USER MANUAL Electa Amator III Sonus Faber

5 SMALTIMENTO Rischio di danni al mobile del diffusore! Non usare prodotti per la pulizia, cere per mobili, liquidi detergenti o alcool. Non usare panni ruvidi. Questo apparecchio contiene materiali che possono inquinare se dispersi nell’ambiente. Consegnare l’apparecchio da smaltire ad un centro per la raccolta differenziata.. ITALIANO8 ENGLISH 1 GENERAL INFORMATION Dear Customer, We would like to thank and congratulate you for having chosen Electa Amator III speakers for listening to your favourite Music. Electa Amator III speakers are deigned to immediately meet our customers’ highest expectations. As our aim is to ensure you get the best possible listening result in full safety, please read this instruction manual carefully before installation. Should you have any doubts or enquiries, please contact your sales point’s technical staff, the ofcial Sonus Faber distributor in your country, or Sonus faber directly by writing to [e-mail]. Finally, we highly suggest registering online with the website www.sonusfaber.comin order to keep up to date on all the latest news, initiatives and promotions offered by Sonus faber. Enjoy your music! 1 General information 8

1.1 Information for users 8

1.2 Warranty and after sales support 9

1.3 Declaration of conformity 9

3.1.1 Content of the packaging 11

3.3 Speakers in the environment 11

4 Maintenance and cleaning 13 5 Disposal 13 6 Technical specications 26 7 Support drawings 27

1.1 INFORMATION FOR USERS

SUMMARY9 ENGLISH Sonus faber SpA with headquarter in Via Antonio Meucci, 10 - 36057 Arcugnano (VI) Italy, declare under our sole responsibility that Electa Amator III to which this declaration relates is in conformity to: Directive: 2014/30/EC (EMC) Electromagnetic compatibility. 2011/65/EU (RoHS) Restriction of the use of certain hazardous substances in electrical and electronic equipment. 2012/19/EU (WEEE) Waste electrical and electronic equipment. 2006/1907/EC (REACH) Registration, Evaluation, Authorisation and Restriction of Chemical. 2001/95/UE (GPSD) General product safety. Standards: EN 62368-1:2017 Audio/video, information and communication technology equipment – Part 1: Safety requirements. EN 55013:2013 EN 55020:2015 EN 61000-6-1:2013 EN 61000-6-3:2012 Arcugnano, 01/08/2018 CEO Jeff Poggi

CONFORMITY WITH INTERNATIONAL STANDARDS

EN 62368-1:2014 Audio/video, information and communication technology equipment – Part 1: Safety requirements

UL 62368-1:2014 Audio/video, information and communication technology equipment – Part 1: Safety requirements

Audio/video, information and communication technology equipment – Part 1: Safety requirements

FCC Rules Code of Federal Regulations Title 47 - Telecommunications - Part 15 - Radio Frequency Devices: Subpart B - Unintentional Radiators. CARB California Air Resources Board: code of regulation ATCM 93120 phase 2 compliant for formaldehyde emission

1.3 DECLARATION OF CONFORMITY

Electa Amator III loudspeakers are designed and manufactured according to the highest quality standards. Should however a fault or a malfunction occur, the loudspeakers are covered by warranty, in compliance with the regulations in force in the country where the loudspeakers were purchased. In such cases, please contact the Sonus faber dealer from whom you purchased your loudspeakers, or the ofcial Sonus Faber distributor for your country; the contact information for all the distributors can be found on our website:

• https://www.sonusfaber.com/distributori-store/

• https://www.sonusfaber.com/en/distributors-stores/ The following should also be kept in mind for your convenience:

• The warranty on the loudspeakers covers any manufacturing defects;

• Keep the receipt as proof of purchase to show to the retailer if necessary;

• Keep the loudspeakers’ original packaging so that they can be transported without suffering damage if they need to be shipped to an authorised service centre;

• The loudspeakers must be accompanied by a description of the malfunction or defect encountered. The product’s warranty will be void under the following conditions:

• If the product has been disassembled or modied by persons other than a Sonus Faber authorised service centre;

• If the product has been used in a manner that is not consistent with the indications contained within this manual

• This instruction manual must be read carefully and kept in an accessible location for any needs that may arise.

