• Damage to hearing if the stipulated hearing protection is not worn.

• Dirt particles, dust etc. can get irritate the eyes or face de- spite wearing safety goggles.

• Inhaling swirled up particles. Warning! This power tool generates an electromagnetic field during op- eration. This field can impair active or passive medical implants under certain conditions. In order to prevent the risk of serious or deadly injuries, we recommend that persons with medical implants consult with their physician and the manufacturer of the medical implant prior to operating the power tool.

8. Before commissioning

• Open the packaging and carefully remove the device.

• Remove the packaging material, packaging and transport safety devices (if applicable).

• Check that the delivery is complete.

• Check the device and accessory parts for transport damage.

• If possible, keep the packaging until the end of the warranty period.7GB/IE/NI DANGER The device and the packaging are not children‘s toys! Do not let children play with plastic bags, films or small parts! There is a danger of choking or suffocating!

• Before connecting the machine, make certain that the data on the type plate matches with the mains power data.

• Check the device for transport damage. Report any damage immediately to the transport company which was used to deliver the compressor.

• Install the compressor near the point of consumption.

• Avoid long air lines and supply lines (extension cables).

• Make sure that the intake air is dry and free of dust.

• Do not install the compressor in a damp or wet room.

• The compressor may only be used in suitable rooms (with good ventilation and an ambient temperature from +5 °C to 40 °C). There must be no dust, acids, vapours, explosive gases or inflammable gases in the room.

• The compressor is designed to be used in dry rooms. It is prohibited to use the compressor in areas where work is con- ducted with sprayed water.

• The compressor may only be used outdoor briefly when the ambient conditions are dry.

• The compressor must always be kept dry and must not be left outdoors after work is complete.

9. Attachment and operation

m Attention! Always make sure the device is fully assembled before commissioning! You require the following for assembly: 1x open-ended spanner 14 mm 1x Phillips screwdriver (not included in the scope of delivery)

9.1 Fitting the wheels (fig. 3)

• Fit the supplied wheels (5) as shown.

9.2 Installing the supporting foot (fig. 4)

• Fit the supplied supporting foot (7) as shown.

9.3 Installing the air filter (fig. 5, 6)

• Remove the transport lid (16) and screw the air filter (4) to the equipment.

• Insert the hose (4d) into the opening of the air filter (4).

9.4 Mains connection

• The compressor is equipped with a mains cable with protec- tive contact plug. This can be connected to any 230 V∼ 50 Hz protective contact socket, with fuse protection of at least 16A.

• Before you use the machine, make sure that the mains volt- age is the same as the operating voltage and the machine power on the rating plate.

• Long supply cables, extensions, cable reels, etc. cause a drop in voltage and can impede motor start-up.

• At low temperatures below +5 °C, sluggishness may make starting difficult or impossible.

9.5 On/Off switch (fig. 1)

• Pull the On/Off switch (3) upwards to switch on the com- pressor.

• To switch off the compressor, press the On/off switch (3) down.

9.6 Setting the pressure (fig. 1, 2)

• Use the pressure regulator (15) to set the pressure on the pressure gauge (12).

• The pressure set can be drawn from the quick couplings (10, 11).

• The vessel pressure can be read off at the pressure gauge (13).

9.7 Setting the pressure switch (fig. 1)

• The pressure switch (2) is set at the factory. Cut-in pressure approx. 5.5 bar Cut-out pressure approx. 8 bar

9.8 Fitting the compressed air hose (fig. 1, 2)

• Connect the plug nipple (14a) of the compressed air hose (14) to one of the quick couplings (10, 11). Then attach the compressed air tool to the quick coupling (14b) of the compressed air hose (14).

9.9 Thermal protector

The thermal protector is built into the device. If the thermal protector has tripped, proceed as follows:

• Pull out the mains plug.

• Wait about two to three minutes.

• Plug the device in again.

• If the device does not start, repeat the process.

