| Product type | Cordless reciprocating saw |
| Brand | Parkside |
| Model | PSSAP 20Li B2 |
| Rated voltage | 20 V |
| Stroke rate | 0 - 3000 min⁻¹ |
| Stroke length | 22 mm |
| Max cutting capacity (wood) | 150 mm |
| Max cutting capacity (steel) | 12 mm |
| Max cutting capacity (non-ferrous metals) | 18 mm |
| Max cutting capacity (metal pipe) | 100 mm |
| Battery type | Lithium-ion, 20 V, 4 Ah (PAP 20 A3) |
| Included charger | Rapid charger PLG 20 B1 (input 230-240 V~, output 21.5 V / 4.5 A) |
| Charging time (4 Ah battery) | 60 minutes |
| Sound pressure level | 87.6 dB(A) (uncertainty 3 dB) |
| Sound power level | 98.6 dB(A) (uncertainty 3 dB) |
| Main features | LED work area lighting, variable speed control, adjustable base plate |
| Safety | Lock-off switch, protection against unintentional starts |
| Included accessories | 1 reciprocating saw, 1 PAP 20 A3 battery, 1 PLG 20 B1 charger, 1 carrying case, 1 instruction manual |
| Product warranty | 5 years |
| Battery warranty | 1 year |
| Maintenance | Clean with a dry cloth, no user maintenance required |
Frequently Asked Questions - PSSAP 20Li B2 PARKSIDE
User questions about PSSAP 20Li B2 PARKSIDE
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Cordless electric saw in PDF format for free! Find your manual PSSAP 20Li B2 - PARKSIDE and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. PSSAP 20Li B2 by PARKSIDE.
USER MANUAL PSSAP 20Li B2 PARKSIDE
AKKU-SÄBELSÄGE 20 V / CORDLESS SABRE SAW 20 V / SCIE SABRE SANS FIL 20 V PSSAP 20-Li B2
DE AT CH
AKKU-SÄBELSÄGE 20 V
Operation and safety notes
Translation of the original instructions
FR BE
SCIE SABRE SANS FIL 20 V
GB/IE Operation and safety notes Page 24
Warnings and symbols used 25
Introduction. 25
Intended use. 25
Scope of delivery. 26
Parts description. 26
Technical data 26
Safety instructions. 28
General power tool safety warnings. 28
Reciprocating saws safety warnings 31
Vibration and noise reduction. 33
Behaviour in emergency situations. 33
Residual risks 33
Battery charger safety warnings 34
Before first use. 34
Accessories 34
Operation 35
- Attaching/removing the battery pack 35
Checking the battery pack charging level 35
Charging the battery pack. 35
Adjusting the base plate. 36
Inserting/removing the saw blade. 36
Switching on and off 37
Speed control. 37
LED work light 37
Trial run 38
Working instructions 38
Cleaning and care 39
Cleaning. 39
Maintenance. 39
Repair. 39
Storage 40
Transportation 40
Disposal. 40
Warranty 41
EC declaration of conformity 42
| Warnings and symbols used The following warnings are used in this instruction manual, on the packaging and on the rating label: | |||
| Read the instruction manual. | Switch the product off and remove the battery pack before replacing attachments, cleaning and when not in use. | ||
| Follow the warnings and safety notes! | max. 45°C | Protect the battery pack against heat and continuous intense sunlight. | |
| Use in dry indoor rooms only. | Protect the battery pack against water and moisture. | ||
| Wear protective gloves! Protect the battery | pack from fire. | ||
| Wear hearing protection! Protection class II (double insulation) | |||
| Wear eye protection! | ~ | Alternating current | |
| - | Direct current | ||
| T3.15A | Fuse | ||
CORDLESS SABRE SAW 20 V PSSAP 20-Li B2
Introduction
We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.
Intended use
This cordless sabre saw (hereinafter "product" or "power tool") is designed for light and medium sawing through wood, chip board, plastic, metal, and plaster board.
The product is not intended to handle heavy sawing work, such as in stones or in workpieces exceeding the maximum cutting capacity (see "Technical data").
Always use the correct saw blades according to the intended use! Observe the technical requirements of this product (see "Technical data") when purchasing and using saw blades!
The LED work light 10 on this product is intended to illuminate the immediate work area.
Any other use or modification of the product are considered improper use and can result in hazards such as death, life-threatening injuries and damage. The manufacturer is not liable for any damages caused by improper use. The product is not intended for commercial use or for any other use.
Scope of delivery
WARNING!
The product and the packaging are not children's toys! Children must not play with plastic bags, sheets and small parts! There is a danger of choking and suffocation!
1 x Cordless sabre saw 20 V PSSAP 20-Li B2
1× Battery pack PAP 20 A3
1× Rapid battery charger PLG 20 B1
1x Carrying case
1x Instruction manual
Parts description
Figure A:
1 Locking lever
2 Chuck ring
3 Sawblade holder
4 Base plate
5 Switch lock
6 On/off switch/speed control
7 Rear handle
8 Battery pack
9Front handle
10 LED work light
Figure B:
8 Battery pack
11 Release button for battery pack
12 button (charging level)
13 Charging level LEDs (red/orange/green)
Figure C:
14 Battery charger (rapid battery charger)
15 Power cord with power plug
16 Charging control LED - Green
17 Charging control LED - Red
Not illustrated:
18 Carrying case
Technical data
Cordless sabre saw PSSAP 20-Li B2
Rated voltage: 20V
Stroke rate: 0 - 3000 min
Stroke length: 22mm
Saw blade intake: Standard
Maximum cutting capacity:
Wood: 150 mm
Steel: 12 mm
Non-ferrous metal: 18 mm
Metal pipe: 100 mm
Battery pack PAP 20 A3
Type: Lithium-Ion
Rated voltage: 20V max.
Capacity: 4 Ah
Energy value: 72 Wh
Number of cells: 10
Rapid battery charger PLG 20 B1
Input:
Rated voltage: 230 - 240V
Rated frequency: 50Hz
Rated power: 120 W
Output:
Rated voltage: 21.5 V
Charging current: 4.5 A
Protection class: II /
Fuse (internal): 3.15 A / T3.15A
Charging time:
Battery type PAP 20 A3, 4.0 Ah (supplied): 60 minutes
Battery type PAP 20 A1, 2.0 Ah (available separately): 45 minutes
Recommended ambient temperature:
While charging: +4 to +40^ C
During operation: +4 to +40^
During storage: +20 to +26 °C
Noise emission value
The measured values have been determined in accordance with EN 62841. The A-rated noise level of the power tool is typically as follows:
Sound pressure level L_pA : 87.6 dB(A)
Uncertainty K_pA 3 dB
Sound power level LwA: 98.6 dB(A)
Uncertainty Kwa: 3 dB
Vibration emission value
Vibration total values (triaxial vector sum)
determined according to EN 62841:
Cutting boards
(with saw blade Bosch S644D)
Main handle:
Hand/arm vibration a_h,8 : 21.26 m/s²
Uncertainty K: 1.5m / s^2
Auxiliary handle:
Hand/arm vibration a_h,8 22.17 m/s²
Uncertainty K: 1.5m / s^2
Cutting wooden beams
(with saw blade Bosch S644D)
Main handle:
Hand/arm vibration a_h,WB : 23.54 m/s²
Uncertainty K: 1.5m / s^2
Auxiliary handle:
Hand/arm vibration a_h,WB : 25.46 m/s²
Uncertainty K: 1.5m / s^2
WARNING!
Wear ear protection!
NOTE
The declared vibration total values and the declared noise emission values have been measured in accordance with a standard test method and may be used for comparing one tool with another.
The declared total vibration values and the declared noise emission values may also be used for a preliminary assessment of exposure.
WARNING!
The vibration and noise emissions during actual use of the power tool can differ from the declared values depending on the manner in which the tool is used, especially what kind of workpiece is processed. Try to minimise exposure to vibration and noise. Examples of measures to reduce vibration include wearing gloves when using the tool and limiting working time. All parts of the operating cycle must be taken into account (e.g. times when the power tool is switched off and when it is running idle in addition to the trigger time).
Safety instructions
- General power tool safety warnings
WARNING!
Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
Work area safety
1) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
3) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
Electrical safety
1) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
2) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
3) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
4) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
5) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
6) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
1) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
2) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
3) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
4) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
5) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
6) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
7) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
8) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
Power tool use and care
1) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
2) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
3) Disconnect the plug from the power source and / or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
4) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
5) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
6) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
7) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
8) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
Battery tool use and care
1) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
2) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
3) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
4) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
5) Do not use a battery pack for tool that is damaged or modified. Damaged or modified batteries exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
6) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130^ may cause explosion.
7) Follow all charging instruction and do not charge the battery pack or tool outside the temperature range specified in the instruction. Charging improperly or at temperatures outside the specified range may damage the battery and increase the risk of the fire.
Service
1) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
2) Never service damaged battery packs. Service of battery packs should be only be performed by the manufactured or authorized service providers.
Reciprocating saws safety warnings
1) Hold the power tool by insulated gripping surfaces when performing an operation where the accessory tool may contact hidden wiring.
Accessory tools contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock.
2) Use clamps or another practical way to secure and support the workpiece to a stable platform. Holding the workpiece by hand or against your body leaves it unstable and may lead to loss of control.
3) Keep hands away from the sawing area. Do not reach underneath the workpiece. Upon contact with the blade there is a risk of injury.
4) Only when the power tool is turned on should the sawing blade be moved against the workpiece. There is a risk of kickback if the accessory tool jams in the workpiece.
5) Make sure that the base plate is securely placed against the workpiece during sawing. The saw blade can tilt and lead to loss of control over the power tool.
6) After you have finished work, turn the power tool off and do not pull the saw blade out of the cut until it has come to a standstill. In this way you will avoid any kickback and can safely put down the power tool.
7) Use only undamaged saw blades in perfect condition. Bent or blunt blades can break, adversely affect the cut or cause kickback.
8) Do not brake the saw blade after switching the product off by applying side pressure. The saw blade may be damaged, break or cause a kickback.
9) Tighten the material firmly. Do not support the workpiece by hand or foot. Do not touch any objects or the ground with the saw running. There is a risk of kickback.
10) Use suitable detectors in order to find hidden supply lines or ask the local utility company. Contact with electrical cables can lead to electric shock and fire, contact with a gas pipe can result in an explosion. Damage to a water pipe can lead to property damaged and electric shock.
11) Hold the power tool tightly with both hands while working and ensure a secure footing. The power tool is guided more securely with both hands.
12) Secure the workpiece. A workpiece that is retained with clamping products or a vice is held more securely than with your hand.
13) Wait until the power tool has stopped before placing it down. The accessory tool can tilt and lead to loss of control over the power tool.
14) Do not saw any materials (e.g. lead-based paints and coatings or materials containing asbestos) whose dust can be harmful.
Vibration and noise reduction
To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibration and low-noise operating modes as well as wear personal protective equipment.
Take the following points into account to minimise the vibration and noise exposure risks:
Only use the product as intended by its design and these instructions.
Ensure that the product is in good condition and well maintained.
Use correct accessory tools for the product and ensure they are in good condition.
- Keep tight grip on the handles / grip surface.
- Maintain this product in accordance with these instructions and keep it well lubricated (where appropriate).
Plan your work schedule to spread any high vibration tool use across a longer period of time.
Behaviour in emergency situations
Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety warnings and follow them to the letter. This will help to prevent risks and hazards.
Always be alert when using this product, so that you can recognise and handle risks early. Fast intervention can prevent serious injury and damage to property.
Switch the product off and disconnect it from the mains if there are malfunctions. Have the product checked by a qualified professional and repaired, if necessary, before you operate it again.
Residual risks
Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product:
Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.
Injuries and damage to property due to broken accessory tools or the sudden impact of hidden objects during use.
Danger of injury and property damage caused by flying objects.
NOTE
This product produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and the medical implant manufacturer before operating this product!
Battery charger safety warnings
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
- Do not charge nonrechargeable batteries. Disregarding this instruction is hazardous.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in to order to avoid a hazard.
- Protect the electrical parts against moisture. Do not immerse such parts in water or other liquids to avoid electrical shock. Never hold the appliance under running water. Pay attention to the instructions provided for cleaning, maintenance and repair.
