USER MANUAL Feetmaster Klarfit

Dear Customer, Congratulations on purchasing this device. Please read the following instructions carefully and follow them to prevent possible damages. We assume no liability for damage caused by disregard of the instructions and improper use. Scan the QR code to get access to the latest user manual and more product information. CONTENT Safety Instructions 14 Device overview 16 Commissioning and Operation 17 Troubleshooting 19 Disposal Considerations 20 Manufacturer & Importer (UK) 20 TECHNICAL DATA Item number 10031106, 10031107 Power supply 12 V / DC Power consumption 36 W14

SAFETY INSTRUCTIONS General instructions

• Read the safety instructions carefully before use.

• Children from the age of 8, physically and physically impaired persons should only use the device if they have been familiarized in detail with the functions and safety precautions by a supervisor beforehand.

• Make sure that children do not play with the device.

• The unit contains a heater, therefore surfaces may become hot during operation. Persons who are sensitive to heat should use the device with caution.

• If the power cord or plug is damaged, it must be replaced by the manufacturer, an authorized service center or a similarly qualied person.

• If the housing is damaged, do not use the device. Contact a specialist company or the manufacturer for repair.

• Unplug the unit from the wall outlet after use and before cleaning.

• Do not cover the unit during massage to prevent the motor from overheating and breaking.

• If you feel uncomfortable during the massage, stop the massage immediately.

• If the device does not work properly, have it checked by a professional.

• Use only parts that are specically recommended by the manufacturer.

• Do not insert any objects into the foot opening of the massager.

• Do not touch the control panel of the device with wet hands.

• When you want to stop the massage, stop the device rst before unplugging it from the power outlet.

• This device is not intended for self-treatment or medical treatment. If you need medical treatment, consult a physician.15

Notes on the location

• Do not use the device in very humid or dusty places.

• Do not use the device in rooms where the temperature is higher than 40°C.

• Do not use the device outdoors.

• Do not use the device near electric heaters and stoves and avoid direct sunlight. Groups of people who should consult a doctor before use:

• Persons who feel unwell and are under the treatment of a physician.

• Persons with high blood pressure, heart problems, arteriosclerosis or thrombosis.

• Persons with a malignant tumor.

• Pregnant women or women in the menstrual phase.

• People with osteoporosis.

• Persons with pacemakers.

• Persons who are currently ill. Notes on the duration of use

• You can use the device 1-2 times a day for 5-10 minutes to loosen your muscles and improve blood circulation. Have a massage for 5-15 minutes before going to bed to promote a relaxed sleep. Instructions for safe use

• Do not fall asleep during foot massage.

• Do not use the device in a drunken state or when you are not feeling well.

• Do not use the massager for more than 30 minutes at a time, and do not warm your feet for more than 2 hours at a time.

• If the fabric cover breaks, do not continue to use the device.

• Do not use the device for an hour before eating.

• If the unit is stored in a cold place, move it to a warm place before use to allow condensation to evaporate. Water inside could damage electrical parts of the appliance. Therefore, leave the device in a warm place for at least 1 hour before use.16

DEVICE OVERVIEW 1 Time 2 Mode 3 Intensity 4 Heating 5 Power 6 Massage bag Time: Use this button to set the massage time.

• Blue: massage time is 10 minutes.

• Red: massage time is 15 minutes.

• Blue and red: massage duration is 20 minutes.17

• Mode 1 is preset. Press the key once to enter mode 2. Press the key once more to enter mode 3.

• In mode 1 the blue light is on, in mode 2 the red light is on. In mode 3, the blue and red lights ash alternately.

• In mode 1 and 2 the feet are massaged with the foot roller and the air bag, in mode 3 only with the air bag. Intensity key

• Preset is low intensity. Press the button once to switch to medium intensity. Press the button again to switch to high intensity.

• At low intensity the blue light is on, at medium intensity the green light is on. At high intensity, the red light is on. Heating key

• In the normal state, the heating is on and the blue light is on. To stop the heating function, press the heating key. The light goes off and the heating stops. Power key

• As soon as you insert the plug into the socket, the device is ready for operation and the red light ashes.

• Press the button to start the massage. Preset is: mode 1, heating and fan on. All lights come on. The preset massage time is 10 minutes.

• Once the preset or entered time has elapsed, the unit will return to its original state (red light ashing).

• After the massage, pull the plug out of the socket.18

• When not in use for an extended period of time, store the unit in the carton and keep it in a safe, dry and well-ventilated place.

• Pull the plug out of the socket.

• Do not hang the device by the cable.

• Be careful not to scratch the surface with sharp objects.

• Do not expose the device to direct sunlight or high temperatures. Cleaning

• Make sure to unplug the device from the power outlet before cleaning.

• Clean the surface with a dry cloth. Do not use abrasive cleaners or thinners for cleaning. Care

• Keep the unit away from damp places.

• If you do not use the device for a long time, pack it so that dust cannot accumulate on it.19

TROUBLESHOOTING Error Possible cause Solution The device does not run. No power. Check that the plug is plugged in and that the on switch has been ipped. The function keys do not respond. Press the on switch. The device stops suddenly. No power. Check that the plug is rmly in place. The massage time has ended. Restart the massage by pressing the on switch again. The device has been in operation for too long. Allow the unit to cool down and then restart it. The foot roller is blocked. Keep the soles of your feet loose during the massage. The foot roller is blocked. Keep the soles of your feet loose during the massage.20

DISPOSAL CONSIDERATIONS If there is a legal regulation for the disposal of electrical and electronic devices in your country, this symbol on the product or on the packaging indicates that this product must not be disposed of with household waste. Instead, it must be taken to a collection point for the recycling of electrical and electronic equipment. By disposing of it in accordance with the rules, you are protecting the environment and the health of your fellow human beings from negative consequences. For information about the recycling and disposal of this product, please contact your local authority or your household waste disposal service. MANUFACTURER & IMPORTER (UK) Manufacturer: Chal-Tec GmbH, Wallstrasse 16, 10179 Berlin, Germany. Importer for Great Britain: Berlin Brands Group UK Ltd PO Box 1145 Oxford, OX1 9UW United Kingdom21