• If the device does not start again, switch the device off and on again using the on/off switch (3).

• If you have carried out all of the steps above and the device still does not work, contact our service team.

10. Electrical connection

The electrical motor installed is connected and ready for operation. The connection complies with the applicable VDE and DIN provisions. The cus- tomer‘s mains connection as well as the extension cable used must also comply with these regula- tions. When working with spray attachments and during temporary use outdoors, the device must be connected to a residual current circuit breaker with a trigger current of 30 mA or less.

10.1 Important information

In the event of overloading, the motor will switch itself off. After a cool-down period (time varies) the motor can be switched back on again.

10.2 Damaged electrical connection cable

The insulation on electrical connection cables is often dam- aged. This may have the following causes:

• Pressure points, where connection cables are passed through windows or doors.8 GB/IE/NI

• Kinks where the connection cable has been improperly fas- tened or routed.

• Places where the connection cables have been cut due to being driven over.

• Insulation damage due to being ripped out of the wall outlet.

• Cracks due to the insulation ageing. Such damaged electrical connection cables must not be used and are life-threatening due to the insulation damage. Check the electrical connection cables for damage regularly. Ensure that the connection cables are disconnected from elec- trical power when checking for damage. Electrical connection cables must comply with the applicable VDE and DIN provisions. Only use connection cables of the same designation. The printing of the type designation on the connection cable is mandatory.

• Extension cables up to 25 m long must have a cross-section of 1.5 mm

Connections and repair work on the electrical equipment may only be carried out by electricians. Please provide the following information in the event of any enquiries:

• Type of current for the motor

• Data of machine type plate

• Data of motor type plate

11. Cleaning, maintenance and storage

m Attention! Pull out the mains plug before carrying out any cleaning and maintenance work! Risk of injury from electric shock! m Attention! Wait until the equipment has cooled down completely! Danger of burning! m Attention! Always depressurise the equipment before carrying out any cleaning and maintenance work! Danger of injury!

• Keep the device as free of dust and dirt as possible. Rub the device clean with a clean cloth or blow it off with com- pressed air at low pressure.

• We recommend that you clean the device directly after every use.

• Clean the device at regular intervals using a damp cloth and a little soft soap. Do not use aggressive cleaning agents or solvents; they could attack the plastic parts of the device. Make sure that no water can penetrate the device interior.

• The hose and injection tools must be disconnected from the compressor before cleaning. The compressor must not be cleaned with water, solvents or similar.

11.2 Maintaining the pressure vessel (fig. 1)

Attention! To ensure a long service life for the pressure vessel (8), drain off the condensate after each use by opening the drain screw (6). Release the vessel pressure first (see 11.6.1). Open the drain screw (6) by turning it anti-clockwise (looking at the screw from the bottom of the compressor). In order to drain the condensation water completely out of the pressure vessel (8), it must be tilted slightly to the side so that the drain screw (16) is the lowest point. Then close the drain screw (6) again (turn it clockwise). Check the pressure vessel (8) for rust and damage each time before use. Do not use the compressor with a damaged or rusty pressure vessel (8). If you discover damage, please contact the customer service workshop.

11.3 Safety valve (fig. 7)

The safety valve (9) has been set for the highest permitted pres- sure of the pressure vessel (8). It is not permitted to adjust the safety valve (9) or remove the connection lock (9b) between the exhaust nut (9a) and its cap (9c). Actuate the safety valve (9) every 30 operating hours but at least 3 times a year to ensure that it works when required. Turn the perforated exhaust nut (9a) counterclockwise to open it and use your hands to pull the valve rod outwards over the perforated exhaust nut (9a) to open the outlet of the safety valve (9). Now, the valve audibly releases air. Then, tighten the exhaust nut (9a) clockwise again.

11.4 Cleaning the air filter (fig. 8, 9)

The air filter (4) prevents dust and dirt being sucked in. It is es- sential to clean this air filter (4) after at least every 300 hours in service. A blocked air filter (4) significantly reduces the com- pressor power. Turn the air filter (4) counterclockwise to remove it. Open the filter cover (4c) and remove it. You can now take out the filter element (4b). Carefully tap out the filter element (4b), the filter cover (4c) and the filter housing (4a). These components must then be blown out with compressed air (approx. 3 bar) and reassembled in reverse order.

11.5 Service information

With this product, it is necessary to note that the following parts are subject to natural or usage-related wear, or that the follow- ing parts are required as consumables. Wearing parts*:air filter

• may not be included in the scope of supply!

m Attention! Pull out the mains plug and ventilate the equip- ment and all connected pneumatic tools. Store the compressor in such a way that it cannot be used by unauthorised persons. m Attention! Store the compressor only in a dry location which is not accessible to unauthorised persons. Always store upright, never tilted!9GB/IE/NI

11.6.1 Releasing excess pressure

Release the excess pressure by switching off the compressor and using the compressed air which is still left in the pressure vessel (8), e. g. with a compressed air tool running in idle mode or with a blow-out pistol.

Use the transport handle (1) to transport the device, and drive the compressor with it. When lifting the compressor, note its weight (see Technical data). Ensure that the load is well secured when transporting the com- pressor in a motor vehicle.

13. Disposal and recycling

The device is supplied in packaging to avoid transport dam- ages. This packaging is raw material and can thus be used again or can be reintegrated into the raw material cycle. The device and its accessories are made of different materi- als, such as metals and plastics. Take defective components to special waste disposal sites. Check with your specialist dealer or municipal administration! The packaging is wholly composed of environmen- tally-friendly materials that can be disposed of at a local recycling centre. Contact your local refuse disposal authority for more details of how to dispose of your worn-out electrical devices. Old devices must not be disposed of with house- hold waste! This symbol indicates that this product must not be dis- posed of together with domestic waste in compliance with the Directive (2012/19/EU) pertaining to waste electrical and electronic equipment (WEEE). This prod- uct must be handed over at the intended collection point. This can be done, for example, by returning it when purchasing a similar product or delivering it to an authorised collection point for the recycling of old electrical and electronic devices. Im- proper handling of waste equipment may have negative conse- quences for the environment and human health due to poten- tially hazardous substances that are often contained in electrical and electronic equipment. By properly disposing of this product, you are also contributing to the effective use of natural resources. You can obtain information on collection points for waste equipment from your municipal administration, public waste disposal authority, an authorised body for the dis- posal of waste electrical and electronic equipment or your waste disposal company.10 GB/IE/NI

Fault Possible cause Remedy The compressor does not start. Mains voltage is not available. Check the cable, mains plug, fuse and socket. Mains voltage is too low. Make sure that the extension cable is not too long. Use an extension cable with large enough wires. Outside temperature is too low. Never operate with an outside temperature of below +5 °C. Motor is overheated. Allow the motor to cool down. If necessary, remedy the cause of the overheating. The compressor starts but there is no pressure. The safety valve leaks. Contact your local service centre. Only allow qualified personnel to carry out repairs. The seals are damaged. Check the seals and have any damaged seals replaced by a service centre. The drain screw for condensate leaks. Tighten the screw by hand. Check the seal on the screw and replace if necessary. The compressor starts, pressure is shown on the pressure gauge, but the tools do not start. The hose connections have a leak. Check the compressed air hose and tools and replace if necessary. A quick coupling has a leak. Contact your local service centre. Only allow qualified personnel to carry out repairs. Insufficient pressure set on the pressure regula- tor. Increase the set pressure with the pressure regulator.11GB/IE/NI

15. Warranty certificate

Dear Customer, All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that your device devel- ops a fault, please contact our service department at the address shown on this guarantee card. Of course, if you would prefer to call us then we are also happy to offer our assistance under the service number printed below. Please note the following terms under which guarantee claims can be made:

• These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights. We do not charge you for this guarantee.

• Our guarantee only covers problems caused by material or manufacturing defects, and it is restricted to the rectification of these defects or replacement of the device. Please note that our devices have not been designed for use in commercial, trade or industrial applications. Consequently, the guarantee is invalidated if the equipment is used in commercial, trade or industrial applications or for other equivalent activities. The following are also excluded from our guarantee: compensation for transport damage, damage caused by failure to comply with the installation/assembly instructions or damage caused by unprofessional installation, failure to comply with the operating instruc- tions (e.g. connection to the wrong mains voltage or current type), misuse or inappropriate use (such as overloading of the device or use of non-approved tools or accessories), failure to comply with the maintenance and safety regulations, ingress of foreign bodies into the device (e.g. sand, stones or dust), effects of force or external influences (e.g. damage caused by the device being dropped) and normal wear resulting from proper operation of the device. The guarantee is rendered null and void if any attempt is made to tamper with the device.

• The guarantee is valid for a period of 3 years starting from the purchase date of the device. Guarantee claims should be submitted be- fore the end of the guarantee period within two weeks of the defect being noticed. No guarantee claims will be accepted after the end of the guarantee period. The original guarantee period remains applicable to the device even if repairs are carried out or parts are re- placed. In such cases, the work performed or parts fitted will not result in an extension of the guarantee period, and no new guarantee will become active for the work performed or parts fitted. This also applies when an on-site service is used.

• In order to assert your guarantee claim, please contact the service partner shown below. If the complaint is within the guarantee period, we will provide you with a return slip, with which you can return your defective device free of charge to us. It would help us if you could describe the nature of the problem in as much detail as possible. If the defect is covered by our guarantee then your device will either be repaired immediately and returned to you, or we will send you a new device. Of course, we are also happy offer a chargeable repair service for any defects which are not covered by the scope of this guarantee or for units which are no longer covered. To take advantage of this service, please send the device to our service address. Service-Hotline (GB/IE/NI):

• The object of the declaration described above fulfils the regulations of the directive 2011/65/EU of the European Parliament and Council from 8th June 2011, on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

• Der oben beschriebene Gegenstand der Erklärung erfüllt die Vorschriften der Richtlinie 2011/65/EU des Europäischen Parlaments und des Rates vom 8. Juni 2011 zur Beschränkung der Verwendung bestimmter gefährlicher Stoffe in Elektro- und Elektronikgeräten. Ichenhausen, den 02.08.2021 __________________________ Unterschrift / Andreas Pecher / Head of Project Management First CE: 2020 Subject to change without notice Documents registrar: Thomas Schuster Günzburger Str. 69, D-89335 Ichenhausen X 2000/14/EC_2005/88/ECAnnex V Annex VINoise: measured L = 83.7 dB(A); guaranteed L = 86 dB(A)P = KW; L/Ø = cmNotified Body: TÜV SÜD Industrie Service GmbH Westendstrasse 199; 80686 München Notified Body No.: 00362010/26/ECEmission. No: X 2006/42/EC Annex IVNotified Body: Notified Body No.: Certificate No.: Standard references: EN 1012-1:2010; EN 60204-1:2018; EN 61000-6-1:2007; EN 61000-6-3:2007/A1:2011; EN 50581:2012; EN 286-1:1998/A1:2002 Brand / Marke: Parkside Article name: QUIET COMPRESSOR - PSKO 24 B2 Art.-Bezeichnung: LEISE-KOMPRESSOR - PSKO 24 B2 Art. no. / Art.-Nr.: 3906146974-3906146980; 39061469915-39061469916 Ident. no. / Ident.-Nr.: 01001-94173 This declaration of conformity is issued under the sole responsibility of the manufacturer. Die alleinige Verantwortung für die Ausstellung dieser Konformitätserklärung trägt der Hersteller. CE Declaration of Conformity Translation of the original CE declaration of conformity CE-Konformitätserklärung Originalkonformitätserklärung

17. Declaration of conformity