The appliance is suitable for indoor use only.
■ ATTENTION! This charger is only designed for charging the battery pack types:
Parkside 20 V battery pack
PAP 20 A1 2 Ah 5 cells
PAP 20 A2 3 Ah 10 cells
PAP 20 A3 4 Ah 10 cells
An up-to-date list of battery compatibility can be found at www.lidl.de/akku.
Before first use
Accessories
To operate this product safely and correctly, the following accessories, i.e. tools and saw blades, are necessary:
Suitable saw blade
Accessories and saw blades are available through your authorised dealer. When buying always consider the technical requirements of this product (see "Technical data"). If you are not certain, ask a qualified specialist and get advice from your trusted dealer.
NOTE
This instruction manual contains information and suggestions for several saw blades and their uses. The saw blades depicted are not necessarily included in the shipment, but are meant to indicate additional possibilities for using this product.
Suitable battery packs and chargers
Battery Parkside 20 V battery pack
pack: PAP 20 A1, PAP 20 A2, PAP 20 A3
Charger: Parkside 20 V charger PLG 20 A1, PLG 20 A2, PLG 20 B1, PLG 20 A3
Operation
- Attaching/removing the battery pack
Removing the battery pack: Press the battery pack release button [1]. Remove the battery pack [8] (Fig. D).
- Attaching the battery pack: Align the battery pack 8 to the handle and slide it into it. Ensure it clicks noticeably in place.
- Checking the battery pack charging level
(Fig. B)
Check battery pack charge level: Press the button 12. The charging level LEDs 13 light up:
LED 13
Charging level
Red/orange/green Maximum
Red/orange Medium
Red Low
Charging the battery pack (Fig. C)
NOTE
The battery pa may be charged at any time without reducing the life.
Interrupting the charging process does not damage the battery pack 8
Charge the battery pad before operation when it is at medium or low charging level.
The charging control LEDs (gre and red 17) indicate the status of the charger 14 and the battery pack 8:
LED Status
Red LED lights up Battery pack
charges
Green LED lights up Battery pack fully charged
Green and red LED Battery pack
flashing defective
Red LED flashing Battery pack too
cold or too warm
Green LED lights up
(without battery pack) Charger ready
Insert the battery pa8 into the charger 14.
Connect the power cord with power pl of the charger 14 to the socket.
When the battery pack is fully charged: Remove the battery pack from the charger 14 Then disconnect the power cord with power plug 15 of the charger from the socket.
Adjusting the base plate (Fig. E)
WARNING!
Always switch the product off, remove the battery pack 8 and let the product cool down before making any adjustments!
CAUTION! RISK OF INJURY!
Saw blades can be sharp and become hot during use. Always wear protective gloves when handling saw blades.
CAUTION! RISK OF INJURY!
Remove the saw blade from the product before adjusting the base plate 4 (see "Inserting/removing the saw blade").
Do not use the product without having inserted the base plate 4
To adapt to the workpiece, the base plate 4 can be adjusted and swivelled to different positions.
Unlock the base pla:Turn the locking lever 1 in a counter-clockwise direction.
Adjust the desired position of the base plate by pushing it in or pulling it out.
Lock the base pl:Turn the locking lever 1 in a clockwise direction.
- Inserting/removing the saw blade
WARNING!
Always switch the product off, remove the battery pack 8 and let the product cool down before making any adjustments!
CAUTION! RISK OF INJURY!
Saw blades can be sharp and become hot during use. Always wear protective gloves when handling saw blades.
CAUTION! RISK OF INJURY!
Do not use any blunt, bent or damaged saw blade.
Always install a suitable saw blade for the job.
Inserting the saw blade
(Fig. F)
Turn the chuck ria in a counter-clockwise direction.
Insert the saw blade into the saw blade holder 3
Release the chuck ring and let it return to its original position.
Before use: Pull on the saw blade and check if it is inserted safely and tightly.
Removing the saw blade
(Fig. G)
Turn the chuck ri in a counter-clockwise direction.
Pull the saw blade out of the saw blade holder 3
Release the chuck ring and let it return to its original position.
NOTE
For certain work, the saw blade can also be inserted after turning through 180^ .
- Switching on and off
CAUTION! RISK OF INJURY!
Always wear protective gloves when handling or working with the product.
CAUTION! RISK OF INJURY!
Before switching on the product: Ensure the saw blade is not in contact with the workpiece.
Ensure your stance is stable. Always hold the product's front 9 and rear handle firmly with both hands while working (Fig. H).
- Keep your hands away from the saw blade when the product is in operation.
NOTE
The on/off switch cannot be locked.
(Fig. 1)
Switching on: Release the switch lock 5 by pushing it in on the left or right side. Press and hold the on/off switch 6. Regulate the speed as required (see "Speed control").
Switching off: Release the on/off switch 6
When releasing the on/off switch, the switch lock 5 moves back into its original position.
Speed control
By using the on/off switch, you can progressively control the speed:
Pressure Speed
Gentle pressure: Lower speed
Greater pressure: Higher speed
LED work light
This product is equipped with a LED work light to illuminate the immediate working area to improve visibility in poorly lit areas.
The LED work light lights up automatically as soon as the product is switched on.
NOTE
The LED work light stays on for an additional approx. 10 seconds after switching off the product.
Trial run
NOTE
Always carry out a no-load trial run before starting work and after every saw blade replacement. Switch the product off immediately if the saw blade is not running smoothly, if considerable vibration occurs or if you hear abnormal noises.
Working instructions
CAUTION! RISK OF INJURY AND DAMAGE TO PROPERTY!
Wear gloves when handling the saw blade. In this way, you avoid injury from cuts.
Do not use any blunt or bent blades or blades which are damaged in any other way.
Before sawing the workpiece, check for hidden foreign objects such as nails, screws. These must be removed.
Always insert a suitable saw blade.
Secure the workpiece with the aid of clamping devices on the workbench.
Apply only as much pressure as is required for sawing. If there is excessive pressure, the sawing blade may bend and break.
- Switch the product off immediately if the sawing blade jams.
- Spread the saw cut out and pull the blade out carefully.
CAUTION! RISK OF INJURY AND DAMAGE TO PROPERTY!
Always stand to the side of the product when working.
Always make sure that the workplace is well ventilated.
Avoid over-stressing the product while working.
Regular cuts
Verify the saw blade is not touching the workpiece. Then, switch on the product.
Apply the base plate to the workpiece.
Use even pressure, advancing at a steady pace when making your cut. You can make horizontal, diagonal, or vertical cuts.
When you are finished: First, switch off the product. Then, pull the saw blade out of the workpiece.
Plunge cuts
(Fig. J)
Plunge cuts are very challenging and are associated with a higher risk of injuries. Only use this technique if you are familiar with it.
Plunge cuts may only be carried out in soft materials such as wood or plasterboard and with short blades (max. length 150~mm ). There is a risk of kickback and personal injury.
Place the front edge of the base plate on the workpiece so that the saw blade does not touch the workpiece.
Turn the product on. Let the saw blade slowly plunge into the workpiece.
When the workpiece depth has been cut through, continue sawing as usual.
Flush cuts
(Fig. K)
With elastic bi-metal saw blades you can separate water pipes, for example, flush to the wall.
Make sure that the saw blade is always longer than the pipe diameter. There is a risk of kickback and personal injury.
Cleaning and care
WARNING!
Always switch the product off, remove the battery pack 8 and let the product cool down before performing inspection, maintenance and cleaning work!
Cleaning
Never allow fluids to get into the product.
The product must always be kept clean, dry and free from oil or grease. Remove debris from it after each use and before storage.
Regular and proper cleaning will help ensure safe use and prolong the life of the product.
Clean the product with a dry cloth. Use a soft brush for areas that are hard to reach.
In particular clean the air vents after every use with a cloth and soft brush.
The vents must always be clear.
NOTE
Do not use chemical, alkaline, abrasive or other aggressive detergents or disinfectants to clean this product as they might be harmful to its surfaces.
Maintenance
The product is maintenance-free.
Before and after each use, check the product and accessories (e.g. saw blades) for wear and damage. If required, exchange them for new ones as described in this instruction manual. Observe the technical requirements (see "Technical data").
Check covers and safety devices for damages and correct installation. Replace as necessary.
Replace a blunt or bent saw blade or one which has been damaged in some other way.
Repair
This product does not contain any parts that can be repaired by the user. Contact an authorised service centre or a similarly qualified person to have it checked and repaired.
Storage
Clean the product as described above.
Store the product and its accessories in a dark, dry, frost-free, well-ventilated place.
Always store the product in a place that is inaccessible to children. The ideal long term storage (longer than 3 months) temperature is between +20 and +26^ .
Store the product in its case.
Battery pack advice
Only store the battery pack partially charged. The battery pack should be charged to 40 to 60% (red and orange LED in the charge indicator light up) before storing for extended periods.
Check the battery pack charge about every 3 months when storing for extended periods. Recharge as necessary.
Transportation
Transport the product in its carrying case 18.
- Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles.
- Secure the product to prevent it from slipping or falling over.
Disposal
The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.
Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1 - 7: plastics / 20 - 22: paper and fibreboard / 80 - 98: composite materials
The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.
Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.
To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.
Faulty or used batteries / rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries / rechargeable batteries and / or the product to the available collection points.
Environmental damage through incorrect disposal of the batteries / rechargeable batteries!
Before disposal: Remove the battery pack from the product.
Warranty
The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.
The warranty for this product is 5 years from the date of purchase. Should this product show any fault in materials or manufacture within 5 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you.
The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the product has been damaged, or used or maintained improperly.
The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.
The warranty for the battery pack is 1 year from the date of purchase.
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
Please have the till receipt and the item number (e.g. IAN 123456_7890) available as proof of purchase.
You will find the item number on the type plate, an engraving on the front page of the instructions (bottom left), or as a sticker on the rear or bottom of the appliance.
If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.
You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.
Service
GB Service Great Britain
Tel.: 0800 404 7657
E-Mail: owim@lidl.co.uk
IE Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., {peak})
(0,06 EUR/Min., (off peak))
E-Mail: owim@lidl.ie
C
EC declaration of conformity
EC DECLARATION OF CONFORMITY
IAN: 322690
Product identification: CORDLESS SABRE SAW 20V
Model Number: HG05469
The object of the declaration described above is in conformity with the relevant Community harmonisation legislation:
| Directive 2006/42/EC |
| Directive 2014/30/EU |
| Directive 2014/35/EU |
| Directive 2011/65/EU |
References to the relevant harmonised standards used or references to the specifications in relation to which conformity is declared:
| N° / Parts |
| Directive 2006/42/EC |
| EN 62841-1:2015 |
| EN 62841-2-11:2016 |
| Directive 2014/30/EU |
| EN 55014-1:2006/A2:2011 |
| EN 55014-2:1997/A2:2008 |
| EN 61000-3-2:2014 |
| EN 61000-3-3:2013 |
| Directive 2014/35/EU |
| EN 60335-1:2012/A13:2017 |
| EN 60335-2-29:2004/A11:2018 |
| EN 62233:2008 |
| Directive 2011/65/EU |
| EN 50581:2012-09 |
Additional information - Further related standards:
| N° / Parts |
| EN 55014-1:2017 |
| EN 55014-2:2015 |
Name and address of the manufacturer:
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Original declaration of conformity
GB
Akumulator PAP 20 A3
Typ: Litowo-jonowy
Akumulator: Akumulator Parkside 20 V: PAP 20 A1, PAP 20 A2, PAP 20 A3
tadowarka: tadowarka Parkside 20 V: PLG 20 A1, PLG 20 A2, PLG 20 B1, PLG 20 A3
- Obstuga
DEKLARACJA ZGODNOSCICI WE
IAN:
322690
Okreslenie wyrobu:
AKUMULATOROWA PIKA SZABLASTA 20 V
Model Number:
HG05469
Rychlonabiječka PLG 20 B1
Vstup:
Jmenovite napeti: 230-240 V~
Jmenovita frekvence: 50 Hz
Jmenovity vykon: 120 W
Vystup:
Directive 2006/42/EC
Directive 2014/30/EU
Directive 2014/35/EU
Directive 2011/65/EU