• Adjust the stand support feet, when used, in such a way as to obtain the best possible stability.

• Avoid placing heavy objects upon the loudspeaker, as these can compromise its stability.

• If the loudspeakers are to be positioned upon a raised support surface (e.g. mezzanines, wooden boosters, etc.), check beforehand to make sure that the surface is capable of bearing the weight. Also make sure that there is sufcient friction to prevent the loudspeakers from moving due to the vibrations from it generated under normal operating conditions.

• Do not place any objects containing ammable liquids, substances, or liqueable substances upon the loudspeaker.

• Use one of the connection diagrams contained in this instruction manual. The connection of two or more loudspeakers in parallel can damage your amplier. If in doubt, contact your dealer.

• Avoid staying in close proximity to the loudspeakers while the audio system is operating at high volume. This can cause permanent damage to your hearing. Children must be kept at a safety distance of least 50 cm from the loudspeaker.

• The speakers generate an electromagnetic eld that is harmless to humans and pets, but can compromise the proper functionality of electronic equipment, such as CRT monitors or TVs, when placed in close proximity. If this occurs, increase the equipment’s distance from the loudspeakers. Do not place credit cards or other similar magnetic stripe cards on the loudspeaker.

• The technology underlying the speakers’ functionality is based on the principles of electromagnetism, and the user should therefore avoid operating equipment that generates strong electromagnetic elds, as these could affect the loudspeaker’s proper functionality. Avoid placing transmitting devices such as mobile phones, cordless phones, intercom systems etc. on top of the loudspeakers.

• Do not connect the loudspeakers directly to a constant voltage sound distribution system (100 V, 70.7 V or similar). This could result in a serious system overload, with possible damage to the loudspeaker and/or the amplier.

• Do not place audio cables and electrical power cables in close proximity to one another. An electromagnetic eld is present in the vicinity of the power cables, which can cause an unpleasant humming noise. If this should occur, move the audio cables and electrical power cables away from each other. 2 SAFETY INFORMATION 3 INSTALLATION Proceed with unpacking as indicated below, making reference to the images in Chapter 7, Figure 1 A, B, C and D: Respect the following general indications:

• Use a paper cutter to open the packaging. Do not insert the blade too deep to avoid damaging the contents.

• Keep all the packaging elements for any future transport operations.

• Do not wear any watches, bracelets, rings, etc., in order to avoid scratching the loudspeakers and their nishes. The same care must be taken in order to protect the loudspeakers from any metal elements present on the clothes you are wearing, such as zippers, buttons, belt clasps, rivets, etc.

Hold the loudspeaker securely with both hands in order to avoid dropping it. The indicated operations can be performed more safely and conveniently by two people. The packaging materials can cause pollution. These materials must not be disposed of as domestic waste, and must be brought to a waste collection and recycling centre. Do not leave the packaging materials within the reach of children! They could pose a risk of poisoning or suffocation if ingested.11 ENGLISH As well as the pair of speakers, the packaging also includes:

• 2 Fabric dust guards

• 4 Decoupling silicone feet The following accessories are contained in the package dedicated to the stand:

• 4 Locking screws If one or more of these items is missing, notify the retailer from whom the product was purchased. Refer to the images contained in Chapter 7, Figure 2, 3 and 4. The Electa Amator III Speakers are designed to be easily inserted within the listening environment. In order to obtain excellent performance, refer to the images in Chapter 7, Figure 5 and 6. The conformation of the listening environment and the loudspeakers’ positioning can affect the entire audio system’s performance. For example, basically, a room with irregular shape can improve the response within the listening environment, since they limit the formation of standing waves, while a room with a parallelepiped shape is potentially more suitable to generate balanced sound images. The presence of carpets and curtains positively affect the acoustics of the environment, contributing to the absorption of the rst reections and the lowering of reverberation. There are no xed and universally-applicable rules for every environment. Nevertheless, one good approach to positioning the loudspeakers within the listening environment is to start by dividing the listening environment’s oor plan, assuming a rectangular shape, into three areas with equal surface, as indicated by the dotted lines in Figure 5. Position the loudspeakers on the rst line (A), at an adequate distance from the lateral walls, and position the listening point on the second line (B). In this way, undesired acoustic effects, deriving from intense rst reections, which would be generated with loudspeakers positioned in proximity of the walls and corners of the room, are minimised. Figure 6 shows how the loudspeakers’ axis should converge toward the listening position by crossing over top of it, thus creating the classic “isosceles triangle” stereophonic conguration. This measure, which consists in positioning the loudspeakers in such a way as to literally point them towards the listener’s ears, allows signicant improvement in the focus of the stereophonic image. Given that the illustrated procedure, which is aimed at creating quasi-ideal listening conditions, cannot be applied by all of our customers due to objective problems linked to the organization of the living environment, it is recommended to position the two loudspeakers away from the corners of the room, and at a distance of at least 1 m from the end walls. The two loudspeakers should be at least 1.8 metres apart from each other. The listening point should be at a height of approximately 1.1 metres off the ground. The distance between the loudspeakers themselves, and between the loudspeakers and the listening point, can be subsequently adjusted as desired.

ENGLISH Refer to the images in Chapter 7, Figure 7, 8 and 9. After the loudspeakers have been positioned, their connections must be completed. The terminals allow for connections using cables with spade terminals, stripped cable, or banana plugs. The Electa Amator III loudspeakers’ terminals are equipped with jumpers, which allow the loudspeakers to be connected as follows. Depending on the pre-selected method of connection, said jumpers may have to be removed. The accurate tightening and periodic inspection of the terminals can help to improve performance. Use a single stereo amplier or one pre-ampliers coupled with a pair of power cables. Make the connections as indicated in Figure 7. This connection layout serves to increase the overall sound quality, particularly the regarding detail resolution at low frequencies. Use a single stereo amplier or one pre-amplier coupled with two pairs of power cables. Remove the jumpers between the terminals and make the connections as indicated in Figure 8. Bi-amplication generally improves the sound quality, and particularly ensures greater dynamics and control of the bass frequencies. Use two stereo ampliers or one pre-amplier (of the same brand and model, if possible) and two pairs of power cables. Remove the jumpers between the terminals and make the connections as indicated in Figure 9.

The connections must be made with the equipment turned off!13 ENGLISH The Electa Amator III loudspeakers do not require any particular maintenance operations, except for periodic general cleaning. In order to preserve the loudspeakers’ nish, cover them with the supplied fabric dust-protection sheet, especially if the loudspeakers are not expected to be used for an extended period of time. Disposal of the electrical and electronic equipment. Directives WEEE 2012/19/EU - RoHS 2011/65/EU. The crossed-out waste bin symbol shown on the equipment indicates that the product must be disposed of separately from household waste at the end of its service life. The user is responsible for bringing the equipment to an appropriate waste collection facility at the end of its service life. The separate disposal of the decommissioned equipment for recycling, treatment and disposal in compliance with the current environmental protection regulations will help prevent potential negative consequences for the environment and human health, and will allow for the recycling of the materials and components of which the product is comprised. For more detailed information regarding the collection systems available in your area, please contact your local waste disposal service or the shop/dealer where you purchased the product. Do not use products like waxes or detergents to clean the wood parts, as these could stain or damage the wood or the loudspeakers themselves. Use a soft cloth (e.g. microbre, like that supplied), and moisten it slightly with the liquid supplied in the cleaning kit, if necessary. Wood is a natural living material that can be affected by the environmental conditions. We recommend positioning the loudspeakers away from heat sources or windows, above all during the summer months. Avoid exposing the loudspeakers to direct sunlight. Use a soft brush to eliminate any dust that may have accumulated on the cabinet, the front panels, and the loudspeakers themselves, taking care not to damage the loudspeakers’ delicate membranes. To clean the marble parts of the base of the speaker and the base of the stand, it is recommended to use a cloth dampened in water or common liquid neutral detergents with low alkaline content. Do not use aggressive strong chemical products such as acetone, trichloroethylene, acids, abrasive agents, strong de-greasers, alcohol, lemon or wine. These measures will help you to keep your loudspeakers’ working perfectly for years to come. Time will help improve the sound by breaking in the speakers’ moving parts (membranes and suspensions), and the acoustic chamber will become accustomed to music being played the more it is used - much like what happens with acoustic string instruments!

• 4 Entkoppelnde Silikonfüße The following accessories are contained in the package dedicated to the stand:
